2AATL-L297BSRWifi/bt Module

FN-LINK TECHNOLOGY LIMITED

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: May 21, 2022
Application Purpose: Original Equipment
Date of Application: May 19, 2022
Equipment Note: Wifi/bt Module
Frequency Range: 2402.00000000 - 2480.00000000
Company: FN-LINK TECHNOLOGY LIMITED
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

FN-LINKTECHNOLOGYLIMITED1 PRODUCTSPECIFICATION L297B-SR Wi-FiDual-band2x211ac+Bluetooth5.0 ComboModule Version:v1.2 FN-LINKTECHNOLOGYLIMITED2 L297B-SRModuleDatasheet Customer: CustomerP/N: Signature: Date: Office:14thfloor,BlockB,phoenixzhigu,XixiangStreet,BaoanDistrict,Shenzhen Factory:NO.8,LitongRD.,LiuyangEconomic&TechnicalDevelopmentZone,Changsha,CHINA TEL:+86-755-2955-8186Website:www.fn-link.com Ordering Information PartNO.Description FGL297BSRX-00 NXP88W8997,b/g/n/ac,Wi-Fi+BLE5.0,2T2R,13X15mm, SDIO/UART,PCBversionV1.0 L297B-SR FN-LINKTECHNOLOGYLIMITED3 CONTENTS 1.GeneralDescription .............................................................................................................. 5 1.1Introduction ......................................................................................................................... 5 1.2Description .......................................................................................................................... 5 2.Features .................................................................................................................................... 6 3.BlockDiagram ........................................................................................................................ 7 4.GeneralSpecification ........................................................................................................... 7 4.12.4GHzWI-FISpecification .............................................................................................. 7 4.25GHzWI-FISpecification ................................................................................................. 8 4.3BluetoothSpecification ..................................................................................................... 9 5.IDsettinginformation ........................................................................................................... 9 6.PinDefinition ........................................................................................................................ 10 6.1PinOutline ........................................................................................................................ 10 6.2PinDefinitiondetails ........................................................................................................ 10 7.ElectricalSpecifications .................................................................................................... 12 7.1HostInterfaceSpecifications ......................................................................................... 12 7.1.1SDIOSpecifications.................................................................................................12 7.1.2DefaultSpeed,High-SpeedModes..........................................................................12 7.1.3SDR12,SDR25,SDR50Modes(upto100MHz)(1.8V).......................................13 7.1.4SDR104Mode(208MHz)(1.8V)...........................................................................14 7.1.5DDR50Mode(50MHz)(1.8V)...............................................................................15 7.2High-SpeedUARTSpecifications ................................................................................. 17 7.2.1UARTTimingDiagram............................................................................................17 7.2.2UARTBaudRatesSupported...................................................................................17 8.Sizereference ....................................................................................................................... 18 8.1ModulePicture ................................................................................................................. 18 8.2MarkingDescription ......................................................................................................... 18 8.3PhysicalDimensions ....................................................................................................... 19 8.4LayoutRecommendation ............................................................................................... 20 9.TheKeyMaterialList .......................................................................................................... 21 10.ReferenceDesign .............................................................................................................. 22 11.RecommendedReflowProfile ....................................................................................... 23 12.Package ................................................................................................................................ 24 12.1Reel ................................................................................................................................. 24 12.2PackagingDetail ............................................................................................................ 24 13.Moisturesensitivity ........................................................................................................... 25 L297B-SR FN-LINKTECHNOLOGYLIMITED4 RevisionHistory VersionDateContentsofRevisionChangePrepardeCheckedApproved V1.02021/11/19NewversionFCTzqQjp V1.12022/01/19 AddModulepicture Revisionpindefinition Addmarkingdescription FCTzqQjp V1.22022/02/15UpdatepingoutlineFC L297B-SR FN-LINKTECHNOLOGYLIMITED5 1.GeneralDescription 1.1Introduction Thisdocumentistospecifytheproductrequirementsfor802.11a/b/g/n/acandBluetooth5.0 SDIO&UARTmodule.ThismodulebasedonNXP(MARVELL)88W8997chipsetthatcompliedwithIEEE 802.11a,IEEE802.11b,IEEE802.11g,IEEE802.11n,IEEE802.11acstandardfrom2.4~2.5GHzand 5.15GHz~5.85GHz,anditalsocanbeusedtoprovideupto11MbpsforIEEE802.11b,54MbpsforIEEE 802.11aandIEEE802.11g,150Mbpsfor802.11nand866.7MbpsforIEEE802.11actoconnectyourwireless LAN. 1.2Description ModelNameL297B-SR ProductDescriptionSupportWi-Fi/Bluetoothfunctionalities Dimension LxWxH:13x15x2.3mm Wi-FiInterface SupportSDIOV2.0/3.0 BTInterfaceUART/SDIO OSsupportedAndroid/…

Text truncated - open the document above for the full version.

