2ACB6-TT3002Attendant Ecosystem Pendant

Wireless Ecosystem Version 0.3, March 2014 Pendant User Guide Pendant User Guide The system locates a pendant alert Reset the alert Where can I use the Pendant? What do the status lights mean? Call for Help Push the “Help” button for 1 second. When you see the right red LED light blinking, the call was successfully sent. The nearest locator description will be displayed with the pendant alert both on the CMU and a pager. It may take around 12 seconds for the system to calculate the closest locator. Push and hold the “Help” button for 6 seconds. The both red LED lights will blink 3 times. The Pendant will work in the Alert Coverage Area set up during the system installation. The Pendant will NOT work if you leave the campus. Do not use the pendant in a shower or bath as it is not waterproof. Light Pattern Meaning Left Red LED blinks twice You have successfully completed adding the device wirelessly to the system Right Red LED blinks 3 times then blinks slowly An active alert has been successfully sent. The LED will blink for 3 minutes and then will stop blinking to preserve battery. Both Red LEDs blink 3 times after an alert has been sent You have successfully closed an active alert. HELP Button Status Lights Wireless Ecosystem Version 0.3, March 2014 Pendant User Guide Pendant User Guide FCC Statement FCC Part 15 ID: 2ACB6-TT3002 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/ TV technician for help This equipment complies with the FCC RF radiation exposure limits set forth for an uncontrolled environment. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

March 27, 2014 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR Pendant, 2ACB6-TT3002

February 21, 2014 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Short Term Confidentiality Request for Pendant, 2ACB6-TT3002

Direct Supply ® Attendant® Ecosystem TM Pendant Model: TT3002. Lot: 4xxx. SN: 4xxx-xxxxx. Conforms to UL STD 1069 and 2560 Numbering system: -Model: specified by Touchtown -Lot: indicates date of manufacture. 1 st digit indicates year (e.g., “4” = 2014), last 3 digits indicate day of year (e.g., “001” = Jan 1, “365” = Dec 31) -Serial number (SN): first 4 digits same as lot number , last 5 digits are unique sequential number, starting with 00001. 5/8/2014 1 3.1 Labels on Pendant Enclosure (TT100170) 3.1.1 Pendant Product Label Size: See spec on next page. 0.71” x 0.46” Color: white Printing: black Affixed by: Epic FCC ID: 2ACB6-TT3002 xxxxx Label layout to be rearranged after final ETL text is specified. TT100170 TOUCHTOWN CONFIDENTIAL INFORMATION. Phoenix Packaging and Label Spec, v1.11 Refer to installation instructions.

