2AC9W-CMC181UHF Reader

UHF Reader User Manual 1 Quick Guide 1.1 Product introduction CMC181 is a high-performance UHF RFID reader, with complete proprietary intellectual property rights, supporting DRM (Dense Reader Mode) , excellent network stability ,especially suit for enterprise scale batch group application, can be widely applied to various RFID application systems such as SCM, Access control, anti-fake and shop floor control system and so on. Application:
Vehicle management
Customs clearance management
Storage and logistics management
Access control system
Shop floor control
Asset management Features ： ：： ：
Compliant with the EPC Class1 Gen2 (ISO18000-6C) ；
High scanning speed, up to 750 tags/s;
Extra scanning range, up to 12 m (adjustable, vary with antenna);
4 auto switch antenna ports can support 4 antennas in use simultaneously;
High reliability, aluminum out case, for the harsh work condition. Specifications ： ：： ： Specifications Protocol ISO18000（EPC Class1 Gen2） Operating Frequency US:902MHz～928MHz (standard) Europe:865MHz～868MHz China:920MHz～928MHz Working mode FHSS or fixed frequency with software settings Output power 5dBm～30dBm (1dBm step by software) RF interface Four TNC interfaces Communication interface RJ45 IO 2 ways relay output, 1 photoelectric isolated inputs Reading distance Maximum up to 12M Writing distance Maximum up to 3M Maximum length of EPC Maximum up to 496 bits Indicating lamp Power, inventory and four antennas Power adapter 12V/3A Power consumption Maximum up to 13W Physical parameters size 222mm*158.5mm*33.7mm weight 1.094kg Shell material Aluminum alloy Environmental parameters Working temperature -20°C～+50°C Storage temperature -40°C～+85°C Storage humidity 5%～95% no condensation 1.2 Function description for UHF reader ： ：： ： The top view for UHF reader ： ：： ： The side view for UHF reader ： ：： ： 1.3 The definition of IO port： ：： ： Symbol Function +12V +12V power output D02+ 2 ways output circuit D02- D01+ D01- DI+ 1 way input circuit DI- GND Power GND Icon show： ：： ： 1. The fixed screw holes 2. Ant port 3. Power lamp 4. Ant lamp 5. Inventory lamp 6. Icon show ： ：： ： 1. RJ45 2. I/O port 3. Power switch 4. Power interface 12V-OUT J11 CON8 1 2 3 4 5 6 7 8 DO2+ DI1+ DO2- DI1- DO1- DO1+ 1 1 1 1 2 3 4 5 1 2 3 4 1.4 Product size（ （（ （mm） ）） ） 1.5 Standard fittings Item Quantity Remark Mainframe 1 UHF reader Reticle 1 Standard line, 2M for standard Terminal 1 8 pin,3.96mm space between pins, green Power adapter 1 DC 12V/3A 1.6 Attention 1. Use standard power adapter of 12V/ 3A; 2. Non authorized person shall not change equipment, decompose and assembly, otherwise, it will cancel the warranty period; 3. Don’t put the equipment storage or installed in direct sunlight, high humidity, dew and other heat source place; 4. The cable’s length between ant and UHF reader should not exceed 10 meters. When the length is longer than two meters, you’d better use RF cable of low loss, or affecting the reading distance; 5. Electronic tag’s read-write distance is related to the gain of the antenna size, the angle between the tag and the antenna size, the labels on items related to such factors as the medium and the surrounding environment. So in practical application , please according to the site conditions to select the best match. 2 The Demo of use System frame for UHF reader ： ：： ： A whole RFID system consists of UHF reader, antenna and tag. The host sends reading and writing command to UHF reader through RJ45 interface. After receiving command, UHF reader sends a specific frequency electromagnetic wave to space by the antenna. When the tag goes into the magnetic field, the energy obtained from tag’s internal antenna will drive the tag circuit, whose internal information is sent. The UHF reader will accept and send the information to the host. The system frame’s sketch map is shown in figure 2.0: Figure2.0 system frame map 2.1 Presenter Name Specs Amount UHF reader 222mm*158.5mm*33.7mm 1 Reticle Standard cable 1 Circularly polarized antenna 225mm*225mm*39mm 1 Tag UHF some PC ／ 1 Power adapter DC 12V/3A 1 2.2 The software instructions on PC ： ：： ： 2.2.1 Working in TCP/IP mode 1. Connect one side of the electric supply with 12V power adapter, the other side of 12V power adapter connected with UHF reader. Connect cable of antenna with UHF reader, connected with PC by reticle. Then open power switch of UHF reader and PC. Electric supply 12Vpowera dapter UHF reader Ant RFID tag PC TCP/IP RF Cable 2. Double click “UHF Demo” on PC shown in figure 2.1, and you will go into figure 2.2. Figure 2.1 Figure 2.2 Icon show: Search: get devices’ IP Open: connect the device Close: disconnect the device Refresh: refresh the interface of the device Same line while Different antennas: add count Inventory Test: no add count, easy to long distant operation Language setting： ：： ： English/traditional Chinese Inventory display Data display 3. In Figure 2.2 ,select“ TCP/IP” and then click “search”, you will see Figure 2.3. Figure 2.3 Icon show Set Config: set device’s network parameters Get Config: get device’s network parameters Config: fill in network parameters including in IP, Mask and Gateway. 4. Click “OK” to get all UHF reader devices .You choose every device by clicking the MAC ,then click “Get Config” to gain device’s network parameters .After getting device’s network parameters ,you can fill in what you want to set ,then click “Set Config”. And click “open” to connect network, if success, UHF reader will show you “Init OK” and firmware version .UHF reader will automatically search corresponding ant port .see in Figure 2.4. Figure 2.4 1） ）） ） Inventory a. Pander data display option .You can select appropriate option, such as you’d better pander “Multiple lines while different antennas” with multi-ant ports. b. Make UHF tags dead against the center of the antenna. c. Click “Inventory” and “Inv Once”. Show you in Figure 2.5. d. Click “Stop” to complete inventory. Figure 2.5 2) Tag Operation…
