2AB9A-7DTB25TITAN 2

HS-7DTB25 Titan Plus User Manual December 2013 Please read this user’s manual carefully before use. CONGRATULATIONS! Thank you for your purchase of this Hip Street product and we hope you enjoy using it. Please visit our website at www.hipstreet.com . Please ensure that you fully read and understand the information within this user manual prior to using your product. It is advised that you keep this user manual in a safe place for future reference. We sincerely hope that this high quality product offers you endless hours of entertainment. Important safety precautions • Always follow these basic safety precautions when using the unit. This will reduce the risk of product damage and personal injury. • Do not disassemble, repair or modify the unit by yourself. Refer servicing to qualified personnel. • Do not dispose of the unit in extreme heat to avoid explosion. • Keep the unit away from direct sunlight or heat source. • Do not expose the unit to rain or moisture to avoid any malfunction. • Do not use the unit in a rather dry environment to avoid static. • Never apply heavy impact on the unit like dropping it or placing it on a magnet. • Clean only with a dry cloth. Make sure the unit is turned off before cleaning. Do not use liquid cleanser. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class C digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. This device complies with Canadian ICES-003 and RSS-210 Chapter One – Overview 1-1 Appearance 1-2 Buttons/Ports 1‐3 Power ON/OFF and Sleep/Wake mode Power ON Long press the power button for about 3-4 seconds to power ON the tablet. Power OFF (Shut down) Press and hold the power button for about 3-4 seconds, press OK when prompted to shut down. 1-4 Standby Mode Standby Short press the power button to standby the tablet when the tablet is powered ON. Wake up Short press the power button to wake the screen up when the tablet is powered ON and in standby mode. 1-5 Lock and Unlock the Screen Lock The system will automatically lock the screen and enter the standby mode if there is no activity from the user. Preset sleep time designated by user. You can set up the sleep time in the system settings under <display>. Unlock Drag to the right to unlock, shown below. Drag to the left to enter the Camera/Video mode from the lock screen. 1-6 Home Screen Info 1-7 Text Input When using the tablet, you can use the on-screen keyboard to enter text, numbers, symbols directly. After tapping and selecting an area to input text, the default keyboard will be automatically displayed. ‐ To switch from letters to numbers, tap ‐ To toggle caps lock ON/OFF, double tap Chapter Two - Internet 2-1 Browser Internet browsing requires a local wireless network. If there are network issues, please contact your network operator or the service provider. First tap in the Home Screen to enter the Application Menu. Then tap (Settings) to access the Wi-Fi menu. Slide the Wi-Fi switch to the ON position, select the desired local network, enter the password (if required) and tap <connect> “ Tap the browser icon in the application menu to begin browsing the internet. To enter in a URL, tap the input area to bring up the soft keyboard, then type in the website. Chapter Three: Applications 3-1 Camera/Video Camera Tap in the application menu to enter the camera mode. Tap to take a picture of what is displayed by the camera. “ Tap to enter camera settings: White Balance, Exposure， Save Video “ Tap to enter into video mode. Tap Setting： White Balance, Timer， Save Tap this to start recording a video View Photos and Videos In the Gallery interface, click on the photo to view it, and you can also view the photos in a slideshow 3-2 Photos Tap the Gallery icon in the application menu to view your photos, which includes all the pictures. Tap to classify the pictures by time and place. Tap to enter camera mode. Ta…

Text truncated - open the document above for the full version.

THINKMAX TECHNOLOGIES INC. SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 THINKMAX TECHNOLOGIES INC. SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2014/4/21 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, THINKMAX TECHNOLOGIES INC. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： TITAN 2 Trade Name： Model Name： HS-7DTB25 Serial Model： N/A FCC ID : 2AB9A-7DTB25 We affirm that between SIEMIC and THINKMAX TECHNOLOGIES INC. , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature Name: Josie Lombardi Title: Purchasing Manager Address: 560 DENISON STREET, UNIT 5, MARKHAM,ontaria, L3R2M8,Canada

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 THINKMAX TECHNOLOGIES INC. 2014-4-21 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AB9A-7DTB25 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Name: Josie Lombardi Title: Purchasing Manager Address: 560 DENISON STREET, UNIT 5, MARKHAM,ontaria, L3R2M8,Canada

Kobian Canada Inc. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2014-4-21 SUBJECT: FCC Application for (FCC ID: 2AB9A-7DTB25) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Signature Name: Josie Lombardi Title: Purchasing Manager Address: 560 DENISON STREET, UNIT 5, MARKHAM,ontaria, L3R2M8,Canada

