2ABTAHNL85CBAutomatic Upper Arm Blood Pressure Monitor

1 Instruction Manual Automatic Upper ArmBlood Pressure Monitor Model No. HL858CB 2 Table of Contents Medical Disclaimer.......................................................................................03 Intended Use...............................................................................................03 About Blood Pressure.................................................................................04 Measurement Method............................................................................06 Accuracy.......................................................................................................06 Precautions.................................................................................................... 07 Device Overview...........................................................................................09 Symbol Definitions.....................................................................................12 Features.......................................................................................................13 InstallingBatteries.....................................................................................18 Using the AC Adapter.................................................................................19 Applying the Cuff........................................................................................20 Measurement Procedure..........................................................................21 Bluetooth Transmission.................................................................................25 Memory Function........................................................................................26 Storage and Maintenance.........................................................................29 Troubleshooting...........................................................................................30 Warranty & Recalibration..........................................................................31 Specifications..............................................................................................32 Note..............................................................................................................34 Appendix........................................................................................................36 Blood Pressure Diary.................................................................................38 3 Medical Disclaimer This manual and product are not meant as a substitute for advice provided by your doctor. You are not to use the information contained herein, or this product for diagnosing or treating a health problem or prescribing any medication. If you have or suspect that you have a medical problem, promptly consult your healthcare provider. Intended Use This device uses the oscillometric method to automatically measure systolic and diastolic blood pressure as well as heart rate. The measurement position is at human being’s arm. All values can be read out in one LCD panel. The device is designed and recommended for use by people over the age of 18 with arm circumference ranging fromapprox.9 inches to 17 inches (23 cm to 43 cm) and for home use. 4 About Blood Pressure 1. What is blood pressure? Blood pressure is the measurement of the force of blood pushing against the walls of the arteries. Arterial blood pressure is constantly fluctuating during the course of the cardiac cycle. The highest pressure in the cycle is called the systolic blood pressure, and represents the pressure in the artery when the heart is beating. The lowest pressure is the diastolic blood pressure, and represents the pressure in the artery when the heart is at rest. Both the systolic and the diastolic pressure are necessary for a physician to evaluate the status of a patient's blood pressure. Many factors such as physical activity, anxiety or the time of day, can influence your blood pressure. Blood pressure is typically low in the mornings and increases from the afternoon to the evening. It is on average lower in the summer and higher in the winter. 2. Why is it useful to measure blood pressure at home? Having one's blood pressure measured by a doctor in a hospital or a clinic, is often associated with anevent called “White Coat Hypertension” where the patient becomes nervous or anxious, thus raising his blood pressure. There are also numerous other factors that might cause your blood pressure to be raised at a specific time of day. This is why medical physician recommend home monitoring as it is important to get readings of blood pressure during different times of the day to really get an idea of your real blood pressure. Medical physicians generally recommend the “Rule of 3”, where you are encouraged to take your blood pressure three times in a row (at 3 ~ 5 minute interval), three times a day for three days. After three days you can average all the results and this will give you an accurate idea of what your blood pressure really is. A Abou A. Stan with and c WHO Orga JNC the J on Eval Hi gh Publ How pres unde Pleas B. Vari Indiv seas hype work (hyp pres The varia whol ever The rise the g pain ut Bl dards fo out rega classifica O: W anization 7: The S Joint Nat Preventi uation, a h Blood ication N o ever the sure and erstandin se consul ations in vidual blo sonal basi er tense p k and is a per tens ssure sym graph ations in le day wit ry five mi thick line in blood graph) an . ood or assess ard to ag ationsad World eventh Re ional Com ion, De nd Treatm Pressure o.04-523 above ch d it's in g non-in t with yo n blood p ood press is. These patients. N at its lowe se: mea mptom.) below ill blood pre th measu nutes. e represen pressure nd 12 PM ( 5 Pres sment o e, have b dapted fr Health eport of mmittee tection, ment of e. NIH 0 Au gust hart is not ntended nvasive b ur physic pressure sures var variation Normally est during ans a p ) lustrated essure ov urement t nts sleep. at 4 PM (B in the…

Text truncated - open the document above for the full version.

Health & Life Co., Ltd. Automatic Upper Arm Blood Pressure Monitor FCC ID. : 2ABTAHNL85CB EUT External Photos Figure 1 General Appearance (Front and Side View) Figure 2 General Appearance (Back and Side View)

Health & Life Co., Ltd. Automatic Upper Arm Blood Pressure Monitor FCC ID. : 2ABTAHNL85CB FCC ID Label Location z Label Placement Location z FCC ID Label Format FCC ID Label Placement Location

Health & Life Co., Ltd. Automatic Upper Arm Blood Pressure Monitor FCC ID. : 2ABTAHNL85CB EUT Internal Photos Figure 3 Internal View (Removed Cover) Figure 4 Internal View (Removed LCD Panel, LCA Panel/Back View) Health & Life Co., Ltd. Automatic Upper Arm Blood Pressure Monitor FCC ID. : 2ABTAHNL85CB Figure 5 Internal View (Main Board, Front View) Figure 6 Internal View (Main Board, Back View) Health & Life Co., Ltd. Automatic Upper Arm Blood Pressure Monitor FCC ID. : 2ABTAHNL85CB Figure 7 Internal View (OSD Board, Front View) Figure 8 Internal View (OSD Board, Back View) Health & Life Co., Ltd. Automatic Upper Arm Blood Pressure Monitor FCC ID. : 2ABTAHNL85CB Figure 9 Internal View (BT Module, Front View) Figure 10 Internal View (BT Module, Back View)

