2ABCF-VSPHOENIXSELECTRONIC DART SYSTEM

HONG International Corp.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Nov 25, 2013
Application Purpose: Original Equipment
Date of Application: Nov 25, 2013
Equipment Note: ELECTRONIC DART SYSTEM
Frequency Range: 13.55900000 - 13.55900000
Company: HONG International Corp.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

VSPHOENIX S USER GUIDE CONTENTSSafety Instructions VSPHOENIX S Manual 3 General safety instructions 1. Available voltage: AC 110~120V / 60Hz 2. Be careful not to bend or push the power cord. 3. Do not place the power cord in place where many passing through are allowed. 4. Unplug the power cord during a thunderstorm. 5. Do not touch any other areas except the designated area. There is risk of electric shock or short circuit. 6. The machine inspection when the electrics are charged should be done by store management administrator or technician. Attentions Name of each part of VSPHOENIX S VSPHOENIX S Size & Specification Names of the major parts of the lower part How to assemble VSPHOENIX How to measure and install the throw line Router connection Online setting Set Network Set Network FAQ 3 4 6 8 10 14 18 19 20 23 24 25 26 28 29 31 33 34 37 42 43 44 45 46 47 Attention before the installation 1. Installation place Place the back of machine and the runway in their approximate final positioning leaving a 10 cm gap in between them for the protection against heat. Avoid high temperature and moisture area. Avoid the vibration and noisy area. (Make sure there is no speaker or amplifier near the machine.) Choose solid and horizontal place to install for the stabilization of dart system. In case of installing in other places except in the surface of the wall, the machine should be reinforced to not fall down by fixing with L bracket. Make sure not to let machine touch each other when the installation place is confined. 2. To use safely, The voltage of outlet should be larger than 110V~120V. If it exceeds the standard due to parallel connections or etc., it may causes fire. Do not touch electrical wiring placed inside of the machine. Do not alter or attempt to modify any parts of the machine in any way. Our Company is not responsible for the damages or thunderstruck caused by customer’s fault. 3. Safety instructions There are high temperature and pressure areas inside the machine. Please be careful when inspecting inside of the machine. Do not touch things not mentioned in the instruction. Do not place any flammable agents near the machine and be aware of fire protection. 4 If any problems are occurred, If the machine is not working properly, please turn off the power, remove the plug from the outlet and contact store management administrator. 5. about liability Our company does not accept any temporary modification, repair and exchange to the contents that are not mentioned in the user’s instructions. Our company is not responsible for any accidents; thus, consumer’s special attention will be needed. 2 VSPHOENIX S Manual SETUP MODE Other Management Methods CREDIT SETUP How to get into SETUP MODE SETUP MODE Control SETUP MAIN MENU EXPLANATION EASY SETUP / MENU SETTING GAME SETTING SYSTEM SETTING COIN ASSIGNMENT BOOKS EVENTLOG Power / Lighting Monitor screen / Miss recognition Sound Coin or Bill / Stuck PHOENIX Card Online / Versus Movie How to setup credit Payment setting (FREE PLAY) Segment management tip/ Daily management Orders of regular scheduled inspection 38 39 40 41 How to solve VS Phoenix-S problem Standard and Installation Methods Online VS PHOENIX S A specification or design can be changed without any notices. 37MACHINE STYLE VSPHOENIX S MANUAL 54 VSPHOENIX S Manual Name of each part of VSPHOENIX SName of each part of VSPHOENIX S VSPHOENIX S SPECName of each part of VSPHOENIX S Speaker(Left) 27 inch LED Monitor Speaker(Right) Camera(Player) Camera(Target) Target 23 inch LED Monitor Arrow Buttons Woofer Lower LED Dard Reader Select Button Lower Handle Move Wheels Control Feet Upper Handle Back Door KEY Power Switch LED THROW Vents A/C Power Inlet Fuse (5A) Lan Reset Switch (Use when a main board BIOS is an error) Right View FrontBack Left View KEY VSPHOENIX S MANUAL 76 VSPHOENIX S MANUAL VSPHOENIX S SIZE VSPHOENIX-S Specification VSPHOENIX S SpecificationVSPHOENIX S Specification 2,154mm 2,510mm 700mm700mm Weight Height UPPER Weight68.8kg Height Depth 914mm 440mm(Not including Foot Step) 600mm(Including Foot Step) LOWER 109.1kg 165w A TYPE (Standard Type) Height Width 2,154mm Depth Gross Weight Power Consumption 585mm(Including Foot Step) 700mm 585mm <A TYPE> <B TYPE> Weight Height UPPER Weight68.8kg Height Depth 914mm 440mm(Not including Foot Step) 600mm(Including Foot Step) LOWER 122.6kg 190w B TYPE (27” Dual Monitor) Height Width 2,510mm Depth Gross Weight Power Consumption 585mm(Including Foot Step) 700mm 1,240mm 40.3kg 1,240mm 53.8kg VSPHOENIX S SIZE VSPHOENIX-S Specification VSPHOENIX S MANUAL 98 VSPHOENIX S MANUAL VSPHOENIX S SpecificationVSPHOENIX S Specification Main Parts on the Lower Part Main Parts of PC Box Other Parts Coin Key : 4 ea (2ea for left and right coin box) House Dart : 21ea(Including Tips)THROW LINE : 1 ea Master Key : 5 eaHexagonal Headed Bolt : 12 eaPower Cord : 1 ea Wrench : 1ea (Upper part connect to Lower part 4 pcs + Foot Step 8 pcs) Woofer Speaker PC Box SETUP Button Cable Guide Sticker Coin Box (1 on both left and right) Card Reader COIN RAIL <Back of Lower Part><Inside of Lower Part> COIN Machine BILL Machine CAMERA Decoder (Assy) Main Board SET SSD 64GB LINE Connector Board(Black) LED CONTROLL BOARD Camera SMPS(Outer) / MODEL : NES - 150W / 12V VSPHOENIX S MANUAL 11 VSPHOENIX S Assembly InstructionsVSPHOENIX S Assembly Instructions 10 VSPHOENIX S MANUAL 1. Be careful with camera and its support to avoid breakage. 2. After installation, please fix machine with machine foot. 3. Should be setup by 2 or more person for safety Notice before Installation Should be setup by 2 or more person for safety. Required Parts Top Bracket 1ea / Wrench Bolts 4ea(Including Washer) / LED Monitor 1ea / Monitor Cable 3M 1ea / Wooden Pannel 1ea / AD paper 1ea / Protection Acrylic 1ea / Screw 4ea B TYPE Assembly(Monitor on top) 1 2 Remove steel plate on the back Remove wooden plate on the back 3 Disconnect Sensing PCB cables 4 Remove LED monitor Separate LED monitor by loosenin…

