2ACJF-EXT-D2260GD2260G

ALTICE LABS MANUAL Smart Wi-Fi User Manual D2260G Version 1.3 | 2020 -08 Q_PDS_DM_09_V1.2 Smart Wi-Fi User Manual 3 Document’s version history Document’s version hist ory Ver sion Dat e Aut hor Des cription 1.3 25 -08 -2020 Manuel Veríssimo Initial version Q_PDS_DM_09_V1.2 4 Copyright © Altice Labs, S.A. All rights reserved. This document contains proprietary information belonging to Altice Labs which is legally protected by copyright and industrial property rights and, as such, may not be copied, photocopied, reproduced, translated or converted into electronic format, either partially or in its entirety, without prior written permission from Altice Labs. Nothing in this document shall be construed or interpreted as the granting of a license to make use of any software, information or products referred to in the document. This document is for information purposes only and does not constitute a legally binding offer. The communication of the information contained in this document shall not oblige Altice Labs to supply the products and services identified and described herein. Altice Labs reserves the right to effect changes to this document, at any time and without prior notice, and may not be held responsible for any inaccuracy in, or obsolescence of, the information, or for any losses or damage that may be incurred as a result of the use of the information. Altice Labs Rua Eng. José Ferreira Pinto Basto 3810 -106 Aveiro – Portugal http://www.alticelabs.com Tel: +351 234 403 200 Fax: +351 234 424 723 Q_PDS_DM_09_V1.2 Smart Wi-Fi User Manual 5 Contents Contents Document’s version history ......................................................................................................... 3 List of figures ............................................................................................................................... 7 Glossary ...................................................................................................................................... 9 1 Introduction ........................................................................................................................... 11 1.1 What is Mesh ................................................................................................................... 11 1.2 Features .......................................................................................................................... 12 2 System objectives ................................................................................................................ 15 2.1 Management features ..................................................................................................... 15 2.1.1 Customer .................................................................................................................. 15 2.1.2 Operator ................................................................................................................... 15 3 Smart Extender ..................................................................................................................... 17 3.1 INTERFACES, LEDS AND BUTTONS ........................................................................... 17 3.1.1 LEDS AND BUTTONS ............................................................................................. 18 3.2 Te chnical Specifications .................................................................................................. 20 3.2.1 Wi -Fi ......................................................................................................................... 21 3.2.2 Standards ................................................................................................................. 22 3.3 Get Smart Wi-Fi up and running ..................................................................................... 24 3.3.1 Package content ...................................................................................................... 24 3.3.2 PUT THE Smart Wi-Fi IN OPERATION ................................................................... 24 3.3.2.1 Power on ........................................................................................................... 24 3.3.2.2 Shut down ......................................................................................................... 25 3.3.3 PUT THE SMART MESH IN Wi-Fi NETWORK ....................................................... 25 4 User interface ....................................................................................................................... 26 4.1 Mobile application initial screen ...................................................................................... 26 4.2 Login ................................................................................................................................ 27 4.3 Initial Setup ...................................................................................................................... 27 4.3.1 Change name or password ...................................................................................... 28 4.3.2 Ready to Smart Wi-Fi ............................................................................................... 28 4.3.3 Add extender ............................................................................................................ 29 4.3.4 Find a place for extender ......................................................................................... 29 4.3.5 Good place for extender .......................................................................................... 30 4.3.6 Plug your extender ................................................................................................... 30 4.3.7 Connect the extender ............................................................................................... 31 4.3.8 Name your extender ...........................................................................................…

Text truncated - open the document above for the full version.

Confidentiality Request Letter Date: August 26, 2020 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Att: OET Department FCC ID: 2ACJF-EXT-D2260G Regarding FCC Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request long-term confidential treatment of the followig information: Block Diagrams Schematics Operational Description _____________________________ (Signature) Ricardo Cunha Altice Labs (Registered Grantee)

Date: Wednesday, August 26, 2020 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Rd. Columbia MD 21046 Ref: Agent letter for FCC ID: 2ACJF-EXT-D2260G We, Altice Labs, S.A. Rua Eng Jose Ferreira Pinto Basto Aveiro, 3810-106, Portugal hereby authorize, DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía Severo Ochoa, 2 & 6 29590, Málaga, Spain Agent: Álvaro Corrales Sedeño e-mail: [email protected] Phone: +34 952 619 198 to act as our agent in the preparation of this application for equipment certification, including the signing of all documents relating to these matters. We also hereby certify that neither we nor any party to this application are subject to a denial of U.S. Federal benefits, which include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862 because of conviction for possession or distribution of controlled substance. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by DEKRA Testing and Certification, S.A.U., still resides with us. This agreement expires one year from the current date. Sincerely, By: Ricardo Cunha Title: Telecom Engineer Company: Altice Labs, S.A. Telephone: +351234403200 e-mail: [email protected]

