2AC7TGAZEBO60WTent Sound

User’s Manual of Tent Sound System YUK-GAZEBO-60W Thank you for your choosingYUK-GAZEBO-60W, a stereo blue tooth tent sound system, and we provide you with detailed instructions so that you could have a better experience in the product, have knowledge of the relevant introductions of the product and its usage. Please carefully read the instruction before using it, where any error caused by printing or translation, please understand. I. Cautions Please carefully read and obey the below items so that you can properly use the player and ensure its good performance: z Don’t impact the main body of the device hard z Don’t get it exposed to the chemicals like benzene and diluting agent. z Don’t get it close to the intensive magnetic field and electric field z Please avoid the sunshine or heated appliances z Please don’t disassemble, repair or change the machine by yourself z Don’t listening to the music at a high volume so as to avoid the bad influence on your hearing II. Functions [Audio of blue tooth] Bluetooth V2.1+EDR, the maximum receiving distance is 10 meters [MP3 play] directly play the files of MP3 stored in the IT card [Input of audio] it has the interface of stereo audio and can readily achieve the connections with computer, digital player and cell phones [Breakpoint memory] automatically record the music you quit last time III. Remote control and its functional keys 1. //pause/play: Press it during the playing of blue tooth, it pauses; press it during its pause, it resumes playing 2. last music： press it during playing to switch into the last music 3. next music：press it during playing to switch into the next music 4. model key：Model switching: during the playing model of blue teeth, press it to switch into TF playing or AUX playing 5.Volume key ：Press “一”, the volume will be reduced while press “+”, the volume will be increased 6、“0----9”digital key ：Under the situation of TF playing, press any number and then it will switch into the corresponding music. 7、 the remote controller is a common series, this product does not support 100+, 200 + function. IV. Parameter of product Blue tooth specification: Bluetooth V2.1+EDR Transmitting distance: ≤10M (varies with the various environmental factors and the connected blue tooth equipment) Voltage: DC 24V Output power: 30W×2 Frequency response: 20Hz-20 KHz Sensitivity: 90db±2db Noise-signal ratio: ≥88dB Frequency performance: Full range V. Instructions for basic functions Model of turning on: when you turn on the sound box, it gives out the sound of toot and meanwhile, the two indicator lamps shine for around 2 seconds at the same time. Linking up with blue tooth: after turning on the sound system, it will automatically search for blue tooth and the blue indicator lamp of blue tooth shines fast; when you turn on your transmitting equipment of blue tooth, please click the link of available equipment, and then the blue indicator lamp in question keeps lighting and sound box shows the successful connection by giving out toot ; This device enjoys resuming function, namely, the equipment with successfully connection will automatically connect when restarting the blue tooth. Tips: if the device failed to be connected, please turn it off and restart it Music playing of blue tooth：after blue tooth is connected successfully, your device will direct play the music or switch into the playing model of blue tooth by pressing the key “ ” in the remote control, the blue indicator lamp of the blue teeth shines slowly, and then, the music will be perfectly shown in this device. During the playing, you press “ ” to pause, and then press “”, it will resume playing; press , the device will play the last music; press, it will play the next music. 1. In the model of blue tooth play, the operation of functions for the keys in the remote control depends on the their availabilities in the blue tooth transmitting device 2. Some cell phones don’t support the function of fade in and fade out, so when you pause the playing or switch the music, sometimes there is POP 3.he disconnected testing is not a real-time one, so when the sound box of blue teeth is off, the terminal of cell phone will be disconnected after a while. 4. For some cell phones, when you press within 3 seconds after it plays, it will go back to the initial position of the playing music, so you need to press the key twice to achieve the function of playing the last music. 5. Some domestic cell phones can only match but not be connected, as the software of the cell phone terminal needs to detect the hand-free device before connecting 6. Some cell phones don’t support the simple matching, for example, the one with Symbian system, you need to type into matching password 0000 when conducting it Playing of AUX audio: separately insert the audio wire supplied in the attachment into the interface of audio input and the ones of music players such as cell phone and computer, and then the red indicator lamp of AUX will be on ; as long as the player starts to work, the music will be played immediately, and the volume and music selection can be freely controlled by the player. Tips：Under the status of AUX“ 、、、、digit” will not work, and they are under the control of blue tooth transmitting device Music paly of TF card：After Inserting TF card into the groove, its red indicator lamp will be on and the player will automatically switch into the model of TF playing, and meanwhile, the red lamp will shine slowly. The way for key operation is the same as that of blue tooth. Press the digits from 0 to 9 to switch into the corresponding music; Tips：The music files stored in the TF must be the format of MP3, or they can not be player VI. Compatibility Based on the rank of CLASS 2 power, we employ the standard of Bluetooth V2.1+EDR, which is compatible with the applications of blue tooth 2.1 and its low versions, so the transmitting speed can be up to 3Mbit/s VII: the scope of use: The sound is suitable for being installed: Do…

