Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 4.60 mW |
| 2 | 15C | 2.41 GHz - 2.46 GHz | 57.00 mW |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesSingle Modular Approval. Output power listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM integrators. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with transmitter operating conditions to satisfy RF exposure compliance. Only the antenna listed in this filing can be used. The Grantee is responsible for providing the documentation required for modular use. The responsibility for the use of this module, in all configurations utilized or contemplated, remains with the Grantee. The host integrator must follow the integration instructions provided by the module manufacturer and ensure that the composite system end-product complies with the FCC requirements by a technical assessment or evaluation of the FCC rules and KDB Publication 996369. This device supports 20/40MHz WLAN bandwidth modes.
