2AAV8QT14RReceiver

400W Metal Fog Machine with Wireless Remote Control Set User Manual READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE IMPORTANT SAFETY INSTRUCTION CAUTION: -Risk of burn, fire or electrical shock. -For indoor use only. -Please read instruction manual before using. -Don’t immerse in liquid. -Not for space heating purpose. I. FOG MACHINE TECHNICAL SPECIFICATIONS Item Code：5724042 Fuse: 5A, 125V Model: FM400-E Preheat Time: 3~ 5 Minutes Rating Voltage: AC120V, 60Hz Fog Output: 2,000 CFM Power: 400W Tank Capacity: 0.55 Liter Ambient Temperature: -10 ~ 45°C Dimensions: L236.5 × W147 × H194 mm L9.3 × W5.7 × H7.6 inch II. RECEIVER: TECHNICAL SPECIFICATIONS Item Name: Receiver Model Number: QT-14R Rating Voltage: AC120V, 60Hz Working Current: 50mA Max. III. TRANSMITTER: TECHNICAL SPECIFICATIONS Item Name: Transmitter Model Number: QT-14T Working Voltage: 12V DC Working Current: 15mA Max. Require: 1 x 12V, 27A Battery (Included) WARNING: To prevent risk of personal injury, fire, and electric shock: ● Never leave unit unattended while plugged in. Unplug when not in use. ● Read all important safety instructions and cautions. ● Connect only to a properly grounded outlet. ● Place product on a flat, level HARD surface and connect the cord to prevent the product from overturning. ● For use only in covered areas. Keep unit dry, do not expose to rain or moisture. Do not immerse unit. ● Leave enough space for good ventilation. Keep unit cool and away from other objects. ● Use only with SVI Fog Liquid (sold separ ately). ● Do not operate unit without fog liquid. ● Pour fog liquid carefully to avoid spills which could result in electrical shock. Do not use if liquid spills onto unit. Let unit dr y completely before plugging in. ● Do not overfill the liquid. ● Keep away from flames and flammable/explosive substances to avoid fire or explosions. Never pour flammable liquids such as gas, perfume etc. into the fog machine. ● Keep product and fog liquid out of reach of children. Use only under adult supervision. ● Do not spray in the direction of flames or people. Stay at least 20 inches (50cm) from the nozzle at the front of the unit. ● Do not obstruct the nozzle. ● Do not open unit. No user serviceable part s inside, please re fer to your vendor. Only an electrician can change the power cord. ● Clean unit before storage to avoid damages. OPERATION INSTRUCTION: 1. Remove all packaging before use. NOTE: Please contact the store if you find any broken or missing part s. 2. Place the unit on a flat, level surface. 3. Unscrew the lid on the reservoir tank towards the back of the Fog Machine and pour the Fog Liquid inside. Do not spill Fog Liquid onto the unit. Do not overfill. If liquid gets into Fog Machine, allow unit to dr y completely before plugging in. Do not cut, pinch, or break the tube connected through the tank lid. Close the lid to the reservoir tank tightly. Always make sure there is enough Fog Liquid in the tank before using the Fog Machine. 4. Plug the Receiver into the back of the Fog Machine. Now connect the unit with the proper power supply (120V AC). 5. Warm up time is approximately 3 - 5 minutes. When fully heated, the light on the Receiver will turn on and the Fog Machine will be ready to produce fog. 6. Remove the battery’s insulating piece at the back of the Transmitter for the first time you use it. You can see the “ON/OFF” buttons on the transmitter. Push “ON” to produce fog, and press “OFF” to stop the flow of fog. 7. Unplug the unit before refilling the fog machine, and follow the directions in Step 3. 