Cover Letter(s)

Single Modular approval Declaration letter We ，FN-LINK TECHNOLOGY LIMITED apply Single modular approval for Product Name: Wifi/bt Module Model: L297B-SR FCC ID: 2AATL-L297BSR According to 996369 D01 Module Equip Auth Guide v01r04 and 15.212 requirement: 1) The radio elementsmust have the radio frequencycircuitryshielded.Physical componentsand tuningcapacitor(s)may be locatedexternalto the shield,but must be on the moduleassembly; Answer ： Yes ， Shieldedfor both side . 2) The modulemust have bufferedmodulation/datainputsto ensurethat the device willcomplywith Part 15 requirementswith any type of input signal; Answer ： Yes ； All inputsto the modulesare bufferedthroughlogic or microprocessor inputs. 3)The modulartransmittermust have its own powersupplyregulation. Answer ： Yes ； A low drop out regulatoris used for modularpowersupplyregulation. 4) The modulemust containa permanentlyattachedantenna,or containa unique antennaconnector,and be marketedand operatedonly with specificantenna(s),per Sections15.203,15.204(b),15.204(c),15.212(a),2.929(b); Answer ： Yes ； Deviceis equippedwith non-detachableexternalantenna. (5)The module must demonstrate compliance in a stand-alone configuration; Answer ：Yes，distance between modular and all AEs are bigger than 10cm ，refer to setup photo. (6)The module must be labeled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements); Answer ：Yes ；The modular has a permanent fixed label, and below statement was listed in the UserManual;The host device must be labeled to display the FCC ID of the module “Contains FCC ID:2AATL-L297BSR” (7)The module must comply with all specific rules applicable to the transmitter includingall the conditions provided in the integration instructions by the grantee; Answer ：Yes ；The module comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee, Refer to test report and user manual . (8)The module must comply with RF exposure requirements Answer ：Yes ；Transmitter meets MPE calculation of 47 CFR 1.1307 . Refer to MPE Reports and Refer to modular installation manual Please contact me if you have any further questions. Thanks for your attention. Best Regards, <Signature> Nam e ： Jim Hu Title：Manager Applicant Company：FN-LINK TECHNOLOGY LIMITED

Cover Letter(s)

DATE: 2022.5.10 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AATL-L297BSR Product Name: Wifi/bt Module Reauest f。r Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions 「ules, we hereby 「equest that the following documents be held confidential: (List he「e the documents for which you are seeking confidentiality - for example ... ) •Schematics •Block diagram •Ope「ationdescription These materials contain t「adesecrets and proprieta叩informationand a「enot custom a「ilyreleased to the public. The public disclosu「eof this info「「nationmight be ha「mfulto the company and provide unjustified benefits to our competitors. HU UH AV m ，．．目’EE U BJ a，，‘ a· · ne 咀m qua 〈 M川 Title: Manager Applicant Company: ·FN-LINK TECHNOLOGY LIMITED

Cover Letter(s)

D ATE: 2022.5.10 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint BlueAsia of Technical Services(Shenzhen) Co.,Ltd. IOT Test Centre of BlueAsia，Building C, No. 107, Shihuan Road, Shiyan Sub-District, Baoan District,Shenzhen, Guangdong Province, China (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application.For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with FN-LINK TECHNOLOGY LIMITED. / No.8, Litong Road, Liuyang Economic & Technical Development Zone, Changsha, Hunan, CHINA (Applicant Name and address) <Signature> Name：Jim Hu Title：Manager Applicant Company：FN-LINK TECHNOLOGY LIMITED

External Photos

ProductName: Wifi/btModule Module Development Board ANT:

