2ABFL105REGRegister Unit for RFID Tag

Higenx Technical Guide i HP Higenx Technical User Guide 1 December 2013 Higenx, Castleboy, Kilchreest, Loughrea, Co. Galway, Ireland Phone: +353 (0) 91-840016 Email: [email protected] Higenx Technical User Guide 1 Preface Audience This document is intended for anyone involved in the installation and/or maintenance of HigenX hand-hygiene systems. Product Support Product support and answers to any questions about the content of this document can be obtained by contacting Support at: HigenX, Castleboy, Kilchreest, Loughrea, Co. Galway, Ireland Phone: +353 (0) 91-840016 Email: [email protected] Higenx Technical User Guide 2 Contents Preface ............................................................................................................................................ 1 Audience...................................................................................................................................... 1 Product Support .......................................................................................................................... 1 Contents .......................................................................................................................................... 2 System Overview ............................................................................................................................ 5 The Higenx Personal Tag ............................................................................................................... 6 Overview .................................................................................................................................. 6 Logging in: ............................................................................................................................... 6 Usage after Login: ................................................................................................................... 7 Logging out: ............................................................................................................................. 7 Note on Logging in/out: ........................................................................................................... 9 Non-compliance warnings: ...................................................................................................... 9 The different Tag states .......................................................................................................... 9 Replacing the Personal Tag batteries ...........................................Error! Bookmark not defined. The Higenx Register Unit.............................................................................................................. 10 Overview ................................................................................................................................ 10 Using the Register Unit .........................................................................................................10 Setting up and location of Higenx Register Unit ................................................................... 12 The Higenx Zone Control unit....................................................................................................... 15 Overview ................................................................................................................................ 15 Placing the Zone Control unit ................................................................................................ 15 Setting up the Zone Control unit: .......................................................................................... 17 The Higenx Dispenser .................................................................................................................. 19 Overview ................................................................................................................................ 19 Using a dispenser .................................................................................................................. 19 Setting up the Higenx dispenser ........................................................................................... 19 Maintaining the manual dispenser ........................................................................................ 20 Automatic Dispensers ............................................................................................................... 21 Higenx Data Collection ................................................................................................................. 22 Overview.................................................................................................................................... 22 Higenx Technical User Guide 3 Methods of data collection ........................................................................................................ 22 Data Collection with GSM enabled Higenx Register Unit ............................................................ 22 Automatic data collection via a permanently connected PC ................................................ 23 Manual Data Collection................................................................................................................. 24 Manual downloads by customer............................................................................................ 24 Collecting the data ................................................................................................................. 24 Installation Instructions for Higenx manual data collection software ........................................... 28 Technical Specifications ...................................................................................................................i Device address assignment in HigenX system ...............................................................................ii Higenx Technical User Guide 4 Regulatory Statements for FCC and Industry of Canada s: FCC ID: 2ABFL1…

Text truncated - open the document above for the full version.

THIS MUST BE SIGNED BY THE APPLICANT AND SHOULD BE PLACED ON APPLICANTS LETTERHEAD ONLY IF AGENT IS SUBMITTING APPLICATION 022311 – 6 Itronik Interconnect Ltd. Cloughaun, Kilchreest, Loughrea Co. Galway VAT NUMBER: IE 6409285B Directors ; Mike Mahony, Frank Boyle Co. Reg no; 389285 353 91 840055, Fax 353 91 840007 Authority to Act as Agent Date: _29November 2013 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Compliance Engineering Ireland _____ is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: _____(29 November 2014)_____ By: _____Mike Mahony_______________ (Signature 1 ) (Print name) Title: Managing Director On behalf of: Itronik Interconnect Ltd__________________________ (Company Name) Telephone: 0035391 840055__________________________ 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD 022311 – 6 Request for Confidentiality Date: _____29 November 2013___ Subject: Confidentiality Request for: ______2ABL105REG______ 11591A-105REG Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term x Permanent Block Diagrams Short Term External Photos Short Term Permanent* 2 Internal Photos Short Term x Permanent Operation Description/Theory of Operation Short Term x Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term x Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ ______Itronik interconnect Ltd.______ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180 ) 3 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: _____Mike Mahony_______________ (Signature 4 ) (Print name) 2 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 3 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 4 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD 022311 – 6 authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Front Back Side

Register labels a) Module b) Label dimensions 25MM by 55MM c) Location of the label at the side of the enclosure Itronik MODEL: 105REG FCC ID : 2ABFL105REG IC : 11591A-105REG

Internal Front: Internal Rear:

