DESKTOP TYPE DIGITAL SIGNAGE Package Contents User manual Power adapter Please make sure all of the following are present when you unpack your DESKTOP TYPE DIGITAL SIGNAGE Features 8” / 10.1"LCD panel Resolution 1280*800 RK 3128 Quad core cortex A7 / RK3288 Quad core cortex A17 RAM 1GB (3128) / RAM 2GB (3288) Internal memory 16GB Android 6.0(3128) / Android 8.1/10.0(3288) Multi Point capacitive touch Microphone Bluetooth 4.0 WiFi 802.11b/g/n RJ45 of ethernet interface USB for serial USB 2.0 host Type-c TF card,support up to 32GB 2*2W speaker Adapter:12V/1.5A SIZE:130x185MM 材质：80G书写纸黑白印刷， 正反面印刷 折页 Android all in one User Manual 8” 10.1” DESKTOP TYPE DIGITAL SIGNAGE User Manual This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed of at the end of its life separately from your household waste. There are separate collection systems for recycling in your country. For more information, please contact the local authority or your retailer where you purchased the product. FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. 8“ Exterior Components RJ45 Microphone Type-c 3.5mm earphone output TF card 1 2 No No Function Function 3 4 5 6 7 8 9 DC power supply port Power key 10.1“ Exterior Components Serial portTTL) USB 2.0 host 1357 2 52.97mm 54.97mm 129.37mm 16.5° 172.62mm 196.11mm 9.96mm 9.96mm 108.04mm 9.84mm 9.80mm 468 9 9 1357 2468 61.25mm 63.25mm 16.5° 217.38mm 9.38mm 9.38mm 136.16mm 10.36mm 10.31mm 5V TX RX GND 5V TX RX GND RJ45 Microphone Type-c 3.5mm earphone output TF card 1 2 No No Function Function 3 4 5 6 7 8 9 DC power supply port Power key Serial portTTL) USB 2.0 host 1)Do not push objects into holes and ventilation slots. Do not expose this product to moisture or place any objects l ed with liquids on or near the product. Do not place a naked ame sou ce, such as lighted candles, on or near this product. Do not store or operate the device in environments where the temperature is above 50 degrees celsius or below -10 degrees celsius. Do not intentionally hit the device or place heavy or sharp objects on the device. Only use accessories specied by the manu acturer. Keep the device away from benzene, diluents, and other chemicals. Do not attempt to repair this product yourself. Always use a qualied se vice agent to perform adjustments or repairs. Copyright Information All intellectual property rights in this publication are owned by and protected by applicable copyright laws and international treaty provisions. retains all rights not expressly granted. No part of this publication may be reproduced in any form whatsoever or used to make any derivative work without prior written approval by . Reserves the right to revise this publication, and/or make improvements or changes in the product(s) and/or the program(s) described in this documentation at any time without prior notice. The information in this document is provided in good faith, but without any representation or warranty whatsoever, whether it is accurate,or complete or otherwise, and on express understanding that shall have no liability whatsoever to other parties in any way arising from or relating to the information or its use. All other trademarks are the property of their respective owners. Other company and brand products and service names are trademarks or registered trademarks of their respective holders. Important Notices WT8012T FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. The device has been evaluated to meet general RF exposure requirement. The device can be used under exposure conditions other than 20cm.

FCCID:2ABC5-E0008

LabelLocationOnEUT Label ProductName:Androidallinone ModelNumber:WT8012T FCCID:2ABC5-E0008 ThisdevicecomplieswithPart15oftheFCCRules.Operation issubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived,including interferencethatmaycauseundesiredoperation.

FCCID:2ABC5-E0008 ANT

version01 SHENZHENELECTRONTECHNOLOGYCO.,LTD. DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.: WT8012T,WT8017T,WT1012T,WT1017T FCCID:2ABC5-E0008 fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsforinternalantennatype(s) describedbelow: ModelNo.ofantenna:N/A Typeofantenna:PIFAAntenna BLE: Gainoftheantenna:1.5dBi Frequencyrange:2402-2480MHz Wifi2.4G: Gainoftheantenna:1.5dBi Frequencyrange:2412-2462MHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname: SHENZHENELECTRONTECHNOLOGYCO.,LTD. Address:Building2,YingfengIndustrialZone,TantouCommunity,SonggangStreet,Bao'an, Shenzhen,China City: Shenzhen ZIP/Postalcode: Country:China Place:ShenzhenChinaDate:2021-01-28 Signature:

RFEXPOSUREEVALUATION AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeusedto evaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF)Radiation asspecifiedin§1.1307(b) FCCID:2ABC5-E0008 EUTSpecification EUTAndroidallinone Frequencyband(Operating)WLAN:2.412GHz~2.462GHz WLAN:5.18GHz~5.32GHz/5.50GHz~5.70GHz WLAN:5.745GHz~5825GHz Others:2.402GHz~2.480GHz(BLE) DevicecategoryPortable(<20cmseparation) Mobile(>20cmseparation) Others___ ExposureclassificationOccupational/Controlledexposure(S=5mW/cm2) GeneralPopulation/Uncontrolledexposure(S=1mW/cm2) AntennadiversitySingleantenna Multipleantennas Txdiversity Rxdiversity Tx/Rxdiversity Max.outputpowerBLE:6.858dBm(0.0049W) WIFI2.4G:16.46dBm(0.0443W) Antennagain(Max)1.5dBi EvaluationappliedMPEEvaluation SAREvaluation LimitsforMaximumPermissibleExposure(MPE) Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) Power Density(mW/cm 2 ) Average Time (A)LimitsforOccupational/ControlExposures 300-1500----F/3006 1500-100000----56 (B)LimitsforGeneralPopulation/UncontrolExposures 300-1500----F/15006 1500-100000----130 Friistransmissionformula:Pd=(Pout*G)\(4*pi*R2) Where Pd=PowerdensityinmW/cm 2 Pout=outputpowertoantennainMw G=gainofantennainlinearscale Pi=3.1416 R=distancebetweenobservationpointandcenteroftheradiatorincm PdthelimitofMPE,1mW/cm2.Ifweknowthemaximumgainoftheantennaand totalpowerinputtotheantenna,throughthecalculation,wewillknowthedistance wheretheMPElimitisreached. MeasurementResult Operating Mode Channel Frequency (MHz) Measured Power (dBm) Tuneup tolerance (dBm) Max.Tune upPower (dBm) Antenna Gain (dBi) Powerdensity at20cm (mW/cm 2 ) Powerdensity Limits (mW/cm 2 ) 802.11b 241214.7914.79±115.791.50.0107 1 243714.4214.42±115.421.50.00981 246214.3714.37±115.371.50.00971 802.11g 241216.4616.46±117.461.5 0.0157 1 243716.1216.12±117.121.50.0145 1 246215.8615.86±116.861.50.01361 802.11n (HT20) 241215.9115.91±116.911.50.01381 243715.9715.97±116.971.50.01401 246215.9515.95±116.951.50.01391 BLE 24026.8586.858±17.8581.50.0017 1 24406.3546.354±17.3541.50.0015 1 24806.6176.617±17.6171.50.00161
