2AB7YVDWIFIRT3WiFi Module

Viper Design, LLC
WiFi Module - FCC ID 2AB7YVDWIFIRT3 - Viper Design, LLC
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Apr 13, 2023
Application Purpose
Original Equipment
Date of Application
Apr 13, 2023
Equipment Note
WiFi Module
Frequency Range
2412.00000000 - 2462.00000000
Company
Viper Design, LLC
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Features • IEEE 802.11 b/g/n Compliant Transceiver • Bluetooth Low Energy (BLE) 5.0 • ARM Cortex-M33 32-bit 200 MHz CPU o With floating-point unit (FPU) • Integrated 32Mbit serial flash • UART/SPI interfaces to Host Controller • Integrated PCB trace antenna • Input voltage 3.3V • FCC and IC certified RF/Analog • Frequency Range: 2.4GHz ISM dual radio • WiFi 802.11 b/g/n o Channels: 1-11 o Modulation: DSSS, OFDM • Bluetooth Low Energy (BLE) 5.0 o Channels: 3 advertising, 37 data o Modulation: GFSK Package • SMT Mounting • Compact Module design Applications • Consumer Electronics • Internet of Things (IoT) • Industrial Controls • Remote Device Management • Fitness and Health Care • White Goods / Appliances • Gateways / Bridges • Home Automation VDWIFIRT3 WiFi 802.11 b/g/n BLE 5.0 Module – User Manual VDWIFIRT3 WiFi Module Viper Design LLC 154 Cude Lane Madison, TN 37115 Phone: 615-420-6467 Version 1.2 Page 2 of 13 Typical Application Electrical Characteristics Parameter Min. Typ. Max. Units DC Supply Voltage 2.97 3.3 3.63 V DC Supply Current 150 300 mA SPI0 Clock - - 25 MHz SPI1 Clock - - 25 MHz VDWIFIRT3 WiFi Module Viper Design LLC 154 Cude Lane Madison, TN 37115 Phone: 615-420-6467 Version 1.2 Page 3 of 13 Pin Assignments Pin Name Pin Type Note 1 SWD DATA I/O 2 SPI0 CSn I/O 1 3 SPI0 CLK O 1 4 SPI0 MISO O 1 5 SPI0 MOSI I/O 1 6 SPI1 CLK O 2 7 SPI1 CSn I 2 8 SPI1MISO O 2 9 SPI1 MOSI P 2 10 SWD CLK I 11 OUT1 O 3 12 OUT2 O 3 13 OUT3 O 3 14 OUT4 O 3 15 VDD P 3.3V 16 VDD P 3.3V 17 GND P 18 GND P 19 IN1 I 3 20 IN2 I 3 21 IN3 I 3 22 CHIP ENABLE I 23 DEBUG TX O 24 DEBUG RX I 25 GND P 26 RESERVED 27 WIFI TX O 28 WIFI RX I 29 – 32 NC 4 Pin Type: I = Input, O = Output, P = Power, I/O = bi-directional Note 1: Master Mode Note 2: Slave Mode Note 3: Firmware Defined Note 4: No Connect VDWIFIRT3 WiFi Module Viper Design LLC 154 Cude Lane Madison, TN 37115 Phone: 615-420-6467 Version 1.2 Page 4 of 13 Dimensions All dimensions in mm. VDWIFIRT3 WiFi Module Viper Design LLC 154 Cude Lane Madison, TN 37115 Phone: 615-420-6467 Version 1.2 Page 5 of 13 Recommended PCB Footprint Altium Library file available from Viper Design L.L.C. VDWIFIRT3 WiFi Module Viper Design LLC 154 Cude Lane Madison, TN 37115 Phone: 615-420-6467 Version 1.2 Page 6 of 13 RF Certification Information Model Number: VDWIFIRT3 FCC ID and IC Number for this product is as follows FCC ID: IC: 2AB7YVDWIFIRT3 20699-VDWIFIRT3 Note Changes or modifications to this device not expressly approved by Viper Design LLC could void the user's authority to operate the equipment. Class B Device “NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.” VDWIFIRT3 WiFi Module Viper Design LLC 154 Cude Lane Madison, TN 37115 Phone: 615-420-6467 Version 1.2 Page 7 of 13 RF Exposure “This equipment complies with radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with Maximum distance 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Cet équipement est conforme aux limites d’exposition aux radiations dans un environnement non contrôlé. Cet équipement doit être installé et utilisé å distance minimum de 20 cm entre le radiateur et votre corps. Cet émetteur ne doit pas être co-localisées ou opérant en conjonction avec tout autre antenne ou transmetteur." Low Power License-Exempt Device “This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: 1. this device may not cause interference, and 2. this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L 'exploitation est autorisée aux deux conditions suivantes: 1. l’appareil ne doit pas produire de brouillage, et 2. l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible den compromettre le fonctionnement." Labels Host Device must contain the following label on the outside of the unit: Contains FCC ID: 2AB7YVDWIFIRT3 Contains IC: 20699-VDWIFIRT3 VDWIFIRT3 WiFi Module Viper Design LLC 154 Cude Lane Madison, TN 37115 Phone: 615-420-6467 Version 1.2 Page 8 of 13 General Statements 1. PCB antenna with maximum gain is -3.21 dBi. Brand Model Name Antenna Type Connector Gain NOTE Viper VDWIFIRT3 PCB N/A -3.21 dBi WLAN/BLE Antenna 2. Any change of antenna type is not allowed, WIFI module only use PCB antenna. 3. Host containing WIFI modules must comply with FCC Rule requirements. The modular can be installed or integrated in mobile or fix devices only. This modular cannot be installed in any portable device. If the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is inst…
