2ABUB-D580-AUTwo Way Radio

FCC Caution. § 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. § 15.21 Information to user. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. § 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Specific Absorption Rate (SAR) information: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authorityto operate the equipment. For Remote controller, SAR tests are conducted using standard operating positions accepted bythe FCC/ISEDC with the device transmitting at its highest certified power level in all tested frequency bands, although theSAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well belowthe maximum value. Before a new model device is available for sale to the public, it must be tested and certified to the FCCthat it does not exceed the exposure limit established by the FCC/ISEDC, Tests for each device are performed in positions andlocations (e.g. at the ear and worn on the body) as required by the FCC/ISEDC. For body worn operation, this model devicehas been tested and meets the FCC/ISEDC RF exposure guidelines when used with an accessory designated for this productor when used with an accessory that Contains no metal and that positions the handset a minimum of 10 mm from the body.Non-compliance with the above restrictions may result in violation of RF exposure guidelines. Tm maintain compliance with the FCC/ISEDC’s RF exposure guidelines, hold the transmitter and antenna at least 1 inch(2.5centimeters) from your face and speak in a normal voice, with the antenna pointed up and away from the face.

2.911 (d)(5)(i) Equipment Type Attestation v1.2 Shenzhen Samhoo Sci&Tech Co.,ltd. Section 2.911(d)(5)(i) Certification – Equipment Type Company name: Shenzhen Samhoo Sci&Tech Co.,ltd. Address: A617, 6th Floor, Building A, Oshida Building, No. 4, Meizhi Road, Meiting Community, Meilin Street, Futian District, Shenzhen, Guangdong, China Product Name: Two Way Radio FCC ID: 2ABUB-D580-AU Model(s): D580-AU 2.911(d)(5)(i) Equipment Type We, [Shenzhen Samhoo Sci&Tech Co.,ltd.] (“the applicant”) certify that the equipment for which authorization is sought through certification is not: • Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. • Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Lin Yuan Date: 2024-11-05 Title and Company name: Manager Shenzhen Samhoo Sci&Tech Co.,ltd. NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

2.911 (d)(5)(ii) Applicant Attestation v1.3 Shenzhen Samhoo Sci&Tech Co.,ltd. Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Shenzhen Samhoo Sci&Tech Co.,ltd. Address: A617, 6th Floor, Building A, Oshida Building, No. 4, Meizhi Road, Meiting Community, Meilin Street, Futian District, Shenzhen, Guangdong, China Product Name: Two Way Radio FCC ID: 2ABUB-D580-AU Model(s): D580-AU 2.911(d)(5)(ii) Applicant filing We, [Shenzhen Samhoo Sci&Tech Co.,ltd.] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Lin Yuan Date: 2024-11-05 Title and Company name: Manager Shenzhen Samhoo Sci&Tech Co.,ltd. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Bazhong Juxing Technology Co., Ltd 2.911 (d)(7)USA Agent v1.4 Section 2.911(d)(7) USA Agent for Service of Process Company name: Shenzhen Samhoo Sci&Tech Co.,ltd. Address: A617, 6th Floor, Building A, Oshida Building, No. 4, Meizhi Road, Meiting Community, Meilin Street, Futian District, Shenzhen, Guangdong, China Product Name: Two Way Radio FCC ID: 2ABUB-D580-AU Model(s): D580-AU 2.911(d)(7) USA Designated Agent for Service of Process We, [Shenzhen Samhoo Sci&Tech Co.,ltd.] (“the applicant”) designate [Wilson Tech Service LLC] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: USA MEIHUA TRADING INC USA Address: 5379 Pine Valley Ct Boulder CO 80301 United States FRN Number: 0033406166 Contact Name: Harley Quinn Telephone No: 1-312-363-9424 Email: [email protected] Applicant Company name: Shenzhen Samhoo Sci&Tech Co.,ltd. Address: A617, 6th Floor, Building A, Oshida Building, No. 4, Meizhi Road, Meiting Community, Meilin Street, Futian District, Shenzhen, Guangdong, China Grantee FRN Number: 0005881040 FCC Grantee Code: 2ABUB Contact Name: Lin Yuan Telephone No: +86-0755 8226 7833 Email: [email protected] Signature: Title: Manager Signature: Title: Manager Date:2024-11-05 Date: 2024-11-05 Bazhong Juxing Technology Co., Ltd 2.911 (d)(7)USA Agent v1.4 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-securit y-threats-to-the-communications-supply-chain-through-the

