1 Digital Color Screen Mobile Phone User Manual 1.1 Introduction  Thank you for choose our digital color screen mobile phone. By reading these guidelines before using your mobile phone you will have an overall knowledge of this phone set and understand its simple but outstanding functions.  This phone set is designed for GSM/GPRS networks. On top of basic functions, it enables you to use name card style phone book, sound effect, clock/ alarm, agenda, calculator, games, audio player, camera (optional), video recorder (optional), sound recorder and other functions. It serves your work and leisure time. Having unique interface and perfect feature designing this phone set meets all your expectation.  Our phone set meets the GSM/GPRS standard and has the qualification from related organizations worldwide.  Our company reserves the rights modifying the content in this Instruction without pre-notify. 1.1.1 Mobile phone guideline  Switch off your mobile phone before boarding an aircraft or in hospital and any other facility where posted notices require you to do so. Mobile phone effects the electronic equipments and medication equipments. This phone set has auto switch on function, please check your alarm setting and make sure the phone set will not switch on automatically during the flight.  Certain electronic equipment may not be shielded against the RF signals from our phone, such as hearing aid, pacemakers, other medical devices, fire sensor, auto gate and others. For the satisfactory operation of the 2 equipment and for the safety of personnel, please consult the manufacturer or local sales outlet to discuss alternatives.  Do not put hard pressure or hit on the screen. Rough handling can break the internal circuit board and the screen. The liquid from screen can dangerous human eyes. Please wash eyes with water immediately and go to hospital for further exam if the liquid is in eyes.  Do not modify or dismantle the mobile. Unauthorized modify or dismantle will result in damaging the mobile phone.  In some cases, mobile phone has side effect to the vehicle carried electronic equipments. Please do not use mobile phone under that circumstance. Failure to observe these instructions may lead to the denial of legal right.  Do not operate mobile phone with sharp object such as needle or ball pen. Sharp object will damage mobile phone or lead to malfunction.  Please do not use mobile phone which wire is damaged. Otherwise it will dangerous the user.  Please do not place mobile phone close to magnetic objects. Mobile phone can eliminate the information from disc, credit car and other cards.  Please keep small metal objects away from mobile phone’s ear phone. The speaker has magnetism and attract small metal objects which has potential to damage itself and the one who use it,  Precipitation, humidity and liquids will corrode electronic circuits. Keep the phone dry. 1.1.2 Batteries guideline  Please keep mobile phone away from fire. Fire will damage the batteries and lead to explosion.  During changing batteries, hard pressure will cause the batteries leaking, over heated, explosion and 3 caught fire.  Do not short-circuit the battery. Accidental short circuiting can occur when a metallic object (wire line, clip) or necklace connect two terminals. Short circuit may damage the battery.  Please do not weld the battery’s terminal. Welding the battery will damage it.  The battery liquid is dangerous to human eyes. Please wash eyes with water immediately and go to hospital for further exam if the liquid is in eyes.  Do not modify or dismantle the battery. Unauthorized modify or dismantle will result in damaging the mobile battery.  Do not place batteries in or on the microwave oven or over heated places. That may damage the battery.  During charging, using or storing, if batteries temperature rise, color change, or deformed, please stop using and replace with new battery.  The battery liquid is dangerous to human eyes. Please wash eyes with water immediately and go to hospital for further exam if the liquid is in eyes.  If the battery liquid is leaking or smelly, please remove it from fire to avoid explosion.  Please keep battery away from humidity. Humidity will cause over heat, corrosion of the batteries.  Please do not leave the battery in hot places such as in a car in summer as you will reduce the capacity and life time of the battery.  Please do not leave the battery on charger for over 24 hours 1.1.3 Charger & accessories  Please charge with dedicated voltage. Using mismatched power will damage the mobile phone and 4 charger.  Short circuit charger is forbidden. It will cause electric shock and damage the charger.  If the power line is damaged, please do not use the charger.  Please keep the charger free from dust all the time.  Keep charger away from liquid. Spilled liquid will dangerous the charger.  If charger has close contact with liquid, take off the charger from socket immediately to prevent further damage.  Do not modify or dismantle the charger. Unauthorized modify or dismantle will result in damaging the charger or personnel.  Please do not charge in humidity place. Humidity will cause over heat, corrosion of the batteries.  Do not touch the charger, power line or socket with wet hands. Doing so may give you an electric shock or damage the phone  Do not store heavy article on top of power line or dismantle it. Doing so will cause electric shock and fire.  Unplug the charger from socket before cleaning and maintenance.  Take the terminal to unplug the charger. Pulling the power line to unplug will damage the charger and cause electric shock or fire. 1.1.4 Cleaning & maintenance  Mobile phone, batteries and charger are not water proof. Please do not use them in humidity place such as shower room. Avoiding spilled by rain.  Clean mobile phone, batteries and charger with soft fabric. 5  Do not use harsh chemicals, cleaning solvents or strong detergents…
