2ABHWBN-HH-G03Smart Terminal

- 1 - BN-HH-G03 User Manual Contents 1、Device Description ...................... 2 2、Device Parameters .......................... 4 3、Device Installation ...................... 5 3.1 Unfold ...................................... 6 3.2 Charge Attention .................. 6 4 、BN-HH-G03 Opertaion .................... 8 4.1 Power ON and Off .................. 8 4.2 Device Lock and Unlock ...... 8 4.3 Volume Change ........................ 9 4.4 Front Panel Function Key .. 9 - 2 - 1、Device Description - 3 - - 4 - 2、Parameters Parameter s CPU 1.2GHz 4 core OS Android 4.4 Module RFID/Barcode Reader Size 153*74*19mm Weight 270g(include battery) Camera 800 Million Pixels Screen Type Tps Capacity Type Mult-touch， Size 1280*800 Pixels，5inch Sound Vibrator Yes Speaker Yes Mic0 Yes Storage ROM 16GB RAM 2GB RFID □ HF ISO 14443，ISO 15693 - 5 - □ UHF ISO 18000-6C，EPC Gen2 Barcode Type CCD Image Reader Support 1D and 2D Barcode。 PDF417，Datamatrix， Maxicode, and so on Battery Type 3.7V，Li-Ion 3600 mAh battery Standby Time * 72H Max. Operatio n Time ** 12H Max. SDK OS Android 4.4 System Language Java（JDK 16） Developm ent Kit Java SE Development Kit Eclipse，Android SDK r18 ADT Plugin for Eclipse *Standby Status: Screen is off, Barcode and RFID module is power off **Operation Status：Screen is on, Barcode and RFID module is power on - 6 - 3、Device Installation 3.1 Unfold Check the package contain below items: 1.Handphone 2.Charger 3.Battery 4.Dataline 5.User Manual 6.QC card 3.2 Charge Attention The device should be charged before the first time use , until the power is full, it could be used then. Please use the charger, battery and dateline qualified by BayNexus, otherwise any broken or fail we don’t promise. If the battery is complete used ,under this situation, the device would not operate immediately with the charger. Please wait several minutes until the device work. □ Using Charger Any problem due to the improper usage are not guaranteed. The device could be used with charging, but it would cause the charging time longer. If the charger source is not stable, the touch screen would invalid. If so ,please unplug the charger from the device. While charging ,the device would be a little hot and it is common phenomenon, it would not affect the device work - 7 - performance. If charging the device while it is power off, the screen will show the icon below indicate the battery status. Note: The USB port cannot be data exchanging and charging. The USB connection is only used for engineering purposes in the factory or an authorized service facility and not used by the end-user. - 8 - 4 、BN-HH-G03 4.1 Power On and Off □ Hold on the power key several second, the screen will show the BayNexus logo, then loading the Android operation system, it would take two minutes around. □ If you want to power off the device, please hold on the power key, then touch the power off key. □ If you want to reboot the device, please hold on the power key, then touch the reboot key. □ In same area restricted the usage of wireless device, please follow the guide, hold on the power key ,then touch then flight mode to stop the wireless function. 4.2 Device Lock and Unlock □ Device Lock While not using the device, please lock the device to prevent the improper operation. Hold on the power key and press the lock function to lock it. If the device is not used in a specified time, it would be locked automatically. □ Device Unlock If you want to unlock the device, when the touch screen is off, hold on the power key and slide right to - 9 - unlock it. 4.3 Volume Change Press the upside or downside of the volume key to change the sound volume. 4.4 Front Panel Function Key touch to open the current application option list touch to return to the main screen, hold on to view the application running list, touch to return to the last screen. - 10 - FCC Regulations: FCC ID: 2ABHWBN-HH-G03 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. - 11 - —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/ TV technician for help. Caution: Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.

BayNexus Inc Declaration of Conformity We, BayNexus Inc, declare on our sole responsibility that the below PCB board is directly bought by us, but we only use RFID function, not support other functions and SIM. Since we have fixed the housing mold and it cannot be changed. So there’re a SIM port on the shell. But the product does not support SIM function. Sincerely, BayNexus Inc Jason Liu

BayNexus Inc POWER OF ATTORNEY DATE: August 20, 2015 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 We, the undersigned, hereby authorize TA Technology (Shanghai) Co., Ltd./Qu Yun on our behalf, to apply to FCC on our equipment for FCC ID: 2ABHWBN-HH-G03. Any and all acts carried out by TA Technology (Shanghai) Co., Ltd. on our behalf shall have the same effect as acts of our own. Sincerely, BayNexus Inc Jason Liu

