2ABEU-YLCT03YLYLCT03YL

Doris Pro(美国版) 比例：按标注尺寸为准 单位：mm 说明书 P0 2021-04-30 设计师 赵寅钧 产品经理 质量工程师 色相正确、印迹牢固、 套印准确、各色套印 不露杂色，套印误差≤ 0.1mm 印刷+联机过油+裁切+骑马钉 金东太空梭105g无光铜 模切走位≤±0.5mm PT Cool Gray 11C Night mode 02 More features Set your own night mode in the app. The lamp will turn on automatically with cozy nightlight during the preset night mode period. If not in the preset period, the lamp will return to the default state saved in the APP. * The Night Mode is off by default. Please activate it in Yeelight APP. 1. The wireless charging indicator will flash 3 times when the lamp is connected to the power supply with its original adaptor. 2. Put the mobile phone in the wireless charging area. The mobile phone is charging when yellow indicator light is on. If not, please adjust the phone to proper position. 3. When the phone is fully charged, the yellow indicator light is off and the wireless charging terminates. Instructions 01 ON/OFF buon Wireless charging indicator Product Description Lamp cap Lamp arm Base ON/OFF Wireless charging area Wireless charging indicator Wireless charging area Wireless charging Installation Plug the adaptor connector into the DC ternimal, then connect the power. Yeelight Staria Bedside Lamp Pro User Manual 1. Open the Home APP in your iPhone or iPad. 2. Tap "Add Accessories" and follow the instructions in the app to scan the QR code in the user manual or on the product base, or enter the 8-digit setup code above the QR code to grant the Apple Home app access. * Make sure the Wi-Fi network is available and you can get access to the internet normally. This product is not compatible with 5G network. * To ensure proper Homekit compatibility, it is recommended to use iOS 9 or above; * HomeKit codes are indicated under the base of lamp. Please be noted that HomeKit codes are required for reset every time. Apple is the trade mark of Apple LLC. * Please reset the lamp before using it in a new network environment . How to Reset Tap and hold the ON/OFF buon, and re-insert the adaptor connector into the DC termnial till the light is breathing, and then release the ON/OFF buon. 03 Apple HomeKit Smart Control Wireless charging indicator status Power on: the indicator flashes 3 times Charging: indicator on Charging completed or not charging: indicator off Error warning: the indicator flashes quickly Foreign object: the indicator flashes quickly This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. To satisfy FCC RF exposure requirements, a separation distance of 20 cm or more should be maintained between the antenna of this device and persons during device operation. To ensure compliance, operations at closer than this distance is not recommended. Limited by local law regulations, version for North America does not have region selection option. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Model No.: YLCT03YL Operating temperature: -10 ~ 35°C Operating humidity: 0%-85%RH Color temperature : 2700 K-6000 K Wireless charging output:10W MAX Wireless charging distance: ≤3.5mm Compatible with: Android 4.4 & iOS9.0 and above Compatible with: Android 4.4 & iOS9.0 and above Product Features Basic Parameters Name : Yeelight Staria Bedside Lamp Pro Rated input: 100 -240V~50/60Hz 0.45A Rated Power: 18W(Wireless Charging Module+LED modules) CRI: Ra95 Input: 12V 1.5A Power factor: 0.5 Wireless connection: Wi-Fi IEEE 802.11 b/g/n 2.4GhZ FCC ID: 2ABEU-YLCT03YL Contains FCC ID: 2AC7Z-ESPWROOM32D Adjustable color temperature Adjustable brightness Foreign object detection Personalized schedule 10W fast charging Voice control Cozy nightlight Smart timer Warnings EU Declaration of Conformity Check the voltage before using the product. Improper voltage may damage the product and cause potential safety hazards. The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent or a similar qualified person. The light will produce heat during operation. Please keep proper ventilation. Using adapters other than the original one may cause product damage or safety hazards. Do not tilt the lamp but place it smoothly. potential safety hazard. * All the pictures shown in this manual are for reference only. Hereby, Qingdao Yeelink Information Technology Co., Ltd., declares that the radio equipment type YLCT03YL is in compliance with Directive 2014/53/EU. WEEE Disposal and Recycling Information All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which should not be mixed with unsorted household waste. Instead, you should protect human health and the environment by ha…

Text truncated - open the document above for the full version.