FCB034_00 //DEKRA Testing and Certification, S.A.U. // www.dekra-product-safety.com/wireless December 3rd 2020 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía C/ Severo Ochoa 2 & 6 29590 Campanillas Málaga, España Ref: sDoC declaration letter for equipment with FCC ID: 2ACJF-EXT-D2260G Pursuant to §15.101 of the Commission’s Rules (47 C.F.R.), Altice Labs, S.A. hereby declare that the device above mentioned is classified under the following equipment class/classes: JAB Part 15 Class B Digital Device JAD Part 15 Class A Digital Device JAV Other Non-Digital SDoC Devices JBP Part 15 Class B Computing Device/Personal Computer JBC Part 15 Class B Computing Device/Personal Computer CXX Communications Rcvr for use w/ licensed Tx and CBs CRR Superregenerative Receiver CYY Communications Receiver used w/Pt 15 Transmitter HID Part 15 TV Interface Device And will follow the Authorization procedure Supplier’s Declaration of Conformity prior to the initiation of marketing. Sincerely, Pa __________________________ By: Ricardo Cunha Title: Telecom Engineer Company: Altice labs, S.A. Telephone: +351234403200 e-mail: [email protected]

i l AUSA PN: 44275 MAC: XXXXXXXXXXXX S/N: XXXXXXXXXXX D2260G XXX-X MM/YYYY Assembled in Vietnam FCC ID: 2ACJF-EXT-D2260G xxxx FCC ID: 2ACJF-EXT-D2260G 被贴物表面(在对应的方格填充黑色)： 塑料面 塑料弧面铁机壳面/金属面 光油\覆膜彩盒 牛皮彩盒90度折角封口电源线180度对折角 电源/PLC产品高温其它() 牛皮盒\外箱光油彩盒90度折角封口 1.黑色印刷,无边框,R4 (Black printing,no frame,R4) 2.材料: 100#亮白PET,UV油墨,背胶 (Material:100# bright white PET, with UV ink,adhesive) 3.原材料及后处理工艺均能满足我司《环保技术标准》要求. (Raw materials and the corresponding post processing should meet requirements defined in the T&W Environmental Protection Technical Standards) 54mm 22mm i R4mm l 2mm 根据生产信 息发布流程 发布 MM/YYYY 型号，固定 MAC地址，SN由客户提供或见生产信息发布流程 打印字体：Calibri,标示的为粗体 硬件版本 硬件版本: 硬件版本取生产信息发布流程客户数据Model-HW revision列的值 例如： 条码类型：QR CODE 扫描显示：MAC空格SN(单行显示） MM:月份 YY:年 例如：2020年1月 01/2020 0 -0.2 0 -0.2 AUSA PN: 44275AUSA PN: 44275 MAC: XXXXXXXXXXXX MAC: XXXXXXXXXXXX S/N: XXXXXXXXXXX MAC: XXXXXXXXXXXX S/N: XXXXXXXXXXX MAC: XXXXXXXXXXXX S/N: XXXXXXXXXXX D2260G XXX-X MM/YYYY Assembled in Vietnam Calibri Light 4pt Label Specifications 贴纸尺寸：宽54mm*高22mm 材 质：100#亮白PET ( 贴纸）,UV油墨， 背胶 DR3010X_SN+MAC_Label_v1 DR3010X Ver 1 2020.8.7 100%Adobe Illustrator CC 2018 W05-1 FCC ID: 2ACJF-EXT-D2260G xxxx 贴于此处 变量，根据实际生产信息打印 Provided by label supplier Print following contents based on what supplier provides

