2ABEPIM100310.6 inch MID

1 NuVision 10.6 inch MID TM106A510L Shenzhen Tianzheng Hongye Technology Co.Ltd. 3 Introduction Thank you for purchasing the NuVision TM106A510L 10.6” Android tablet with Google Thank you for purchasing the NuVision TM106A510L 10.6” Android tablet with Google Play. With a fast and responsive Intel Atom processor, this new quad core tablet is the perfect companion for streaming videos & TV shows, reading e-Books, taking breathtaking photos, checking emails, and engaging with social media. It offers 16GB of internal storage, Bluetooth connectivity, dual cameras (2MP front/ 5M rear), and a TF card slot to add more storage. We have included access to popular fun and educational apps for kids, Microsoft Office apps (read-only versions), on-the-go productivity services, and a utility app. The following information will help you get the most out of your tablet. We strongly recommend reading it thoroughly before first use. For more information, check out the on-line user manual available at www.nuvision.com What You Should Know to Ensure Best Performance: • Charge the battery completely before first use. • While updates download in the background, tablet performance can be affected until completed. • Close unused applications. Open apps that run in the background will affect overall performance. • Battery Consumption: Play times on a fully charged battery will vary depending on your display settings, apps that remain open, and internet use (ie: streaming video content). NuVision Customer Service Phone: (800) 890-1288 Hours: 8:30am to 5:30pm PST M-F Email: [email protected] Customer Service For more information, visit www.nuvision.com 45 Software System Updates Google Play Updates To ensure the tablet runs smoothly it is recommended to perform periodic system software updates, especially during initial set up of the tablet. You may receive notifications (on the Lock screen) from time to time that software updates are available. Tap the notification to be directed to the update. Other options to access updates: 1. Tap OTA Update located in the App tray. 2. From the Home screen tap on Settings > About Tablet > System Update. NOTE: To perform an update, you must be connected to WiFi. The first time you sign on to Google’s Play Store, updates will automatically start downloading on to the tablet. The download icon will appear in the Navigation Bar at the top left of screen. Installing a new application while multiple apps are downloading will reduce tablet speed and performance. After all downloads and updates have been installed, the tablet will resume normal operating performance. To view the progress of downloads working in the background, slide your finger down from the top left edge of the screen. 76 TM106A510L Tablet At-a-Glance 1. Camera (Front/Back) 2. Volume Control 3. Power Button 4. Headphones 5. DC 6. Micro USB 7. HDMI 8. Micro USB 9. TF Card 10. Speakers TMAX DIGITAL,INC. MODEL:TM106A510L FCC ID: 2ABEPTM106A510L INPUT: 5V/2.5A MADE IN CHINA 9 1010 Tablet Transfer Cable AC Power Adapter (May differ in appearance.) 9 Starting Your Tablet 8 Home Screen At-a-Glance 1. Press and hold the Power button for 3 seconds. (If your tablet does not turn on, or instructs you to “Connect your charger”, connect the AC adapter and charge the unit.) 2. At the Start-up screen, slide your finger up to unlock. 3. Once you’ve arrived at the Home screen, you can begin using your tablet. 1. Connection/Activity 2. Google Search Box 3. Google Audio Search 4. Status Bar 5. Previous Page 6. App 7. Home 8. Open Apps 9. Options 10. Take Screenshot 11. Volume 12. App Tray It is recommended to fully charge the tablet before first use. To charge the tablet, plug the 1) USB cable into the AC adapter, and 2) attach the other end to the DC input on the tablet. 3) Plug the AC adapter into a wall outlet. 1 2 3 TMAX DIGITAL,INC. MODEL:TM106A510L FCC ID: 2ABEPTM106A510L INPUT: 5V/2.5A MADE IN CHINA When the tablet is ON and charging, the battery icon will pulsate. It is fully charged when an icon of a full battery is displayed on the screen. A complete battery charge may take up to 5 hours. It is normal for the tablet to get warm while charging, playing high intensity games, or streaming video. Battery life will vary depending on usage. 10 Charging Your Tablet 11 Touching and Typing Type goes in field Need Information Type goes in field Need Information Type goes in field Need Information Type goes in field Need Information Type goes in field Need Information Type goes in field Need Information To select an item on the screen, simply tap it once with your fingertip. Some items may require you to “double-tap”. To type into an text field (i.e., when inputting your name, or a web address), tap the text field. The on-screen keyboard will appear, and allow you to type the information you wish to enter. Touch and Hold: Keep your finger on an on-screen item until it glows or activates an alternate menu. Drag: Move an App or object by touching and holding the image, then sliding it to the destination. Slide: When there are extra “screens” to the side, slide one or more fingers from one side to another. 1312 Connecting to the Internet In order to connect to the internet, you will need the following: • A wireless router or an access point with a broadband internet connection. • The name of your network (SSID), as well as the password or other credentials, if your network is secure. The wireless router must support WiFi 802.11b/g/n connections. Go to SETTINGS > WIRELESS & NETWORKS > WiFi Turn on the WiFi setting from OFF to ON by sliding the switch to the right. The Tablet will scan for available WiFi networks within range. Secured networks will require a password. Once you have successfully entered your information the tablet will remember your settings. Distance may vary or WiFi Available Here + Network Name/SSID Password Wireless Router Wireless Router Connecting Bluetooth Your Tablet is compatible with Bluetooth capable devices. Once yo…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Shenzhen Tianzheng Hongye Technology Co.Ltd. 2015/10/18 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ___ Shenzhen Tianzheng Hongye Technology Co.Ltd. _ hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： 10.6 inch MID Trade Name： NuVision Model Name： TM106A510L Serial Model： TM1003Q,TM106A520L,TM106A530L FCC ID： 2ABEPIM1003 Sincerely, Client’s name / title : Quanxing Huang / Manager Contact information / address : Building C, Guancheng Science and Technology Park, Zhenxing Road,Carp River Industrial Zone,Gongming, Shenzhen City, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Shenzhen Tianzheng Hongye Technology Co.Ltd. 2015/10/16 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ABEPIM1003 We hereby request confidential treatment of information accompanying this application as outlined below: - . Block Diagram - Schematics - Operational Description - The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s name / title : Quanxing Huang / Manager Contact information / address : Building C, Guancheng Science and Technology Park, Zhenxing Road,Carp River Industrial Zone,Gongming, Shenzhen City, China