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label TITAN 2 Model NO.: HS-7DTB25 Input Rating: DC 5V/ 1500mA FCC ID: 2AB9A-7DTB25 THINKMAX TECHNOLOGIES INC. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 ANT Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8

SAR TEST REPORT For TITAN 2 Model Number: HS-7DTB25 FCC ID: 2AB9A-7DTB25 IC: 11937A-7DTB25 Report Number : WT148001119 Test Laboratory : Shenzhen Academy of Metrology and Quality Inspection National Testing Center for Digital Electronic Products Site Location : Bldg. Metrology and Quality Inspection, Longzhu Road, Shenzhen, Guangdong, China Tel : 0086-755-26941599 Fax : 0086-755-26941545 Web : www.smq.com.cn Report No.: WT148001119 Page 2 of 76 Test report declaration Applicant : THINKMAX TECHNOLOGIES INC. Address : 560 DENISON STREET, UNIT 5, MARKHAM,ontaria, L3R2M8 ,Canada Manufacturer : THINKMAX TECHNOLOGIES INC. Address : 560 DENISON STREET, UNIT 5, MARKHAM,ontaria, L3R2M8 ,Canada EUT Description : TITAN 2 Model No : HS-7DTB25 Trade mark : : Serial Number : : / FCC ID : : 2AB9A-7DTB25 Test Standards: IEEE 1528-2013 FCC KDB 865664 D01 v01 Canada’s Safety Code 6 RSS-102 The EUT described above is tested by Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory to determine the compliance of the applicable standards stated above. Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory is assumed full responsibility for the accuracy of the test results. The results documented in this report only apply to the tested sample, under the conditions and modes of operation as described herein. The test report shall not be reproduced in part without written approval of the laboratory. Project Engineer: Date: Apr.28.2014 (Liu Zheng) Checked by: Date: Apr.28.2014 (Yang Dongping) Approved by: Date: Apr.28.2014 (Lin Bin) Report No.: WT148001119 Page 3 of 76 TABLE OF CONTENTS TEST REPORT DECLARATION ......................................................................................................... 2 1. REPORTED SAR SUMMARY ................................................................................................. 5 2. GENERAL INFORMATION ...................................................................................................... 6 2.1. Report information .......................................................................................................... 6 2.2. Laboratory Accreditation and Relationship to Customer ......................................... 6 3. DESCRIPTION OF THE DEVICE UNDER TEST（DUT） ............................................... 8 3.1. DUT Description ............................................................................................................. 8 3.2. RF output power Tune up limit ..................................................................................... 9 3.3. Applied Standards ........................................................................................................ 10 3.4. SAR Limit ....................................................................................................................... 10 4. TEST CONDITIONS ................................................................................................................ 11 4.1. Temperature and Humidity ......................................................................................... 11 4.2. Introduction of SAR ...................................................................................................... 11 4.3. Test Configuration ........................................................................................................ 11 5. DESCRIPTION OF THE TEST EQUIPMENTS ................................................................. 13 5.1. Measurement System and Components .................................................................. 13 5.2. Isotropic E-field Probe Type ES3DV3 ....................................................................... 14 5.3. Phantoms....................................................................................................................... 14 5.4. Tissue-equivalent Liquids ........................................................................................... 15 5.5. Device Holder ............................................................................................................... 19 5.6. Test Position ................................................................................................................. 20 5.7. Scan Procedures .......................................................................................................... 22 5.8. SAR Averaging Methods ............................................................................................. 22 6. MEASUREMENT UNCERTAINTY ....................................................................................... 23 6.1. Uncertainty for SAR Test ............................................................................................ 23 6.2. Uncertainty for System Validation ............................................................................. 24 7. CONDUCTED TEST RESULTS ........................................................................................... 25 8. EXPOSURE POSITIONS CONSIDERATION .................................................................... 26 9. SAR TEST RESULTS ............................................................................................................. 27 Report No.: WT148001119 Page 4 of 76 9.1. WIFI SAR results .......................................................................................................... 27 9.2. Repeated SAR results ................................................................................................. 27 APPENDIX A: SYSTEM CHECKING SCANS ............................................................................ 29 APPENDIX B: SYSTEM VALIDATION ........................................................................................ 32 APPENDIX C: MEASUREMENT SCANS ................................................................................... 33 APPENDIX D: RELEVANT PAGES FROM PROBE CALIBRATION REPORT(S) ............. 38 APPENDIX E: RELEVANT PAGES FROM DIPOLE VALIDATION KIT…

Text truncated - open the document above for the full version.