Text truncated - open the document above for the full version.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City,Guangdong Province, China 2014-9-12 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AC7TGAZEBO60W We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: Licai Chen / R&D Manager address: 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City,Guangdong Province, China

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City,Guangdong Province, China 2014-9-12 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: 2AC7TGAZEBO60W Model: YUK-GAZEBO-60W Product name: Tent Sound Sincerely, signature : name / title: Licai Chen / R&D Manager address: 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City,Guangdong Province, China

.

Label location

Antenna location

FCC ID: 2AC7TGAZEBO60W Keyway Testing Technology Co., Ltd. Report No. 14KWE091877F Page 1 of 25 FCC TEST REPORT(Bluetooth) for Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. Tent Sound Model Number: YUK-GAZEBO-60W FCC ID: 2AC7TGAZEBO60W Prepared for : Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. Address : 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City, Guangdong Province, China Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 14KWE091877F Date of Test : Sep. 10~14, 2014 Date of Report : Sep. 15, 2014 FCC ID: 2AC7TGAZEBO60W Keyway Testing Technology Co., Ltd. Report No. 14KWE091877F Page 2 of 25 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY .......................................................................................................................... 4 2. GENERAL PRODUCT INFORMATION......................................................................................... 4 2.1. Product Function.................................................................................................................... 4 2.2. Description of Device (EUT) .................................................................................................. 4 2.3. Difference between Model Numbers...................................................................................... 4 2.4. Independent Operation Modes .............................................................................................. 4 2.5. Test Supporting System......................................................................................................... 4 3. TEST SITES .................................................................................................................................. 5 3.1. Test Facilities ......................................................................................................................... 5 3.2. List of Test and Measurement Instruments............................................................................ 6 4. TEST SET-UP AND OPERATION MODES .................................................................................. 7 4.1. Principle of Configuration Selection .......................................................................................7 4.2. Block Diagram of Test Set-up ................................................................................................ 7 4.3. Test Operation Mode and Test Software ............................................................................... 7 4.4. Special Accessories and Auxiliary Equipment ....................................................................... 7 4.5. Countermeasures to Achieve EMC Compliance.................................................................... 7 5. EMISSION TEST RESULTS ......................................................................................................... 8 5.1. Radiated Emission Test ....................................................................................................... 11 6. 20DB OCCUPY BANDWIDTH..................................................................................................... 17 6.1. Limits.................................................................................................................................... 17 6.2. Test setup ............................................................................................................................ 17 7. BAND EDGE COMPLIANCE TEST............................................................................................. 19 7.1. Limits.................................................................................................................................... 19 7.2. Test setup ............................................................................................................................ 19 8. ANTENNA REQUIREMENTS...................................................................................................... 20 8.1. Limits.................................................................................................................................... 20 8.2. Result................................................................................................................................... 20 9. PHOTOGRAPHS OF TEST SET-UP .......................................................................................... 21 10. PHOTOGRAPHS OF THE EUT............................................................................................... 23 FCC ID: 2AC7TGAZEBO60W Keyway Testing Technology Co., Ltd. Report No. 14KWE091877F Page 3 of 25 Keyway Testing Technology Co., Ltd. Applicant: Address: Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City, Guangdong Province, China Manufacturer: Address: Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City, Guangdong Province, China E.U.T: Tent Sound Model Number: YUK-GAZEBO-60W Trade Name: YUK Serial No.: ------ Date of Receipt: Sep. 10, 2014 Date of Test: Sep. 10~14, 2014 Test Specification: FCC Part 15, Subpart C Section 15.249: Oct. 1, 2013 ANSI C63.4:2009 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Sep. 15, 2014 Tested by: Reviewed by: Approved by: Jack Bu / Engineer Andy Gao / Supervisor Jade Yang/ Supervisor Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Test…