BayNexus Inc 2ABHWBN-HH-G03 label location Justification letter DATE: September 25, 2015 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Dear Sir/Madam, We, BayNexus Inc, requests acceptance of the labeling proposal described below for FCC ID:2ABHWBN-HH- G03. Since the product housing is extremely limited space available to attach the required label carrying the FCC identifier, attaching the label to the back cover is not acceptable because the back cover is a removable item. For this reason, we proposes placing the label carrying the FCC identifier inside the compartment as shown Firstly, the FCC ID label on the inside screwed cover- battery compartment, s o that, it is viewable to our users every time when they remove the back cover; and it does not affect the designing and structuring of the removable back cover. Check out the photo below showing clearly the location of the FCC ID and the removed back cover in figure 1. Figure 1 BayNexus Inc There is no need to remove the inside cover to charge the battery and the battery is not to be sold separate. There is a cradle for charging. In the bottom of the product there are two pin, please see the below picture as shown in figure 2. Figure 2 The below figure 3 is shown that the product is charging. Figure 3 Secondly, we print the FCC ID on the bottom side of our package (box), so that it is always viewable every time a new device is purchased. Check out a photo below showing clearly the location of the FCC ID on the package in figure4. BayNexus Inc Figure 4 Sincerely, BayNexus Inc Jason Liu

BayNexus Inc BayNexus Inc Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2ABHWBN-HH-G03 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram 2ABHWBN-HH-G03_Block Diagram. pdf Part List 2ABHWBN-HH-G03_BOM.pdf schematic 2ABHWBN-HH-G03_SCH.pdf Operation Description 2ABHWBN-HH-G03_Technical Operation.pdf Tune up 2ABHWBN-HH-G03_Tune-up Procedure .pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Sincerely, Jason Liu

2ABHWBN-HH-G03 External photo

5 6 7

1 2ABHWBN-HH-G03_ Internal photo 2 3 4 5 6

Report No. RXA1507-0129SAR Page 1 of 8 TESTING No. L2264 SAR TEST REPORT Product Name Smart Terminal Model Name BN-HH-G03 Brand Name Baynexus FCC ID 2ABHWBN-HH-G03 Client BayNexus Inc Manufacturer BayNexus Inc Date of issue September 17, 2015 TA Technology (Shanghai) Co., Ltd. TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1507-0129SAR Page 2 of 8 GENERAL SUMMARY Reference Standard(s) FCC 47CFR §2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices KDB 447498 D01 Mobile Portable RF Exposure v05r02: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies Conclusion SAR test exclusion Comment The test result only responds to the measured sample. Approved by Kai Xu Director Revised by Jiangpeng Lan SAR Manager Performed by Liang Ye SAR Engineer TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1507-0129SAR Page 3 of 8 TABLE OF CONTENT 1. General Information ........................................................................................................................ 4 1.1. Notes of the Test Report .......................................................................................................... 4 1.2. Testing Laboratory ................................................................................................................... 4 1.3. Applicant Information ............................................................................................................... 5 1.4. Manufacturer Information ......................................................................................................... 5 1.5. Information of EUT ................................................................................................................... 5 2. Test Results .................................................................................................................................... 6 2.1. Conducted Power Results ....................................................................................................... 6 2.2. Standalone SAR Test Exclusion Considerations ...................................................................... 6 ANNEX A: The EUT Appearances and Test Configuration ..................................................................... 7 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1507-0129SAR Page 4 of 8 1. General Information 1.1. Notes of the Test Report TA Technology (Shanghai) Co., Ltd. has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L2264. TA Technology (Shanghai) Co., Ltd. guarantees the reliability of the data presented in this test report, which is the results of measurements and tests performed for the items under test on the date and under the conditions stated in this test report and is based on the knowledge and technical facilities available at TA Technology (Shanghai) Co., Ltd. at the time of execution of the test. TA Technology (Shanghai) Co., Ltd. is liable to the client for the maintenance by its personnel of the confidentiality of all information related to the items under test and the results of the test. This report only refers to the item that has undergone the test. The test results in this test report relate only to the devices specified in this report.This report shall not be reproduced except in full without the written approval of TA Technology (Shanghai) Co., Ltd. If the electronic report is inconsistent with the printed one, it should be subject to the latter. 1.2. Testing Laboratory Company: TA Technology (Shanghai) Co., Ltd. Address: No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China City: Shanghai Post code: 201201 Country: P. R. China Contact: Xu Kai Telephone: +86-021-50791141/2/3 Fax: +86-021-50791141/2/3-8000 Website: http://www.ta-shanghai.com E-mail: [email protected] TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1507-0129SAR Page 5 of 8 1.3. Applicant Information Company: BayNexus Inc Address: B307,530 Building TaiHu International Science park Wu XI China 1.4. Manufacturer Information Company: BayNexus Inc Address: B307,530 Building TaiHu International Science park Wu XI China 1.5. Information of EUT General Information Device Type: Portable Device Exposure Category: Uncontrolled Environment / General Population State of Sample: Prototype Unit IMEI: 863930021086487 Hardware Version: S80-V31 Software Version: 90 0C 00 00 00 00 07 Antenna Type: Internal Antenna Device Operating Configurations: Operating Mode(s): RFID (902-928); (tested) Auxiliary equipment details AE1: Battery Model: G3 Manufacturer: ShenZhen FREE Technology co.，Ltd S/N: 624053P TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1507-0129SAR Page 6 of 8 2. Test Results 2.1. Conducted Power Results Table 1: Conducted Power Measurement Results RFID Conducted Power (dBm) Channel/Frequency(MHz) 902.75 915 927.25 DSB-ASK 9.522 9.443 9.202 2.2. Standalone SAR Test Exclusion Considerations Per FCC KDB 447498 D01, the SAR exclusion threshold for distances <50mm is defined by the following equation: (max. power of channel, including tune-up tolerance, mW) (min. test separation distance, mm) ∗Frequency (GHz)≤3.0 Band Configuration Frequency (MHz) Maximum Power (dBm) Separation Distance (mm) Calculation Result SAR Exclusion Thresholds Standalone SAR RFID Head 927.25 10 5 1.93 3.0 No Fllow the Calculation Result, the Smart Terminal qualifies for the SAR test exclusion. ***END OF REPORT *** TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1507-0129SAR Page 7 of 8 ANNEX A: The EUT Appearances and Test Configuration a.EUT TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1507-0129SAR Page 8 of 8 b.Battery Picture 1: Constituents of the EUT

