2AAYF-AF3333 channel FM wireless intercom

DATE : Jan 16, 2014 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint _ Shenzhen BATT Testing Technology Co., Ltd. 11F, Bldg.B, Xinbaoyuan, Xinanhu Commercial city, Bao’an District, Shenzhen, Guangdong, China _, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Calford Technology Ltd../ Room 107, Wah Wai Centre, 38 – 40 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong. Dated this Jan 16, 2014 Agency agreement expiration date: Usually Give 8 - 12 Months By: Vincent Cheung Signature Printed Title: Director On behalf of : Calford Technology Ltd. Telephone: 852-23307330

DATE : Jan 16, 2014 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AAYF-AF333 Product Name: 3 channel FM wireless intercom Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational Description • Part List & Tune up These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Jan 16, 2014 Agency agreement expiration date: Usually Give 8 - 12 Months By: Vincent Cheung Signature Printed Title: Director On behalf of : Calford Technology Ltd. Telephone: 852-23307330

Outside View Outside View Outside View Outside View

3-CHANNEL FM WIRELESS INTERCOM FCC ID : 2AAYF-AF333 POWER : 6V DC, 800 mA THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS : (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. www.intertalk-sales.comMADE IN CHINA Model No. : AF333 Model No. : AF333

Label Location

Interior View Interior View Interior View Interior View

RF Exposure Applicable Standard According to §1.1307(b)(5), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a Portable device. The Section 4.3.1 and Appendix A of KDB447498 D01 V05r01 was used as the guidance. Calculation Result (Worse Case): [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [vf(GHz)] =240/300 * 0.680= 0.54, this value is less than 7.5 for 10-g extremity SAR exclusion thresholds. The minimum test separation distance is decided by the following figure: 3 cm The extremity SAR measurement is not necessary.

Prediction of MPE limit at a given distance MW-CBDA-SMR-10W80-PS8, Uplink Outdoor Donar Antenna Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal:23.70(dBm) Maximum peak output power at antenna input terminal:234.4228815(mW) Antenna gain(typical):2.15(dBi) Maximum antenna gain:1.640589773(numeric) Prediction distance:20(cm) Prediction frequency:462(MHz) MPE limit for uncontrolled exposure at prediction frequency:0.308(mW/cm^2) Power density at prediction frequency:0.076512(mW/cm^2) Maximum allowable antenna gain:8.198205719(dBi) Margin of Compliance:6.048205719 2 4R PG S p =
