User guide User guide English 288010 cover.indd 230/09/2015 1:55:25 PM 288010 cover.indd 330/09/2015 1:55:25 PM English 1 ENGLISH Welcome The AirCurve ™ 10 ST-A is a bilevel positive airway pressure device. WARNING Read this entire guide before using the device. CAUTION In the US, Federal law restricts this device to sale by or on the order of a physician. Indications for use AirCurve 10 ST-A The AirCurve 10 ST-A device is indicated to provide non-invasive ventilation for patients weighing more than 30 lb (13 kg) or more than 66 lb (30 kg) in iVAPS mode with respiratory insufficiency or obstructive sleep apnea (OSA). It is intended for home and hospital use. The humidifier is intended for single patient use in the home environment and re-use in a hospital/institutional environment. Contraindications Positive airway pressure therapy may be contraindicated in some patients with the following pre-existing conditions:  severe bullous lung disease  pneumothorax or pneumomediastinum  pathologically low blood pressure, particularly if associated with intravascular volume depletion  dehydration  cerebrospinal fluid leak, recent cranial surgery, or trauma. Adverse effects You should report unusual chest pain, severe headache, or increased breathlessness to your prescribing physician. An acute upper respiratory tract infection may require temporary discontinuation of treatment. The following side effects may arise during the course of therapy with the device:  drying of the nose, mouth, or throat  nosebleed  bloating  ear or sinus discomfort  eye irritation  skin rashes. 2 At a glance The AirCurve 10 ST-A includes the following:  Device  HumidAir ™ humidifier (if supplied)  Air tubing  Power supply unit  Travel bag  SD card (already inserted). Contact your care provider for a range of accessories available for use with the device including:  Air tubing (heated and non-heated): ClimateLineAir ™ , ClimateLineAir Oxy, SlimLine ™ , Standard  HumidAir humidifier  Side cover for use without the humidifier  Filter: Hypoallergenic filter, standard filter  Air10 ™ DC/DC converter (12V/24V)  SD card reader  Air10 oximeter adapter  Air10 USB adapter  Power Station II  Air10 tubing elbow English 3 About your device 1 Air outlet 6 HumidAir humidifier 2 Air filter cover 7 Screen 3 Retention clip 8 Adapter cover 4 Power inlet 9 SD card cover 5 Serial number and device number 10 LED alarm indicator About the control panel Start/Stop button Press to start/stop therapy. Press and hold for three seconds to enter power save mode. Dial Turn to navigate the menu and press to select an option. Turn to adjust a selected option and press to save your change. Home button Press to return to the Home screen. Different icons may be displayed on the screen at different times including: Ramp Time Wireless signal strength (green) Humidity Wireless transfer not enabled (grey) Humidifier warming No wireless connection Humidifier cooling Airplane Mode Alarm muted 4 Setup CAUTION Do not overfill the humidifier as water may enter the device and air tubing. 1. With the device on a stable level surface, grip the retention clip on the back of the device and pull up to open. Note: The retention clip is shown in the open position. 2. (a) Plug the power connector into the device power inlet then (b) push down the retention clip to secure in place. Connect one end of the power cord into the power supply unit and the other end into the power outlet. 3. Connect the air tubing firmly to the air outlet located on the rear of the device. 4. Open the humidifier and fill it with water up to the maximum water level mark. Do not fill the humidifier with hot water. 5. Close the humidifier and insert it into the side of the device. 6. Connect the free end of the air tubing firmly onto the assembled mask. See the mask user guide for detailed information. Recommended masks are available on www.resmed.com. Note: Ensure the device is placed so that the LED alarm indicator is clearly visible. English 5 Starting therapy 1. Fit your mask. 2. Press Start/Stop or breathe normally if SmartStart ™ is enabled. You will know that therapy is on when the Monitoring screen is displayed. The pressure bar shows the inspiratory and expiratory pressures in green. The green bar will expand and contract as you breathe in and out. The screen will go black automatically after a short period of time. You can press Home or the dial to turn it back on. If power is interrupted during therapy, the device will automatically restart therapy when power is restored. The AirCurve 10 ST-A device has a light sensor that adjusts the screen brightness based on the light in the room. Stopping therapy 1. Remove your mask. 2. Press Start/Stop or if SmartStart is enabled, therapy will stop automatically after a few seconds. Note: If Confirm Stop is enabled, a message is displayed asking if you want to stop therapy. Turn the dial to select Yes and then press the dial to stop therapy. Once therapy has stopped, the Sleep Report gives you a summary of your therapy session. Usage hours –Indicates the number of hours of therapy you received last session. Mask Seal–Indicates how well your mask sealed: Good mask seal. Needs adjusting, see Mask Fit. Humidifier–Indicates if your humidifier is working properly: Humidifier working. Humidifier might be faulty, contact your care provider. If set by your care provider, you will also see: Events per hour–Indicates the number of apneas and hypopnoeas experienced per hour. More Info–Turn the dial to scroll down to view more detailed usage data. 6 Power save mode Your AirCurve 10 ST-A device records your therapy data. In order to allow it to transmit the data to your care provider, you should not unplug the device. However, you can put it into power save mode to save electricity. To enter power save mode:  Press and hold Start/Stop for three seconds. The screen goes black. To exit power save mode:  Press Start/Stop once. The Home sc…
