2ABFG-YRIZW2USPB2Digital Door Lock

'LJLWDO'RRU/RFN

iRevo-ASSA ABLOY Korea 10f of JEI PLATZ Bldg., 186, Gasandigital 1‐ro, Geumcheon‐gu, Seoul, 08502, Korea August 09, 2022 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: I, the undersigned, hereby authorize SGS Korea Co., Ltd. and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by SGS Korea Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; iRevo-ASSA ABLOY Korea 10f of JEI PLATZ Bldg., 186, Gasandigital 1‐ro, Geumcheon‐gu, Seoul, 08502, Korea i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely yours, Name / Title : Jang, Soo‐kyung / Manager Company Name : iRevo‐ASSA ABLOY Korea

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal B usiness Name iRevo-ASSA ABLOY Korea Address 10f of JEI PLATZ Bldg., 186, Gasandigital 1-ro, Geumcheon-gu, Seoul, 08502, Korea Grantee Code 2ABFG FCC ID 2ABFG-YRIZW2USPB2 Authorized Contact Name Jang, Soo-kyung Contact Email [email protected] Contact Phone 82-2-2107-5741 I, the undersigned, certify that I a m an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accep ts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal ben efits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant S ignature: Date: August 09, 2022 Print Name: Jang, Soo-kyung Title: Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

iRevo-ASSA ABLOY Korea 10f of JEI PLATZ Bldg., 186, Gasandigital 1-ro, Geumcheon-gu, Seoul, 08502, Korea Letter of Declaration Product Equality August 08, 2022 We, as a manufacturer, hereby declare that our product has variant model names as listed below. Variant model is totally same as basic model but it differs in the authentication method that opens the door. Each model differences are described in the below table. Sincerely yours, Soo-Kyung, Jang / Research Engineer iRevo-ASSA ABLOY Korea Tel: +82-2-2107-5741 E-mail: [email protected] YRD137-ZW-605 YRD137-ZW-0BP YRD137-ZW-BSP

External photos of EUT Top view of EUT Bottom view of EUT Side view of EUT

Model name: YRD137-ZW-619 Internal photos of EUT Model name: YRD137-ZW-619 Internal view of EUT Model name: YRD137-ZW-619 Top view of Main PCB Bottom view of Main PCB Model name: YRD137-ZW-619 Top view of Sub PCB Bottom view of Sub PCB Model name: YRD137-ZW-619 Vie w of Antenna & Module Z-Wave Module Z-Wave Antenna