Shenzhen Samhoo Sci&Tech Co.,ltd. Agent Authorization Company name: Shenzhen Samhoo Sci&Tech Co.,ltd. Address: A617, 6th Floor, Building A, Oshida Building, No. 4, Meizhi Road, Meiting Community, Meilin Street, Futian District, Shenzhen, Guangdong, China Product Name: Two Way Radio FCC ID: 2ABUB-D580-AU Model(s): D580-AU We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Lin Yuan Date: 2024-11-05 Title and Company name: Manager Shenzhen Samhoo Sci&Tech Co.,ltd.

Shenzhen Samhoo Sci&Tech Co.,ltd. Nov. 14, 2024 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Extended Frequencies Justification for Certification of Transmitter with: Company name: Shenzhen Samhoo Sci&Tech Co.,ltd. Address: A617, 6th Floor, Building A, Oshida Building, No. 4, Meizhi Road, Meiting Community, Meilin Street, Futian District, Shenzhen, Guangdong, China Product Name: Two Way Radio FCC ID: 2ABUB-D580-AU Model(s): D580-AU Dear Sir/Madam, This transmitter was designed to operate in following frequency ranges: 400-470MHz. To aid equipment authorization in other countries which accept the United States FCC Grant for Certification, Shenzhen Samhoo Sci&Tech Co.,ltd. is requesting that the FCC lists the frequencies 400-470MHz, under FCC Rule Parts 90 on the FCC Grant. Shenzhen Samhoo Sci&Tech Co.,ltd. attests that the Dual Band Digital Two Way Radio, will not be marketed to USA users with the frequency band which is not allowed by the rule part 90. Per the FCC’s KDB634817 guidance, as an alternative to listing the exact frequencies, we acknowledge that it’s a violation of the FCC Rules if this device operates on unauthorized frequencies. Also, equipment programming is the responsibility of Authorized Service Personnel, the Dual Band Digital Two Way Radio complies with 47 CFR Part 90.203(e), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. Please contact me if you require any additional information. Sincerely Yours, Signature: Name: Lin Yuan Title: Manager Frequency Range FCC Rule Part 400-406MHz For Federal 406.1-450MHz FCC Part 90 450-454MHz FCC Part 90 454-455MHz FCC Part 22 456-460MHz FCC Part 22/90 460-462.5375MHz FCC Part 90 462.7375-467.5375MHz FCC Part 90 467.7375-470MHz FCC Part 90

Shenzhen Samhoo Sci&Tech Co.,ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-11-05 Subject; Request for Confidentiality FCC ID: 2ABUB-D580-AU To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Name: Lin Yuan Date: 2024-11-05 Title and Company name: Manager Shenzhen Samhoo Sci&Tech Co.,ltd.

