2ABBL-M10701TABLET PC

1 Foreword 1. Announcements Maintenances  Please keep Device dry. Do not let equipment, charger contact water and vapor, or use wet hand to operate equipment or charger. Lest cause short-circuit, corrosion caused by equipment failure and personnel.  Don’t make equipment and charger strongly impact or vibration. Lest cause equipment, battery and charger fault, fire or explosion.  Don’t put this equipment and charger in the too high or too low temperature region. Otherwise you may cause equipment, battery and charger fault, fire or explosion.  Don’t hit, throw, acupuncture the Device, and avoid drop, extrusion, bending Device.  Don’t unauthorized equipment and accessories, otherwise the equipment and accessories will not in the company’s warranty scope. 2 2. Safety T ips Before using internet Tablet, please read this section information,and let your child know this information. For detailed information, please refer to the Safety guidelines and notes:  Do not use Device when driving, in order to remain safe.  In medical sites, please comply with relevant provisions or regulations. Please close Device near the medical equipment area.  Please close Device or open planes mode when you are boarding to avoid wireless signals jamming aircraft control signal.  Please close Device near the use of high precision electronic equipment; otherwise it may lead to electronic equipment disable.  Do not unauthorized to remove Device and accessories. Only authorized institutions can repair this Device.  Please put Device away from magnetic equipment. The radiation of Device will erase information which is on magnetic storage device.  Please don’t use Device in the high temperature and flammable areas. 3  Please don’t put Device and accessories in this place which children can touch it, please do not let the child use Device unsupervised.  Pease abide by the relevant laws and regulations when you use the Device, and respect others lawful rights and privacy.  Please strictly abide by relevant specification of this manual when you use USB cable. Otherwise it might damage your Device or personal computer.  Please don’t use Device in the damp environment such as bathroom etc. to avoid the Device soaked or flushed by the liquid. 4 Contents Appearance and Buttons.....................................................................6 Quick Start.............................................................................................7 Main Interface Function/Icon.............................................................8 Application Installation........................................................................10 Internet...................................................................................................11 3G Connection.......................................................................................12 Operating Details of Main Interface...................................................13 OTG Function.........................................................................................17 TF Card...................................................................................................18 Basic Setting...........................................................................................19 Accessibility.............................................................................................22 Trouble Shooting...................................................................................24 Do’s for disposal of product..................................................................27 5 Appearance and Buttons 1. Front Camera 2. “”: Power Button-long press this button to turn On/Off the player, short press this button to turn off and lock the display. 3. Earphone Jack 4. USB Port: Micro USB 5 Pin data port supports external U-disc, USB mouse/keyboard, 3G data card, etc. 5. DC in 6. “V-”: volume down 7. Reset socket 8. TF card slot 9. “V+”: volume up 6 1. Quick Start 1-1. Power On/Off and unlock: At the power OFF status, long press “” for three seconds to turn ON. It will take some time to power on, please wait. Energy-saving and locking mode: at the process of using, system will automatically enter energy-saving mode, press “” to wake up the screen, system will enter unlocking mode in one second, slip “” to unlock. Notes: Power Off: At the status of using, press “” for 5 seconds, the screen will show power off option. Select “Power off” option; confirm your choice and system will automatically turn off. Select “Cancel” to cancel power off operation. Notes: At the status of low-power, it will have warning voice; connect the DC adapter and begin to charge, it will automatically turn off. If the product cannot boot, please check the battery. 1-2．Battery and Charge Battery should be charged for 8 to 12 hours for the first time in order to make sure battery with enough power. 7 Please use charger approved by our company for charging. Before charging, insert the miniport of the adaptor into DC jack and the other side into power socket. Then the device is being charged, the battery icon will show the charging status. Please don’t disconnect the charger until device is fully charged. Battery icon will show whether it is fully charged. Please note the following precautions for protecting lithium battery a. Don’t charge in high temperature environment (like under direct sunshine) b. Lithium battery doesn’t need to discharge. User can charge the battery when there is still power left. c. While charging, it is normal that both charger and device will heat up 2：Main Interface Function/Icon 2-1 ： Main interface function icon definition 8 Icon Definition Icon Definition Google Search Setting Back Function Module Menu Back to main interface from any interface Camera System current time Battery WIFI signal Menu New device found Setting Menu 2-2．Main Interface Long press power to turn on, the screen is locked after power on; slip unlock key to unlock and enter the mai…

Text truncated - open the document above for the full version.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 HLS Technology Corporation Limited 2015.10.29 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ABBL-M10701 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : michael wu Client’s name & title : CEO Contact information / address: 4F,B4 Building,3rd Industrial Zone, Fenghuanggang, Bao'an District,Shenzhen, China