Text truncated - open the document above for the full version.

Cover Letter(s)

FCC, Request for non-disclosure Date: November 19, 2013 Page 1 of 1 HONG International Corp. 3F, JnK Digital Tower 222-3, Guro-3Dong, Guro-Gu, Seoul, Republic of Korea Subject: Request for confidentiality FCC ID: 2ABCF-VSPHOENIXS Gentlemen: Pursuant to Sections 0.457 and 0.459 of the Commission's Rules, we hereby request confidential treatment of information accompanying this application as outlined below: ☑ Block Diagrams ☑ Operational Description ☑ Schematic Diagrams the above materials contain trade secrets and pr oprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. <City> Seoul-si <Name and signature of applicant> Byung Chang Oh / Team Manager HONG International Corp. Tel : +82-2-6124-6731 Fax : +82-2-6124-6759 E-mail : bbc@ darts.kr

Cover Letter(s)

HONG International Corp. 3F, JnK Digital Tower 222-3, Guro-3Dong, Guro-Gu, Seoul, Republic of Korea November 19, 2013 Subject: DoC declaration To Whom it may concern, We, as the grantee of this project FCC ID: 2ABCF-VSPHOENIXS, would like to declare that the composite portion categorized as computer peripheral hasbeen authorized under the Declaration of Conformity procedures. Test Laboratory : Korea Standard Quality Laboratories #102, Jangduk Dong, Hwasung City, Kyunggi Do, South Korea Regards, Signature: Name/Title : Byung Chang Oh / Team Manager Company Name : HONG International Corp. Address : 3F, JnK Digital Tower 222-3, Guro-3Dong, Guro-Gu, Seoul, Republic of Korea TEL: +82-2-6124-6731 FAX: +82-2-6124-6759 Email: [email protected]

