2AC7IW110MOBILE PHONE

Interglobe Connection Corp
MOBILE PHONE - FCC ID 2AC7IW110 - Interglobe Connection Corp
Click to zoom

Application Details

Equipment Class
PCE - PCS Licensed Transmitter held to ear
Date of Grant
Oct 15, 2014
Application Purpose
Original Equipment
Date of Application
Oct 15, 2014
Equipment Note
MOBILE PHONE
Frequency Range
1850.20000000 - 1909.80000000
Company
Interglobe Connection Corp
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Interglobe Connection Corp MOBILE PHONE W110 ※FCC Statement ※1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: ※(1) This device may not cause harmful interference. ※(2) This device must accept any interference received, including interference that may cause undesired operation. ※2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. ※NOTE: ※This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. ※This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ※Reorient or relocate the receiving antenna. ※Increase the separation between the equipment and receiver. ※Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ※Consult the dealer or an experienced radio/TV technician for help. ※※SAR Information Statement ※Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for this model phone when tested for use at the ear is 1.349W/Kg and when worn on the body, as described in this user guide, is 0.517W/Kg(Body-worn measurements differ among phone models, depending upon available accessories and FCC requirements). While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure. The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/ oet/fccid after searching on ※FCC ID: 2AC7IW110 Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications Industry Asso-ciation (CTIA) web-site at http://www.wow-com.com. * In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a sub-stantial margin of safety to give additional protection for the public and to account for any variations in measurements. ※※Body-worn Operation ※This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 15mm must be maintained between the user's body and the handset, including the antenna. Third-party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an approved antenna.

External Photos

Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 38 of 49 8 EUT Constructional Details Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 39 of 49 Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 40 of 49 Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 41 of 49 Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 42 of 49

ID Label/Location Info

Label: Label尺寸:50*95mm label location: Label location

Internal Photos

Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 43 of 49 Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 44 of 49 Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 45 of 49 Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 46 of 49 Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 47 of 49 Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 48 of 49 Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 49 of 49 ------End of report------

RF Exposure Info

Shenzhen Zhongjian Nanfang Testing Co., Ltd. Report No: CCIS14090074501 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1 Cover Page FCC SAR REPORT Applicant: Interglobe Connection Corp Address of Applicant: 7500 NW 25 th Street 112 Miami, Florida 33122 USA Equipment Under Test (EUT) Product Name: MOBILE PHONE Model No.: W110 Trade mark EKO FCC ID: 2AC7IW110 Applicable standards: FCC 47 CFR Part 2.1093 Date of Test: 11 Sep., 2014 ~ 17 Sep., 2014 Test Result: Maximum Reported 1-g SAR (W/kg) Head: 1.349 Body: 0.517 Report No: CCIS14090074501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900745RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 2 of 116 2 Version Version No. Date Description 00 29 Sep., 2014 Original Prepared by: Date: 29 Sep., 2014 Report Clerk Reviewed by: Date: 30 Sep., 2014 Project Engineer Report No: CCIS14090074501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900745RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 3 of 116 3 Contents 1 COVER PAGE ....................................................................................................................................................... 1 2 VERSION ............................................................................................................................................................... 2 3 CONTENTS ........................................................................................................................................................... 3 4 SAR RESULTS SUMMARY ................................................................................................................................. 5 5 GENERAL INFORMATION .................................................................................................................................. 6 5.1 CLIENT INFORMATION ..................................................................................................................................................................... 6 5.2 GENERAL DESCRIPTION OF EUT ................................................................................................................................................... 6 5.3 MAXIMUM RF OUTPUT POWER ...................................................................................................................................................... 7 5.4 ENVIRONMENT OF TEST SITE ......................................................................................................................................................... 7 5.5 TEST LOCATION ............................................................................................................................................................................. 7 6 INTRODUCTION ................................................................................................................................................... 8 6.1 INTRODUCTION ............................................................................................................................................................................... 8 6.2 SAR DEFINITION ............................................................................................................................................................................ 8 7 RF EXPOSURE LIMITS ....................................................................................................................................... 9 7.1 UNCONTROLLED ENVIRONMENT ..................................................................................................................................................... 9 7.2 CONTROLLED ENVIRONMENT ......................................................................................................................................................... 9 7.3 RF EXPOSURE LIMITS .................................................................................................................................................................... 9 8 SAR MEASUREMENT SYSTEM ....................................................................................................................... 10 8.1 E-FIELD PROBE............................................................................................................................................................................ 11 8.2 DATA ACQUISITION ELECTRONICS (DAE) .................................................................................................................................... 11 8.3 ROBOT ........................................................................................................................................................…

Text truncated - open the document above for the full version.