HLS Technology Corporation Limited WIFI Channel 12 & 13 Declaration Letter To whom it may concern : We have declared below featured for FCC equipment authorization in regard to 802.11b/g/n channel 12 & 13 operating capability for FCC ID : 2ABBL-M10701 Please check Product hardware does not have the capability to operate on channel 12 & 13 Product hardware has the capability to operate on channel 12 & 13. However , these 2 channels will be disabled via software and user will not able to enable these 2 channels Product hardware has the capability to operate on channel 12 & 13. And meeting KDB 594280 D01 requirement. Pls explain detail here. Others Pls explain detail here. Company Name: HLS Technology Corporation Limited Address : 4F,B4 Building,3rd Industrial Zone,Fenghuanggang,Bao’an District Shenzhen, China Name / Title : michael wu / CEO Signature : Phone : 86-755-89534212 Email : [email protected] Date :10/29/2015

Differences Description We HLS Technology Corporation Limited state: Product： TABLET PC Model Name： M10701,M10702,M10703,M10704,M10705, M10706,M10707,M10708,M10709 FCC ID: 2ABBL-M10701 The electrical circuit design, layout, components used and internal wiring for above models are identical, only different in model name. Signatory Date 10/29/2015 Signature Name: michael wu Title: CEO Company: HLS Technology Corporation Limited Address: 4F,B4 Building,3rd Industrial Zone, Fenghuanggang, Bao'an District,Shenzhen, China

Project No: STS1509121 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Project No: STS1509121 Photo 3 Photo 4 Project No: STS1509121 Photo 5 Photo 6 Project No: STS1509121 Photo 7 Photo 8

Label TABLET PC Model name: M10701 FCC ID: 2ABBL-M10701 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. label

Project No: STS1509121 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 BT/WIFI ANTENNA Project No: STS1509121 Photo 3 Photo 4 Project No: STS1509121 Photo 5