Page 1 of 4 External Picture Page 2 of 4 Page 3 of 4 Page 4 of 4

SAA203353 Made in China Model：YLCT03YL ta：35°C Lamp Input：12V 1.5A Rated Power：5W(Lamp)+13W(Wireless Charging module) FCC ID：2ABEU-YLCT03YL Contains FCC ID：2AC7Z-ESPWROOM32D DRY LOCATIONS ONLY POUR EMPLACEMENTS SECS SEULEMENT Qingdao Yeelink Information Technology Co., Ltd. Yeelight Staria Bedside Lamp Pro SAA203353 SN:XXXX/XXXXXXXXProduction Date:11/2019SN:XXXX/XXXXXXXXProduction Date:11/2019 图标高度不小于5mm 工艺说明 1、镭雕 2、 颜色 Patone428C 3、位置大小如图示 4、附着力符合我司工艺要求 5、镭雕/丝印内容清晰，无断线，毛边，杂质、 凸起等缺陷。 6、条码二维码要求参考相关包材图纸 V1.0 Doris Pro 2021.04.30 Doris pro 底座(北美版)丝印图纸 产品参数镭雕图纸 物料号 青岛易来智能科技股份有限公司 文件编号：QWI-02-001-F09 版本：A 黄敬轩 字体：方正悠黑508R SN号，根据实际生成 二维码尺寸根据产品生产时的SN号码生成 50mm 6mm 52.3 mm 74mm73.3mm Label location

Page 1 of 7 Internal Picture Page 2 of 7 Page 3 of 7 Page 4 of 7 Page 5 of 7 Page 6 of 7 Page 7 of 7

Qingdao Yeelink Information Technology Co., Ltd. MPE ASSESSMENT REPORT Report Type: FCC MPE assessment report Model: YLCT03YL REPORT NUMBER: 210300972SHA-002 ISSUE DATE: April 6, 2021 DOCUMENT CONTROL NUMBER: TTRFFCCMPE-02_V1 © 2018 Intertek Intertek Testing Services Shanghai Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRFFCCMPE-02_V1© 2018 Intertek Page 2 of 10 Report no.: 210300972SHA-002 Applicant: Qingdao Yeelink Information Technology Co., Ltd. 10F-B4, Building B, Qingdao International Innovation Park, No.1 Keyuan Weiyi Road, Laoshan District, Qingdao City, Shandong Province, P.R.China Manufacturer: Qingdao Yeelink Information Technology Co., Ltd. 10F-B4, Building B, Qingdao International Innovation Park, No.1 Keyuan Weiyi Road, Laoshan District, Qingdao City, Shandong Province, P.R.China Manufacturing site: Guangdong Changhong Component Technology Co.,Ltd. No.2-1, Tongji West Road, Nantou Town, Zhongshan City, Guangdong Province, China. Product Name: Yeelight Staria Bedside Lamp Pro Type/Model: YLCT03YL FCC ID: 2ABEU-YLCT03YL SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: FCC PART 1 SECTION 1.1310 PREPARED BY: REVIEWED BY: Project Engineer Wade Zhang Reviewer Daniel Zhao Report No.: 210300972SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 3 of 10 Revision History Report No. Version Description Issued Date 210300972SHA-002 Rev. 01 Initial issue of report April 6, 2021 Report No.: 210300972SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 4 of 10 Measurement result summary TEST ITEM FCC REFERANCE TEST RESULT NOTE RF Exposure 1.1310 Pass - Notes: 1: NA =Not Applicable 2. Determination of the test conclusion is based on IEC Guide 115 in consideration of measurement uncertainty. Report No.: 210300972SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 5 of 10 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test (EUT) Product name: Yeelight Staria Bedside Lamp Pro Type/Model: YLCT03YL Description of EUT: The EUT is a wireless lighting equipment which have wireless charger function, the WIFI module was certified (FCC ID: 2AC7Z- ESPWROOM32D). Rating: DC 12V 1.5A by adaptor Category of EUT: Class B EUT type: Table top Floor standing Software Version: / Hardware Version: / Sample received date: Feb 20, 2021 Date of test: Feb 20, 2021 ~ Mar 26, 2021 1.2 Technical Specification Frequency Range: 110kHz – 205kHz Report No.: 210300972SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 6 of 10 1.3 Description of Test Facility Name: Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Telephone: 86 21 61278200 Telefax: 86 21 54262353 The test facility is recognized, certified, or accredited by these organizations: CNAS Accreditation Lab Registration No. CNAS L0139 FCC Accredited Lab Designation Number: CN1175 IC Registration Lab CAB identifier.: CN0051 VCCI Registration Lab Registration No.: R-14243, G-10845, C-14723, T-12252 A2LA Accreditation Lab Certificate Number: 3309.02 Report No.: 210300972SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 7 of 10 2 TEST SPECIFICATIONS 2.1 Standards or specification FCC PART 1 SECTION 1.1310 KDB 680106 D01 RF Exposure Wireless Charging App v03r01 2.2 Mode of operation during the test Within this test report, EUT was tested with empty load, half load and full load, the full load is the worst case and we listed the results in the report. 2.3 Test peripherals list Item No. Name Band and Model Description 1 wireless load Provided by client 100% power level 2 wireless load Provided by client 50% power level 3 wireless load Provided by client 0% power level 2.4 Record of climatic conditions Test Item Temperature (°C) Relative Humidity (%) Pressure (kPa) RF Exposure 23 57 102 2.5 Instrument list Used Equipment Manufacturer Type Internal no. Due date Exposure Level Tester Narda ELT-400 EC 2928 2021-08-15 Field sensor & Field meter AR FL17000 EC 5818-1 2021-05-21 Report No.: 210300972SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 8 of 10 3 RF Exposure Assessment Test result: Pass 3.1 Assessment Limit 3.2 Assessment Configuration Report No.: 210300972SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 9 of 10 3.3 Assessment Results Test result of Magnetic Field Strength: Test Position Test distance (cm) Test result (A/m) Limit (A/m) Result (Pass/Fail) A: Right 15 0.066 1.63 *0.5 Pass B: Left 15 0.067 1.63 *0.5 Pass C: Front 15 0.069 1.63 *0.5 Pass D: Back 15 0.067 1.63 *0.5 Pass E: Top 15 0.068 1.63 *0.5 Pass Test result of Electric Field Strength: Test Position Test distance (cm) Test result (V/m) Limit (V/m) Result (Pass/Fail) A: Right 15 2.25 614 *0.5 Pass B: Left 15 2.25 614 *0.5 Pass C: Front 15 2.34 614 *0.5 Pass D: Back 15 2.23 614 *0.5 Pass E: Top 15 2.25 614 *0.5 Pass Report No.: 210300972SHA-002 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 10 of 10 Considerations of compliance 68010…