Test Report No. : F690501-RF-EMC000707 Page : 2 of 12 EMH7081-01A(2021.04.09)(1) A4(210mm*297mm) Contents 1. General Information ................................................................................................... 4 1.1 Client Information ................................................................................................ 4 1.2 Test Laboratory ................................................................................................... 4 1.3 General Information of E.U.T. ............................................................................. 4 1.4 Operating Modes and Conditions ........................................................................ 4 1.5 Peripheral Equipments ........................................................................................ 4 1.6 Cable List ............................................................................................................ 5 1.7 System Configurations ........................................................................................ 5 1.8 Test System Layout ............................................................................................ 5 1.9 Modifications/Notes ............................................................................................. 5 1.10 Applicable Standards for Testing ...................................................................... 5 1.11 Summary of Test Results .................................................................................. 5 2. Emission Test ............................................................................................................ 6 2.1 Test Results ........................................................................................................ 6 2.2 Test Method and Limits ....................................................................................... 6 2.2.1 Test Method ............................................................................................... 6 2.2.2 Test Limits .................................................................................................. 6 2.3 Radiated Emission .............................................................................................. 8 2.3.1 Test Equipments ........................................................................................ 8 2.3.2 Test Site ..................................................................................................... 8 2.3.3 Environment Conditions ............................................................................. 8 2.3.4 Test Results ............................................................................................... 9 Appendix A : Measurement Uncertainty ...................................................................... 12 Test Report No. : F690501-RF-EMC000707 Page : 3 of 12 EMH7081-01A(2021.04.09)(1) A4(210mm*297mm) Revision History Revision Report number Description 0 F690501-RF-EMC000707 Initial Test Report No. : F690501-RF-EMC000707 Page : 4 of 12 EMH7081-01A(2021.04.09)(1) A4(210mm*297mm) 1. General Information 1.1 Client Information Applicant iRevo-ASSA ABLOY Korea Applicant Address 10f of JEI PLATZ Bldg., 186, Gasandigital 1-ro, Geumcheon-gu, Seoul, 08502, Korea Manufacturer iRevo-ASSA ABLOY Korea Manufacturer Address 10f of JEI PLATZ Bldg., 186, Gasandigital 1-ro, Geumcheon-gu, Seoul, 08502, Korea 1.2 Test Laboratory Name and Address SGS Korea Co., Ltd. - Giheung Laboratory 35, Giheungdanji-ro 121beon-gil, Giheung-gu, Yongin-si, Gyeonggi-do, Republic of Korea - Gunpo Laboratory 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, 15807, Republic of Korea FCC Registration No. KR0150 IC Registration No. 7837B Phone + 82 31 548 0710 Fax + 82 31 548 0719 e-mail [email protected] 1.3 General Information of E.U.T. Classification Specification Product Name Digital Door Lock Model Name YRD137-ZW-619 Alt. Model Name YRD137-ZW-605, YRD137-ZW-0BP, YRD137-ZW-BSP Model Differences Refer Note1. Serial No. None EMI Classification Class B Test Voltage DC 6 V (AA Battery 4 EA) Rated Voltage DC 6 V Highest Internal Frequency 916 ㎒ H/W Version PV01 S/W Version V2.2.6 Function This product is an electronic door locking equipment Note1. Model Differences Model Name Differences (Color of appearance) Basic Model YRD157-ZW-619 SILVER Alt. Model YRD157-ZW-605 GOLD YRD157-ZW-0BP Oil Rubbed Bronze YRD157-ZW-BSP Matt BLACK 1.4 Operating Modes and Conditions Operating mode Operating Condition 1) unlocking operation Status that pressing a button on the EUT for unlocking. 1.5 Peripheral Equipments Description Model Serial No. Manufacturer - - - - Test Report No. : F690501-RF-EMC000707 Page : 5 of 12 EMH7081-01A(2021.04.09)(1) A4(210mm*297mm) 1.6 Cable List Start END Cable Spec. Used core Name I/O Port Name I/O Port Length (m) Shield EUT - - - - - - 1.7 System Configurations Description Model Serial No. Manufacturer Note Main Board WGA5.8V MAIN PV01 220428 PC4M-D448S-E1 - - Front Board WGA5.8V PB FRONT PV01 220502 PC2F-D449S-E1 - - Motor - - - - 1.8 Test System Layout Test System Layout 1.9 Modifications/Notes - There was no modified item during the test. 1.10 Applicable Standards for Testing 1.11 Summary of Test Results Test Item Standards Results Conducted Emission FCC Part 15 Subpart B Section 15.107 ICES-003 Issue 7:2020 N/A Radiated Emission FCC Part 15 Subpart B Section 15.109 ICES-003 Issue 7:2020 Complied Note : Test methods of all test items are performed according to the basic standards in this table. Standards Status Deviation FCC Part 15 Subpart B ICES-003 Issue 7:2020 ANSI C63.4a:2017 Applicable No Deviation Test Report No. : F690501-RF-EMC000707 Page : 6 of 12 EMH7081-01A(2021.04.09)(1) A4(210mm*297mm) EMISSION 2. Emission Test 2.1 Test Results Test Items Standards Test Results Conducted Emission FCC Part 15 Subpart B Section 15.107 ICES-003 Issue 7:2020 ANSI C63.4a:2017 N/A Radiated Emission FCC Part 15 Subpart B Section 15.109 ICES-003 Issue 7:2020 ANSI C63.4a…

Text truncated - open the document above for the full version.

Test setup photos of EUT Radiated Emission (Below 1 ㎓ ) _ Front _ (Test Model : YRD137 ) Radiated Emission (Below 1 ㎓ ) _ Rear _ (Test Model : YRD137 ) Radiated Emission ( Above 1 ㎓ ) _ Front _ (Test Model : YRD137 ) Radiated Emission ( Abov e 1 ㎓ ) _ Rea r _ (Test Model : YRD137 )
