2ABKFBER-TRV2radio controller

Differences Description We Guangzhou Biaiyue Electronic Products Co., Ltd. state: Product name: radio controller Model: BER-TRV2, BER-TRV1, BER-TRC1, BER-RXV1, BER-RXV2, BER-RXV3 All model’s software and electric circuit are the same, only with pr oduct appearance,decoration,color and name are different. Test m odel is BER-TRV2. Signatory Signature Date: 2013/12/18 Name: Zheng Jiang Title: General Manager Tel: +86-20-34786455 Company: Guangzhou Biaiyue Electronic Products Co., Ltd.

Guangzhou Biaiyue Electronic Products Co., Ltd. SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 Guangzhou Biaiyue Electronic Products Co., Ltd. SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2013/10/12 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Guangzhou Biaiyue Electronic Products Co., Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： radio controller Model Name： BER-TRV2, BER-TRV1, BER-TRC1, BER-RXV1, BER-RXV2, BER-RXV3 Trade name: N/A FCC ID： 2ABKFBER-TRV2 We affirm that between SIEMIC and __ Guangzhou Biaiyue Electronic Products Co., Ltd. __, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Signature Date: 2013/12/18 Name: Zheng Jiang Title: General Manager Tel: +86-20-34786455 Company: Guangzhou Biaiyue Electronic Products Co., Ltd.

Guangzhou Biaiyue Electronic Products Co., Ltd. SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 Guangzhou Biaiyue Electronic Products Co., Ltd. SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 2013/12/18 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ABKFBER-TRV2 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Date: 2013/12/18 Name: Zheng Jiang Title: General Manager Tel: +86-20-34786455 Company: Guangzhou Biaiyue Electronic Products Co., Ltd.

Top View Bottom View Rear View Left View Left View Front View Right View

Label: FCC ID: 2ABKFBER-TRV2 Guangzhou Biaiyue Electronic Products Co., Ltd. Model No.: BER-TRV2 Model name: radio controller This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Label: Label Location FCC ID: 2ABKFBER-TRV2 Guangzhou Biaiyue Electronic Products Co., Ltd. Model No.: BER-TRV2 Model name: radio controller This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Top View Top View Bottom View Top View Antenna Top View Bottom View

FCC RADIO TEST REPORT FCC ID: 2ABKFBER-TRV2 Product： radio controller Trade Name： N/A Model Name： BER-TRV2, BER-TRV1, BER-TRC1, BER-RXV1, BER-RXV2, BER-RXV3 Serial Model： N/A Report No.： BZT-131206132F Prepared for Guangzhou Biaiyue Electronic Products Co., Ltd. Floor3, No.8, Shanzhuang road Hecun, Dashi Town Panyu Dis. Guangzhou China Prepared by BZT Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China Page 2 of 37 Report No.: BZT-131206132F ` TEST RESULT CERTIFICATION Applicant’s name ................. : Guangzhou Biaiyue Electronic Products Co., Ltd. Address ................................. : Floor3, No.8, Shanzhuang road Hecun, Dashi Town Panyu Dis. Guangzhou China Manufacture's Name ............ : Guangzhou Biaiyue Electronic Products Co., Ltd. Address ................................. : Floor3, No.8, Shanzhuang road Hecun, Dashi Town Panyu Dis. Guangzhou China Product description Product name............................ : radio controller Model and/or type reference : BER-TRV2 Serial Model： BER-TRV1, BER-TRC1, BER-RXV1, BER-RXV2, BER-RXV3 Rating(s) ................................ : DC 6V from battery Standards ............................. : FCC Part15.249 Test procedure ............................... : ANSI C63.4-2003 This device described above has been tested byBZT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval ofBZT, this document may be altered or revised byBZT, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : 09 December. 2013 ~14 December. 2013 Date of Issue .......................................... : 15 December. 2013 Test Result.............................................. : Pass Testing Engineer : (Apple Huang) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 37 Report No.: BZT-131206132F ` Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 10 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 3 . ANTENNA REQUIREMENT 12 3.1 STANDARD REQUIREMENT 12 3.2 EUT ANTENNA 12 3.3 CONDUCTED EMISSION MEASUREMENT 13 3.3.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.3.2 TEST PROCEDURE 14 3.3.3 DEVIATION FROM TEST STANDARD 14 3.3.4 TEST SETUP 14 3.2.5 TEST RESULT 15 3.4 RADIATED EMISSION MEASUREMENT 15 3.4.1 RADIATED EMISSION LIMITS 16 3.4.2 TEST PROCEDURE 16 3.4.3 DEVIATION FROM TEST STANDARD 17 3.4.4 TEST SETUP 17 3.4.5 TEST RESULTS (BLOW 30MHZ) 19 3.4.6 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 20 3.4.7 TEST RESULTS (ABOVE 1000 MHZ) 22 3.4.8 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 25 4 . BANDWIDTH TEST 33 4.1 TEST PROCEDURE 33 4.2 DEVIATION FROM STANDARD 33 4.3 TEST SETUP 33 4.4 TEST RESULTS 34 5 . EUT TEST PHOTO 37 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 4 of 37 Report No.: BZT-131206132F ` 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.249) Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.203 Antenna Requirement Pass 15.249 Radiated Spurious Emission Pass 15.205 Band Edge Emission Pass 15.249 Occupied Bandwidth Pass NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 5 of 37 Report No.: BZT-131206132F ` 1.1 TEST FACILITY BZT Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registered No.: 701733 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 6 of 37 Report No.: BZT-131206132F ` 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment radio controller Trade Name N/A Model Name BER-TRV2 Serial Model BER-TRV1, BER-TRC1,BER-RXV1, BER-RXV2, BER-RXV3 Model Difference All model’s software and electric circuit are the same, o nly with product appearance,decoration,color and name are different. Test model is BER-TRV2. Product Description The EUT is a radio controller Operation Frequency: 2404~2478MHz Modulation Type: GFSK Antenna Designation: Internal antenna Antenna Gain(Peak) 3 dBi EIRP 98.07 dbuv/m@3m Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Adapter N/A Battery DC 6V for 4*AA battery Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 7 of 37 Report No.: BZT-131206132F ` 2. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 01 2404 12 2430 23 2457 02 2407 13 2433 24 2459 03 2409 14 2435 25 2461 04 2412 15 2438 26 2464 05 2414 16 2440 27 2466 06 2416 17 2442 28 2468 07 2419 18 2445 29 2471 08 2421 19 2447 30 2473 09 2423 20 2449 31 2476 10 2426 21 2452 32 2478 11 2428 22 2454 3. Table for Filed Antenna Ant . Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 N/A N/A Internal antenna NA 3.0 Antenna Page 8 of 37 Report No.: BZT-131206132F `…