Report Ref: 13E4814-1b Page 1 of 25 Project Number: 13E4814-1b Prepared for: Itronik Interconnect Ltd. By Compliance Engineering Ireland Ltd Clonross Lane Derrockstown Dunshaughlin Co. Meath FCC Site Registration: 92592 Industry Canada Assigned Site Code: 8517A-2 FCC ID: 2ABFL105REG IC: 11591A-105REG Date 25 th April 2014 FCC EQUIPMENT AUTHORISATION Test Report EUT Description Register unit (for RFID Tag) Authorised : John McAuley Compliance Engineering Ireland Ltd Clonross Lane, Derrockstown, Dunshaughlin, Co. Meath Tel: +353 1 8256722 Fax: +3531 8256733 Report Ref: 13E4814-1b Page 2 of 25 TEST SUMMARY The equipment complies with the requirements according to the following standards. FCC Part Section(s) RSS-210 Section TEST PARAMETERS Test Result 15.231(a) A1.1.1(a) MAXIMUM MODULATION PERCENTAGE (M%) PASS 15.231(b) A.1.1.2(1) RADIATED EMISSIONS PASS 15.231(c) A1.1.3 20dB BANDWIDTH PASS 15.207(a) RSS Gen 7.2.4 CONDUCTED EMISSIONS ON THE MAINS PASS RSS Gen Issue 3 2010 RSS-210 Issue 8 2010 THIS REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL, WITHOUT THE WRITTEN APPROVAL OF COMPLIANCE ENGINEERING IRELAND LTD Report Ref: 13E4814-1b Page 3 of 25 Exhibit A – Technical Report Table of Contents 1.0 EUT DESCRIPTION..............................................................................................................................4 1.1 EUT OPERATION..................................................................................................................................5 1.2 MODIFICATIONS...................................................................................................................................5 1.3 DATE OF TEST......................................................................................................................................5 1.4.1 MEASUREMENT UNCERTAINTY.......................................................................................................6 2.0 EMISSIONS MEASUREMENTS............................................................................................................7 2.1 CONDUCTED EMISSIONS MEASUREMENTS...................................................................................7 2.2 RADIATED EMISSIONS MEASUREMENTS.......................................................................................7 2.3 TEST CRITERIA...................................................................................................................................10 2.4 CARRIER POWER ..............................................................................................................................10 2.5 OCCUPIED BANDWIDTH...................................................................................................................10 3.0 MAXIMUM MODULATION PERCENTAGE (M%)..............................................................................12 4.0 FIELD STRENGTH OF SPURIOUS RADIATED EMISSIONS..........................................................15 5.0 LIST OF TEST EQUIPMENT...............................................................................................................19 Report Ref: 13E4814-1b Page 4 of 25 1.0 EUT Description The EUT was a module using a short range 433 MHz band transceiver for RFID communication to personal TAG unit. Model: 105REG Type: Register unit for Personal Tag unit FCC ID: 2ABFL105REG Company: Itronik Interconnect Ltd. Contact Christopher Slattery Address: Itronik Interconnect Ltd Cloughaun,Kilchreest Loughrea, Co. Galway, Ireland Phone: +353921840055 e-mail: [email protected] Test Standards: 47 CFR, Part 15.231(a,e) Type of radio: Stand-alone Transmitter Type: FSK Operating Frequency Range(s): 434.099 MHz Number of Channels: One Antenna: Integral Transmitter power configuration: Mains. Oper. Temp Range: 5° C to +35° C Classification: DSR Test Methodology: Measurements performed according to the procedures in ANSI C63.4-2003 ANSI C63.10-2009 Report Ref: 13E4814-1b Page 5 of 25 1.1 EUT Operation Operating Conditions during Test: The equipment under test was operated during the measurement under the following conditions: The EUT was mains powered. The EUT was operated in continuous modulated mode (duty cycle was 50uS on and 30uS off) for all tests except duty cycle test. For the duty cycle test, the EUT was operated in normal operation mode, where transmission from the EUT was triggered from a unit external to the anechoic chamber.. Environmental conditions During the measurement the environmental conditions were within the listed ranges: Normal Temperature: +15 to +35 ° C Humidity: 20-75 % 1.1 Modifications No modifications were required in order to pass the test specifications. 1.2 Date of Test The tests were carried out on one sample of the EUT during the month of November 2013. Report Ref: 13E4814-1b Page 6 of 25 1.4 Electromagnetic Emissions Testing The guidelines of CISPR 16-4 were used for all uncertainty calculations, estimates and expressions thereof for EMC testing. A copy of Compliance Engineering Ireland Ltd.’s policy for EMC Measurement Uncertainty is available on request. RF Requirements: Spurious emissions in accordance with FCC CFR 15.107, 15.109 and 15.209. Tests were carried out to the requirements of CISPR 16-4 and ANSI C63.4-2003. 1.4.1 Measurement Uncertainty The measurement uncertainty (with a 95% confidence level) for the conducted emissions test was ±3.5 dB. The measurement uncertainty (with a 95% confidence level) for the radiated emissions test was ±5.3 dB (from 30 to 100 MHz), ±4.7 dB (from 100 to 300 MHz), ±3.9 dB (from 300 to 1000 MHz) and ±3.8 dB (from 1 GHz to 40 GHz). Report Ref: 13E4814-1b Page 7 of 25 2.0 Emissions Measurements 2.1 Conducted Emissions Measurements The EUT was powered was connected to the mains through a LISN and measurements were carried out using a Receiver over the frequency range 150KHz to 30MHz. . 2.2 Radiated Emissions Measurements Radiated Power measurements were made at the Compliance Engineering Ireland L…

Text truncated - open the document above for the full version.

Test Set up Fig 1 Test setup Fig 2 Test setup Fig 3 Test setup Fig 4 Test setup Fig 5 Test setup