Text truncated - open the document above for the full version.

FCC ID: 2AC7TGAZEBO60W Keyway Testing Technology Co., Ltd. Report No. 14KWE091877F Page 1 of 25 FCC TEST REPORT(Bluetooth) for Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. Tent Sount Model Number: YUK-GAZEBO-60W FCC ID: 2AC7TGAZEBO60W Prepared for : Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. Address : 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City, Guangdong Province, China Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 14KWE091877F Date of Test : Sep. 10~14, 2014 Date of Report : Sep. 15, 2014 FCC ID: 2AC7TGAZEBO60W Keyway Testing Technology Co., Ltd. Report No. 14KWE091877F Page 2 of 25 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY .......................................................................................................................... 4 2. GENERAL PRODUCT INFORMATION......................................................................................... 4 2.1. Product Function.................................................................................................................... 4 2.2. Description of Device (EUT) .................................................................................................. 4 2.3. Difference between Model Numbers...................................................................................... 4 2.4. Independent Operation Modes .............................................................................................. 4 2.5. Test Supporting System......................................................................................................... 4 3. TEST SITES .................................................................................................................................. 5 3.1. Test Facilities ......................................................................................................................... 5 3.2. List of Test and Measurement Instruments............................................................................ 6 4. TEST SET-UP AND OPERATION MODES .................................................................................. 7 4.1. Principle of Configuration Selection .......................................................................................7 4.2. Block Diagram of Test Set-up ................................................................................................ 7 4.3. Test Operation Mode and Test Software ............................................................................... 7 4.4. Special Accessories and Auxiliary Equipment ....................................................................... 7 4.5. Countermeasures to Achieve EMC Compliance.................................................................... 7 5. EMISSION TEST RESULTS ......................................................................................................... 8 5.1. Radiated Emission Test ....................................................................................................... 11 6. 20DB OCCUPY BANDWIDTH..................................................................................................... 17 6.1. Limits.................................................................................................................................... 17 6.2. Test setup ............................................................................................................................ 17 7. BAND EDGE COMPLIANCE TEST............................................................................................. 19 7.1. Limits.................................................................................................................................... 19 7.2. Test setup ............................................................................................................................ 19 8. ANTENNA REQUIREMENTS...................................................................................................... 20 8.1. Limits.................................................................................................................................... 20 8.2. Result................................................................................................................................... 20 9. PHOTOGRAPHS OF TEST SET-UP .......................................................................................... 21 10. PHOTOGRAPHS OF THE EUT............................................................................................... 23 FCC ID: 2AC7TGAZEBO60W Keyway Testing Technology Co., Ltd. Report No. 14KWE091877F Page 3 of 25 Keyway Testing Technology Co., Ltd. Applicant: Address: Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City, Guangdong Province, China Manufacturer: Address: Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City, Guangdong Province, China E.U.T: Tent Sount Model Number: YUK-GAZEBO-60W Trade Name: YUK Serial No.: ------ Date of Receipt: Sep. 10, 2014 Date of Test: Sep. 10~14, 2014 Test Specification: FCC Part 15, Subpart C Section 15.249: Oct. 1, 2013 ANSI C63.4:2009 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Sep. 15, 2014 Tested by: Reviewed by: Approved by: Jack Bu / Engineer Andy Gao / Supervisor Jade Yang/ Supervisor Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Test…

Text truncated - open the document above for the full version.
