2AC7TMUBE06WUmbrella with musical sound

User’s Manual of Sound System for Musical Umbrella YUK-MUBE-06W Thank you for your choosingYUK-MUBE-06W, a stereo blue tooth tent, and we provide you with detailed instructions so that you could have a better experience in the product, have knowledge of the relevant introductions of the product and its usage. Please carefully read the instruction before using it, where any error caused by printing or translation, please understand. I. Cautions Please carefully read and obey the below items so that you can properly use the player and ensure its good performance: z Don’t impact the main body of the device hard z Don’t get it exposed to the chemicals like benzene and diluting agent. z Don’t get it close to the intensive magnetic field and electric field z Please avoid the sunshine or heated appliances z Please don’t disassemble, repair or change the machine by yourself z Don’t listening to the music at a high volume so as to avoid the bad influence on your hearing II. Functions e maximum receiving distance is 10 meters [Breakpoint memory] automatically record the music you quit last time [Stereo] perfectly show stereo music played by blue tooth equipment III. Parameter of product Blue tooth specification: Bluetooth V2.1+EDR Transmitting distance: ≤10M (varies with the various environmental factors and the connected blue tooth equipment) Voltage: DC 4.5V Output power: 3W×2 Frequency response: 20Hz-20 KHz Sensitivity: 90db±2db Noise-signal ratio: ≥88dB Frequency performance: Full range IV: Instructions for basic functions Model of turning on: when you turn on the sound box, it gives out the sound of toot and meanwhile, the indicator lamp shines for around 2 seconds. Linking up with blue tooth: after turning on the sound system, it will automatically search for blue tooth and the red indicator lamp of blue tooth shines fast; when you turn on your transmitting equipment of blue tooth, please click the link of available equipment, and then the red indicator lamp in question keeps lighting and sound box shows the successful connection by giving out toot ; This device enjoys resuming function, namely, the equipment with successfully connection will automatically connect when restarting the blue tooth. Tips: if the device failed to be connected, please turn it off and restart it Music playing of blue tooth: after blue tooth is connected successfully, your device automatically switch into the model of playing music in the blue tooth, its red light slowly shines and the music will be perfectly shown in this device. You can freely control over the volume of sound and the selection of music through the transmitting device of blue tooth Tips： 1. Some cell phones don’t support the function of fade in and fade out, so when you pause the playing or switch the music, sometimes there is POP 2. The disconnected testing is not a real-time one, so when the sound box of blue teeth is off, the terminal [Audio of blue tooth] Bluetooth 2.1+EDR, th of cell phone will be disconnected after a while. 3. Some domestic cell phones can only match but not be connected, as the software of the cell phone terminal needs to detect the hand-free device before connecting 4. Some cell phones don’t support the simple matching, for example, the one with Symbian system, you need to type into matching password 0000 when conducting it V: compatibility Based on the rank of CLASS 2 power, we employ the standard of Bluetooth2.1+EDR, which is nd its low versions, so the transmitting speed can be up to 3Mbit/s Six, the scope of use: The sound is suitable for being installed: Dongguan Xin Yi hardware plastic products Co., Ltd,production: Kmart: UM-15A031B/87008763227-9 music umbrella Sears music umbrella: UM-15A031B/20513 and the same structure of the sun umbrella. as follows： VII. Problems and solutions Phenomena Problem Solutions Failure of connection and matching for several times 1.Check whether the sound system is on the mode of search or turn on the device again 2. Too many blue tooth devices around the sound system lead to the difficulty in searching, please turn off other blue tooth devices. Low sound or sound distortion 1.Inspect the sound volume of blue tooth and adjust it at the proper position 2.Low voltage of power source Staccato music 1.Whether it is beyond the effective connecting distance of the sound system, or barriers exist between the sound box and blue tooth equipment The indicator lamp of blue tooth is not on 1. It means the low power source, please check it. 2. Restart the device. compatible with the applications of blue tooth 2.1 a FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City,Guangdong Province, China 2014-9-12 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: 2AC7TMUBE06W Model: YUK-MUBE-06W Product name: Umbrella with musical sound Sincerely, signature : name / title: Licai Chen / R&D Manager address: 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City,Guangdong Province, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City,Guangdong Province, China 2014-9-12 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AC7TMUBE06W We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: Licai Chen / R&D Manager address: 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City,Guangdong Province, China

Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City,Guangdong Province, China Sep 19, 2014 To: FCC From: Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. RE: Supersede request for FCC ID: 2AC7TMUBE06W , granted on Sep. 18 2014. Request to supercede label & manual. Grantee has requested to update the label and manual from the original. Sincerely, signature : name / title: Licai Chen / R&D Manager address: 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City,Guangdong Province, China

.

