2ABD3-MS280I0000Internet Radio

User Manual MS-280i Please read this user manual carefully before using the receiver. LOCATION OF CONTROLS 1. LCD Display 2. Speaker 3. POWER Press to stand by ON/OFF 4. VOLUME/HOME Dial to increase the volume level or decrease the volume level. Press to back the main menu. 5. PRESET Press to store and hold to recall the favorite stations. 6. Remote lens 7. Earphone jack 8. ← Press to go to the previous station or go back to the up menu. 9. DIAL/SELECT Dial to find the different menus and press to confirm the choice. 10. → Press to go the next station or enter the submenu. 11. Telescope antenna 12. Phone charger (5V) 13. LAN adaptor/USB playback 14. Line out Jack 15. Aux-In jack 16.DC Socket Remoter controller: NOTE: FCC Statements NOTE: Changes or Modifications not expressly approved by the party responsible could void the user‟s authority to operate this device. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. SETTING UP Those steps for connecting your radio to your network Step 1 Switching on the radio Plug the cable from the AC adapter into the socket labeled DC on the back of the radio, then power on the radio. Caution: Use only the mains adapter supplied with the radio. Connecting a power supply with a different rating will cause permanent damage to the radio and may be hazardous. The display on the front of the radio will light up and say: Then show After a few seconds, it will show: If it complete the initialing, it will auto scan the ESSID as Then it will list all the ESSID names it can find, you can select one of you want to use, maybe it will request you input the correct WEP(Wired Equivalent Privacy) or WPA(Wi-Fi Protected Access) code. If your network is not configured to need a WEP or a WPA code, the unit will connect to the ESSID auto and success as Or if you are requested to input the encryption, you can do as below 1. Select the one you want to use <linksys> <aershan> ....... Network OK <linksys> CC WiFi 2 Connecting to Network >>>>>>>>>> Scanning for Wireless ....... 2. Then it will show you Note: The encryption code would have been set up by the person who set up and configured your network. After 3 seconds the display goes into the code entry mode or press “enter”. Please refer to the 1.2.5 to know clear of the “Remote control character list” for you to enter the passwords. Press “→” button to go to the next word, press “←” button to delete the wrong word you have entered. 3. If you complete the key then you can use “Enter” to confirm. The display shows “Connect WiFI” as the radio connects to the network. 4. If the connecting is OK, it will show you Function 1.1 TuneIn Radio You can listen to the interne radio under this section. There are several methods to browse the stations. - Browse Presets - Browse WEB Presets - Browse Stations - Search station Enter Password ■ 1/1 ←Move→ INPUT:0-9↑↓ OK↙ Connecting to network TuneIn Radio Media Center FM - History Normally, you can choose “Browse Stations” to view the broadcast radio from different countries under the submenu “By Location”. When the radio name shows on the display, you can press “→” button to active below operation. Add to preset i. Press “DIAL/SELECT” to store the current station into my favorite. User can store 20 stations. ii. User can recall the station by press number 0-9. Or press “★” from the remote controller to see the favorites list, then choose the stored station which you want to listen and press “DIAL/SELECT” to confirm. Auto scan Auto scanning the every station from the currently list for your review in 30 seconds again and again until you confirm the one you need. Remark：Press „Select‟ button or the “OK” button on the remote to stop station scanning and remain on the currently one. Play Play the current radio station. 1.2 Media Center USB Play the music from the USB driver. UPNP Visit the shared folder from your PC. My playlist User can view the playlist under this menu. Clear my playlist User can clear the playlist under this section. 1.3 FM Station selecting 1．You can press“0，1－9” of the remote and enter the station selecting menu，and go with the shortcut into the station which you like to listen.（1-20）. 2．You can press “Preset” button and enter the station selecting menu， Dial the “VOLUME/SELECT” or “↑”&“↓”to select FM station（1-20），and press „Select‟ button to recall FM station. 3．You can press “Left” & “Right” buttons to turn to the Previous/ Next FM presetting station. 4．20 maximum storage of FM station. Remark :Press “Left” and “Right” buttons to do the FM stations switching and it will turn to the 1st station if the currently one is not the presetting station.. Store FM station 1．It can auto store the available FM stations by hold "DIAL/SELECT" or "OK" on remote controller for auto scanning. (Details refer to2.5.3) 2．You can keep pressing „Preset‟ and enter the storage menu，and press the number buttons or“↑”、“↓” to select the presetting FM station number（1-20），and press “Selec…

Text truncated - open the document above for the full version.

OCEAN DIGITAL TECHNOLOGY LIMITED Flat B, 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road, Kowloon Bay, Hong Kong. Tel: +852 24201464 Fax: +852 37532352 Email: [email protected] Date : Nov 23 rd , 2013 FCC ID: 2ABD3-MS280I0000 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Specifically, “Ocean Digital Technology Ltd.” requests that the following materials be withheld from public inspection under 47CFR 0.459 because they are confidential trade secrets and technical data which would be guarded from competitors. (1) detailed circuit schematic of unit under test (2) parts list (3) block diagram (4) Circuit Description Therefore, in accordance with 47CFR Sections 0.457 and 0.459 we request that the above listed materials, copies of which are attached here, be withheld from public inspection. Sincerely, _____________ Karen Ho Business Manager