ID Label/Location Info

FCCID:2AATL-L297BSR

Internal Photos

ProductName: Wifi/btModule

RF Exposure Info

Page 1 of 9 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Add:BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict,Shenzhen,GuangdongProvince,China Tel:+86-755-23059481Email:[email protected] TESTREPORT ProductName: Wifi/btModule BrandMark: FN-LINK ModelNo.: L297B-SR FCCID: 2AATL-L297BSR ReportNumber: BLA-EMC-202203-A4006 DateofSampleReceipt: 2022/3/9 DateofTest: 2022/3/9to2022/5/7 DateofIssue: 2022/5/7 TestStandard: 47CFRPart1.1307,Part1.1310greater than20cm TestResult:Pass Preparedfor: FN-LINKTECHNOLOGYLIMITED No.8,LitongRoad,LiuyangEconomic&TechnicalDevelopmentZone, Changsha,Hunan,CHINA Preparedby: BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict, Shenzhen,GuangdongProvince,China TEL:+86-755-23059481 Compiledby:Reviewby: Approvedby:Date:2022/5/7 ReportNo.:BLA-EMC-202201-A8402 Page 2 of 9 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] REPORTREVISERECORD VersionNo.DateDescription 002022/5/7Original ReportNo.:BLA-EMC-202201-A8402 Page 3 of 9 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] TABLEOFCONTENTS 1TESTSUMMARY........................................................................................................................................4 2GENERALINFORMATION.........................................................................................................................5 3GENERALDESCRIPTIONOFE.U.T..........................................................................................................5 4BLOCKDIAGRAMOFEUTCONNECTION..............................................................................................6 5LABORATORYLOCATION.........................................................................................................................7 6RFEXPOSURECOMPLIANCEREQUIREMENT......................................................................................8 6.1LIMITS........................................................................................................................................................................8 6.2TESTPROCEDURE..........................................................................................................................................................8 6.3EUTRFEXPOSUREEVALUATION.....................................................................................................................................9 ReportNo.:BLA-EMC-202201-A8402 Page 4 of 9 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 1TESTSUMMARY TestitemTestRequirementTestMethodClass/SeverityResult RFExposure 47CFRPart 1.1307,Part 1.1310greaterthan 20cm CFR47Part 1.1310 CFR47Part1.1310PASS ReportNo.:BLA-EMC-202201-A8402 Page 5 of 9 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 2GENERALINFORMATION ApplicantFN-LINKTECHNOLOGYLIMITED Address No.8,LitongRoad,LiuyangEconomic&TechnicalDevelopmentZone, Changsha,Hunan,CHINA ManufacturerFN-LINKTECHNOLOGYLIMITED Address No.8,LitongRoad,LiuyangEconomic&TechnicalDevelopmentZone, Changsha,Hunan,CHINA FactoryFN-LINKTECHNOLOGYLIMITED Address No.8,LitongRoad,LiuyangEconomic&TechnicalDevelopmentZone, Changsha,Hunan,CHINA ProductNameWifi/btModule TestModelNo.L297B-SR 3GENERALDESCRIPTIONOFE.U.T. HardwareVersion1.0 SoftwareVersion1.0 OperationFrequency:2402MHz-2480MHz ModulationType:GFSK,π/4DQPSK,8DPSK ChannelSpacing:1MHz NumberofChannels:79 AntennaType:ExternalAntenna AntennaGain:4dBi(Providedbytheapplicant) OperationFrequency:2402MHz-2480MHz ModulationType:GFSK ChannelSpacing:2MHz NumberofChannels:40 AntennaType:ExternalAntenna AntennaGain:4dBi(Providedbytheapplicant) OperationFrequency: 802.11b/g/n(HT20):2412MHzto2462MHz 802.11n(HT40):2422MHzto2452MHz ModulationType: 802.11b:DSSS(CCK,DQPSK,DBPSK) 802.11g/n:OFDM(64QAM,16QAM,QPSK,BPSK) ChannelSpacing:5MHz NumberofChannels: 802.11b/g/n(HT20):11 802.11n(HT40):7 ReportNo.:BLA-EMC-202201-A8402 Page 6 of 9 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] AntennaType:ExternalAntenna AntennaGain:4dBi(Providedbytheapplicant) OperationFrequency: Band1:5180MHz-5240MHz;Band2:5260MHz~5320MHz Band3:5500MHz~5700MHz;Band4:5745MHz-5825MHz Channelnumbers: Band1:802.11a/802.11n(HT20)/802.11ac(HT20):4, 802.11n(HT40)/802.11ac(HT40):2,802.11ac(HT80):1 Band2:802.11a/802.11n(HT20)/802.11ac(HT20):4, 802.11n(HT40)/802.11ac(HT40):2,802.11ac(HT80):1 Band3:802.11a/802.11n(HT20)/802.11ac(HT20):11, 802.11n(HT40)/802.11ac(HT40):5,802.11ac(HT80):3 Band4:802.11a/802.11(HT20)/802.11ac(HT20):5, 802.11n(HT40)/802.11ac(HT40):2, 802.11ac(HT80):1 Channelseparation: 802.11a/n/ac(HT20):20MHz, 802.11n/ac(HT40):40MHz,802.11ac(HT80):80MHz Modulationtechnology: (IEEE802.11a/n/ac) BPSK,QPSK,16-QAM,64-QAM,256QAM Dataspeed(IEEE802.11a)6Mbps,9Mbps,12Mbps,18Mbps,24Mbps,36Mbps,48Mbps,54Mbps Dataspeed(IEEE 802.11n/ac): Upto866.7Mbps AntennaType:Externalantenna Antennagain:Antenna1:4dBi,Antenna2:4dBi Note: Antennanumber:2 SISOmode：802.11a MIMOmode：802.11n(HT20)/802.11n(HT40)/802.11ac(HT20)/ 802.11ac(HT40)/802.11ac(HT80) DirectionalgainofMIMOmode:4+10log2=7.01dBi Remark:TheAntennaGainissuppliedbythecustomer.BlueAsiaisnotresponsibleforthisdata 4BLOCKDIAGRAMOFEUTCONNECTION ReportNo.:BLA-EMC-202201-A8402 Page 7 of 9 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 5LABORATORYLOCATION Alltestswereperformedat: BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict,Shenzhen,GuangdongProvince, China Telephone:TEL:+86-755-28682673FAX:+86-755-28682673 Notestsweresub-contracted. ReportNo.:BLA-EMC-202201-A8402 Page 8 of 9 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:m…