PRODUCT SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4GHz SMD on ground antenna SHEET No. B EC No: ABU2011-0104 1 of 5 DATE: 2011-05-16 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: PS-47948-001 Travis Zeng 2011-05-05 Amos Cheah 2011-05-05 Welson Tan 2011-05- 05 TEMPLATE FILENAME: PRODUCT_SPEC[SIZE_A4](V.1).DOC d TITLE 2.4GHz SMD On-ground Antenna TABLE OF CONTENTS 1.0 SCOPE 2.0 PRODUCT DESCRIPTION 3.0 APPLICABLE DOCUMENTS AND SPECIFICATIONS 4.0 RATINGS 5.0 PERFORMANCE 6.0 TEST GROUPINGS 7.0 RECOMMENDED REFLOW CONDITION 8.0 PACKING PRODUCT SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4GHz SMD on ground antenna SHEET No. B EC No: ABU2011-0104 2 of 5 DATE: 2011-05-16 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: PS-47948-001 Travis Zeng 2011-05-05 Amos Cheah 2011-05-05 Welson Tan 2011-05- 05 TEMPLATE FILENAME: PRODUCT_SPEC[SIZE_A4](V.1).DOC d 2.4GHz SMD On Ground Antenna 1.0 SCOPE This Product Specification covers the mechanical, electrical and environmental performances requirements and test methods for 2.4GHz SMD on ground antenna. 2.0 PRODUCT DESCRIPTION 2.1 PRODUCT NAME AND SERIES NUMBER 2.4GHz SMD on ground antenna 47948-**** 2.2 Design and Construction Antenna shall be of the design, construction and physical dimensions specified on the applicable sales drawing. 2.3 Materials a) Housing: Refer to respective Molex sales or engineering drawings b) Plating: Refer to respective Molex sales or engineering drawings 3.0 APPLICABLE DOCUMENTS AND SPECIFICATIONS See drawings and other sections of this specification for the relevant reference documents. In cases where the specification differs from the drawings, the drawings take precedence. 4.0 RATINGS 4.1 RF POWER 2 Watts 4.2 TEMPERATURE Operating: - 30°C to + 85°C Storage : - 40°C to + 85°C 4.3 HUMIDITY Storage : +15~70% RH Test : +80~95% RH PRODUCT SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4GHz SMD on ground antenna SHEET No. B EC No: ABU2011-0104 3 of 5 DATE: 2011-05-16 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: PS-47948-001 Travis Zeng 2011-05-05 Amos Cheah 2011-05-05 Welson Tan 2011-05- 05 TEMPLATE FILENAME: PRODUCT_SPEC[SIZE_A4](V.1).DOC d 5.0 PERFORMANCE 5.2 MECHANICAL REQUIREMENTS ITEM DESCRIPTION TEST CONDITION REQUIREMENT 5.2.1 Plating thickness measure Use X-ray measure the thickness of plating The plating thickness SPEC:Cu 12~16uM;Mid-P Ni 2~4uM;Au 0.1 ~0.2uM. 5.2.2 Cross cut Test Cross cut adhesion test Testing is performed in accordance with ASTM D-3359-93 acceptance criteria > 2B as acceptance, <35% peeling off. 5.3 RELIABILITY REQUIREMENTS ITEM DESCRIPTION TEST CONDITION REQUIREMENT 5.3.1 Peeling Force Apply six axial peeling force on parts soldered on the PCB at the speed rate of 25±3 mm/minute 8 N Min 5.3.2 Solderability testing Dip solder tails into the molten solder (held at 245+-5°C for 5s) Solder coverage: 95% Min. 5.1 ELECTRICAL REQUIREMENTS ITEM DESCRIPTION TEST CONDITION REQUIREMENT 5.1.1 Frequency Range Measure antenna on recommended PCB through VNA E5071C 2400MHz-2483.5MHz 5.1.2 Return Loss Measure antenna on recommended PCB through VNA E5071C < -9 dB 5.1.3 Peak Gain Measure antenna on recommended PCB through OTA chamber 3.0dBi 5.1.4 Avg. Total Efficiency Measure antenna on recommended PCB through OTA chamber >70% 5.1.5 Polarization Measure antenna through the OTA chamber Liner 5.1.6 Input Impedance Measure antenna on recommended PCB through VNA E5071C 50Ohms PRODUCT SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4GHz SMD on ground antenna SHEET No. B EC No: ABU2011-0104 4 of 5 DATE: 2011-05-16 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: PS-47948-001 Travis Zeng 2011-05-05 Amos Cheah 2011-05-05 Welson Tan 2011-05- 05 TEMPLATE FILENAME: PRODUCT_SPEC[SIZE_A4](V.1).DOC d The meaning of text “No mechanical damage” in the table above is: a. no soldering problem b. no adhesion problem of glue c. no peel off of plating 5.4 ENVIRONMENTAL REQUIREMENTS ITEM DESCRIPTION TEST CONDITION REQUIREMENT 5.4.1 Humidity Test 1.Test condition: The device under test is kept for 12 hours in an environment with a temperature of 55 degrees and a relating humidity of 95%. Thereafter for 12 Hours in an environment with a temperature of 25 degrees and a relative humidity of 95%. The cycle is repeated until a total of 6 cycles have been completed. Hereafter the conditions are stabilized at room temperature. 1) Parts should meet RF spec before and after test. 2） No cosmetic problem 5.4.2 Temperature cycling test 1.Test condition: The product temperature is decreased from room temperature to -40 degrees during 2 Hours and kept there for 2 hours. Then temperature is increased to 85 degree during 2 hours and kept for 2 hours. The temperature is then again decreased to -40 degrees during a 2- hours period. The cycle is repeated until a total of 6 cycles have been completed. Hereafter the conditions are stabilized at room temperature. 1) Parts should meet RF spec before and after test. 2） No cosmetic problem 5.4.3 Salt mist test 1.Test condition: The device under test is exposed to a spray of a 5% (by volume) resolution of Nacl in water for 2 hours. Thereafter the device under test is left for 1 week in room temperature at a relative humidity of 95%. The cycle is repeated until a total of 2 cycles have been completed. Here after the conditions are stabilized at room temperature. 1) Parts should meet RF spec before and after test. 2) No visible corrosion. Discoloration accept. 5.4.4 HNO3 Test General test condition 1) No corrosion. PRODUCT SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: 2.4GHz SMD on ground antenna SHEET No. B EC No: ABU2011-0104 5 of 5 DATE: 2011-05-16 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: PS-47948-001 Travis Zeng 2011-05-05 Amos Cheah 2011-05-05 Welson Tan 2011-05- 05 TEMPLATE FILENAME: PRODUCT_SPEC[SIZE_A4](V.1).DOC d 6.0 TEST GROUPINGS Note: All test specimens (except group 5) shall pass t…