OCEAN DIGITAL TECHNOLOGY LIMITED Flat B, 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road, Kowloon Bay, Hong Kong. Tel: +852 24201464 Fax: +852 37532352 Email: [email protected] Date : Nov 6th, 2013 PHOENIX TESTLAB GmbH Königswinkel 10 D-32825 Blomberg Dear Sirs, Re. : Letter of Appointment This is the letter of authorization to accept our appointment of The Hong Kong Standards and Testing Centre Ltd. Mr. KC Lee as agent for Ocean Digital Technology Ltd., Flat B., 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road, Kowloon Bay, Hong Kong to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with Certification of the following product of Ocean Digital Technology Ltd. Product name : Internet Radio Model : MS-280i This authorization will expire one year from the date of this letter. _________________________ Karen Ho Business Manager

PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT REAR VIEW OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT LEFT VIEW OF THE PRODUCT RIGHT VIEW OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT TOP VIEW OF THE PRODUCT BTTOM VIEW OF THE PRODUCT

PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT BOTTOM VIEW PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT

STC Test Report Date: 2013-10-31 Page 1 of 87 No.: DM113038 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from the Hong Kong Standards and Testing Centre Ltd. For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of Homepage. Applicant (KIC002): Ocean Digital Technology Ltd. Flat B., 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road, Kowloon Bay, HongKong Manufacturer: Ocean Digital Technology Ltd. Flat B., 12/F., Yeung Yiu Chung (No.8) Ind. Bldg., 20 Wang Hoi Road, Kowloon Bay, HongKong Description of Sample(s): Product: Internet Radio Brand Name: N/A Model Number: MS-280i FCC ID: 2ABD3-MS280I0000 Date Sample(s) Received: 2013-10-16 Date Tested: 2013-10-16 to 2013-10-21 Investigation Requested: Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2012 and ANSI C63.4: 2009 for FCC Certification. Conclusion(s): The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remark(s): --- LONG Yun Jian, Along Authorized Signatory ElectroMagnetic Compatibility Department For and on behalf of STC (Dongguan) Company Limited STC Test Report Date: 2013-10-31 Page 2 of 87 No.: DM113038 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage CONTENT: Cover Page 1 of 87 Content Page 2 of 87 1.0 General Details 1.1 Test Laboratory Page 3 of 87 1.2 Equipment Under Test [EUT] Page 3 of 87 Description of EUT operation 1.3 Date of Order Page 3 of 87 1.4 Submitted Sample Page 3 of 87 1.5 Test Duration Page 3 of 87 1.6 Country of Origin Page 3 of 87 1.7 RF Module Details Page 4 of 87 1.8 Antenna Details Page 4 of 87 2.0 Technical Details 2.1 Investigations Requested Page 5 of 87 2.2 Test Standards and Results Summary Page 5 of 87 2.3 Table for Test Modes Page 6 of 87 3.0 Test Results 3.1 Emission Page 7 - 78 of 87 Appendix A List of Measurement Equipment Page 79 of 87 Appendix B Ancillary Equipment Page 79 of 87 Appendix C Photographs Page 80 - 87 of 87 STC Test Report Date: 2013-10-31 Page 3 of 87 No.: DM113038 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.0 General Details 1.1 Test Laboratory STC (Dongguan) Company Limited EMC Laboratory 68 Fumin Nan Road, Dalang, Dongguan, China Telephone: (86 769) 81119888 Fax: (86 769) 81116222 1.2 Equipment Under Test [EUT] Description of Sample(s) Product: Internet Radio Manufacturer: Ocean Digital Technology Ltd. Brand Name: N/A Model Number: MS-280i Input Voltage: 12.0Vd.c. with Jack The AC/DC adaptor was provided by the applicant with following details: Brand name: N/A; Model no.: DYS182-120150W-2; Input: 100-240Va.c. 50/60Hz 0.45A MAX; Output: 12Vd.c. 1.5A. 1.2.1 Description of EUT Operation The Equipment Under Test (EUT) is a Internet Radio, it is Audio System, modulation by IC; and type is frequency hopping speed spectrum Modulation. 1.3 Date of Order 2013-10-16 1.4 Submitted Sample(s): 1 Sample 1.5 Test Duration 2013-10-16 to 2013-10-21 1.6 Country of Origin China STC Test Report Date: 2013-10-31 Page 4 of 87 No.: DM113038 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.7 RF Module Details Module Model Number: BM81SPK02 Module FCC ID: N/A Module Transmission Type: Bluetooth V3.0+EDR Modulation: FHSS (GFSK / π/4-DQPSK / 8DPSK) Data Rates: 1 MBps: GFSK 2 MBps: π/4-DQPSK 3 MBps: 8DPSK Frequency Range: 2400-2483.5MHz Carrier Frequencies: 2402MHz – 2480MHz Module Specification (specification provided by manufacturer) 1.8 Antenna Details Antenna Type: Build-in PCB Antenna Antenna Gain: 1.13dBi STC Test Report Date: 2013-10-31 Page 5 of 87 No.: DM113038 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 2.0 Technical Details 2.1 Investigations Requested Perform Electromagnetic Interference measurements in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2012 Regulations. FCC Pubic Notice DA 00-705 and ANSI C63.4: 2009 for FCC Certification. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Fail N/A Maximum Peak Conducted Output Power FCC 47CFR 15.247(b)(1) FCC Pubic Notice DA 00-705 N/A Radiated Spurious Emis…

Text truncated - open the document above for the full version.

PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF RADIATED EMISSION TEST SET UP PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF CONDUCTED EMISSION TEST SET UP