FCC ID : 2ABBL-M10701 RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID : 2ABBL-M10701 Maximum measured transmitter power. BT4.0 The Worst Case frequency Maximum Peak Conducted Output Power Tune up tolerance Max Antenna Gain GHz dBm dBm dBi 2.412 -4.047 -4±1 0 2.437 -3.847 -4±1 0 2.462 -3.364 -4±1 0 Remark: The Worst case gain of the antenna is 0 dBi. 0 dBi logarithmic terms convert to numeric result is nearly 1 (2.402GHz) -3dbm= 0.5012mw (2.441GHz) -3dbm= 0.5012mw (2.480GHz) -3dbm=0.5012mw BT4.0: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 0.5012/5*√2.402=1.5536≤3.0 [(mid. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 0.5012/5*√2.441=1.5661≤3.0 [(min. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 0.5012/5*√2.480=1.5786≤3.0 Threshold at which no SAR required is 1.5786 ≤ 3.0 for 1-g SAR, Separation distance is 5mm. FCC ID : 2ABBL-M10701 WIFI The Worst Case frequency Maximum Peak Conducted Output Power Tune up tolerance Max Antenna Gain GHz dBm dBm dBi 2.402 9.4 8.5±1 0 2.441 9.1 8.5±1 0 2.480 8.9 8.5±1 0 Remark: The Worst case gain of the antenna is 0 dBi. 0 dBi logarithmic terms convert to numeric result is nearly 1 (2.402GHz) -9.5dbm= 8.9125mw (2.441GHz) -9.5dbm= 8.9125mw (2.480GHz) -9.5dbm= 8.9125mw WIFI: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 8.9125/5*√2.412=2.7683≤3.0 [(mid. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 8.9125/5*√2.437=2.7826≤3.0 [(min. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 8.9125/5*√2.462=2.7969≤3.0 Threshold at which no SAR required is 2.7969 ≤ 3.0 for 1-g SAR, Separation distance is 5mm.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS1509121F01 Issued for HLS Technology Corporation Limited 4F,B4 Building,3rd Industrial Zone,Fenghuanggang,Bao’an District Shenzhen, China Product Name: TABLET PC Brand Name: NO Model No.: M10701 Series Model: M10702,M10703,M10704,M10705, M10706,M10707,M10708,M10709 FCC ID: 2ABBL-M10701 Test Standard: FCC Part 15.247 S T L A B S Page 2 of 38 Report No.: STS1509121F01 TEST RESULT CERTIFICATION Applicant’s name .................. : HLS Technology Corporation Limited Address ................................... : 4F,B4 Building,3rd Industrial Zone,Fenghuanggang,Bao’an District Shenzhen, China Manufacture's Name ............. : SHENZHEN HENGLONGSHENG TECHNOLOGY CO. LIMITED Address ................................... : 4F,B4 Building,3rd Industrial Zone,Fenghuanggang,Bao’an District Shenzhen, China Product description Product name............................ : TABLET PC Model and/or type reference . : M10701 Series Model ............................. : M10702,M10703,M10704,M10705, M10706,M10707,M10708,M10709 Standards............................... : FCC Part15.247 Test procedure ............................... : ANSI C63.10-2013 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, thidocument may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test .............................................. : Date (s) of performance of tests .............. : 25 Sep. 2015 ~10 Oct. 2015 Date of Issue ............................................. : 12 Oct. 2015 Test Result ................................................. : Pass Testing Engineer : (Jin Ming) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) Page 3 of 38 Report No.: STS1509121F01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 5 1.2 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 10 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 3. EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.2 TEST PROCEDURE 13 3.3 TEST SETUP 13 3.4 EUT OPERATING CONDITIONS 13 3.5 TEST RESULTS 14 4. RADIATED EMISSION MEASUREMENT 16 4.1 RADIATED EMISSION LIMITS 16 4.2 TEST PROCEDURE 17 4.3 TEST SETUP 18 4.4 EUT OPERATING CONDITIONS 19 4.5 TEST RESULTS 19 4.6 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 23 5. CONDUCTED SPURIOUS EMISSIONS 24 5.1 REQUIREMENT 24 5.2 TEST PROCEDURE 24 5.3 TEST SETUP 24 5.4 EUT OPERATION CONDITIONS 24 5.5 TEST RESULTS 25 6. POWER SPECTRAL DENSITY TEST 28 6.1 APPLIED PROCEDURES / LIMIT 28 6.2 TEST PROCEDURE 28 6.3 TEST SETUP 28 Page 4 of 38 Report No.: STS1509121F01 Table of Contents Page 6.4 EUT OPERATION CONDITIONS 28 6.5 TEST RESULTS 29 7. BANDWIDTH TEST 31 7.1 APPLIED PROCEDURES / LIMIT 31 7.2 TEST PROCEDURE 31 7.3 TEST SETUP 31 7.4 EUT OPERATION CONDITIONS 31 7.5 TEST RESULTS 32 8. PEAK OUTPUT POWER TEST 34 8.1 APPLIED PROCEDURES / LIMIT 34 8.2 TEST PROCEDURE 34 8.3 TEST SETUP 34 8.4 EUT OPERATION CONDITIONS 34 8.5 TEST RESULTS 35 9. ANTENNA REQUIREMENT 36 9.1 STANDARD REQUIREMENT 36 9.2 EUT ANTENNA 36 10. EUT TEST PHOTO 37 Page 5 of 38 Report No.: STS1509121F01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b) Peak Output Power PASS -- 15.247 (c) Radiated Spurious Emission PASS -- 15.247 (d) Power Spectral Density PASS -- 15.205 Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACTORY Shenzhen STS Test Services Co., Ltd. Add. : 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China CNAS Registration No.: L7649; FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±2.88dB 2 Conducted Emission (150KHz-30MHz) ±2.67dB 3 RF power,conducted ±0.70dB 4 Spurious emissions,conducted ±1.19dB 5 All