Shenzhen Tianzheng Hongye Technology Co.Ltd. WIFI Channel 12 & 13 Declaration Letter To whom it may concern : We have declared below featured for FCC equipment authorization in regard to 802.11b/g/n channel 12 & 13 operating capability for FCC ID : 2ABEPIM1003 Please check Product hardware does not have the capability to operate on channel 12 & 13 Product hardware has the capability to operate on channel 12 & 13. However , these 2 channels will be disabled via software and user will not able to enable these 2 channels Product hardware has the capability to operate on channel 12 & 13. And meeting KDB 594280 D01 requirement. Pls explain detail here. Others Pls explain detail here. Client’s name / title : Quanxing Huang / Manager Contact information / address : Building C, Guancheng Science and Technology Park, Zhenxing Road,Carp River Industrial Zone,Gongming, Shenzhen City, China

Shenzhen Tianzheng Hongye Technology Co.Ltd. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2015-10-18 SUBJECT: FCC Application for ( FCC ID: 2ABEPIM1003) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Client’s name / title : Quanxing Huang / Manager Contact information / address : Building C, Guancheng Science and Technology Park, Zhenxing Road,Carp River Industrial Zone,Gongming, Shenzhen City, China

Shenzhen Tianzheng Hongye Technology Co.Ltd. Model Difference FCC ID: 2ABEPIM1003 Model : TM106A510L,TM1003Q,TM106A520L,TM106A530L All the model are the same circuit and RF module,except the model name and colour. Regards, Client’s signature Client’s name / title : Quanxing Huang / Manager Contact information / address : Building C, Guancheng Science and Technology Park, Zhenxing Road,Carp River Industrial Zone,Gongming, Shenzhen City, China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label 10.6 inch MID Model NO.: TM106A510L FCC ID:2ABEPIM1003 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 WIFI/BT Ant Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10 Photo 11

