Wireless Charger Instructions Dual Function Charger-UP1 Portable wireless high-capacity mobile charger series: Integrated with high performance polymer battery of cutting-edge technology, more than 6000mAh capacity and no memory effect. It can be used to store power and charge electronic devices either wireless or wired. With universal USB & micro USB port, UP1 is the best companion for your daily gadgets like tablets, mobile phones, e-books, game consoles, digital cameras, PSP etc. Anywhere, anytime, solve your power headaches. Portable wireless charger series: All products are qualified to meet Qi international wireless charging standards. Unique intelligent ID charging: automatically identify different devices to adjust output power. All connections are non-exposed. And secure chips can prevent safety hazards such as electric leakage, voltage surge, short circuit etc. Product features: Applied with most advanced wireless charging solution, that is, the system detects status to decide power supply priority which both facilitates user’s need and improves the charging efficiency. Efficient power management system, high performance polymer battery and quality transmitting coil core ensure that our products have high charging efficiency, long life span, more charging cycles. Auto protect functions include self-load, overload, short circuit, thermal, overcharge, over- discharge, metal object detection and other unexpected aspects. Our energy conversion rate reaches as high as 90% while most products only have a 70% rate of poor level. The high ratio greatly reduces energy losses and increases power to charge devices more times. I. Product Specifications： Power Input： DC 5V 2A Capacity： 6000mAh Standby power consumption： 30uA(MAX) Output current： 2A(MAX) USB output： DC 5V 2A Wireless output power： ＜5W Wireless working frequency： 110kHz-205kHz Wireless standby power consumption： less than 10mA Charging distance： 5~8mm Energy conversion rate： USB charging 90%（MAX）； Wireless charging72%（MAX） Surface temperature： 55°C（MAX） Indicator： LED、Buzzer Working temperature： 0°C（32）F-40°C（104） Storage temperature： -20°C（-4）F-60°C（140） II. Instructions for use 1. Steps A. Charge the portable power bank: Use a micro USB cable to connect power bank with adapter (Pic 1). Plug the adapter into 220V mains supply. System will detect the input voltage and start automatically. B. Wireless charging for mobile phones: Match the position of phone’s receiver coil with transmitter coil’s (Pic 2 & Pic 3). Then press the power button. Charging will automatically start when a wireless charging device is detected. (Pay attention on Precautions) C. Wired charging for mobile phone: Use a micro USB cable to connect the mobile charger with the phon e (Picture 4). Press the power button and the charging begins. (Tips: During charging process,do not put y our phone or metal objects on top of the mobile charger transmitting coil. Otherwise it will cause overcurr ent and system will start self-protection. You need to activate the system by charging it.) 2. Charging principles A. Mobile chargers connected with power supply (mains supply) by micro USB cable or standard USB plug-in: ★After detecting the input voltage, system will start the charging following priorities below: 1. wireless charging 2. USB plugged device charging 3. Built-in battery charging ★When a wireless charging device is detected, system will charge the device. At the same time USB output and built-in battery charging are shut down. ★ When the wireless device is fully charged or no wireless device detected, USB output is opened. ★When USB output current is low, system will charge built-in battery. Four bars indicator refers to 25%、 50%、75%、100% power correspondingly. Flashing bar is the current charging level. When USB output current is high, built-in battery charging is shut down. ★When no wireless charging device is detected or the wireless charging is completed, system will shut down the wireless charging function 60s after non-working. Activate this function by short press on the power button. B. Built-in battery discharge： ★short