2ACEG-PR125Bluetooth OLED Activity Monitor

PR125 ‐‐‐‐ Bluetooth OLED Activity Monitor Using the Wrist band The PR125 is easy‐to‐use and simple to navigate. The PR125 works with Act2fit2 App, the app designed to help you track your fitness goals. Simply sync your wrist band data with the fitness app daily so you can review your STEPS, DISTANCE, CALORIES, EXERCISE TIMER, and TARGET GOAL, SLEEP MONITORING, Reminders such as Hydration reminder, Pill reminder, Move alert , Notifications, and monitor your activity for both day and night. PLEASE NOTE: the wrist band will automatically RESET at MIDNIGHT. At that time, the PREVIOUS DAY'S data will automatically be saved. The PR125 stores up to 30 days of activity so you can SYNC the wrist band & app at your convenience. Setting the wrist band Before you can set up your wrist band or transfer data from your wrist band to the fitness app, you need to install the FREE ACT2FIT2 App on your Bluetooth Smart Ready device. Search for the ACT2FIT2 App in iTunes. To provide you with the most accurate information, please set up all information requested in the App. Incorrect or missing information might result in inaccurate workout / activity recordings. Once all information is entered in the app, SYNC the data to your PR125 ‐ SIMPLE! Understanding the Data ESTIMATED CALORIES BURNED NOTE: The ESTIMATED CALORIES BURNED is based on an advanced 24‐hour calories burn formula: BASAL Metabolic Rate (BMR): This is the estimated amount of energy burned daily while you are at rest. Even as you sleep, your body burns energy (expressed in the form of calories). Therefore, when you wake up in the morning, the watch will already display a certain number of burned calories based on the BMR. You DO NOT have to wear the watch for the BMR to record; the BMR is based on a formula, not movement. EXERCISE: When you are wearing the wrist band, your steps + distance + calories + Exercise time will automatically record (based on your motion). Like all exercise routines, the more you walk the more calories you burn. You HAVE to wear the wrist band for the STEPS, DISTANCE & EXERCISE TIME to record; these are all based on movement. For BEST RESULTS, the wrist band should be worn 24/7. Target GOAL METER During your information set‐up (on the app), you will select a daily goal based on calories, steps OR distance. To help you track your daily goal, the % of the goal you have achieved in GOAL mode. WEAR the PR125 24/7 MONITOR daily activity on your watch & app: estimated calories burned, steps, distance and exercise (activity) time SYNC the wrist band data to the fitness app TRACK your goals and progress Battery Conservation Mode To conserve the battery, the display will become inactive after 5 seconds and enter into POWER SAVE MODE. To activate the screen, simply double‐tap the case or press any button to 'WAKE UP" the wrist band. Low Battery Warning Signs of failing / dying batteries are: XXXXXXXXXXXXXXXXXXXXXXXXXXXXxXXXXXXXXXXXXXXXX Xxx (to be explained by Dennis ) ????Once the word "LOW BATT" appears in the display, you will not be able to SYNC data from the watch to the app. (To be confirmed with Dennis. Charging the wrist band (Charging diagram from Cal) Your activity will continue to record on your watch for a limited time, so it is imperative that you have the battery charged to avoid losing your stored activity data. FCC information FCC 1. This Device complies with Part 15 of FCC Rules and Industry Canada License‐exempt RSS standard(s). Operation is subject to the following two conditions : 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation of the device. Note : Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 2. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. Water Resistance THIS WRIST BAND IS NOT WATERPROOF! IPX4 NOTE: Environments with steam or extremely high humidity levels could cause water damage. CAUTION: This WRIST BAND is only water resistant to a STATIC pressure of IPX4 and water damage will occur if you accidentally press a button under water. Please take extreme caution if you decide to wear the wrist band during water‐based activities or while bathing. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks is under license. Other trademarks and trade names are those of their respective owners. IPhone, iPod touch, iPad mini, Mac, iTunes and App Store are trademarks of Apple Inc., registered in the US & other countries. Warnings & Cautions WARNING: Before starting any exercise program, we strongly suggest that you visit your doctor for a complete physical and to discuss your exercise plans. PLEASE READ all information in this instruction manual before using this unit. This is NOT A MEDICAL DEVICE! NOTICE TO PEOPLE WEARING PACEMAKERS : While Bluetooth is a passive system and should have no direct effect on a pacemaker, we strongly recommend anyone fitted with such a device contact their physician or cardiologist before using this product or starting an exercise program. Please keep in mind; your wrist band is a sensitive technical instrument. With proper care and maintenance, it will last for many years. However, improper care and handling can cause the various sensors to be damaged and will harm the functioning capabilities. NEVER push the buttons under water, when the watch is wet or when you are cleaning or rinsing the unit. You are actually pushing water inside the wrist band. THE WRIST BAND IS NOT WATERPROOF. DO NOT use the wrist band i…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Organix Concept Ltd Aug 17, 2015 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Organix Concept Ltd hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product name: Bluetooth OLED Activity Monitor Model No.: PR125, PR121, PR134, PR140 FCC ID: 2ACEG-PR125 Sincerely, Client’s signature: Client’s name / title: Albert Ng/ Manager Contact information / address: Unit B, 10/F, Hyde Centre, 223 Gloucester Road, Wanchi, Hong Kong, China.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Organix Concept Ltd Aug 17, 2015 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACEG-PR125 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: Albert Ng/ Manager Contact information / address: Unit B, 10/F, Hyde Centre, 223 Gloucester Road, Wanchi, Hong Kong, China.

Organix Concept Ltd Date: Aug 17, 2015 Statement FCC ID: 2ACEG-PR125 Model number: PR125, PR121, PR134, PR140 We hereby state that these models are identical in interior structure, electrical circuits and components, and just model number is different for the marketing requirement. Your assistance on this matter is highly appreciated. Sincerely, Applicant’s complete, legal business name: Organix Concept Ltd. Applicant’s mailing address: Unit B, 10/F, Hyde Centre, 223 Gloucester Road, Wanchi, Hong Kong, China Applicant’s Contact Information: Sincerely, Client’s signature: Client’s name / title: Albert Ng/ Manager Contact information / address: Unit B, 10/F, Hyde Centre, 223 Gloucester Road, Wanchi, Hong Kong, China.

External photos

Label and Label location

Internal photos Antenna

FCC ID : 2ACEG-PR125 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 D01 General RF Exposure Guidance v05, section 4.3.1 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, 16 where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 17 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. The test was performed with Bluetooth V4.0 LE Frequency (MHz) Output Power (dBm) Output Power (mW) Target power (dBm) Calculation Value Threshold Value 2402 -1.46 0.71 -2 ± 2 0.31 3.0 2440 -0.47 0.90 -2 ± 2 0.31 3.0 2480 -2.14 0.61 -2 ± 2 0.31 3.0 Threshold at which no SAR required is ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required. SIMULTANEOUS TRANSMISSION EVALUATION N/A

Test Photos