Maximum Permissive Exposure FCC ID: 2ABTAHNL85CB Product Name: Automatic Upper Arm Blood Pressure Monitor Model No: HL858CB 1. According to FCC CFR 47 §1.1310, the criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b). Table 1 Limits for Maximum Permissible Exposure 2. MPE Calculation Health & Life Co., Ltd. declares that the product described above has been evaluated and found to comply with the RF exposure limits for humans, as specified based on ANSI/FCC recommendation. Based on safety distance 20cm, the antenna gain is 4.33 dBi , and the power output is 1.0mW, the power density is5.39x10 -4 mW/cm 2 RF Exposure Calculations: S = (P * G) / (4* π * r^2) or r = (P * G) / (4 * π * S) Where S = Power Density in mW/cm^2 P=-0.35dBm=1.0mw G =4.33dBi=2.71Numerical r = 20cm S = 1.0*2.71/ 4*π* 20^2 =2.71/5026.548=5.39x10 -4 mW/cm 2 Sincerely Yours, ____________________________________ Mr. Ben Cheng Manager AUDIX Technology Corporation

FCC ID: 2ABTAHNL85CB Page 1 of 50 AUDIX Technology Corporation Report No. EM-F140556 APPLICATION FOR CERTIFICATION On Behalf of Health & Life Co., Ltd. Automatic Upper Arm Blood Pressure Monitor Model No.: HL858CB FCC ID: 2ABTAHNL85CB Prepared for : Health & Life Co., Ltd. 9F, No.186, Jian Yi Road, Zhonghe District, New Taipei City, Taiwan Prepared by : AUDIX Technology Corporation EMC Department No. 53-11, Dingfu, Linkou Dist., New Taipei City 244, Taiwan Tel : (02) 2609-9301, 2609-2133 Fax: (02) 2609-9303 File Number : C1M1409047 Report Number : EM-F140556 Date of Test : 2014. 09. 11 ~ 17 Date of Report : 2014. 09. 18 FCC ID: 2ABTAHNL85CB Page 2 of 50 AUDIX Technology Corporation Report No. EM-F140556 TABLE OF CONTENTS Description Page TEST REPORT CERTIFICATION ..............................................................................................4 1. DESCRIPTION OF REVISION HISTORY ........................................................................... 5 2. GENERAL INFORMATION .................................................................................................. 6 2.1. Description of Device (EUT) ........................................................................................................... 6 2.2. Tested Supporting System Details ................................................................................................... 7 2.3. Description of Test Facility ............................................................................................................. 8 2.4. Measurement Uncertainty ................................................................................................................ 8 3. CONDUCTED EMISSION MEASUREMENT ..................................................................... 9 3.1. Test Equipment ................................................................................................................................ 9 3.2. Block Diagram of Test Setup........................................................................................................... 9 3.3. Powerline Conducted Emission Limit (§15.207) ............................................................................. 9 3.4. Operating Condition of EUT ......................................................................................................... 10 3.5. Test Procedure ............................................................................................................................... 10 3.6. Powerline Conducted Emission Measurement Results .................................................................. 10 4. RADIATED EMISSION MEASUREMENT ....................................................................... 13 4.1. Test Equipment .............................................................................................................................. 13 4.2. Test Setup ...................................................................................................................................... 13 4.3. Radiated Emission Limits (§15.209) ............................................................................................. 15 4.4. Operating Condition of EUT ......................................................................................................... 15 4.5. Test Procedure ............................................................................................................................... 16 4.6. Test Results .................................................................................................................................... 17 5. 6dB BANDWIDTH MEASUREMENT ................................................................................ 25 5.1. Test Equipment .............................................................................................................................. 25 5.2. Block Diagram of Test Setup......................................................................................................... 25 5.3. Specification Limits [§15.247(a)(2)] ............................................................................................. 25 5.4. Operating Condition of EUT ......................................................................................................... 25 5.5. Test Procedure ............................................................................................................................... 25 5.6. Test Results .................................................................................................................................... 26 6. MAXIMUM PEAK OUTPUT POWER MEASUREMENT .............................................. 29 6.1. Test Equipment .............................................................................................................................. 29 6.2. Block Diagram of Test Setup......................................................................................................... 29 6.3. Specification Limits [§15.247(b)-(3)] ............................................................................................ 29 6.4. Operating Condition of EUT ......................................................................................................... 29 6.5. Test Procedure ............................................................................................................................... 29 6.6. Test Results .................................................................................................................................... 30 7. EMISSION LIMITATIONS MEASUREMENT ................................................................. 31 7.1. Test Equipment .............................................................................................................................. 31 7.2. Block Diagram of Test Setup......................................................................................................... 31 7.3. Specification Limits (§…

Text truncated - open the document above for the full version.

FCC ID: 2ABTAHNL85CB Page 47 of 50 AUDIX Technology Corporation Report No. EM-F140556 11. PHOTOGRAPHS 11.1. Photos of Conducted Disturbance Measurement FRONT VIEW OF CONDUCTED MEASUREMENT BACK VIEW OF CONDUCTED MEASUREMENT FCC ID: 2ABTAHNL85CB Page 48 of 50 AUDIX Technology Corporation Report No. EM-F140556 11.2. Photos of Radiated Measurement at Semi-Anechoic Chamber 11.2.1.Frequency Range 30MHz~1GHz Operated with batteries Operated with AC adapter FCC ID: 2ABTAHNL85CB Page 49 of 50 AUDIX Technology Corporation Report No. EM-F140556 11.2.2.Frequency Range Above 1GHz Operated with batteries Operated with AC adapter FCC ID: 2ABTAHNL85CB Page 50 of 50 AUDIX Technology Corporation Report No. EM-F140556 11.3. Photo of Section RF Conducted Measurement