Shenzhen Samhoo Sci&Tech Co.,ltd. FCC Part 90 Letter Date: 2024-11-14 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Declaration of compliance to the requirements of §90.203 Company name: Shenzhen Samhoo Sci&Tech Co.,ltd. Address: A617, 6th Floor, Building A, Oshida Building, No. 4, Meizhi Road, Meiting Community, Meilin Street, Futian District, Shenzhen, Guangdong, China Product Name: Two Way Radio FCC ID: 2ABUB-D580-AU Model(s): D580-AU Dear Sir/Madam, We, Shenzhen Samhoo Sci&Tech Co.,ltd., acknowledge that this device will not be marketed to USA users with the frequency band which is not allowed by rule part 90.and it is a violation of FCC rules if this device is operated on unauthorized frequencies inside the U.S.A. This equipment meets the requirements of the FCC Rules, Parts 90.203(e) and (g), as applicable. Programming of this products transmit frequencies can be performed ONLY by the manufacturer or by service or by maintenance personal. The operator can’t program transmit frequencies using the equipment’s external operation controls. This is to certify that the requirements of 47 CFR Part 90.203(j)(4) and (5) spectrum efficiency are met by the Telo Communication (Shenzhen) Co., Ltd demonstrated by the tests conducted on the sample radio provided. The tests show that the 4FSK data rate is in accordance with ETSI TS 102 361-1, that is 9600 bits per second in a 12.5 kHz bandwidth to satisfy the data rate requirement of 4800 bits per second per 6.25 kHz of channel bandwidth(10K14F3E emission) The equipment include a spectrum efficiency standard of one voice channel per 6.25 kHz of channel bandwidth. Sincerely Yours, Signature: Name: Lin Yuan Title: Manager

FCC ID: 2ABUB-D580-AU Page 1 of 4 External Photos of the EUT Fig.1 Fig.2 Draft FCC ID: 2ABUB-D580-AU Page 2 of 4 Fig.3 Fig.4 Draft FCC ID: 2ABUB-D580-AU Page 3 of 4 Fig.5 Fig.6 Draft FCC ID: 2ABUB-D580-AU Page 4 of 4 Fig.7 Fig.8 Draft

Size: 20mm*15mm M/N: D580-AU FCC ID: 2ABUB-D580-AU Label location

FCC ID: 2ABUB-D580-AU Page 1 of 2 Internal Photos of the EUT Fig.1 Fig.2 Draft FCC ID: 2ABUB-D580-AU Page 2 of 2 Fig.3 Fig.4 Draft

SAR TEST REPORT Applicant: Shenzhen Samhoo Sci&Tech Co.,ltd. Address: A617, 6th Floor, Building A, Oshida Building, No. 4, Meizhi Road, MeitingCommunity, Meilin Street, Futian District, Shenzhen, Guangdong, China FCC ID: 2ABUB-D580-AU Product Name: Two Way Radio Standard(s): 47 CFR Part 2(2.1093) The above device has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: 2403Y45741E -20 Date Of Issue: 2024/10/28 Reviewed By: Ken Zong Title:SAR Engineer Approved By: Karl Gong Title:SAR Engineer Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: 2403Y45741E-20 Page 2 of 61 SAR TEST RESULTS SUMMARY Operation Frequency Bands Highest Reported 1g SAR (W/kg) Limits (W/kg) Head Face Up (Gap 25mm) Body-Worn (Gap 0mm) PTT(406.1-470MHz) 3.13 5.94 8.0 Maximum Simultaneous Transmission SAR Items Head Face Up (Gap 25mm) Body-Worn (Gap 0mm) Limits Sum SAR(W/kg) N/A N/A 8.0 SPLSR N/A N/A 0.04 EUT Received Date: 2024/10/19 Test Date: 2024/10/23 Test Result: Pass China Certification ICT Co., Ltd (Dongguan) Report No.: 2403Y45741E-20 Page 3 of 61 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: 2403Y45741E-20 Page 4 of 61 CONTENTS DOCUMENT REVISION HISTORY .......................................................................................... 