2ABLQ-BTSPEAKERPortable Bluetooth Speaker

FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

NOGOINTERNATIONALCo.,Ltd FederalCommunicationsCommission AuthorizationandEvaluationDivision 1435OaklandMillsRoad Columbia,MD21046 Date:May29,2015 SUBJECT:FCCApplicationfor(FCCID:2ABLQ-BTSPESKER) ToWhomItMayConcern: We,theundersigned,herebyattesttothefactthatwewillapplytheDeclarationofConformity proceduretotheclassBcomputerperipheralportionofthiscompositedevice.Weunderstandthat devicessubjecttotheDoCprocedurearerequiredtobetestedtoshowcompliancewiththeFCC technicalregulationsbyarecognizedaccreditedtestinglaboratory.Thetestinglaboratorymustbe accreditedbyaCommissionapprovedaccreditationbodyordesignatedunderthetermsofa government-to-governmentMutualRecognitionAgreement(MRA).Alistingofthoseaccredited testinglaboratoriesthathavebeenrecognizedbytheCommissionispublishedontheFCCWebpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Selectthe"accredited"optiontosearchforFCCrecognizedaccreditedtestfirms. Testfacilitieslocatedincountries,wheretheU.S.doesnothaveanoperationalTelcomMRAarenot recognizedbytheFCCtotestfortheDoCprocedure. Testingwasdonebywhichhasbeenaccreditedinaccordancetoalloftherequirementsof47CFR 2.948(d)and(e)oftheFCCrulesandKDB349827. Regards, Signatory Signature: Date:May29,2015 Name:JohnsonYou Telephone:0755-27388660 Email:[email protected] Company:NOGOINTERNALTIONALCO.,LTD Address:The4thF.ofBkdg.1,Huangtianindustrialzone, Xixiangtown,Bao’andistrict,Shenzhen,China

<NOGOINTERNATIONALCO,.LTD> OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 Date:2015/05/19 Subject;RequestforConfidentiality FCCID:2ABLQ-BTSPEAKER ToWhomItMayConcern, PursuanttotheprovisionsofSections0.457and0.459ofCommission'srules(47CFR0.457, 0.459),wearerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentfrompublicdisclosureindefinitely. SchematicDiagram  BlockDiagram  OperationalDescription Abovementioneddocumentcontainsdetailedsystemandequipmentdescriptionareconsidered asproprietaryinformationinoperationoftheequipment.Thepublicdisclosureofabove documentsmightbeharmfultoourcompanyandwouldgivecompetitoranunfairadvantagein themarket. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatandcorrespondent duringcertificationreviewprocesscannotbegrantedasconfidentialdocumentsandthose informationwillbeavailableforpublicreviewoncethegrantofequipmentauthorizationis issued. Sincerely, Signature: Name:JohnsonYou Title:ExportManager Email:[email protected]

External photo

LABELARTWORKANDLOCATION FCCIDLocation FCC ID Label 30mm*15mm

Internal photo

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2ABLQ-BTSPEAKER Product: Portable Bluetooth Speaker Model No.: NB21 Additional Model No.: NB15, NB17, NB19, NB20, NB22, NB23, NB25, NB26, NB27, NB28 Trade Mark: Report No.: TCT150504E020 Issued Date: June 1, 2015 Issued for : NOGO INTERNATIONAL CO., LTD The 4th F.of Bldg.1, Huangtian industrial zone,Xixiang town, Bao'an district, Shenzhen, China Issued By: Shenzhen Tongce Testing Lab. 1F, Leinuo Watch Building, Fuyong Town, Baoan Dist, Shenzhen, China TEL: +86-755-27673339 FAX: +86-755-27673332 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT150504E020 Page 2 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification....................................................................................... 3 2. Test Result Summary ............................................................................... 4 3. EUT Description ........................................................................................ 5 4. Genera Information................................................................................... 6 4.1. Test environment and mode................................................................................. 6 4.2. Description of Support Units................................................................................ 6 5. Facilities and Accreditations ................................................................... 7 5.1. Facilities .................................................................................................................7 5.2. Location ................................................................................................................. 7 5.3. Measurement Uncertainty..................................................................................... 7 6. Test Results and Measurement Data ...................................................... 8 6.1. Antenna requirement ............................................................................................ 8 6.2. Conducted Emission ............................................................................................. 9 6.3. Conducted Output Power ................................................................................... 13 6.4. Emission Bandwidth ........................................................................................... 16 6.5. Power Spectral Density....................................................................................... 19 6.6. Test Specification................................................................................................ 19 6.7. Conducted Band Edge and Spurious Emission Measurement ....................... 22 6.8. Radiated Spurious Emission Measurement ...................................................... 25 Report No.: TCT150504E020 Page 3 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: Portable Bluetooth Speaker Model No.: NB21 Additional Model No.: NB15, NB17, NB19, NB20, NB22, NB23, NB25, NB26, NB27, NB28 Applicant: NOGO INTERNATIONAL CO., LTD Address: The 4th F.of Bldg.1, Huangtian industrial zone, Xixiang town, Bao'an district, Shenzhen, China Manufacturer: Shenzhen Xin Feng Long Industrial CO., LTD Address: The 4th F.of Bldg.1, Huangtian industrial zone, Xixiang town, Bao'an district, Shenzhen, China Date of Test: May 06 – May 15, 2015 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 KDB 558074 D01 DTS Meas Guidance v03r02 The above equipment has been tested by Shenzhen Tongce Testing Lab. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date:June 1, 2015 Neil Wong Reviewed By: Date:June 1, 2015 Joe Zhou Approved By: Date:June 1, 2015 Tomsin Report No.: TCT150504E020 Page 4 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247 (b)(3) PASS 6dB Emission Bandwidth §15.247 (a)(2) PASS Power Spectral Density §15.247 (e) PASS Band Edge 1§5.247(d) PASS Spurious Emission §15.205/§15.209 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT150504E020 Page 5 of 31 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product Name: Portable Bluetooth Speaker Model : NB21 Additional Model: NB15, NB17, NB19, NB20, NB22, NB23, NB25, NB26, NB27, NB28 Trade Mark: Operation Frequency: 2402MHz~2480MHz Channel Separation: 2MHz Number of Channel: 40 Modulation Technology: GFSK Antenna Type: Internal Antenna Antenna Gain: 0dBi Power Supply: Rechargeable Li-ion Battery DC3.7V Operation Frequency each of channel Channel FrequencyChannel FrequencyChannelFrequencyChannel Frequency 0 2402MHz10 2422MHz20 2442MHz30 2462MHz 1 2404MHz11 2424MHz21 2444MHz31 2464MHz ... ... ... ... ... ... ... ... 8 2418MHz18 2438MHz28 2458MHz38 2478MHz 9 2420MHz19 2440MHz29 2460MHz39 2480MHz Remark: Channel 0, 19 & 39 have been tested. Report No.: T…

Text truncated - open the document above for the full version.

RadiatedEmission ConductedEmission