ID Label/Location Info

1. Label Location & Label Drawing Made in Korea Electronic Dart System Model : VSPHOENIXS FCC ID : 2ABCF-VSPHOENIXS HONG International Corp. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received. including interference that may cause undesired operations. Label position 50mm 25mm

Internal Photos

Parts List/Tune Up Info

TRF No.: EN 60335-2-82 F Attachments 3 : List of Critical Components Component (Part no.) Manufacturer(Brand) Mode(Type) Rating or Characteristics Tested by Plug I-Sheng Manufacturing ( SongGang) Factory SP-022 250 V~, 16 A CE Cord I-Sheng Manufacturing ( SongGang) Factory - 60227 IEC 53 (H05VV-F), 3G0.75 ㎟ CE Appliance couplers (Connector) I-Sheng Manufacturing ( SongGang) Factory IS-14 250 V~, 10 A CE Noise Filter Set Applianc e couplers (Applianc e Inlet) Dong il Technology Ltd DAC-4 250 V~, 10 A CE Noise Filter Dong il Technology Ltd IH-1022-H 250 V~, 10 A CE Current fuse Holder Schurter AG FPG 1 250 V~, 10 A CE Current Fuse Suzhou Littelfuse OVS.LTD 312 250 V~, 5 A CE Rocker Switch (Power) Ningbo Yinxian Lihe Switch Factory RL2 250 V~, 16 A CE Micro-Switch (Control_6EA) Qingdao Daesung Electronics Co., Ltd VP333A-0D 250 V~, 5 A CE TFT-LCD (Top) LG Display Co., Ltd LM230WF3 12d.c., 0.475 A CE SMPS (TFT-LCD_Top) Yantai Sam Hwa Polymers Co., Ltd. SAD04212-UV- 36 100-240 V~, 50/60 ㎐, 1.0 A (O/P : 12 Vd.c., 3 A) CE TFT-LCD (Bottom) LG Display Co., Ltd LM230WF3 12d.c., 0.475 A CE 직류전원장치 (TFT- LCD_Bottom) Yantai Sam Hwa Polymers Co., Ltd. SAD04212-UV- 36 100-240 V~, 50/60 ㎐, 1.0 A (O/P : 12 Vd.c., 3 A) CE SMPS Part(NES-50-24) TRF No.: EN 60335-2-82 PCB SHUNDE JUNDA ELECTRONIC CO LTD JD-D V-0 CE Current Fuse (FS1) Suzhou Walter Electronic Co., Ltd FSD 3.15A 250 V~, 3.15 A CE X-Capacitor (C1) Weixu Electronics (Shenzhen) Co., Ltd. GS-L 275 V~, 0.47 ㎌, X2 CE Line Filter(LF1) Mean Well LF-133-R1 15 mH, Class B CE X-Capacitor (C2) Weixu Electronics (Shenzhen) Co., Ltd. GS-L 275 V~, 0.1 ㎌, X2 CE Y-Capacitor (C3, C4) PT.Samcon SD 250 V~, 2 200 ㎊, Y1 CE Y-Capacitor (C30) PT.Samcon SD 250 V~, 4 700 ㎊, Y1 CE Transformer (S/W, T1) Mean Well TF-1013 Class B CE Y-Capacitor (C31) PT.Samcon SD 250 V~, 1 000 ㎊, Y1 CE Photocouper (U2, U3) SHARP PC123 Viso : 5 000 Vrms CE SMPS Part (NES-75-12) PCB SHUNDE JUNDA ELECTRONIC CO LTD JD-D V-0 CE Current Fuse (FS1) Suzhou Walter Electronic Co., Ltd FSD 3.15A 250 V~, 4 A CE X-Capacitor (C1) Weixu Electronics (Shenzhen) Co., Ltd. GS-L 