2ACEK-HYBRID2Tablet PC

1 1 Introduction 1.1 Acknowledgement Thanks for your purchase of our product. MR601 is high definition tablet PC. Its CPU is MT8312, which apply the Cortex-A7, dominant frequency is 1.2GHz, it is based on Android 4.2.2 operation system, and easy to expand the third application procedure. The product is designed with various functions, including WCDMA, WIFI, BT, GPS,FM, voice call and so on. It is easy to achieve wireless communication and internet, you have access to surf the internet anytime and anywhere; it is also built with high accuracy GPS module, so that it can be used for navigating through installing map software. There are many sensors which offer you brand-new operation and entertainment; besides, it has camera shooting, which leads electronic consumption to enter into a fresh palm internet entertainment time. The manual systemically introduces the functions, use techniques and announcements, please read this manual carefully before your operation. 1.2 Announcements Preventive maintainance z Please always keep the TABLET PC dry. To avoid the device short trouble, corrosion fault and electric short, please prevent the device, battery and charger from water and moisture, and don’t operate the device or charger by wet hand. z To avoid failure of device, battery and charger, please prevent the device, battery, charger from violent shock or shake. z To avoid failure of device, battery and charger, please prevent the device, battery, charger of all over heating or too cold circumstance z Never shock, throw, prod the TABLET PC, or drop, extrude, bend the TABLET PC. z Never disassemble the device and accessories arbitrarily, otherwise the device and accessories are not in our company warranty scope. 2 1.3 Safety Instruction Before the operation of the TABLET PC, please read this chapter and teach your kids about these information. For further details, please refer to the safety instructions and announcement. z Never use the TABLET PC when driving car, in order to ensure safe driving. z In the medical area, please abide by related rules and regulations. Please shut down the TABLET PC when it is near to the medical area. z To avoid the wireless signal to interrupt the plane- controlled signal, please shut down the TABLET PC or using airplane mode when you are boarding a flight, z To avoid electronic equipment failure, please shut down the TABLET PC in the vicinage of high-accuracy electronic equipments. z Please don’t disassemble the TABLET PC and accessories. Only authorized agent has access to service the TABLET PC. z Please keep the TABLET PC far away from magnetic equipments, the radiation of TABLET PC may erase the data stored in the magnetic equipments. z Never use the TABLET PC in the vicinage of high temperature, inflammable gas ( gas station). z Protect the TABLET PC and accessories from kids reach scope, and avoid the kids to use the TABLET PC without parents’ supervision. z Please comply with related rules and regulations, and respect others’ privacy and legal rights while using the TABLET PC. z Please strictly adhere to related instructions in the manual when using USB cable to ensure the safety of the TABLET PC or PC. z Never use the TABLET PC in bathroom or other huTablet PC environment, and please protect the TABLET PC from liquid wash or wet. 3 2 TABLET PC Introduction 2.1 TABLET PC Operation and Preparation Battery Charging If this navigator is first used, please use AV adaptor to fully charge it. 1. Apply the power adptor to charge for TABLET PC. 2.2 TABLET PC Status and Reminder Reminder icons When some remind message appears in your reminder window, please click column and slip the screen to open the reminder list. Choose the menu you need, and confirm the information. Then you can close the reminder window through clicking the column to slide up. Please refer to below status icons: New email Airplane Mode on USB connected USB debugging connected Return button Downloading Current electric volume. Home button WIFI connected, internet is available 4 Reminder board Reminder icons will work while receiving emails, WIFI is open, you can open the reminder board to view the detailed information. Open the reminder board When the reminder column shows new reminder icon, please hold the column and slip down your finger, then the reminder board is opened. 5 3 Quick Start Guide 3.1 Keys Function Keys Funcction Description： Power button Short press to sleep/wake up, long press to startup and shutdown. Vo l u m e +（up） increase the volume Vo l u m e -（down） decrease the volume HOME button （home） Click it in any interface will return to main interface. Back button（back） click it in any interface will return to previous menu Menu button This button will display in menu interface. Setting button display recently browsed history 3.2 Startup and Shutdown Startup Long press POWER key for three seconds, you can enter into startup picture. The system enters into screen lock status, please unlock it. Shutdown 1． Long press POWER, it will popoup shutdown window. 2． Shutdowm window contains mute mode, airplane mode,reboot mode and shutdown four options. 3． Click Shutdown is the last step. 3.3 Open and Close of the Screen Screen will be closed on its own when no operation happens. 1. Screen will be closed on its own if no operation happens for some time to save battery 6 power 2. When screen is open, press POWER key, the screen will be closed immediately. Open the screen when it is closed. If the screen is closed, short press POWER to open the screen. The screen will be locked open it, it will show the picture as below picture, left slide to unlock and enter into camera, right slide the unlock icon to unlock the screen. Picture 3.1 3.4 Usage of Touch Screen TABLET PC operating methods There are below methods to view the main screen, menu and application procedure in your TABLET PC. Click When you want to use the screen keyboard typing or choose application in the main interface, you only need…

Text truncated - open the document above for the full version.