press power button, system is activated and will charge following the sequence: Wireless charging, USB output. ★When wireless charging device is detected, system will charge the device and shut down USB output. ★When the wireless device is fully charged or no wireless device detected, USB output is opened. ★When built-in battery is discharging, Four bars indicator refers to 25%、50%、75%、100% power correspondingly. To save battery, indicator bars will be deactivated automatically. Short pressing power button will activate the indicator. When battery power is less than 1%, last bar will blink off after 4 seconds. Meanwhile, system shuts down automatically. ★When no wireless charging device is detected or the wireless charging is completed, system will shut down the wireless charging function 60s after non-working. Activate this function by short press on the power button. ★When wireless charging function is deactivated and no output is detected, system will shut down automatically after 60 seconds. C. Single wireless charging function device： O Use micro USB cable and adapter or standard USB to supply power to the charger O Default input is DV 5V by adapter or standard USB plug-in. Due to current limit of USB ports, sometimes charger may restart during charging. Adapter 5V/2A is recommended. O Two indicators: red light refers to standby mode or error. Blue flashing light refers to normal charging mode. O Buzzer of the wireless charger: it will beep once when the phone is placed in the correct position. III. Precautions: ★No authorized teardown is allowed. ★For indoor use. ★Putting metal objects on surface of charger is prohibited. ★For a longer life of the product, it’s recommended to charge after the built-in battery runs out. ★Charge the device at least once every three months. ★Away from fire and shock. ★Stop using the product if the…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2013-12-5 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Shenzhen Yupin Technology Co.,Ltd hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description： model name： UP1 FCC ID: 2ABGM-UPW001 We affirm that between SIEMIC and ____ Shenzhen Yupin Technology Co.,Ltd ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Client’s name / title : Contact information / address : 4th Floor, Building Two, Dongpeng Industrial Park, Second Industrial District, Mabu New Village, Shiyan Street, Shenzhen City Shenzhen Yupin Technology Co.,Ltd dianxiaobao Wenying Zhong / Manager

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Contact information / address: Shenzhen Yupin Technology Co.,Ltd 2013-12-5 2ABGM-UPW001 Wenying Zhong /Manager 4th Floor, Building Two, Dongpeng Industrial Park, Second Industrial District, Mabu New Village, Shiyan Street, Shenzhen City

Coupling surface area For Model Number: UP1 FCC ID: 2ABGM-UPW001 d=6.4 cm, S=π(d/2) 2 =32.17 cm 2 Accord QI certification requirements below: d=44mm+20mm

Shenzhen Yupin Technology Co.,LTD Cover Letter ‐ Wireless Charger Approval FCC ID: 2ABGM‐UPW001 Data: Nov. 12, 2013 Gentlemen: There’s a Wireless dianxiaobao that would like to have your authorization as an Inductive wireless power transfer applications approval. The specific product as below, Wireless dianxiaobao with its designed features and specified description, meets special requirements for KDB 680106 D01 section 5.2 requirements. Company : Shenzhen Yupin Technology Co.,LTD Product Name : Wireless dianxiaobao Model Number : UP1 FCC ID : 2ABGM‐UPW001 KDB 680106 D01 Section 5.2 Requirements: Product Technical Specification： Result: a) Power transfer frequency is less that 1 MHz 110~205 kHz Complied b) Output power from each primary coil is less than 5 Watts <5Watts Complied c) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils --- Complied d) Client device is inserted in or placed directly in contact with the transmitter --- Complied e) The maximum coupling surface area of the transmit (charging) device is between 60 cm2 and 400 cm2. Please reference report of SIEMIC See attached f) Aggregate leakage fields at 10 cm surrounding the device from all simultaneous transmitting coils are demonstrated to be less than 30% of the MPE limit. Please reference RF exposure report.pdf Complied Sincerely, By: Wenyin Zhong (Signature1) (Print name) Title: Director On behalf of: Shenzhen Yupin Technology Co.,LTD (Company Name) Telephone: (+86)075561821296

Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Model: N/A To: FCC Part 18 Subpart C , FCC Measurement Procedure MP-5 (1986) Report No.: 13070481-FCC-E1-18 Issue Date: November 26, 2013 Page: 21 of 38 www.siemic.com.cn Annex B. EUT AND TEST SETUP PHOTOGRAPHS Annex B. i. Photograph 1: EUT External Photo (there are two colour for the EUT’s appearance: black and colourful) Whole Package - Top View Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Model: N/A To: FCC Part 18 Subpart C , FCC Measurement Procedure MP-5 (1986) Report No.: 13070481-FCC-E1-18 Issue Date: November 26, 2013 Page: 22 of 38 www.siemic.com.cn EUT - Top View(Black) EUT - Bottom View(Black) Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Model: N/A To: FCC Part 18 Subpart C , FCC Measurement Procedure MP-5 (1986) Report No.: 13070481-FCC-E1-18 Issue Date: November 26, 2013 Page: 23 of 38 www.siemic.com.cn EUT - Front View(Black) EUT - Rear View(Black) Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Model: N/A To: FCC Part 18 Subpart C , FCC Measurement Procedure MP-5 (1986) Report No.: 13070481-FCC-E1-18 Issue Date: November 26, 2013 Page: 24 of 38 www.siemic.com.cn EUT - Left Side View(Black) EUT - Right Side View(Black) Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Model: N/A To: FCC Part 18 Subpart C , FCC Measurement Procedure MP-5 (1986) Report No.: 13070481-FCC-E1-18 Issue Date: November 26, 2013 Page: 25 of 38 www.siemic.com.cn EUT - Top View(Colourful) EUT - Bottom View(Colourful) Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Model: N/A To: FCC Part 18 Subpart C , FCC Measurement Procedure MP-5 (1986) Report No.: 13070481-FCC-E1-18 Issue Date: November 26, 2013 Page: 26 of 38 www.siemic.com.cn EUT - Front View(Colourful) EUT - Rear View(Colourful) Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Model: N/A To: FCC Part 18 Subpart C , FCC Measurement Procedure MP-5 (1986) Report No.: 13070481-FCC-E1-18 Issue Date: November 26, 2013 Page: 27 of 38 www.siemic.com.cn EUT - Left Side View(Colourful) EUT - Right Side View(Colourful)

Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Model: N/A To: FCC Part 18 Subpart C , FCC Measurement Procedure MP-5 (1986) Report No.: 13070481-FCC-E1-18 Issue Date: November 26, 2013 Page: 28 of 38 www.siemic.com.cn Annex B.ii. Photograph 2: EUT Internal Photo EUT-Cover Off View Mainborad - Top View Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Model: N/A To: FCC Part 18 Subpart C , FCC Measurement Procedure MP-5 (1986) Report No.: 13070481-FCC-E1-18 Issue Date: November 26, 2013 Page: 29 of 38 www.siemic.com.cn Mainborad - Bottom View Coil Antenna - Top View Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Model: N/A To: FCC Part 18 Subpart C , FCC Measurement Procedure MP-5 (1986) Report No.: 13070481-FCC-E1-18 Issue Date: November 26, 2013 Page: 30 of 38 www.siemic.com.cn Battery – Top View

Shenzhen Yupin Technology Co., Ltd dianxiaobao Main Model: UP1 Serial Model: N/A Jan 17, 2014 Report No.: 13070481-FCC-R1 (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: David Huang Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Mode l: N/A To: FCC 47CFR Part 1 subpart I & part 2 subpart J Report No.: 13070481-FCC-R1 Issue Date: Jan 17, 2014 Page: 2 of 30 www.siemic.com.cn Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. SIEMIC (Shenzhen-China) Laboratories Accreditations for Conformity Assessment Country/Region Scope USA EMC , RF/Wireless , Telecom Canada EMC, RF/Wireless , Telecom Taiwan EMC, RF, Telecom , Safety Hong Kong RF/Wireless ,Telecom Australia EMC, RF, Telecom , Safety Korea EMI, EMS, RF , Telecom, Safety Japan EMI, RF/Wireless, Telecom Singapore EMC , RF , Telecom Europe EMC, RF, Telecom , Safety Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Mode l: N/A To: FCC 47CFR Part 1 subpart I & part 2 subpart J Report No.: 13070481-FCC-R1 Issue Date: Jan 17, 2014 Page: 3 of 30 www.siemic.com.cn This page has been left blank intentionally. Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Mode l: N/A To: FCC 47CFR Part 1 subpart I & part 2 subpart J Report No.: 13070481-FCC-R1 Issue Date: Jan 17, 2014 Page: 4 of 30 www.siemic.com.cn CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION .......................................................................................... 5 2 TECHNICAL DETAILS.......................................................................................................................................... 6 3 MODIFICATION ..................................................................................................................................................... 7 4 TEST SUMMARY .................................................................................................................................................... 8 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS................................................................... 9 ANNEX A. TEST INSTRUMENTATION & GENERAL PROCEDURES ............................................................. 11 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................... 13 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ................................................................................ 26 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST ............................................. 29 ANNEX E. DECLARATION OF SIMILARITY ........................................................................................................ 30 Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Mode l: N/A To: FCC 47CFR Part 1 subpart I & part 2 subpart J Report No.: 13070481-FCC-R1 Issue Date: Jan 17, 2014 Page: 5 of 30 www.siemic.com.cn 1 The purpose of this test programme was to demonstrate compliance of the Shenzhen Yupin Technology Co., Ltd, dianxiaobao and Model: UP1 against the current Stipulated Standards. The dianxiaobao has demonstrated compliance with the FCC 47CFR Part 1 subpart I & part 2 subpart J. EXECUTIVE SUMMARY & EUT INFORMATION EUT Information EUT Description : dianxiaobao Main Model : UP1 Serial Model N/A Input Power : DC 5V 2.0 A Antenna Type : Coil antenna Classification Per Stipulated Test Standard : Non-ISM frequency FCC 47CFR Part 1 subpart I & part 2 subpart J Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Mode l: N/A To: FCC 47CFR Part 1 subpart I & part 2 subpart J Report No.: 13070481-FCC-R1 Issue Date: Jan 17, 2014 Page: 6 of 30 www.siemic.com.cn 2 Purpose TECHNICAL DETAILS Compliance testing of dianxiaobao with stipulated standards Applicant / Client Shenzhen Yupin Technology Co.,Ltd 4th Floor, Building Two, Dongpeng Industrial Park, Second Industrial District, Mabu New Village, Shiyan Street, Shenzhen City Manufacturer Shenzhen Yupin Technology Co.,Ltd 4th Floor, Building Two, Dongpeng Industrial Park, Second Industrial District, Mabu New Village, Shiyan Street, Shenzhen City Laboratory performing the tests SIEMIC (Shenzhen-China) Laboratories Zone A, Floor 1, Building 2, Wan Ye Long Technology Park, South Side of Zhoushi Road, Bao'an District, Shenzhen, Guangdong, China Tel: +86-0755-2601 4629 / 2601 4953 Fax: +86-0755-2601 4953-810 Email: [email protected] Test report reference number 13070481-FCC-R1 Date EUT received November 04, 2013 Standard applied FCC 47CFR Part 1 subpart I & part 2 subpart J Dates of test (from – to) Jan 15, 2014 No of Units #1 Equipment Category Non-ISM frequency Trade Name Power Partner RF Operating Frequency (ies) 110 kHz – 205 kHz FCC ID 2ABGM-UPW001 Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Mode l: N/A To: FCC 47CFR Part 1 subpart I & part 2 subpart J Report No.: 13070481-FCC-R1 Issue Date: Jan 17, 2014 Page: 7 of 30 www.siemic.com.cn 3 MODIFICATION NONE Title: EMC Test Report for dianxiaobao Main Model: UP1 Serial Mode l: N/A To: FCC 47CFR Part 1 subpart I & part 2 subpart J Report No.: 13070481-FCC-R1 Issue Date: Jan 17, 2014 Page: 8 of 30 www.sie…