275 V~, 0.47 ㎌, X2 CE Line Filter(LF1) Mean Well LF-132-R1 15 mH, Class B CE X- Capacitor (C2) Weixu Electronics (Shenzhen) Co., Ltd. GS-L 275 V~, 0.1 ㎌, X2 CE Y- Capacitor (C3, C4) PT.Samcon SD 250 V~, 4 700 ㎊, Y1 CE TRF No.: EN 60335-2-82 Y-Capacitor (C23) PT.Samcon SD 250 V~, 1s00 ㎊, Y1 CE Y- Capacitor (C30) PT.Samcon SD 250 V~, 220 ㎊, Y1 CE Transformer (S/W, T1) Mean Well TF-1302 Class B CE Y- Capacitor (C31) PT.Samcon SD 250 V~, 1 000 ㎊, Y1 CE Photocupler (U2, U3) SHARP PC123 Viso : 5 000 Vrms CE SMPS (Mainboard) Sea Sonic Electronics Co., Ltd SS-350ES 100-240 V~, 50/60 ㎐, 350 W CE Speaker (Built-in Amp) Guangzhou Yingxin Electronic Limited Pan Yu Manufacture Base S2-600B 220-240 V~, 50/60 ㎐, 22 W CE Enclosure (Front) LG Chemical - PP, HB - Enclosure - - Wood - NO DESCRIPTION SPECIFICATION PACKAGE U/PRICE LOCATION Q'TY REMARK VENDOR 1 IC MPU ATmega8-16AU TQFP U1 1 ATMEL 2 IC TTL 74HC00PW TSSOP U2 1 3 IC TTL 74HC123PW TSSOP U3 1 4 IC TTL MAX232 SOP U4 1 5 CRYSTAL 13.560MHz ATS-49/U X1 1 6 DIODE-SW EDS7000 SOT23 D1 1 7 FET 2N7002 SOT23 F1 1 NXP 8 TR-NPN BC817-25 SOT23 Q2~7 6 9 LED RED 1608 D2 1 10 INDUCTOR LCN0805T-R47J-N 2012 L3 1 YAGEO 11 INDUCTOR NLV25T-100J-PFL SMD L1 1 12 INDUCTOR NLV25T-101J-PFL SMD L5,6 2 13 BUZZER KPX-G1205A DIP PZ1 1 (OSC / O) 14 HEADER D-SUB9 ANGLE P1 1 15 CONNECTOR SMW250-02 DIP CN1 1 16 CONNECTOR SMW250-03 DIP CN3 1 17 CAP-C/C 20pF 1608 C1,2 2 18 CAP-C/C 47pF 1608 C13 1 19 CAP-C/C 68pF 1608 C6,9,10,11,12 5 23 CAP-C/C 270pF 1608 C25,41 2 24 CAP-C/C 470pF 1608 C7,21 2 25 CAP-C/C 680pF 1608 C14,15 2 27 CAP-C/C 1800pF 1608 C32 1 28 CAP-C/C 4700pF 1608 C33 1 29 CAP-C/C 6.8nF 1608 C19 1 30 CAP-C/C 10nF 1608 C18,20,22,27,30 5 31 CAP-C/C 100nF 1608 C16,31,40,CP1,2,3,4 7 32 CAP-C/C 1uF 1608 C17,23,24,28,35,36,37,38 8 33 CAP-C/C 4.7uF/16V Type A C3 1 34 CAP-T/T 10uF/16V Type B C39 1 35 CAP-T/T 100uF/10V Type C C42 1 36 CAP 470uF/16V 전해 1 37 RESISITOR 47 1608 R5,17,20,22,25,28,32 7 38 RESISITOR 100 1608 R2 1 39 RESISITOR 180 1608 R18 1 40 RESISITOR 390 1608 R4,23 2 41 RESISITOR 470 1608 R34,39 2 42 RESISITOR 680 1608 R21 1 43 RESISITOR 1K 1608 R9,11,14 3 44 RESISITOR 1.5K 1608 R40,41 2 45 RESISITOR 2K 1608 R24 1 46 RESISITOR 2.2K 1608 R8,16,27,35 4 47 RESISITOR 2.7K 1608 R29 1 48 RESISITOR 4.7K 1608 R3,7,13,33 4 49 RESISITOR 6.8K 1608 R15,26 2 50 RESISITOR 10K 1608 R19,37,38 3 51 RESISITOR 22K 1608 R30 1 52 RESISITOR 100K 1608 R10,36 2 53 RESISITOR 1M 1608 R1 1 54 PCB ReadIC2