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 South Holdings Industrial ltd. SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2014/6/3 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, __ South Holdings Industrial ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： Tablet PC Trade Name： N/A Model Name： M600 Serial Model： MXXX (XXX in the model designation may be any alphanumeric characters denoting different configuration options) FCC ID： 2ACEK-HYBRID2 We affirm that between SIEMIC and ___ South Holdings Industrial ltd. ____ , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Name: lu chunyan Title : Manager Address: Building 1,Hao’er Jiashitai Industrial Park,Fengtang Rd., Tangwei, Fuyong Town,Bao’an District,Shenzhen,China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 South Holdings Industrial ltd. 2014/6/3 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACEK-HYBRID2 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - BOM - Tune up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Name: lu chunyan Title : Manager Address: Building 1,Hao’er Jiashitai Industrial Park,Fengtang Rd., Tangwei, Fuyong Town,Bao’an District,Shenzhen,China

South Holdings Industrial ltd. Model Difference FCC ID: 2ACEK-HYBRID2 Model : M600, MXXX (XXX in the model designation may be any alphanumeric characters denoting different configuration options) All the model are the same circuit and RF module,except the model name and colour.Regards, Client’s signature Name: lu chunyan Title : Manager Address: Building 1,Hao’er Jiashitai Industrial Park,Fengtang Rd., Tangwei, Fuyong Town,Bao’an District,Shenzhen,China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label Tablet PC Model NO.: M600 Input Rating: DC 5V/ 2000mA FCC ID: 2ACEK-HYBRID2 South Holdings Industrial ltd. Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 GSM/WCDMA ANT WIFI/BT ANT Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10

Page 1 of 21 Report No.: NTEK-2014NT0507682F3 FCC Test Report FCC ID: 2ACEK-HYBRID2 Product： Tablet PC Trade Name： N/A Model Number： M600 Serial Model： MXXX (XXX in the model designation may be any alphanumeric characters denoting different configuration options) Report No.： NTEK-2014NT0507682F3 Prepared for South Holdings Industrial ltd. Building 1,Hao’er Jiashitai Industrial Park,Fengtang Rd., Tangwei, Fuyong Town,Bao’an District,Shenzhen,China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website: www.ntek.org.cn Page 2 of 21 Report No.: NTEK-2014NT0507682F3 TEST RESULT CERTIFICATION Applicant’s name................. : South Holdings Industrial ltd. Address ................................. : Building 1,Hao’er Jiashitai Industrial Park,Fengtang Rd., Tangwei,Fuyong Town,Bao’an District,Shenzhen,China Manufacturer's Name.......... : South Holdings Industrial ltd. Address ................................. : Building 1,Hao’er Jiashitai Industrial Park,Fengtang Rd., Tangwei,Fuyong Town,Bao’an District,Shenzhen,China Product description Product name ........................... : Tablet PC Model and/or type reference : M600 Standards............................. : FCC Part15B:2013 ANSI C63.4:2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with Part 15 of FCC Rules. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test............................................: Date (s) of performance of tests .............: 07 May 2014 ~27 May 2014 Date of Issue...........................................: 27 May 2014 Test Result...............................................: Pass Testing Engineer : (Apple Huang) Technical Manager : (Brown Lu) Authorized Signatory : (Bill Yao) Page 3 of 21 Report No.: NTEK-2014NT0507682F3 Table of Contents Page 1 . TEST SUMMARY 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST SETUP 8 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 9 2.4 MEASUREMENT INSTRUMENTS LIST 10 3 . EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION 11 3.1.2 TEST PROCEDURE 12 3.1.3 TEST SETUP 12 3.1.4 EUT OPERATING CONDITIONS 12 3.1.5 TEST RESULTS 13 3.2 RADIATED EMISSION MEASUREMENT 15 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 15 3.2.2 TEST PROCEDURE 15 3.2.3 TEST SETUP 16 3.2.4 EUT OPERATING CONDITIONS 16 3.2.5 TEST RESULTS 17 3.2.6 TEST RESULTS(Above 1GHz) 19 4 . EUT TEST PHOTO 20 Page 4 of 21 Report No.: NTEK-2014NT0507682F3 1. TEST SUMMARY Test procedures according to the technical standards: EMC Emission Standard Test Item Limit Judgment Remark Conducted Emission Class B PASS FCC Part15B:2012 ANSI C63.4: 2003 Radiated Emission Class B PASS NOTE: (1) ’N/A’ denotes test is not applicable in this Test Report (2) For client’s request and manual description, the test will not be executed. Page 5 of 21 Report No.: NTEK-2014NT0507682F3 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration Number:238937; IC Registration Number:9270A-1 CNAS Registration Number:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %. A. Conducted Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE NTEKC01 ANSI150 KHz ~ 30MHz 3.2 B. Radiated Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE NTEKA01 ANSI30MHz ~ 1000MHz 4.7 1GHz ~6GHz 5.0 Page 6 of 21 Report No.: NTEK-2014NT0507682F3 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Tablet PC Model Name M600 Additional Model Number(s) MXXX (XXX in the model designation may be any alphanumeric characters denoting different configuration options) Model Difference All the model are the same circuit and RF module, except the model name and colour. Product Description The EUT is a Tablet PC . Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Connecting I/O port: USB Power Source DC Voltage Adapter Model:JY-05200 Input: 100-240V~,50/60Hz,0.3A Output: 5.0V , 2A Battery DC 3.7V, 2600mAh,19.62Wh Page 7 of 21 Report No.: NTEK-2014NT0507682F3 2.1.1 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 Downloading For Conducted Test Final Test Mode Description Mode 1 Downloading For Radiated Test Final Test Mode Description Mode 1 Downloading Page 8 of 21 Report No.: NTEK-2014NT0507682F3 2.2 DESCRIPTION OF TEST SETUP C-1 E-1 EUT E-2 Notebook E-3 Keyboard C-2 E-4 Mouse AC Plug C-3 E-5 Printer C-4 Page 9 of 21 Report No.: NTEK-2014NT0507682F3 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration duri…

Text truncated - open the document above for the full version.

Page 20 of 21 Report No.: NTEK-2014NT0507682F3 4. EUT TEST PHOTO Radiated Measurement Photos Page 21 of 21 Report No.: NTEK-2014NT0507682F3 Conducted Measurement Photos