Report No.: RXA1507-0129RF01R2 Page 1of 58 TESTING No. L2264 Part 15C TEST REPORT Product Name Smart Terminal Model Name BN-HH-G03 Brand Name Baynexus FCC ID 2ABHWBN-HH-G03 Client BayNexus Inc Manufacturer BayNexus Inc Date of issue September 23, 2015 TA Technology (Shanghai) Co., Ltd. TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RXA1507-0129RF01R2 Page 2of 58 GENERAL SUMMARY Reference Standard(s) FCC CFR47 Part 15C (2014) Radio Frequency Devices 15.205 Restricted bands of operation; 15.207 Conducted limits; 15.209 Radiated emission limits; general requirements; 15.247 Operation within the bands 902-928 MHz,2400-2483.5 MHz, and 5725-5850MHz. ANSI C63.4 Methods of Measurement of Radio-Noise Emission from Low-Voltage Electrical and Electronic Equipment in the Range of 9 KHz to 40GHz. (2014) DA00-705 Filing and Frequency Measurement Guidelines For Frequency Hopping Spread Spectrum System.(2000) Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 2 of this test report are below limits specified in the relevant standards. General Judgment: Pass Comment The test result only responds to the measured sample. Approved by Kai Xu Director Revised by Lingling Kang RF Manager Performed by Peng Tao RF Engineer TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RXA1507-0129RF01R2 Page 3of 58 TABLE OF CONTENT 1. General Information ..................................................................................................................... 4 1.1. Notes of the test report ......................................................................................................... 4 1.2. Testing laboratory ................................................................................................................ 5 1.3. Applicant Information ........................................................................................................... 5 1.4. Manufacturer Information ..................................................................................................... 5 1.5. Information of EUT ............................................................................................................... 6 1.6. Test Date ............................................................................................................................. 6 2. Test Information ........................................................................................................................... 7 2.1. Information about the FHSS characteristics ......................................................................... 7 2.1.1. Pseudorandom Frequency Hopping Sequence ................................................................... 7 2.1.2. Equal Hopping Frequency Use ............................................................................................ 7 2.1.3. System Receiver Input Bandwidth ....................................................................................... 7 2.2. FCC Part 15.247, sections (g) and (h) ................................................................................. 8 2.3. Test Mode ............................................................................................................................ 8 2.4. Summary of test results ....................................................................................................... 9 2.5. Peak Power Output –Conducted ........................................................................................ 10 2.6. Occupied Bandwidth (20dB) .............................................................................................. 13 2.7. Frequency Separation ........................................................................................................ 16 2.8. Time of Occupancy (Dwell Time) ....................................................................................... 19 2.9. Band Edge Compliance ..................................................................................................... 21 2.10. Spurious Radiated Emissions in the Restricted Band..................................................... 24 2.11. Number of hopping Frequency ....................................................................................... 27 2.12. Spurious RF Conducted Emissions ................................................................................ 29 2.13. Radiates Emission .......................................................................................................... 33 2.14. AC Power Line Conducted Emission .............................................................................. 48 3. Main Test Instruments ................................................................................................................ 55 ANNEX A: EUT Appearance and Test Setup .................................................................................... 56 A.1 EUT Appearance .................................................................................................................... 56 A.2 Test Setup .............................................................................................................................. 57 TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RXA1507-0129RF01R2 Page 4of 58 1. General Information 1.1. Notes of the test report TA Technology (Shanghai) Co., Ltd. has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS), and accreditation number: L2264. TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. The site recognition number is 428261. TA Technology (Shanghai) Co., Ltd. has been listed by industry Canada to perform electromagnetic emission measurement. The site recognition number is 8510A. TA Technology (Shanghai) Co., Ltd. guarantees the …

Text truncated - open the document above for the full version.

2ABHWBN-HH-G03 Test Setup Photo Radiated emissions 9kHz-30MHz 30MHz-1GHz b: Above 1GHz Conducted Emission
