ClareOne Door Window Sensor with Shock Installation Manual CLR-C1-DWSHK CLR-C1-DWSHK IM V3 05012020 Description The CLR-C1-DWSHK is a wireless window sensor designed for dual protection; open and close and to detect vibrations made by an intruder attempting to break a window. The sensor contains a piezo detection device that detects vibrations when mounted on a window frame. The detection circuit can be adjusted for sensitivity during installation to ensure maximum coverage. The device also has a built-in reed switch to monitor the open and close of the door or window. When activated, the sensor transmits a signal to the control panel. These are the signals the unit provides: supervisory, tamper and low battery (as needed). The sensor is powered by (2) replaceable 3-VDC, lithium coin-cell batteries. Installation Guidelines • Mounting the sensor on metal can affect the transmitting range performance. Therefore, test the sensor from the desired location using the installer sensor test, before permanently mounting it. • Mount the sensor within 100 ft. of the panel. • Mount the sensor on the frame of the door or window. • Mount to either wood or metallic surfaces. • After mounting the sensor, test the sensor using the procedure in the section “Testing the Sensor”. Mounting the Sensor Mount the sensor using the supplied mounting screws for permanent mounting installations or using the supplied double-sided tape is optional . Note: Sensor and magnet should not exceed 5/8”. Mounting Screws 1. Remove the sensor base from the sensor. 2. Place the sensor base in desired location and mount the base with the supplied screws. Attach the sensor to the base. 3. Mount the magnet into the desired location using the supplied screw and lock washer, making sure the alignment mark lines up with the sensor mark. Shock Test Mode • Test mode is entered automatically when the cover is removed. The LED activates on shock activation and goes out upon shock restoral. • LED is functional only in test mode. • Test mode is active as long as the cover is removed. Shock sensor sensitivity setting An LED test mode (see above) is included to aide in setting sensitivity to desired level 1. Mount sensor in intended location and tap mounting surface with desired level of activation impact 2. Adjust potentiometer until correct sensitivity is obtained The potentiometer adjusts shock sensitivity from minimum Low (CCW) to maximum Hi (CW). These setting are marked on the PCB. In maximum sensitivity mode, the least amount of shock is required to activate a shock alarm. If the potentiometer is set all the way Low (CCW) the shock portion of the device is turned off and only the internal reed switch is active Programming The following steps describe the general guidelines for programming the sensor into panel memory. Refer to the specific panel’s documentation for complete programming details. 1. The internal magnetic reed switch and shock zone use the same ID number 2. Enter panel learn-in/enrollment mode 3. Remove battery tabs 4. Trip sensor using magnet or enter ID # 5. Enter sensor information Note: Loop locations: Shock – Loop 1 Reed Switch – Loop 2 Tamper – Loop 4 6. For second zone trip sensor using magnet or enter ID # 7. Enter sensor information Note: Loop locations: Shock – Loop 1 Reed Switch – Loop 2 Tamper – Loop 4 8. Exit program mode Testing and adjusting the Sensor Take the sensor and magnet to the desired mounting location, making sure to line up the magnet alignment ClareOne Door Window Sensor with Shock Installation Manual CLR-C1-DWSHK CLR-C1-DWSHK IM V3 05012020 marks with each other. Trip the sensor by pulling the magnet away from the sensor. Monitor the system after tripping the sensor. Refer to the specific panel documentation for interpretation of the results to ensure desired signal strength is achieved. Battery Replacement Note: If a low battery alarm occurs, replace the battery within 7 days. • Low battery detect. LED flashes until battery is replaced. Device sends low battery signal to control panel. • The CLR-C1-DWSHK requires (2) 3-VDC, lithium coin- cell batteries (Varta or Panasonic, Model CR2032). Both batteries should be replaced at the same time. 1. Remove sensor cover by pressing on the latch and pulling the cover off 2. Do not remove the circuit board, slide the old batteries out as shown 3. Insert new batteries observing polarity 4. Replace sensor cover CAUTION: Battery may explode if mistreated. Do not recharge, disassemble or dispose of in fire. Specifications Model no. CLR-C1-DWSHK RF frequency 433.95 MHz Compatibility Clare Control Panels Battery type (2) 3-VDC, lithium coin-cell battery (Varta or Panasonic, Model CR2032) Operating temperature range 32 to 120°F (0 to 49°C) Storage temperature range -30 to 140°F (-34 to 60°C) Relative humidity 95% non-condensing Dimensions (L x W x D) 2.25 x 1.0 x 0.50 in. FCC / IC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Per FCC 15.19 (a) (3) and (a) (4), This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation. Per FCC 15.21, The user manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occ…

Text truncated - open the document above for the full version.