Text truncated - open the document above for the full version.

Test Report

Page 1 of 73 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Add:BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict,Shenzhen,GuangdongProvince,China Tel:+86-755-23059481Email:[email protected] TESTREPORT ProductName: Wifi/btModule BrandMark: FN-LINK ModelNo.: L297B-SR FCCID: 2AATL-L297BSR ReportNumber: BLA-EMC-202203-A4002 DateofSampleReceipt: 2022/3/9 DateofTest: 2022/3/9to2022/5/7 DateofIssue: 2022/5/7 TestStandard: 47CFRPart15,SubpartC15.247 TestResult:Pass Preparedfor: FN-LINKTECHNOLOGYLIMITED No.8,LitongRoad,LiuyangEconomic&TechnicalDevelopmentZone, Changsha,Hunan,CHINA Preparedby: BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict, Shenzhen,GuangdongProvince,China TEL:+86-755-23059481 Compiledby:Reviewby: Approvedby:Date:2022/5/7 ReportNo.:BLA-EMC-202203-A4002 Page 2 of 73 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] REPORTREVISERECORD VersionNo.DateDescription 002022/5/7Original ReportNo.:BLA-EMC-202203-A4002 Page 3 of 73 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] TABLEOFCONTENTS 1TESTSUMMARY........................................................................................................................................5 2GENERALINFORMATION.........................................................................................................................6 3GENERALDESCRIPTIONOFE.U.T..........................................................................................................6 4BLOCKDIAGRAMOFEUTCONNECTION..............................................................................................6 5TESTENVIRONMENT................................................................................................................................7 6TESTMODE................................................................................................................................................7 7MEASUREMENTUNCERTAINTY..............................................................................................................7 8DESCRIPTIONOFSUPPORTUNIT..........................................................................................................8 9LABORATORYLOCATION.........................................................................................................................8 10TESTINSTRUMENTSLIST........................................................................................................................9 11CONDUCTEDEMISSIONSATACPOWERLINE(150KHZ-30MHZ).....................................................12 11.1LIMITS................................................................................................................................................................12 11.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................12 11.3PROCEDURE.......................................................................................................................................................12 11.4TESTDATA...........................................................................................................................................................14 12CONDUCTEDBANDEDGESMEASUREMENT.....................................................................................16 12.1LIMITS................................................................................................................................................................16 12.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................16 12.3TESTDATA...........................................................................................................................................................17 13RADIATEDSPURIOUSEMISSIONS........................................................................................................18 13.1LIMITS................................................................................................................................................................18 13.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................19 13.3PROCEDURE.......................................................................................................................................................19 13.4TESTDATA...........................................................................................................................................................21 14RADIATEDEMISSIONSWHICHFALLINTHERESTRICTEDBANDS.................................................29 14.1LIMITS................................................................................................................................................................29 14.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................30 14.3PROCEDURE.......................................................................................................................................................30 14.4TESTDATA...........................................................................................................................................................32 15CONDUCTEDSPURIOUSEMISSIONS...................................................................................................36 ReportNo.:BLA-EMC-202203-A4002 Page 4 of 73 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 15.1LIMITS........................................................................................................................................................…

Text truncated - open the document above for the full version.