6 1. GENERAL INFORMATION .................................................................................................... 7 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 7 1.2 TEST SPECIFICATION, METHODS AND PROCEDURES ........................................................................ 8 1.3 SAR LIMITS .......................................................................................................................................... 9 1.4 FACILITIES ...................................................................................................................................... 10 2. SAR MEASUREMENT SYSTEM .......................................................................................... 11 3. EQUIPMENT LIST AND CALIBRATION .......................................................................... 19 3.1 EQUIPMENTS LIST & CALIBRATION INFORMATION ....................................................................... 19 4. SAR MEASUREMENT SYSTEM VERIFICATION ........................................................... 20 4.1 LIQUID VERIFICATION ...................................................................................................................... 20 4.2 SYSTEM ACCURACY VERIFICATION ................................................................................................. 21 4.3 SAR SYSTEM VALIDATION DATA ............................................................................................. 22 5. EUT TEST STRATEGY AND METHODOLOGY .............................................................. 23 5.1 TEST POSITIONS FOR BODY-WORN AND OTHER CONFIGURATIONS ................................................ 23 5.2 TEST POSITIONS FOR FRONT-OF-FACE ............................................................................................ 24 5.3 TEST DISTANCE FOR SAR EVALUATION .......................................................................................... 24 5.4 SAR EVALUATION PROCEDURE ....................................................................................................... 25 6. CONDUCTED OUTPUT POWER MEASUREMENT ........................................................ 26 6.1 TEST PROCEDURE .............................................................................................................................. 26 6.2 MAXIMUM TARGET OUTPUT POWER ............................................................................................... 26 6.3 TEST RESULTS: .................................................................................................................................. 26 7. SAR MEASUREMENT RESULTS ........................................................................................ 28 7.1 SAR TEST DATA ................................................................................................................................ 28 8. SAR MEASUREMENT VARIABILITY ............................................................................... 30 9. DUT HOLDER PERTURBATIONS ...................................................................................... 31 10. SAR SIMULTANEOUS TRANSMISSION DESCRIPTION ............................................ 32 10.1 SIMULTANEOUS TRANSMISSION: ..................................…