FCC ID: 2ABEPIM1003 RF EXPOSURE EVALUATION METHOD FCC ID:2ABEPIM1003 SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Maximum measured transmitter power. WIFI: TX 802.11b Mode Te s t Channe Frequency Maximum Conducted Output Power(PK) Maximum Conducted Output Power(AV) LIMIT (MHz) (dBm) (dBm) (dBm) CH01 2412 12.87 9.47 30 CH06 2437 12.89 9.58 30 CH11 2462 12.65 9.43 30 TX 802.11g Mode CH01 2412 11.58 8.45 30 CH06 2437 11.75 8.62 30 CH11 2462 11.69 8.56 30 TX 802.11n-HT20 Mode CH01 2412 10.58 8.35 30 CH06 2437 10.66 8.43 30 CH11 2462 10.25 8.02 30 TX 802.11n-HT40 Mode CH03 2422 9.77 7.35 30 CH06 2437 9.65 7.23 30 CH09 2452 9.37 6.95 30 FCC ID: 2ABEPIM1003 BT 3.0 1Mbps Test Channel Frequency (MHz) Peak Output Power (dBm) LIMIT (dBm) CH00 2402 3.68 30 CH39 2441 4.11 30 CH78 2480 3.84 30 2Mbps CH00 2402 5.08 20.96 CH39 2441 5.17 20.96 CH78 2480 4.57 20.96 3Mbps CH00 2402 5.07 20.96 CH39 2441 5.38 20.96 CH78 2480 4.68 20.96 BT 4.0 Te s t Channe Frequency Maximum Conducted Output Power(PK) Maximum Conducted Output Power(PK) (MHz) (dBm) mW CH00 2402 -2.34 0.160 CH19 2440 -2.35 0.223 CH39 2480 -2.56 0.308 Remark: The best case gain of the antenna is 1.0dBi. 1.0 dBi logarithmic terms convert to numeric result is nearly 1.26 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)] FCC ID: 2ABEPIM1003 WIFI: Te s t Channel Range tune up max power (dBm) [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [f(GHz)] Result Limit TX 802.11b Mode CH01 7.6~9.6 9.6 9.120 5 2.412 2.83 3 CH06 7.6~9.6 9.6 9.120 5 2.437 2.85 3 CH11 7.6~9.6 9.6 9.120 5 2.462 2.86 3 TX 802.11g Mode CH01 7.0~9.0 9.0 7.943 5 2.412 2.47 3 CH06 7.0~9.0 9.0 7.943 5 2.437 2.48 3 CH11 7.0~9.0 9.0 7.943 5 2.462 2.49 3 TX 802.11n-HT20 Mode CH01 7.0~9.0 9.0 7.943 5 2.412 2.47 3 CH06 7.0~9.0 9.0 7.943 5 2.437 2.48 3 CH11 7.0~9.0 9.0 7.943 5 2.462 2.49 3 TX 802.11n-HT40 Mode CH03 6.0~8.0 8.0 6.310 5 2.422 1.96 3 CH06 6.0~8.0 8.0 6.310 5 2.437 1.97 3 CH09 6.0~8.0 8.0 6.310 5 2.452 1.98 3 BT 3.0 Te s t Channel Range tune up max power (dBm) [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [f(GHz)] Result Limit 1Mbps CH00 2.5~4.5 4.5 2.818 5 2.402 0.874 3 CH39 2.5~4.5 4.5 2.818 5 2.441 0.881 3 CH78 2.5~4.5 4.5 2.818 5 2.480 0.888 3 2Mbps CH00 4~6 6 3.981 5 2.402 1.234 3 CH39 4~6 6 3.981 5 2.441 1.244 3 CH78 4~6 6 3.981 5 2.480 1.254 3 3Mbps CH00 4~6 6 3.981 5 2.402 1.234 3 CH39 4~6 6 3.981 5 2.441 1.244 3 CH78 4~6 6 3.981 5 2.480 1.254 3 FCC ID: 2ABEPIM1003 BT 4.0 Te s t Channel Range tune up max power (dBm) [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [f(GHz)] Result Limit CH00 -4~-2 -2 0.631 5 2.402 0.196 3 CH39 -4~-2 -2 0.631 5 2.441 0.197 3 CH78 -4~-2 -2 0.631 5 2.480 0.199 3 The test Result is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Conclusion: No SAR is required.