Label location

Antenna location

FCC ID: 2AC7TMUBE06W Keyway Testing Technology Co., Ltd. Report No. 14KWE091876F Page 1 of 23 FCC TEST REPORT(Bluetooth) for Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. Umbrella with musical sound Model Number: YUK-MUBE-06W FCC ID: 2AC7TMUBE06W Prepared for : Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. Address : 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City, Guangdong Province, China Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 14KWE091876F Date of Test : Sep. 10~12, 2014 Date of Report : Sep. 12, 2014 FCC ID: 2AC7TMUBE06W Keyway Testing Technology Co., Ltd. Report No. 14KWE091876F Page 2 of 23 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY .......................................................................................................................... 4 2. GENERAL PRODUCT INFORMATION......................................................................................... 4 2.1. Product Function.................................................................................................................... 4 2.2. Description of Device (EUT) .................................................................................................. 4 2.3. Difference between Model Numbers...................................................................................... 4 2.4. Independent Operation Modes .............................................................................................. 4 2.5. Test Supporting System......................................................................................................... 4 3. TEST SITES .................................................................................................................................. 5 3.1. Test Facilities ......................................................................................................................... 5 3.2. List of Test and Measurement Instruments............................................................................ 6 4. TEST SET-UP AND OPERATION MODES .................................................................................. 7 4.1. Principle of Configuration Selection .......................................................................................7 4.2. Block Diagram of Test Set-up ................................................................................................ 7 4.3. Test Operation Mode and Test Software ............................................................................... 7 4.4. Special Accessories and Auxiliary Equipment ....................................................................... 7 4.5. Countermeasures to Achieve EMC Compliance.................................................................... 7 5. EMISSION TEST RESULTS ......................................................................................................... 8 5.1. Radiated Emission Test ......................................................................................................... 8 6. 20DB OCCUPY BANDWIDTH..................................................................................................... 14 6.1. Limits.................................................................................................................................... 14 6.2. Test setup ............................................................................................................................ 14 7. BAND EDGE COMPLIANCE TEST............................................................................................. 16 7.1. Limits.................................................................................................................................... 16 7.2. Test setup ............................................................................................................................ 16 8. ANTENNA REQUIREMENTS...................................................................................................... 17 8.1. Limits.................................................................................................................................... 17 8.2. Result................................................................................................................................... 17 9. PHOTOGRAPHS OF TEST SET-UP .......................................................................................... 18 10. PHOTOGRAPHS OF THE EUT............................................................................................... 19 FCC ID: 2AC7TMUBE06W Keyway Testing Technology Co., Ltd. Report No. 14KWE091876F Page 3 of 23 Keyway Testing Technology Co., Ltd. Applicant: Address: Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City, Guangdong Province, China Manufacturer: Address: Dongguan City Rely Yunkang Plastic Electronic Technology Co., Ltd. 1st and 2nd floor,Fudu Industrial, Yu Town, Zhangmutou Town, Dongguan City, Guangdong Province, China E.U.T: Umbrella with musical sound Model Number: YUK-MUBE-06W Trade Name: YUK Serial No.: ------ Date of Receipt: Sep. 10, 2014 Date of Test: Sep. 10~12, 2014 Test Specification: FCC Part 15, Subpart C Section 15.249: Oct. 1, 2013 ANSI C63.4:2009 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Sep. 12, 2014 Tested by: Reviewed by: Approved by: Jack Bu / Engineer Jade Yang/ Supervisor Jade Yang/ Supervisor Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written …

Text truncated - open the document above for the full version.

Radiated Emission