Test Report

Page 1 of 151 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Add:BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict,Shenzhen,GuangdongProvince,China Tel:+86-755-23059481Email:[email protected] TESTREPORT ProductName: Wifi/btModule BrandMark: FN-LINK ModelNo.: L297B-SR FCCID: 2AATL-L297BSR ReportNumber: BLA-EMC-202203-A4003 DateofSampleReceipt: 2022/3/9 DateofTest: 2022/3/9to2022/5/7 DateofIssue: 2022/5/7 TestStandard: 47CFRPart15,SubpartC15.247 TestResult:Pass Preparedfor: FN-LINKTECHNOLOGYLIMITED No.8,LitongRoad,LiuyangEconomic&TechnicalDevelopmentZone, Changsha,Hunan,CHINA Preparedby: BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict, Shenzhen,GuangdongProvince,China TEL:+86-755-23059481 Compiledby:Reviewby: Approvedby:Date:2022/5/7 ReportNo.:BLA-EMC-202203-A4003 Page 2 of 151 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] REPORTREVISERECORD VersionNo.DateDescription 002022/5/7Original ReportNo.:BLA-EMC-202203-A4003 Page 3 of 151 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] TABLEOFCONTENTS 1TESTSUMMARY........................................................................................................................................5 2GENERALINFORMATION.........................................................................................................................6 3GENERALDESCRIPTIONOFE.U.T..........................................................................................................6 4BLOCKDIAGRAMOFEUTCONNECTION..............................................................................................7 5TESTENVIRONMENT................................................................................................................................7 6TESTMODE................................................................................................................................................7 7MEASUREMENTUNCERTAINTY..............................................................................................................7 8DESCRIPTIONOFSUPPORTUNIT..........................................................................................................8 9LABORATORYLOCATION.........................................................................................................................8 10TESTINSTRUMENTSLIST........................................................................................................................9 11ANTENNAREQUIREMENT......................................................................................................................12 11.1CONCLUSION.........................................................................................................................................................12 12RADIATEDSPURIOUSEMISSIONS........................................................................................................13 12.1LIMITS................................................................................................................................................................13 12.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................14 12.3PROCEDURE.......................................................................................................................................................14 12.4TESTDATA...........................................................................................................................................................16 13RADIATEDEMISSIONSWHICHFALLINTHERESTRICTEDBANDS.................................................24 13.1LIMITS................................................................................................................................................................24 13.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................25 13.3PROCEDURE.......................................................................................................................................................25 13.4TESTDATA...........................................................................................................................................................27 14CONDUCTEDSPURIOUSEMISSIONS...................................................................................................43 14.1LIMITS................................................................................................................................................................43 14.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................43 14.3TESTDATA...........................................................................................................................................................44 15CONDUCTEDBANDEDGESMEASUREMENT.....................................................................................45 15.1LIMITS................................................................................................................................................................45 15.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................45 ReportNo.:BLA-EMC-202203-A4003 Page 4 of 151 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 15.3TESTDATA...........................................................................................................................................................46 16MINIMUM6DBBANDWIDTH................................................................................................…

Text truncated - open the document above for the full version.

Test Report

ReportNo.:BLA-EMC-202203-A4003 Page 21 of 151 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXBmidchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202203-A4003 Page 22 of 151 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXBhighchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202203-A4003 Page 23 of 151 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXBhighchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202203-A4003 Page 24 of 151 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 13RADIATEDEMISSIONSWHICHFALLINTHERESTRICTEDBANDS TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section6.10.5 TestMode(Pre-Scan)TX TestMode(FinalTest)TX TesterJozu Temperature25°C Humidity60% 13.1LIMITS Frequency(MHz) Field strength(microvolts/meter) Measurement distance(meters) 0.009-0.4902400/F(kHz)300 0.490-1.70524000/F(kHz)30 1.705-30.03030 30-881003 88-2161503 216-9602003 Above9605003 Remark:Theemissionlimitsshownintheabovetablearebasedonmeasurementsemployinga CISPRquasi-peakdetectorexceptforthefrequencybands9-90kHz,110-490kHzandabove1000 MHz.Radi…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jim Hu(Manager)

[email protected]+8613538178944Fax: 075529558196

Test Firm

BlueAsia of Technical Services (Shenzhen)Blue Zheng

[email protected]+86 755-23059481-815

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.40 GHz - 2.48 GHz	5.90 mW

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Single Modular Approval. Power output listed is conducted. This modular has a 20 MHz and 40 MHz bandwidth mode, and can only be used for mobile and fixed applications, with a host antenna circuit trace layout design in strict compliance with the instructions provided. The module grantee is responsible for providing the documentation to the system integrator on restrictions of use, for continuing compliance of the module. The host integrator installing this module into their product must ensure that the final composite product complies with the FCC requirements by a technical assessment or evaluation to the FCC rules, including the transmitter operation and should refer to guidance in KDB 996369.