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 64682RAN.001 2020-12-09 Test report No: NIE: 64682RAN.001 Assessment report RF EXPOSURE REPORT ACCORDING TO FCC 47 CFR Part 2.1091 (*) Identification of item under evaluation Wi-Fi Extender (*) Trademark Altice Labs (*) Model and /or type reference D2260G (*) Other identification of the product HW version: PCB1481 SW version: 1.6.x FCC ID: 2ACJF-EXT-D2260G (*) Features Dual Band Wi-Fi 802.11bgnax (2x2) / anacax (4x4) + 2 Ethernet Gigabit (*) Applicant Altice Labs Rua Eng. José Ferreira Pinto Basto, 3810-106 Aveiro Portugal Test method requested, standard FCC 47 CFR Part 2.1091 Radiofrequency radiation exposure evaluation: mobile devices. Summary IN COMPLIANCE Approved by (name / position & signature) Miguel Lacave Antennas Lab Manager Date of issue 2020-12-09 Report template No FAN36_02 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 64682RAN.001 Page 2 of 9 2020-12-09 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Data provided by the client .......................................................................................................... 3 Identification of the client............................................................................................................. 3 Document history ........................................................................................................................ 3 Appendix A: FCC RF Exposure ................................................................................................... 4 General description of the device under evaluation ................................................................ 5 RF Exposure Assessment result and verdict .......................................................................... 6 Appendix B: FCC RF Exposure information ................................................................................ 7 RF Exposure evaluation for mobile devices ............................................................................ 8 MPE Evaluation ...................................................................................................................... 9 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 64682RAN.001 Page 3 of 9 2020-12-09 Competences and guarantees In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification, S.A.U. has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification, S.A.U. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification, S.A.U. at the time of performance of the test. DEKRA Testing and Certification, S.A.U. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Assessment Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification, S.A.U. General conditions 1. This report is only referred to the item that has undergone the assessment. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification, S.A.U. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification, S.A.U. and the Accreditation Bodies Data provided by the client The following data has been provided by the client: 1. Information relating to the description of the sample ("Identification of the item tested", "Trademark", "Model and/or type reference tested", “General description of the device”). 2. Maximum antenna gain and use distance information. DEKRA Testing and Certification S.A.U. declines any responsibility with respect to the information provided by the client and that may affect the validity of results. Identification of the client Altice Labs Rua Eng. Ferreira Pinto Basto, 3810-106 Aveiro Portugal Document history Report number Date Description 64682RAN.001 2020-12-09 First release DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 64682RAN.001 Page 4 of 9 2020-12-09 Appendix A: FCC RF Exposure assessment result DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 64682RAN.001 Page 5 of 9 2020-12-09 General description of the device under evaluation The device under evaluation consists of a dual band Wi-Fi 6 mesh extender device. According to the manufacturer, during its normal use, the separation distance between the radiating structures of the device and nearby users will be grea…

Text truncated - open the document above for the full version.

Report No：2070873R-E3032110114 Page: 1 of 280 FCC Test Report Product Name ： DUAL BAND WI-FI 6 MESH EXTENDER DEVICE Trade Name ： ALTICE, ALTICE LABS Model No. ： D2260G FCC ID ： 2ACJF-EXT-D2260G Applicant ： Altice Labs, S.A. Address ： Rua Eng. Ferreira Pinto Basto, 3810-106, Aveiro, Portugal Date of Receipt：Jul. 23, 2020 Issued Date ：Dec. 10, 2020 Report No. ：2070873R-E3032110114 Report Version ：V2.0 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of DEKRA Testing and Certification Co., Ltd.. Report No：2070873R-E3032110114 Page: 2 of 280 Test Report Certification Issued Date : Dec. 10, 2020 Report No.: 2070873R-E3032110114 Product Name ： DUAL BAND WI-FI 6 MESH EXTENDER DEVICE Applicant ： Altice Labs, S.A. Address ： Rua Eng. Ferreira Pinto Basto, 3810-106, Aveiro, Portugal Manufacturer ： Altice Labs, S.A. Address ： Rua Eng. Ferreira Pinto Basto, 3810-106, Aveiro, Portugal Model No. ： D2260G FCC ID ： 2ACJF-EXT-D2260G EUT Test Voltage ： AC 100~240V, 50/60Hz Testing Voltage ： AC 120V/60Hz Trade Name ： ALTICE, ALTICE LABS Applicable Standard ： FCC CFR Title 47 Part 15 Subpart C Section 15.247: 2019 ANSI C63.10: 2013 Laboratory Name ： Hsin Chu Laboratory Address ： No.372-2, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County 310, Taiwan, R.O.C. TEL: +886-3-582-8001 / FAX: +886-3-582-8958 Test Result ： Complied Documented By : ( Carol Tsai / Senior Engineering Adm. Specialist ) Tested By : ( Lion Wang / Senior Engineer ) Approved By : ( Louis Hsu / Deputy Manager ) Report No：2070873R-E3032110114 Page: 3 of 280 Revision History Version Description Issued Date V1.0 Initial issue of report Nov. 27, 2020 V2.0 Add Antenna Manufacturer & PN Information Dec. 10, 2020 Report No：2070873R-E3032110114 Page: 4 of 280 TABLE OF CONTENTS Description Page 1. General Information ........................................................................................................ 6 1.1. EUT Description ............................................................................................................. 6 1.2. Test Mode ....................................................................................................................... 9 1.3. Tested System Details .................................................................................................. 11 1.4. Configuration of tested System .................................................................................... 11 1.5. EUT Exercise Software ................................................................................................ 11 1.6. Comments and Remarks .............................................................................................. 12 1.7. Test Facility ................................................................................................................... 13 1.8. List of Test Equipment .................................................................................................. 14 1.9. Duty Cycle .................................................................................................................... 17 1.10. Uncertainty ................................................................................................................... 21 2. Conducted Emission .................................................................................................... 22 2.1. Test Setup .................................................................................................................... 22 2.2. Limits ............................................................................................................................ 22 2.3. Test Procedure ............................................................................................................. 23 2.4. Test Specification .......................................................................................................... 23 2.5. Test Result .................................................................................................................... 24 3. Maximum peak conducted output power ...................................................................... 36 3.1. Test Setup .................................................................................................................... 36 3.2. Test procedures ............................................................................................................ 36 3.3. Limits ............................................................................................................................ 36 3.4. Test Specification .......................................................................................................... 36 3.5. Test Result .................................................................................................................... 37 4. Radiated Emission ....................................................................................................... 39 4.1. Test Setup .................................................................................................................... 39 4.2. Limits ............................................................................................................................ 39 4.3. Test Procedure ............................................................................................................. 40 4.4. Test Specification .......................................................................................................... 40 4.5. Test Result .................................................................................................................... 41 5. RF antenna conducted test .......................................................................................... 89 5.1. Test Setup .................................................................................................................... 89 5.2. Limits .......................…