Test Report

Report Number : KSQ-FCC131116 FCC ID : 2ABCF-VSPHOENIXS Page 1 /23 1. Applicant Name: HONG International Corp. Address: 3F, JnK Digital Tower 222-3, Guro-3Dong, Guro-Gu, Seoul, Republic of Korea FCC ID: 2ABCF-VSPHOENIXS 2. Products Name: Electronic Dart System Model/Type: VSPHOENIXS / Electronic Dart System Manufacturer: SHENZHEN HAX TECHNOLOGY CO., LTD. 3. Test Standard: 47 CFR FCC Part 15 Subpart C:2011 section 15.225 4. Test Method: ANSI C63.10:2009 5. Test Result: Positive 6.Dates of Test: November 14, 2013 to November 18, 2013 7. Date of Issue: November 19, 2013 8. Test Laboratory: Korea Standard Quality Laboratories FCC Designation Number : 100384 Tested by Approved by Soon Ho, Kim Sang Min, Lee Test Engineer: Compliance Engineer: This report may not be reproduced without the full written consent of Korea Standard Quality Laboratories. www.ksqlab.com Korea Standard Quality Laboratories Testing Laboratories for EMC and Safety Compliance #102, Jangduk-Dong, Hwasung-City, Kyunggi-Do, KOREA TEST REPORT Part 15 Subpart C 15.225 Report Number : KSQ-FCC131116 FCC ID : 2ABCF-VSPHOENIXS Page 2 /23 CONTENTS Page 1. VERIFICATION OF COMPLIANCE..............................................................................................................................................................5 2. GENERAL INFORMATION..............................................................................................................................................................6 . 2.1 PRODUCT DESCRIPTION..................................................................................................................................................................................6 2.2 MODEL DIFFERENCES: .....................................................................................................................................................................................6 2.3 RELATED SUBMITTAL(S) /GRANT(S)...........................................................................................................................................................6 2.4 PURPOSE OF THE TEST .................................................................................................................................................................................6 2.5 TEST METHODOLOGY.......................................................................................................................................................................................6 3. SYSTEM TEST CONFIGURATION...............................................................................................................................................7 3.1 JUSTIFICATION ....................................................................................................................................................................................................7 3.2 PERIPHERAL EQUIPMENT................................................................................................................................................................................7 3.3 MODE OF OPERATION DURING THE TEST...........................................................................................................................................7 3.4 CABLE DESCRIPTION FOR THE EUT ........................................................................................................................................................7 3.5 EQUIPMENT MODIFICATIONS .....................................................................................................................................................................7 3.6 CONFIGURATION OF TEST SYSTEM ........................................................................................................................................................8 3.7 ANTENNA REQUIREMENT .............................................................................................................................................................................8 4. PRELIMINARY TEST..........................................................................................................................................................................8 4.1 ACPOWER LINE CONDUCTED EMISSIONS TESTS..............................................................................................................................8 4.2 RADIATED EMISSIONS TESTS .....................................................................................................................................................................8 5. FINAL RESULT OF MEASURMENT............................................................................................................................................9 5.1 CONDUCTED EMISSION TEST.......................................................................................................................................................................9 5.2 Emission Test ....................................................................................................................................................................................................12 5.2.1 Radiated Emissions ............................................................................................................................................................................12 5.2.1.1 Regulation.............................................................................................................................................................................................12 5.2.1.2 Measurement Procedure .............................................................................................................................................................12 5.2.1.3 Test Configuration............................................................................................................................................................................13 5.2.1.4 Test …