Text truncated - open the document above for the full version.

This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Tongzhou Testing Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Tongzhou Testing Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report apply only to the specific sample(s) tested under stated test conditions. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Page 1 of 43 TEST REPORT Report Number : TZ0113241001FRF19 Product Name : Two Way Radio Model/Type reference : D580-A U FCC ID : 2ABUB-D580-AU Prepared for : Shenzhen Samhoo Sci&Tech Co.,ltd. A617, 6th Floor, Building A, Oshida Building, No. 4, Meizhi Road, Meiting Community, Meilin Street, Futian District, Shenzhen, Guangdong, China Prepared By : Shenzhen Tongzhou Testing Co.,Ltd. 1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China Standards : FCC CFR Title 47 Part 95, ANSI/TIA-603-E: 2016 Date of Test : October 15, 2024 ~ October 21, 2024 Date of Issue : October 22, 2024 Prepared by : Lena Wen (File administrators) Reviewed by : Max Zhang (Technical Manager) Approved by : Andy Zhang (General Manager) Report No.: TZ0113241001FRF19 Page 2 of 43 ** Report Revise Record ** Report Version Revise Time Issued Date Valid Version Notes V1.0 / October 22, 2024 Valid Initial release Report No.: TZ0113241001FRF19 Page 3 of 43 1. T E S T S T A N D A R D S The tests were performed according to following standards: FCC Part 2: FREQUENCY ALLOCA-TIONS AND RADIO TREATY MAT-TERS; GENERAL RULES AND REG-ULATIONS FCC Part 90: PRIVATE LAND MOBILE RADIO SERVICES. ANSI/TIA-603-E-2016: Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. ANSI C63.26-2015: IEEE/ANSI Standard for Compliance Testing of Transmitters Used in Licensed Radio Services Report No.: TZ0113241001FRF19 Page 4 of 43 2. G E N E R A L I N F O R M A T I O N 2.1. Client Information Applicant : Shenzhen Samhoo Sci&Tech Co.,ltd. Address : A617, 6th Floor, Building A, Oshida Building, No. 4, Meizhi Road, Meiting Community, Meilin Street, Futian District, Shenzhen, Guangdong, China Manufacturer : Shenzhen Samhoo Sci&Tech Co.,ltd. Address : A617, 6th Floor, Building A, Oshida Building, No. 4, Meizhi Road, Meiting Community, Meilin Street, Futian District, Shenzhen, Guangdong, China 2.2. Description of Device (EUT) Product Name : Two Way Radio Trade Mark : N/A Model Number : D580-A U Model Declaration : N/A Test Model : D580-A U Power Supply : DC 7.4V by battery Hardware version : SH-A580-V01 Software version : V1.0 2.3. Wireless Function Tested in this Report PMR Operation Frequency : 406.1 MHz – 470 MHz Modulation Type : FM Emission Designator : 11K0F3E Maximum Output Power : 5W/1W Antenna Type : Detachable Antenna Note 1: Antenna position refer to EUT Photos. Note 2: the above information was supplied by the applicant. Report No.: TZ0113241001FRF19 Page 5 of 43 2.4. EUT operation mode Modulation Channel separation Frequency (MHz) Operation Description FM 12.5 KHz 406.125 Op1 12.5 KHz 453.0125 Op2 12.5 KHz 469.975 Op3 2.5. Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended forFCC ID: 2ABUB-D580-AU filing to comply with FCC Part 2, FCC Part 90 of the FCC CFR 47 Rules. Report No.: TZ0113241001FRF19 Page 6 of 43 3. T E S T E N V I R O N M E N T 3.1. Address of the test laboratory Shenzhen Tongzhou Testing Co.,Ltd 1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 (2014) and CISPR Publication 22. 3.2. Test Facility FCC Designation Number: CN1275 Test Firm Registration Number: 167722 Shenzhen Tongzhou Testing Co.,Ltd has been listed on the US Federal Communications Commission list of test facilities recognized to perform electromagnetic emissions measurements. A2LA Certificate Number: 5463.01 Shenzhen Tongzhou Testing Co.,Ltd has been listed by American Association for Laboratory Accreditation to perform electromagnetic emission measurement. IC ISED#: 22033 CAB identifier: CN0099 Shenzhen Tongzhou Testing Co.,Ltd has been listed by Innovation, Science and Economic Development Canada to perform electromagnetic emission measurement. The 3m-Semi anechoic test site fulfils CISPR 16-1-4 according to ANSI C63.10 and CISPR 16-1-4:2010 3.3. Environmental conditions During the measurement the environmental conditions were within the listed ranges: Temperature: 15-35 ° C Humidity: 30-60 % Atmospheric pressure: 950-1050mbar Report No.: TZ0113241001FRF19 Page 7 of 43 3.4. Test Description Test Specification clause Test case Pass Fail NA NP Remark §90.205 §2.1046(a) RF Power Output Pass §90.205 §2.1046(a) RF Power Output(Conducted Method) Pass §90.242(b)(8) §90.210 §2.1047 Modulation Characteristic Pass §90.209 §2.1049 99% Occupied Bandwidth Pass §90.210 §2.1049 Emission Mask Pass §90.213 §2.1055 Frequency Stability Pass §2.1051 §2.1053 §90.210 TX spurious emissions Pass §90.214 Transient frequency behavior Pass NA = Not Applicable; NP = Not Performed; 3.5. Statement of the measurement uncertainty The data and results referenced in this document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities. The measurement uncertainty was calculated for all measurements listed in this test report acc. To CISPR 16 – 4 „Specification for radio disturbance and immunity measuring apparatus and methods – Part 4: Uncertainty in EMC Measurements“ and is documented in the Shenzhen Tongzhou Testing Co.,Ltd quality system acc. To DIN EN ISO/IEC 17025. Furthermore, component and process variability of devices similar to that tested may result in additional deviati…

Text truncated - open the document above for the full version.

FCC ID: 2ABUB-D580-AU Page 1 of 1 Test Setup Photos of the EUT Radiated Emission Below 1GHz Radiated Emission Above 1GHz Draft