Text truncated - open the document above for the full version.

Report No：2070873R-E3032110114 Page: 95 of 280 Channel 6 (2437MHz) Channel 11 (2462MHz) Report No：2070873R-E3032110114 Page: 96 of 280 Product DUAL BAND WI-FI 6 MESH EXTENDER DEVICE Test Item RF antenna conducted test Test Mode Mode 1: SISO Mode Date of Test 2020/08/25 Test Site SR12-H Test Temperature 23.0°C Test Humidity 63.0％ IEEE 802.11g (ANT 1) Channel Frequency (MHz) Measure Level (dBc) Limit (dBc) Result 1 2412 42.276 ≧30 Pass 6 2437 49.372 ≧30 Pass 11 2462 48.845 ≧30 Pass Channel 1 (2412MHz) Report No：2070873R-E3032110114 Page: 97 of 280 Channel 6 (2437MHz) Channel 11 (2462MHz) Report No：2070873R-E3032110114 Page: 98 of 280 Product DUAL BAND WI-FI 6 MESH EXTENDER DEVICE Test Item RF antenna conducted test Test Mode Mode 2: CDD Mode Date of Test 2020/08/25 Test Site SR12-H Test Temperature 23.0°C Test Humidity 63.0％ IEEE 802.11n(20M)(ANT 0) Channel Frequency (MHz) Measure Level (dBc) Limit (dBc) Result 1 2412 32.834 ≧30 Pass 6 2437 47.169 ≧30 Pass 11 2462 46.616 ≧30 Pass Channel 1 (2412MHz) Report No：2070873R-E3032110114 Page: 99 of 280 Channel 6 (2437MHz) Channel 11 (2462MHz) Report No：2070873R-E3032110114 Page: 100 of 280 Product DUAL BAND WI-FI 6 MESH EXTENDER DEVICE Test Item RF antenna conducted test Test Mode Mode 2: CDD Mode Date of Test 2020/08/25 Test Site SR12-H Test Temperature 23.0°C Test Humidity 63.0％ IEEE 802.11n(20M)(ANT 1) Channel Frequency (MHz) Measure Level (dBc) Limit (dBc) Result 1 2412 44.503 ≧30 Pass 6 2437 52.427 ≧30 Pass 11 2462 47.866 ≧30 Pass Channel 1 (2412MHz) Report No：2070873R-E3032110114 Page: 101 of 280 Channel 6 (2437MHz) Channel 11 (2462MHz) Report No：2070873R-E3032110114 Page: 102 of 280 Product DUAL BAND WI-FI 6 MESH EXTENDER DEVICE Test Item RF antenna conducted test Test Mode Mode 2: CDD Mode Date of Test 2020/08/25 Test Site SR12-H Test Temperature 23.0°C Test Humidity 63.0％ IEEE 802.11n(40M)(ANT 0) Channel Frequency (MHz) Measure Level (dBc) Limit (dBc) Result 3 2422 38.352 ≧30 Pass 6 2437 40.453 ≧30 Pass 9 2452 36.802 ≧30 Pass Channel 3 (2422MHz) Report No：2070873R-E3032110114 Page: 103 of 280 Channel 6 (2437MHz) Channel 9 (2452MHz) Report No：2070873R-E3032110114 Page: 104 of 280 Product DUAL BAND WI-FI 6 MESH EXTENDER DEVICE Test Item RF antenna conducted test Test Mode Mode 2: CDD Mode Date of Test 2020/08/25 Test Site SR12-H Test Temperature 23.0°C Test Humidity 63.0％ IEEE 802.11n(40M)(ANT 1) Channel Frequency (MHz) Measure Level (dBc) Limit (dBc) Result 3 2422 44.029 ≧30 Pass 6 2437 33.516 ≧30 Pass 9 2452 45.464 ≧30 Pass Channel 3 (2422MHz) Report No：2070873R-E3032110114 Page: 105 of 280 Channel 6 (2437MHz) Channel 9 (2452MHz) Report No：2070873R-E3032110114 Page: 106 of 280 Product DUAL BAND WI-FI 6 MESH EXTENDER DEVICE Test Item RF antenna conducted test Test Mode Mode 2: CDD Mode Date of Test 2020/08/25 Test Site SR12-H Test Temperature 23.0°C Test Humidity 63.0％ IEEE 802.11ax(20M)(ANT 0) Channel Frequency (MHz) Measure Level (dBc) Limit (dBc) Result 1 2412 