8. Unplug the unit when not in use. A. Fog Machine B. Receiver C. Fog Liquid(not included) D. Power Cable E. Transmitter ADDITIONAL INFORMATION a) It is normal for condensation to appear on the nozzle of the Fog Machine. b) A small amount of fog may spray during or after operation. c) The unit will have to reheat af ter long bursts of use. The unit will stop operation for a short period in order to heat up to operating temperature again. While this is happening, fog cannot be produced. The light on the Receiver will turn on again when the unit is ready to generate more fog. MAINTENANCE & SERVICING Note: Use of fogger liquids not included or those other than SVI Fog Liquid are not recommended and may result in blockage, leakage, or other damage to the unit. INSPECTION: Before each use, check unit for any cracks in the enclosure, remote control, cords, and plugs. Make sure there are no exposed wires. Do not use if any of the above conditions are found. CLEANING: Should you experience low fog output af ter many hours of continuous operation or af ter the machine has been idle or in storage for a long time, it is recommended to run a cleaning solution through the sy stem to prevent the accumulation of particles in the heating element. a. While the unit is unplugged and cool, empty all Fog Liquid from the machine and replace with a fog machine cleaning solution in the tank. SVI Fog Machine Cleaning Fluid (not included) is recommended. Plug unit in and allow t o warm as u sual. b. Run unit in a well-ventilated area until tank is empty. c. Cleaning is now complete. All fog machines are prone to clogging due to the consistency of Fog Liquid and the high temperatures at which it vaporizes. However a well maintained machine should provide years of reliable use. STORAGE: It is important to remove all fluid from the unit when storing for an extended period of time. 1. When the unit is unplugged and cool, empty all Fog Liquid from the machine. Plug in unit and allow to warm as usual. 2. Run unit in a well-ventilated area for 10-seconds to confirm tank is empty and dry. 3. Store on a flat, level surface. Keep in a well-ventilated, cool and dry location. For best performance, operate unit for 10-minutes every 3 months. Follow the Operation Instructions and Storage instructions accordingly. FUSE REPLACEMENT If the Fog Machine does not work at all when it is connected to the power socket, then it is prob…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 SHENZHEN QIAOHUA INDUSTRIES LIMITED 201 5- 1-21 To: SI EMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, SHENZHEN QIAOHUA INDUSTRIES LIMITED hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product Description: Receiver Model name: QT-14R,QT-10R,QT-11R,QT-13R,QT-12R,QT-15R,QT-16R FCC ID: 2AAV8QT 14R Sinc erely, Client’s signature ： Client’s name / title: Swiss Yang / General Manager Contact information / address: Qiaohua Industrial Zone, Luo Tian Forestry Center,Song Gang Town, Bao An District,Shenzhen, Guangdong, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 SHENZHEN QIAOHUA INDUSTRIES LIMITED 2015- 1-21 To: Fe deral Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AAV8QT14R We h ereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature ： Client’s name / title: Swiss Yang / General Manager Contact information / address: Qiaohua Industrial Zone, Luo Tian Forestry Center,Song Gang Town, Bao An District,Shenzhen, Guangdong, China