FCC RADIO TEST REPORT FCC ID: 2AB9A-7DTB25 Product： TITAN 2 Trade Name： Model Name： HS-7DTB25 Serial Model： N/A Report No.： NTEK-2014NT0415671F Prepared for THINKMAX TECHNOLOGIES INC. 560 DENISON STREET, UNIT 5, MARKHAM,ontaria, L3R2M8,Canada Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 65 Report No.: NTEK-2014NT0415671F TEST RESULT CERTIFICATION Applicant’s name........ THINKMAX TECHNOLOGIES INC. Address ........................ 560 DENISON STREET, UNIT 5, MARKHAM,ontaria, L3R2M8,Canada Manufacture's Name... THINKMAX TECHNOLOGIES INC. Address ........................ 560 DENISON STREET, UNIT 5, MARKHAM,ontaria, L3R2M8,Canada Product description Product name .................TITAN 2 Model and/or type reference ..................... HS-7DTB25 Serial Model .................... N/A Standards.................... FCC Part15.247 Test procedure ................ ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test...................................... Date (s) of performance of tests ....... 15 Apr. 2014 ~18 Apr. 2014 Date of Issue..................................... 19 Apr. 2014 Test Result......................................... Pass Testing Engineer : (Apple Huang) Technical Manager : (Brown Lu) Authorized Signatory : (Bovey Yang) Page 3 of 65 Report No.: NTEK-2014NT0415671F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 4 . POWER SPECTRAL DENSITY TEST 36 4.1 APPLIED PROCEDURES / LIMIT 36 4.1.1 TEST PROCEDURE 36 4.1.2 DEVIATION FROM STANDARD 36 4.1.3 TEST SETUP 36 4.1.4 EUT OPERATION CONDITIONS 36 4.1.5 TEST RESULTS 37 5 . BANDWIDTH TEST 45 5.1 APPLIED PROCEDURES / LIMIT 45 5.1.1 TEST PROCEDURE 45 Page 4 of 65 Report No.: NTEK-2014NT0415671F Table of Contents Page 5.1.2 EUT OPERATION CONDITIONS 45 5.1.3 TEST RESULTS 46 6 . PEAK OUTPUT POWER TEST 54 6.1 APPLIED PROCEDURES / LIMIT 54 6.1.1 TEST PROCEDURE 54 6.1.2 DEVIATION FROM STANDARD 54 6.1.3 TEST SETUP 54 6.1.4 EUT OPERATION CONDITIONS 54 6.1.5 TEST RESULTS 55 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 56 7.1 DEVIATION FROM STANDARD 56 7.2 TEST SETUP 56 7.3 EUT OPERATION CONDITIONS 56 7.4 TEST RESULTS 57 8 . ANTENNA REQUIREMENT 63 8.1 STANDARD REQUIREMENT 63 8.2 EUT ANTENNA 63 9 . EUT TEST PHOTO 64 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 65 Report No.: NTEK-2014NT0415671F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 65 Report No.: NTEK-2014NT0415671F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 65 Report No.: NTEK-2014NT0415671F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment TITAN 2 Trade Name Model Name HS-7DTB25 Serial Model N/A Model Difference All the model are the same circuit and RF module, except the model name. Product Description The EUT is a TITAN 2 Operation Frequency: 802.11b/g/n(20MHz): 2412~2462MHz 802.11n(40MHz):2422~2452MHz Modulation Type: CCK/OFDM/DBPSK/DAPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20MHz/40MHz):150/144.44/1 30/117/115.56/104/86.67/78/52/6.5Mb ps Number Of Channel 802.11b/g/n20MHz:11CH 802.11n40MHz:7CH Antenna Designation: Please see Note 3. Output Power(Conducted): 802.11b: 18.72 dBm (Max.) 802.11g: 17.55 dBm (Max.) 802.11n(20M): 16.76 dBm (Max.) 802.11n(40M): 15.68 dBm (Max.) Antenna Gain (dBi) 1.0dbi Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specificatio…

Text truncated - open the document above for the full version.

Page 64 of 65 Report No.: NTEK-2014NT0415671F 9. EUT TEST PHOTO Radiated Measurement Photos Page 65 of 65 Report No.: NTEK-2014NT0415671F Conducted Measurement Photos