30.922 ≧30 Pass 6 2437 50.387 ≧30 Pass 11 2462 47.123 ≧30 Pass Channel 1 (2412MHz) Report No：2070873R-E3032110114 Page: 107 of 280 Channel 6 (2437MHz) Channel 11 (2462MHz) Report No：2070873R-E3032110114 Page: 108 of 280 Product DUAL BAND WI-FI 6 MESH EXTENDER DEVICE Test Item RF antenna conducted test Test Mode Mode 2: CDD Mode Date of Test 2020/08/25 Test Site SR12-H Test Temperature 23.0°C Test Humidity 63.0％ IEEE 802.11ax(20M)(ANT 1) Channel Frequency (MHz) Measure Level (dBc) Limit (dBc) Result 1 2412 42.935 ≧30 Pass 6 2437 48.739 ≧30 Pass 11 2462 44.279 ≧30 Pass Channel 1 (2412MHz) Report No：2070873R-E3032110114 Page: 109 of 280 Channel 6 (2437MHz) Channel 11 (2462MHz) Report No：2070873R-E3032110114 Page: 110 of 280 Product DUAL BAND WI-FI 6 MESH EXTENDER DEVICE Test Item RF antenna conducted test Test Mode Mode 2: CDD Mode Date of Test 2020/08/25 Test Site SR12-H Test Temperature 23.0°C Test Humidity 63.0％ IEEE 802.11ax(40M)(ANT 0) Channel Frequency (MHz) Measure Level (dBc) Limit (dBc) Result 3 2422 42.362 ≧30 Pass 6 2437 44.702 ≧30 Pass 9 2452 36.422 ≧30 Pass Channel 3 (2422MHz) Report No：2070873R-E3032110114 Page: 111 of 280 Channel 6 (2437MHz) Channel 9 (2452MHz) Report No：2070873R-E3032110114 Page: 112 of 280 Product DUAL BAND WI-FI 6 MESH EXTENDER DEVICE Test Item RF antenna conducted test Test Mode Mode 2: CDD Mode Date of Test 2020/08/25 Test Site SR12-H Test Temperature 23.0°C Test Humidity 63.0％ IEEE 802.11ax(40M)(ANT 1) Channel Frequency (MHz) Measure Level (dBc) Limit (dBc) Result 3 2422 40.168 ≧30 Pass 6 2437 40.590 ≧30 Pass 9 2452 42.006 ≧30 Pass Channel 3 (2422MHz) Report No：2070873R-E3032110114 Page: 113 of 280 Channel 6 (2437MHz) Channel 9 (2452MHz) Report No：2070873R-E3032110114 Page: 114 of 280 Product DUAL BAND WI-FI 6 MESH EXTENDER DEVICE Test Item RF antenna conducted test Test Mode Mode 1: SISO Mode Date of Test 2020/08/25 Test Site SR12-H Test Temperature 23.0°C Test Humidity 63.0％ 2412MHz (30MHz-25GHz)-11b_Ant 0 2437MHz (30MHz-25GHz)- 11b_Ant 0 Report No：2070873R-E3032110114 Page: 115 of 280 2462MHz (30MHz-25GHz)-11b_Ant 0 Report No：2070873R-E3032110114 Page: 116 of 280 2412MHz (30MHz-25GHz)-11b_Ant 1 2437MHz (30MHz-25GHz)- 11b_Ant 1 Report No：2070873R-E3032110114 Page: 117 of 280 2462MHz (30MHz-25GHz)-11b_Ant 1 Report No：2070873R-E3032110114 Page: 118 of 280 2412MHz (30MHz-25GHz)-11g_Ant 0 2437MHz (30MHz-25GHz)- 11g_Ant 0 Report No：2070873R-E3032110114 Page: 119 of 280 2462MHz (30MHz-25GHz)-11g_Ant 0 Report No：2070873R-E3032110114 Page: 120 of 280 2412MHz (30MHz-25GHz)-11g_Ant 1 2437MHz (30MHz-25GHz)- 11g_Ant 1 Report No：2070873R-E3032110114 Page: 121 of 280 2462MHz (30MHz-25GHz)-11g_Ant 1 Report No：2070873R-E3032110114 Page: 122 of 280 Product DUAL BAND WI-FI 6 MESH EXTENDER DEVICE Test Item RF antenna conducted test Test Mode Mode 2: CDD Mode Date of Test 2020/08/25 Test Site SR12-H Test Temperature 23.0°C Test Humidity 63.0％ 2412MHz (30MHz-25GHz)-11n(20M)_Ant 0 2437MHz (30MHz-25GHz)-11n(20M)_Ant 0 Report No：2070873R-E3032110114 Page: 123 of 280 …