Text truncated - open the document above for the full version.

Qingdao Yeelink Information Technology Co., Ltd. RF TEST REPORT Report Type: FCC Part 15C RF report Model: YLCT03YL REPORT NUMBER: 210300972SHA-001 ISSUE DATE: March 29, 2021 DOCUMENT CONTROL NUMBER: TTRFFCCPART15C_V1 © 2018 Intertek Intertek Testing Services Shanghai Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRFFCCPART15C_V1 © 2018 Intertek Page 2 of 21 Report no.: 210300972SHA-001 Applicant: Qingdao Yeelink Information Technology Co., Ltd. 10F-B4, Building B, Qingdao International Innovation Park, No.1 Keyuan Weiyi Road, Laoshan District, Qingdao City, Shandong Province, P.R.China Manufacturer: Qingdao Yeelink Information Technology Co., Ltd. 10F-B4, Building B, Qingdao International Innovation Park, No.1 Keyuan Weiyi Road, Laoshan District, Qingdao City, Shandong Province, P.R.China Manufacturing site: Guangdong Changhong Component Technology Co.,Ltd. No.2-1, Tongji West Road, Nantou Town, Zhongshan City, Guangdong Province, China. Product Name: Yeelight Staria Bedside Lamp Pro Type/Model: YLCT03YL FCC ID: 2ABEU-YLCT03YL SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: 47CFR Part 15 (2019): Radio Frequency Devices (Subpart C) ANSI C63.10 (2013): American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices PREPARED BY: REVIEWED BY: Project Engineer Wade Zhang Reviewer Daniel Zhao Report No.: 210300972SHA-001 TEST REPORT TTRFFCCPART15C_V1 © 2018 Intertek Page 3 of 21 Content REVISION HISTORY................................................................................................................................................ 4 MEASUREMENT RESULT SUMMARY ..................................................................................................................... 5 1 GENERAL INFORMATION ............................................................................................................................. 6 1.1 DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ..................................................................................................... 6 1.2 TECHNICAL SPECIFICATION .................................................................................................................................... 6 1.3 DESCRIPTION OF TEST FACILITY .............................................................................................................................. 7 2 TEST SPECIFICATIONS ................................................................................................................................... 8 2.1 STANDARDS OR SPECIFICATION ............................................................................................................................... 8 2.2 MODE OF OPERATION DURING THE TEST ................................................................................................................... 8 2.3 TEST SOFTWARE LIST ............................................................................................................................................ 8 2.4 TEST PERIPHERALS LIST ......................................................................................................................................... 8 2.5 TEST ENVIRONMENT CONDITION: ............................................................................................................................ 8 2.6 INSTRUMENT LIST ................................................................................................................................................ 9 2.7 MEASUREMENT UNCERTAINTY ............................................................................................................................. 10 3 RADIATED EMISSIONS ............................................................................................................................... 11 3.1 LIMIT .............................................................................................................................................................. 11 3.2 MEASUREMENT PROCEDURE ............................................................................................................................... 11 3.3 TEST CONFIGURATION ........................................................................................................................................ 12 3.4 TEST RESULTS OF RADIATED EMISSIONS ................................................................................................................. 14 4 CONDUCTED EMISSIONS ........................................................................................................................... 18 4.1 LIMIT .............................................................................................................................................................. 18 4.2 TEST CONFIGURATION ..........................................................................................................................…

Text truncated - open the document above for the full version.

Page 1 of 4 Test Setup Page 2 of 4 1. Radiated Emission Below 30MHz 30MHz to 1GHz Page 3 of 4 Above 1GHz 2. Conducted Emission Page 4 of 4 3. RF Exposure
