Please read the manual before using this product, and save it for future use. USER GUIDE EMPOWRING YOUNG MINDS K109 Pro 1-13 English 14-26 Français 27-39 Deutsch 40-52 ltaliano 53-65 Español English Content FUNCTION OVERVIEW2 ATTENTION1 2SPECIFICATIONS 3START 3HOME SCREEN 7NETWORK CONNECTION 8APP MANAGEMENT 9MULTIMEDIA 11 TROUBLESHOOTING 12 FCC STATEMENT 9INTERNET NAVIGATION 4BASIC SETTINGS 13IC Warnings ATTENTION 1. Before using the tablet, please carefully read the manual and follow the instructions and specifications provided. 2. Always use the original charger provided with the device to charge it, and avoid using other chargers. If the charger is damaged, replace it with a new one that meets the standard voltage (5V/2A). 3. When the tablet prompts for charging during use (typically when the battery level is around 15%), please charge it promptly. 4. To prevent degradation of hardware performance or accelerated aging and damage to the device, it is recommended that you limit your use to 3-4 hours and avoid using it while it is charging. 5. If the tablet experiences a power outage during charging, unplug it immediately. 6. Avoid placing any objects on the tablet to prevent screen damage. 7. When not in use, place the tablet on a stable surface to avoid accidental damage from falls. 8. Handle the tablet screen with care, as it is susceptible to damage from squeezing and collisions. Avoid using your fingernails and apply light touch rather than heavy pressure. 9. Do not rinse the tablet directly with water when cleaning, as it is not waterproof and may become unusable. 10.To avoid damage to the built-in electronic components, keep the tablet away from high temperatures, humidity, and dust. Store it in a dry place and avoid direct sunlight. 1 ENEN SPECIFICATIONS Tablet Specifications Tablet Size RAM ROM Chipset Front Camera Rear Camera Battery Operating System 10.1" 3GB+3GB 64GB A523 2MP 5MP 5000mAh Android 14 Connectivity Power Supply Display GPU CPU WiFi Touchscreen Ports Wi-Fi/Bluetooth 5V/2A IPS/1280*800 HD G57 MC01 Octa-core ARM CortexTm-A55 802.11a/b/g/n/ac/,2.4G/5G WiFi 6 Multi-touch USB Type-C / Micro SD Card Slot FUNCTION OVERVIEW 6. USB-C Port 7. Left Speaker 8. Right Speaker 9. Rear Camera 10. Flash 1. Headphone Jack 2. Front Camera 3. Volume+/Volume- 4. Power on/off 5. Micro SD Card Slot 2 EN HOME SCREEN START Icon on the Bottom Menu 1. Hold down the power button for 2-3 seconds to turn on the tablet. Select the language and follow the start up guide to set up the tablet. 2. Hold down the power button for 2 seconds to display power off and restart options on the screen. Click power off to turn off the tablet. 3. If the tablet freezes, press and hold the power button for 7 seconds to do a forced shutdown. Sleep Mode Simply press the power button once to switch the tablet into sleep mode when the tablet is ON; press again to wake it up. Tip: Go to Settings > Display > Screen timeout to adjust automatic sleep settings 1. Hide 2. Volume- 3. Back 4. Home Screen 5. Recent Activities 6. Volume+ 7. Screenshot Power On/Off Battery 1. A rechargeable Li-ion battery is installed in the tablet. 2. We suggest you drain the battery completely once a month if you only use your tablet occasionally. 3. DO NOT dispose of tablet in fire. 4. Charge the device fully each time to increase the battery life. 5. You can charge the tablet, even if the tablet has some power left in it, as the lithium battery does not need to be fully drained to charge. 6. A full charge can be used for an average of 4 hours. 3 1 234 5 6 7 EN Home settings, Wallpapers, Widgets BASIC SETTINGS Quick Settings Home settings Tap and hold your finger in any blank space on the home screen and a pop-up menu will appear. Tap HOMESETTINGS to enable/disable adding icons to the Home screen. This applies to new Apps installed from Play Store. Wallpapers Tap and hold your finger in any blank space on the home screen and a pop-up menu will appear. You can choose a wallpaper from the Gallery or your downloaded files. Set the one you like to be the wallpaper. Tips Tap an icon and move it on top of another icon to create a new folder on the home screen. Open the folder; tap "Edit Name" to rename the folder. Swipe down from the top of the screen, Tap the icon to change the options in the quick settings. 4 EN More Settings Swipe down from the top of the screen, then tap the icon to enter the detailed setting interface or swipe up from the bottom of the screen, and then tap Settings to enter the setting interface. Network & Internet · Connect to any working Wi-Fi · Enable/disable airplane mode Battery · Display the remaining battery power as a percentage · Enable/disable battery saver mode Apps & Notifications · Check recently opened apps · Check all apps on the tablet · Set app permissions · Uninstall third-party apps · Adjust app notification settings · Clear the cache for apps Connected Devices · Connect the device and check the connected device 5 EN Storage · View and manage your storage space Sound · Set volume levels for media, notifications and alarms · Set Do Not Disturb preferences · Turn on / off the sound for screen lock, charging, and touch Scheduled power on / off · Set a scheduled start time · Set a scheduled shutdown time Accessibility · For vision and hearing impaired users, manage settings for screen readers, subtitles, and more Privacy, Location, Security · Set screen lock pattern, e.g. password, PIN, Swipe, etc · Enable / disable all notifications while the screen is locked · Turn on / off the location services for a specific app Accounts & Password · Add and manage the user accounts on your tablet Display & Wallpaper · Adjust the screen brightness · Adjust the font size and display size · Set eye comfort mode · Set a screensaver · Change the wallpaper Google · Set the preferences for Google related services Digital Wellbeing & Parental Controls · Set timers for your apps 6 EN Wi-Fi Connection 1. Go to Settings > Network & …
