Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Federal Communications Commission (FCC) Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generate, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ο¬ Reorient or relocate the receiving antenna. ο¬ Increase the separation between the equipment and receiver. ο¬ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ο¬ Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the userβs authority to operate this equipment. RF exposure warning This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. The equipment must not be co-located or operating in conjunction with any other antenna or transmitter.
ShenZhen Soundpower Technology Co., Ltd. 202B, Floor 2,B6 Building WenWu Industrial Zone, DaTianYang SongYu Road, SongGang Town, Baoan, Shenzhen, China ------------------------------------------------------------------------------------------------------- Date: 2014-03-28 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2ABHDASP2800X To Whom It May Concern: This letter is to ascertain that the following information of applicant, proudct with model(s) have been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. Applicant: ShenZhen Soundpower Technology Co., Ltd. Product Name: LED Lamp + Bluetooth Wireless Speaker Combo Model: ASP2800X, ASP2810X, ASP2820X, ASP2830X, ASP2840X, ASP2850X, ASP2860X, ASP2870X, ASP2880X, ASP2890X (The symbol "X" can be 0-9 to indicate different color) If you have any question or concerns, pls. contact us. Sincerely,
1 of 2 External Photo (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo
Label Label Location ShenZhen Soundpower Technology Co., Ltd. M/N: ASP2800X Made in china This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: 2ABHDASP2800X
1 of 10 Internal Photo (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo (9) EUT Photo (10) EUT Photo (11) EUT Photo (12) EUT Photo (13) EUT Photo (14) EUT Photo (15) EUT Photo (16) EUT Photo (17) EUT Photo (18) EUT Photo (19) EUT Photo (20) EUT Photo
MRT Technology (Suzhou) Co., Ltd Report No.: 1404RSU00302 Phone: +86-512-66308358 Report Version: V01 Fax: +86-512-66308368 Issue Date: 04-08-2014 Web: www.mrt-cert.com FCC ID: 2ABHDASP2800X Page Number: 1 of 4 RF Exposure Evaluation Declaration FCC ID: 2ABHDASP2800X APPLICANT: ShenZhen Soundpower Technology Co., Ltd. Application Type: Certification Product: LED Lamp + Bluetooth Wireless Speaker Combo Model No.: ASP2800X, ASP2810X, ASP2820X, ASP2830X, ASP2840X, ASP2850X, ASP2860X, ASP2870X, ASP2880X, ASP2890X FCC Classification: FCC Part 15 Spread Spectrum Transmitter (DSS) Test Date: April 03 ~ 05, 2014 Reviewed By : ( Robin Wu ) Approved By : ( Marlin Chen ) The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 1404RSU00302 FCC ID: 2ABHDASP2800X Page Number: 2 of 4 Revision History Report No. Version Description Issue Date 1404RSU00302 Rev. 01 Initial report 04-08-2014 Report No.: 1404RSU00302 FCC ID: 2ABHDASP2800X Page Number: 3 of 4 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- f/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- f/1500 6 1500-100,000 -- -- 1 30 f= Frequency in MHz Calculation Formula: P d = (P out *G)/(4*pi*r 2 ) Where P d = power density in mW/cm 2 P out = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 r = distance between observation point and center of the radiator in cm (The minimum distance is 20cm) P d is the limit of MPE, 1mW/cmΒ². If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Report No.: 1404RSU00302 FCC ID: 2ABHDASP2800X Page Number: 4 of 4 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18Β°C and 78% RH. 1.3. Test Result of RF Exposure Evaluation Product LED Lamp + Bluetooth Wireless Speaker Combo Test Item RF Exposure Evaluation Antenna Gain: The maximum Gain measured in fully anechoic chamber is -1.0dBi in logarithm scale. Freq. Band (MHz) Max. Output power (dBm) Max. Output power (mW) Power Density at R = 20 cm (mW/cm 2 ) Limit S(mW/cmΒ²) 2402 ~ 2480 6.713 4.613 0.00074 1 The End
MRT Technology (Suzhou) Co., Ltd Report No.: 1404RSU00301 Phone: +86-512-66308358 Report Version: V01 Fax: +86-512-66308368 Issue Date: 04-08-2014 Web: www.mrt-cert.com FCC ID: 2ABHDASP2800X Page Number: 1 of 69 FCC ID: 2ABHDASP2800X APPLICANT: ShenZhen Soundpower Technology Co., Ltd. Application Type: Certification Product: LED Lamp + Bluetooth Wireless Speaker Combo Model No.: ASP2800X, ASP2810X, ASP2820X, ASP2830X, ASP2840X, ASP2850X, ASP2860X, ASP2870X, ASP2880X, ASP2890X FCC Classification: FCC Part 15 Spread Spectrum Transmitter(DSS) FCC Rule Part(s): Part 15.247 Test Procedure(s): ANSI C63.10-2009, DA 00-705 Test Date: April 03 ~ 05, 2014 MEASUREMENT REPORT FCC PART 15.247 Bluetooth Reviewed By : ( Robin Wu ) Approved By : ( Marlin Chen ) The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.10-2009 and DA 00-705. Test results reported herein relate only to the item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 1404RSU00301 FCC ID: 2ABHDASP2800X Page Number: 2 of 69 Revision History Report No. Version Description Issue Date 1404RSU00301 Rev. 01 Initial report 04-08-2014 Report No.: 1404RSU00301 FCC ID: 2ABHDASP2800X Page Number: 3 of 69 CONTENTS Description Page Β§2.1033 General Information ......................................................................................................... 