Cinch Systems, Inc. 12075 43 rd St NE Suite 300 St. Michael MN 55376 USA Application Cover Letter FCC ID: 2ABBZ-RF-SHK-433 Cinch Security Systems is applying for original certification to FCC Part 15 Subpart C §15.231 for FCC ID number 2ABBZ- RF-SHK-433 door window shock sensor. The wireless communication interface with a security panel is regarded as a proprietary security protocol. The following model numbers are associated with this application:  RF-SHK-433-CLR  CLR-C1-DWSHK The radio in all models are electrically identical. The differences in the models are the company model naming format. Cinch model Number Clare model number Remark RF-SHK-433-CLR CLR-C1-DWSHK Electrically equivalent devices Electrically all the units are identical. Company Officer: Vice President Telephone Number: 763-497-1059 Email: [email protected]

CSFXXX issue 1 Cinch Systems, Inc. 12075 43 rd St NE Suite 300 St Michael, MN 55376 USA Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 User Manual Declaration FCC ID: 2ABBZ-RF-SHK-433 Please be advised that at the time of application we do not currently have a version of the user manual for the product under the ‘Cinch’ brand. Please be advised that the manual for the Cinch brand will be identical to the user manual already provided for the ‘ClareOne’ brand from a regulatory perspective. Company Officer: Vice President Telephone Number: 763-497-1059 Email: [email protected]

Cinch Systems, Inc. 12075 43rd St NE Suite 300 St Michael MN 55376 USA Periodic Operation Attestation We, the equipment manufacturer and/or responsible party confirm that the equipment is not a radio control device or toy, and is not capable of generating continuous transmissions, voice, or video transmissions. Data shall be sent only along with a control signal. We attest that we have verified and documented that periodic transmissions at regular predetermined intervals do not exist, except where regulatory requirements allow polling or supervision transmissions, including data, to determine system integrity. Please see the detail in the operational description. Company Officer: Vice President Telephone Number: 763-497-1059 Email: [email protected]

Cinch Systems, Inc. 12075 43 rd St NE Suite 300 St Michael, MN 55376 USA Confidentiality Request FCC ID: 2ABBZ-RF-SHK-433 Pursuant to Sections 0.457(d) and 0.459 of the Commission’s Rules, Cinch Systems hereby requests permanent confidential treatment of information accompanying this application as outlined below: Common exhibits for which confidentiality is requested are: Schematics: Block Diagrams: Theory of Operation: Cinch Systems also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of 180 days: Exhibits for which short-term confidentiality is commonly requested are: Internal Photos: External Photos: User Manual: Test Set-up Photographs: The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Company Officer: Vice President Telephone Number: 763-497-1059 Email: [email protected]

Model: RF-SHK-433-CLR Cinch Systems Inc. FCC ID: 2ABBZ-RF-SHK-433 Model: RF-SHK-433-CLR IC : 11817A- RFSHK433 Model: CLR-C1-DWSHK Clare Inc. FCC ID: 2ABBZ-RF-SHK-433 Model: CLR-C1-DWSHK IC : 11817A- RFSHK433

RF-SHK-433 Antenna info Overview: Antenna description:  The antenna is a piece of wire and used in a monopole arrangement. Antenna is permanently attached to the unit. The antenna does not use reverse polarity connector. Antenna Drawing: Antenna design: Antenna specification Frequency band 433.95MHz Frequency (MHz) 430 431 433 434 436 Return loss (dB) < -18 Peak gain (dBi) 0.412 0.22 -0.93 1.67 3.08 Average gain (dBi) -1.34 -3.6 -2.95 -1.9 -1.97 Efficiency (%) 33.8 37.86 48.8 68.3 68.83