emissions,radiated(<1G) 30MHz-200MHz ±2.83dB 6 All emissions,radiated(<1G) 200MHz-1000MHz ±2.94dB 7 All emissions,radiated(>1G) ±3.03dB 8 Temperature ±0.5°C 9 Humidity ±2% Page 6 of 38 Report No.: STS1509121F01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment TABLET PC Trade Name NO Model Name M10701 Series Model M10702,M10703,M10704,M10705,M10706,M10707, M10708,M10709 Model Difference Only different in model name. Product Description The EUT is a TABLET PC Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology BLE Number Of Channel 40 Antenna Designation: Please see Note 3. Antenna Gain (dBi) 0 dbi Channel List Please refer to the Note 2. Adapter Input: AC100-240V, 300mA, 60 Hz Output: DC 5V, 1500mA Battery Rated Voltage: 3.7V capacity :3000mAh Hardware version number -- Software versioning number…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS1509121F02 Issued for HLS Technology Corporation Limited 4F,B4 Building,3rd Industrial Zone,Fenghuanggang,Bao’an District Shenzhen, China Product Name: TABLET PC Brand Name: NO Model No.: M10701 Series Model: M10702,M10703,M10704,M10705, M10706,M10707,M10708,M10709 FCC ID: 2ABBL-M10701 Test Standard: FCC Part 15.247 S T L A B S Page 2 of 61 Report No.: STS1509121F02 TEST RESULT CERTIFICATION Applicant’s name .................. : HLS Technology Corporation Limited Address ................................... : 4F,B4 Building,3rd Industrial Zone,Fenghuanggang,Bao’an District Shenzhen, China Manufacture's Name ............ : SHENZHEN HENGLONGSHENG TECHNOLOGY CO. LIMITED Address ................................... : 4F,B4 Building,3rd Industrial Zone,Fenghuanggang,Bao’an District Shenzhen, China Product description Product name ......................... : TABLET PC Model and/or type reference : M10701 Series Model ........................... : M10702,M10703,M10704,M10705, M10706,M10707,M10708,M10709 Standards .............................. : FCC Part15.247 Test procedure ............................. : ANSI C63.10-2013 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test .............................................. : Date (s) of performance of tests.............. : 25 Sep. 2015 ~10 Oct. 2015 Date of Issue ............................................ : 12 Oct. 2015 Test Result................................................. : Pass Testing Engineer : (Jin Ming) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) Page 3 of 61 Report No.: STS1509121F02 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 DESCRIPTION OF TEST MODES 10 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TEST 11 2.4 DESCRIPTION OF SUPPORT UNITS 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST RESULT 14 3.2 RADIATED EMISSION MEASUREMENT 16 3.2.1 RADIATED EMISSION LIMITS 16 3.2.2 TEST PROCEDURE 17 3.2.3 TEST SETUP 18 3.2.4 EUT OPERATING CONDITIONS 19 3.2.5 TEST RESULT 20 4. CONDUCTED SPURIOUS EMISSIONS 26 4.1 APPLIED PROCEDURES / LIMIT 26 4.2 TEST PROCEDURE 26 4.3 DEVIATION FROM STANDARD 26 4.4 TEST SETUP 26 4.5 EUT OPERATION CONDITIONS 26 4.6 TEST RESULTS 27 5. POWER SPECTRAL DENSITY TEST 39 5.1 APPLIED PROCEDURES / LIMIT 39 5.2 TEST PROCEDURE 39 5.3 DEVIATION FROM STANDARD 39 5.4 TEST SETUP 39 5.5 EUT OPERATION CONDITIONS 39 5.6 TEST RESULTS 40 Page 4 of 61 Report No.: STS1509121F02 Table of Contents Page 6. BANDWIDTH TEST 48 6.1 APPLIED PROCEDURES / LIMIT 48 6.2 TEST PROCEDURE 48 6.3 DEVIATION FROM STANDARD 48 6.4 TEST SETUP 48 6.5 EUT OPERATION CONDITIONS 48 6.6 TEST RESULTS 49 7. PEAK OUTPUT POWER TEST 57 7.1 APPLIED PROCEDURES / LIMIT 57 7.2 TEST PROCEDURE 57 7.3 DEVIATION FROM STANDARD 57 7.4 TEST SETUP 57 7.5 EUT OPERATION CONDITIONS 57 7.6 TEST RESULTS 58 8. ANTENNA REQUIREMENT 59 8.1 STANDARD REQUIREMENT 59 8.2 EUT ANTENNA 59 APPENDIX - PHOTOS OF TEST SETUP 60 Page 5 of 61 Report No.: STS1509121F02 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 12 Oct. 2015 STS1509121F02 ALL Initial Issue Page 6 of 61 Report No.: STS1509121F02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) (reference KDB 558074 d05 v02. /9.1.2) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Conducted Spurious Emission PASS 15.247 (e) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 7 of 61 Report No.: STS1509121F02 1.1 TEST FACTORY Shenzhen STS Test Services Co., Ltd. Add. : 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China CNAS Registration No.: L7649; FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±2.88dB 2 Conducted Emission (150KHz-30MHz) ±2.67dB 3 RF power,conducted ±0.70dB 4 Spurious emissions,conducted ±1.19dB 5 All emissions,radiated(<1G) 30MHz-200MHz ±2.83dB 6 All emissions,radiated(<1G) 200MHz-1000MHz ±2.94dB 7 All emissions,radiated(>1G) ±3.03dB 8 Temperature ±0.5°C 9 Humidity ±2% Page 8 of 61 Report No.: STS1509121F02 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment TABLET PC Trade Name NO Model Name M10701 Series Model M10702,M10703,M10704,M10705,M10706,M10707,M10708, M10709 Model Difference Only different in model name. Product Description The EUT is a TABLET PC Operation Frequency: 802.11b/g/n 20: 2412~2462 MHz 802…

Text truncated - open the document above for the full version.

M10701 DTS Setup photo DTS conduction DTS radiation L DTS radiation H