6 1. INTRODUCTION ..................................................................................................................... 7 1.1. Scope ........................................................................................................................... 7 1.2. MRT Test Location ....................................................................................................... 7 2. PRODUCT INFORMATION ..................................................................................................... 8 2.1. Equipment Description .................................................................................................. 8 2.2. Frequency / Channel Opreation .................................................................................... 9 2.3. Pseudorandom Frequency Hopping Sequence ........................................................... 10 2.4. Device Capabilities ..................................................................................................... 10 2.5. Test Configuration ...................................................................................................... 10 2.6. EMI Suppression Device(s)/Modifications ................................................................... 10 2.7. Labeling Requirements ................................................................................................ 11 3. DESCRIPTION OF TEST ...................................................................................................... 12 3.1. Evaluation Procedure ................................................................................................. 12 3.2. AC Line Conducted Emissions ................................................................................... 12 3.3. Radiated Emissions .................................................................................................... 13 4. ANTENNA REQUIREMENTS ................................................................................................ 14 5. TEST EQUIPMENT CALIBRATION DATA ............................................................................ 15 6. MEASUREMENT UNCERTAINTY ......................................................................................... 16 7. TEST RESULT ...................................................................................................................... 17 7.1. Summary .................................................................................................................... 17 7.2. 20dB Bandwidth Measurement ................................................................................... 18 7.2.1. Test Limit ................................................................................................................ 18 7.2.2. Test Procedure used ............................................................................................... 18 7.2.3. Test Setting ............................................................................................................. 18 7.2.4. Test Setup ............................................................................................................... 19 7.2.5. Test Result .............................................................................................................. 20 7.3. Output Power Measurement ....................................................................................... 23 7.3.1. Test Limit ................................................................................................................ 23 7.3.2. Test Procedure Used .............................................................................................. 23 7.3.3. Test Setting ............................................................................................................. 23 7.3.4. Test Setup ............................................................................................................... 23 7.3.5. Test Result .............................................................................................................. 24 Report No.: 1404RSU00301 FCC ID: 2ABHDASP2800X Page Number: 4 of 69 7.4. Carrier Frequency Separation Measurement .............................................................. 27 7.4.1. Test Limit ..................................................................................β¦
Text truncated - open the document above for the full version.
1 of 3 Test Setup Photo Description: Front view of Conducted Emission Test Setup Description: Back view of Conducted Emission Test Setup Description: Radiated Emission Test Setup for 9kHz ~ 30MHz Description: Radiated Emission Test Setup for 30MHz ~ 1GHz Description: Radiated Emission Test Setup for 1GHz ~ 18GHz Description: Radiated Emission Test Setup for 18GHz ~ 25GHz
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 4.69 mW |

Bluetooth audio receiver
Equipment Class
DXT - Part 15 Low Power Transceiver, Rx Verified
