AAR1000X – ASY Audio Bluetooth Receiver User Manual Features: • Enhance Bluetooth Class (AD2P) Performance • 12hrs of Music Playback Time • Remember up to Six (6) Paired Devices Status Indicator: − Red = 2.5mm connected and charging (Red light will turn off after charge completed) − Blue (one long blink) = Power OFF − Blue (slow continuously blink) = Bluetooth connected − Blue (double-blink) = Power ON and Standby − Blue (fast continuously blink) = Waiting to be paired (paring mode) Charge your AAR10000 Highly recommend to charge your AAR10000 100% before usage. It takes approximately 5 hours to charge the AAR10000 from 0% ~ 100% the first time. 1. Using computer: connect the 2.5mm connector to the AAR10000 power connector and the standard USB port to computer’s USB port 2. Using an electrical outlet: connect the 2.5mm connector to the AAR10000 and the standard USB port to a DC 5V adapter 3. Indicator status: a. RED = charging b. OFF = charge completed Power ON/OFF your AAR10000 1． Power ON: Press and hold the power button for 2 seconds until the indicator double-blinks in blue 2． Power OFF: Press and hold the power button for 2 seconds until the indicator turns on in blue for a whole second then off Use your AAR10000 1. Connect AAR10000 3.5mm connector to the AUX-In / Line-In port of your 2.5mm Power Status Indicator 3.5mm connector Power button ordinary speaker or via the RCA cable set to your home stereo system 2. Turn On the AAR10000 3. Pair it with your Bluetooth enabled device 4. You may now begin enjoy your music! Pair your AAR10000 1. Enable and/or turn on the Bluetooth from the media device, such as: Smartphone, Tablet, Computer...etc. 2. Search AAR10000, enter pair-key “0000” if prompt 3. Paired and connected successfully Technical Specification: Model No. AAR10000 Bluetooth Class 2, A2DP Protocol Battery Type Lithium-Ion Rechargeable Battery Number of USB devices supported SIX (6) Connector 3.5mm Audio Connector Dimension (L x D x W) 1.57 x 1.34 x 0.31(in) Weight 4.40 oz Certifications FCC, CE, Bluetooth SIG Package contents: 9 AAR10000 x 1 9 2.5mm to USB Charging Cable x 1 9 RCA Cable set x 1 9 User Manual x 1 Specifications are subject to change without notice. ASY products are protected with a one (1) year manufacturer limited warranty. Photos of the product may not reflect the actual content. Product compatibility and features are not guaranteed. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertains to ASY USA products and is subject to change at any time, without notice. For the most recent product information please visit http://www.asyusa.com Copyright 2013© ASY USA Corporation [email protected] All Rights Reserved
