AREC AM-500 Quick Start Specifications: AM-500 Wireless Microphone Positioner Front function key Stop tracking and Mute function Effective range of microphone A circle of 12 meter radius Sound input 3.5 audio input jack Power supply AAA dry cell X 2 (Duracell alkaline battery recommended) Power consumption estimates 6 to 8 hours (Duracell alkaline battery recommended) Dimension 41.5mm(L)x21.5mm(W)x94mm(H) Weight 45g Wireless microphone positioner information 1. Upper front: Mute button and light indicator 2. Lower front: Stop tracking button and light indicator 3. Upper right side: Power switch and light indicator 4. Lower right side: Wireless mic. pairing light indicator 5. Left side: 3.5 audio input jack Light indicators of your wireless microphone AREC wireless mic. Light Color Status Upper front Red Muted Lower front Red Auto tracking function suspensive Press and hold for more than 5 sec. to reset to static IP address and the light flashes red Upper side Red & Green The light turns green then turns off after power ON The light turns red when power is low Lower side Blue The light flashes blue intermittently if without paired device The light flashes blue fast when pairing with one device The light flashes blue slowly when paired with one device successfully Federal Communication Commission interference statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation RF Exposure Warning The equipment complies with RF exposure limits set forth for an uncontrolled environment. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.

AREC Inc. 3F, No.367, Sec.2, Wenhua Rd., Banqiao Dist., New Taipei City 220, Taiwan Date: Date: December 06 ,2013 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: 2ABGQA0030 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, AREC Inc. hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Block Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Signature Name/Title: Mitch Sun / Manager Company Name: AREC Inc. Address: 3F, No.367, Sec.2, Wenhua Rd., Banqiao Dist., New Taipei City 220, Taiwan TEL: +886-2-8259-5060 ext.220 FAX: +886-2-8259-5050 Email: [email protected]

Compliance Certification Services Inc. Report No.: T131104W01 Date of Issue: November 27, 2013 A1 - 1 / 5 Rev. 00 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T131104W01 Date of Issue: November 27, 2013 A1 - 2 Rev. 00

Label Sample & Location

Compliance Certification Services Inc. Report No.: T131104W01 Date of Issue: November 27, 2013 A1 - 3 Rev. 00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T131104W01 Date of Issue: November 27, 2013 A1 - 4 Rev. 00 Compliance Certification Services Inc. Report No.: T131104W01 Date of Issue: November 27, 2013 A1 - 5 Rev. 00 RF Module PCB Antenna

Compliance Certification Services Inc. Report No.: T131104W01 - MF Date of Issue: December 20, 2013 Page 1 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. According to KDB 447498 section 4.3.1, the 1-g SAR test exclusion thresholds at test separation distance ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 The max. average power of channel, including tune-up tolerance(mW) is 5 mW @ 2402MHz (With Tune-up tolerance), The min. test separation distance (mm) is 5 mm, So, [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] ·[√f(GHz)] = 1.55 < 3.0 (With Tune-up tolerance). Therefore, standalone SAR measurements are not required for both head and body.

Compliance Certification Services Inc. FCC ID: 2ABGQA0030 Report No.: T131104W01-RP1 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 79 Rev.00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Wireless Microphone Positioner Model: AM-500 Trade Name: AREC Issued to AREC Inc. 3F, No.367, Sec.2, Wenhua Rd., Banqiao Dist., Taipei City 220, Taiwan (R.O.C.) Issued by Compliance Certification Services Inc. No.11, Wugong 6th Rd., Wugu Dist., New Taipei City 24891, Taiwan. (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: November 29, 2013 Compliance Certification Services Inc. FCC ID: 2ABGQA0030 Report No.: T131104W01-RP1 Page 2 Rev.00 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 November 29, 2013 Initial Issue ALL Eunice Shen Compliance Certification Services Inc. FCC ID: 2ABGQA0030 Report No.: T131104W01-RP1 Page 3 Rev.00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION .................................................................................................4 2. EUT DESCRIPTION ........................................................................................................................5 3. TEST METHODOLOGY .................................................................................................................6 3.1 EUT CONFIGURATION .....................................................................................................................6 3.2 EUT EXERCISE .................................................................................................................................6 3.3 GENERAL TEST PROCEDURES ..........................................................................................................6 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS......................................................7 3.5 DESCRIPTION OF TEST MODES ........................................................................................................8 4. INSTRUMENT CALIBRATION .....................................................................................................9 4.1 MEASURING INSTRUMENT CALIBRATION ...................................................................................9 4.2 MEASUREMENT EQUIPMENT USED ......................................................................................9 4.3 MEASUREMENT UNCERTAINTY .......................................................................................... 10 5. FACILITIES AND ACCREDITATIONS ..................................................................................... 11 5.1 FACILITIES .................................................................................................................................... 11 5.2 EQUIPMENT ................................................................................................................................... 11 5.3 TABLE OF ACCREDITATIONS AND LISTINGS .................................................................................. 12 6. SETUP OF EQUIPMENT UNDER TEST .................................................................................... 13 6.1 SETUP CONFIGURATION OF EUT .................................................................................................... 13 6.2 SUPPORT EQUIPMENT ............................................................................................................ 13 7. FCC PART 15.247 REQUIREMENTS .......................................................................................... 14 7.1 20 DB BANDWIDTH .................................................................................................................. 14 7.2 PEAK POWER ................................................................................................................................. 21 7.3 BAND EDGES MEASUREMENT ............................................................................................. 22 7.4 FREQUENCY SEPARATION .................................................................................................... 40 7.5 NUMBER OF HOPPING FREQUENCY .................................................................................... 45 7.6 TIME OF OCCUPANCY (DWELL TIME) ................................................................................ 50 7.7 SPURIO US EMISSIONS ............................................................................................................. 59 7.8 POWERLINE CONDUCTED EMISSIONS ............................................................................................ 77 APPENDIX I PHOTOGRAPHS OF TEST SETUP ............................................................................ 78 APPENDIX 1 - PHOTOGRAPHS OF EUT Compliance Certification Services Inc. FCC ID: 2ABGQA0030 Report No.: T131104W01-RP1 Page 4 Rev.00 1. TEST RESULT CERTIFICATION Applicant: AREC Inc. 3F, No.367, Sec.2, Wenhua Rd., Banqiao Dist., New Taipei City 220, Taiwan (R.O.C.) Equipment Under Test: Wireless Microphone Positioner Tr a d e N a m e : AREC Model: AM-500 Date of Test: November 11 ~ 18, 2013 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements set forth in the above standards. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Miller Lee Angel Cheng Section Manager Section Manager Complia…