Test Report

Shenzhen Zhongjian Nanfang Testing Co., Ltd. Report No: CCIS14090074401 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1. Cover Page FCC REPORT Applicant: Interglobe Connection Corp Address of Applicant: 7500 NW 25 th Street 112 Miami, Florida 33122 USA Equipment Under Test (EUT) Product Name: MOBILE PHONE Model No.: W110 Trade mark: EKO FCC ID: 2AC7IW110 Applicable standards: FCC CFR Title 47 Part 2 FCC CFR Title 47 Part22 Subpart H FCC CFR Title 47 Part24 Subpart E Date of sample receipt: 04 Sep., 2014 Date of Test: 06 Sep., to 28 Sep., 2014 Date of report issued: 29 Sep., 2014 Test Result: PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 2 of 49 2. Version Version No. Date Description 00 29 Sep., 2014 Original Prepared by: Date: 29 Sep., 2014 Report Clerk Reviewed by: Date: 29 Sep., 2014 Project Engineer Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 3 of 49 3. Contents Page 1. COVER PAGE .............................................................................................................................................................. 1 2. VERSION ....................................................................................................................................................................... 2 3. CONTENTS ................................................................................................................................................................... 3 4. TEST SUMMARY ......................................................................................................................................................... 4 5. GENERAL INFORMATION ........................................................................................................................................ 5 5.1 CLIENT INFORMATION ............................................................................................................................................ 5 5.2 GENERAL DESCRIPTION OF E.U.T. ....................................................................................................................... 5 5.3 TEST MODES .......................................................................................................................................................... 8 5.4 RELATED SUBMITTAL(S) / GRANT (S) .................................................................................................................... 8 5.5 TEST METHODOLOGY ............................................................................................................................................ 8 5.6 LABORATORY FACILITY .......................................................................................................................................... 8 5.7 LABORATORY LOCATION ....................................................................................................................................... 8 5.8 TEST INSTRUMENTS LIST ....................................................................................................................................... 9 6. SYSTEM TEST CONFIGURATION ........................................................................................................................ 10 6.1 EUT CONFIGURATION ......................................................................................................................................... 10 6.2 EUT EXERCISE .................................................................................................................................................... 10 6.3 CONFIGURATION OF TESTED SYSTEM ................................................................................................................ 10 6.4 DESCRIPTION OF TEST MODES ........................................................................................................................... 10 6.5 CONDUCTED OUTPUT POWER ............................................................................................................................ 11 6.6 OCCUPY BANDWIDTH .......................................................................................................................................... 14 6.7 MODULATION CHARACTERISTIC .......................................................................................................................... 20 6.8 OUT OF BAND EMISSION AT ANTENNA TERMINALS ..............................…

Text truncated - open the document above for the full version.

Test Setup Photos

Report No: CCIS14090074401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCIS140900744RF No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366 Page 37 of 49 7 Test Setup Photo Radiated Spurious Emission

Contact Information

Applicant

Emilio Dacaret
[email protected]3058781848Fax: 3056773295

Test Firm

Shenzhen Zhongjian Nanfang Testing Co.,LtdBruce Zhang
[email protected]86-755-23118282Fax: 86-755-23116366

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
224E1.85 GHz - 1.91 GHz45.91 mW244KGXW0.08 ppm
Confidentiality
Long Term
Grant Notes
Power listed is ERP for part 22 and EIRP for part 24. SAR compliance for body-worn operating conditions is restricted to belt clips, holsters or similar accessories that have no metallic component in the assembly and must provide a minimum separation distance of 1.5 cm between the device and the body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR values for head, body-worn accessory, and simultaneous transmission exposure conditions are 1.35 W/kg, 0.52 W/kg, and 1.56 W/kg, respectively. This device contains functions that are not operational in the U.S. Territories. This filing is only applicable for U.S. operations.