SHENZHEN QIAOHUA INDUSTRIES LIMITED Statement Model number: QT-14R,QT-10R,QT-11R,QT-13R,QT-12R,QT-15R,QT-16R FCC ID: 2AAV8QT14R We hereb y st ate that these models are identical in interior structure, electrical circuits and compon ents, and just model names and colors are different for the marketing requirement. Your assistance on this matter is highly appreciated. Sincerely, Client’s signature ： Client’s name / title: Swiss Yang / General Manager Contact information / address: Qiaohua Industrial Zone, Luo Tian Forestry Center,Song Gang Town, Bao An District,Shenzhen, Guangdong, China

Accurate Technology Co.,Ltd. To: FCC From: Accurate Technology Co.,Ltd. Request for supersede of external photo Please supersede of external photo The external photos is to add the Fog machine which is the power supply of the receiver. Thank you Client’s signature: Client’s name / title: Sean Liu / Manager Contact information / address: F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China RE: Supersede request for FCC ID: 2AAV8QT14R , Granted on 01 Feb 2015. Date:2015 -02-03

Antenna

Report No.: ATE20150136 Page 1 of 19 FCC ID: 2AAV8QT14R ACCURATE TECHNOLOGY CO., LTD APPLICATION FOR VERIFICATION On Behalf of SHENZHEN QIAOHUA INDUSTRIES LIMITED Receiver Model No.: QT-14R,QT-10R,QT-11R,QT-13R,QT-12R,QT-15R,QT-16R FCC ID: 2AAV8QT14R Prepared for : SHENZHEN QIAOHUA INDUSTRIES LIMITED Address : Qiaohua Industrial Zone, Luo Tian Forestry Center,Song Gang Town, Bao An District,Shenzhen, Guangdong, China Prepared by : Accurate Technology Co., Ltd. Address : F1, Bldg. A&D, Changyuan New Material Port, Keyuan Rd., Science & Industry Park, Nanshan District, Shenzhen 518057, P.R. China Tel: +86-755-26503290 Fax: +86-755-26503396 Report No. : ATE20150136 Date of Test : Jan 16-21,2015 Date of Report : Jan 21,2015 Report No.: ATE20150136 Page 2 of 19 FCC ID: 2AAV8QT14R ACCURATE TECHNOLOGY CO., LTD TABLE OF CONTENTS Description Page Test Report Declaration 1. TEST RESULTS SUMMARY......................................................................................................... 4 2. GENERAL INFORMATION............................................................................................................ 5 2.1. Product of Device (EUT).......................................................................................................................5 2.2. Accessory and Auxiliary Equipment....................................................................................................5 2.3. Description of Test Facility...................................................................................................................6 2.4. Measurement Uncertainty.....................................................................................................................6 3. MEASURING DEVICE AND TEST EQUIPMENT .............................................................. 7 4. POWER LINE CONDUCTED MEASUREMENT......................................................................... 8 4.1. Block Diagram of Test Setup....................................................................................................................8 4.2. The Emission Limit ..................................................................................................................................8 4.3. Configuration of EUT on Measurement..............................................................................................9 4.4. Operating Condition of EUT.................................................................................................................9 4.5. Test Procedure.......................................................................................................................................9 4.6. Power Line Conducted Emission Measurement Results...............................................................10 5. RADIATED EMISSION MEASUREMENT................................................................................. 13 5.1. Block Diagram of Test Setup..................................................................................................................13 5.2. The Emission Limit For Section 15.109 (a) ...........................................................................................14 5.3. EUT Configuration on Measurement................................................................................................14 5.4. Operating Condition of EUT...............................................................................................................14 5.5. Test Procedure.....................................................................................................................................14 5.6. Radiated Emission Noise Measurement Result..............................................................................15 Report No.: ATE20150136 Page 3 of 19 FCC ID: 2AAV8QT14R ACCURATE TECHNOLOGY CO., LTD Test Report Declaration Applicant : SHENZHEN QIAOHUA INDUSTRIES LIMITED Manufacturer : SHENZHEN QIAOHUA INDUSTRIES LIMITED EUT Description : Receiver (A) MODEL NO.: QT-14R,QT-10R,QT-11R,QT-13R,QT-12R,QT-15R,QT-16R (B) SERIAL NO.: N/A (C) POWER SUPPLY: AC 120V Measurement Procedure Used: FCC Rules and Regulations Part 15 Subpart B ANSI C63.4: 2009 The device described above is tested by Accurate Technology Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart B Class B limits both radiated and conducted emissions. The measurement results are contained in this test report and Accurate Technology Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the Equipment Under Test (EUT) is to be technically compliant with the FCC requirements. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Accurate Technology Co., Ltd. Date of Test : Jan 16-21,2015 Date of Report : Jan 21,2015 Prepared by : (Eric Zhang, Engineer) Approved & Authorized Signer : (Sean Liu, Manager) Report No.: ATE20150136 Page 4 of 19 FCC ID: 2AAV8QT14R ACCURATE TECHNOLOGY CO., LTD 1. TEST RESULTS SUMMARY Test Items Test Standard Test Results Power Line Conducted Emission FCC Part 15 Subpart B Pass Radiated Emission FCC Part 15 Subpart B Pass Report No.: ATE20150136 Page 5 of 19 FCC ID: 2AAV8QT14R ACCURATE TECHNOLOGY CO., LTD 2. GENERAL INFORMATION 2.1.Product of Device (EUT) EUT : Receiver Model Number : QT-14R,QT-10R,QT-11R,QT-13R,QT-12R,QT-15R,QT-16R Note: These samples are same except for the model number and colors are difference. So we prepare the QT-14R for test Power Supply : AC 120V Modulation: : ASK Operation Frequency : 433.92MHz Receiver Applicant : SHENZHEN QIAOHUA INDUSTRIES LIMITED Address : Qiaohua Industrial Zone, Luo Tian Forestry Center,Song Gang Town, Bao An District,Shenzhen, Guangdong, China Manufacturer : SHENZHEN QIAOHUA INDUSTRIES LIMITED Address : Qiaohua Industrial Zone, Luo Tian Forestry…

Text truncated - open the document above for the full version.