Text truncated - open the document above for the full version.

Report No：2070873R-E3032110114 Page: 166 of 280 Model No D2260G Site CB2-H Test Voltage AC 120V/60Hz Test Date 2020/8/11 Test Mode Mode 2: CDD Mode Engineer Scott Polarity Vertical Temperature (°C) 25.0 Test Condition 802.11n_BW20M_Ant0+1_Ch1_2.412G Humidity (%RH) 58.0 No Frequency (MHz) Emission Level (dBuV/m) Limit (dBuV/m) Margin (dB) Reading Level (dBuV) Correct Factor (dB/m) Detector Type 1 2310 37.45 54.00 -16.55 24.30 13.15 AV 2 2388.9 50.08 54.00 -3.92 36.38 13.70 AV 3 2390 49.89 54.00 -4.11 36.19 13.70 AV ! 4 2413.9 104.35 54.00 50.35 90.47 13.88 AV 5 2483.5 41.33 54.00 -12.67 26.97 14.36 AV 6 2500 39.94 54.00 -14.06 25.46 14.48 AV Note: 1. All reading above 1GHz is performed with peak and/or average measurements as necessary. 2. Emission Level = Reading Level + Correct Factor. 3. The average measurement was not performed when the peak measured data under the limit of average detection. If the readings given are average, peak measurement should also be supplied. 4. The fundamental for reference only, it’s not restricted by unwanted emission limit. Report No：2070873R-E3032110114 Page: 167 of 280 Model No D2260G Site CB2-H Test Voltage AC 120V/60Hz Test Date 2020/8/11 Test Mode Mode 2: CDD Mode Engineer Scott Polarity Horizontal Temperature (°C) 25.0 Test Condition 802.11n_BW20M_Ant0+1_Ch6_2.437G Humidity (%RH) 58.0 No Frequency (MHz) Emission Level (dBuV/m) Limit (dBuV/m) Margin (dB) Reading Level (dBuV) Correct Factor (dB/m) Detector Type 1 2310 42.86 74.00 -31.14 29.71 13.15 PK 2 2390 50.61 74.00 -23.39 36.91 13.70 PK ! 3 2433 104.64 74.00 30.64 90.63 14.01 PK 4 2483.5 48.88 74.00 -25.12 34.52 14.36 PK 5 2485.8 50.72 74.00 -23.28 3…

Text truncated - open the document above for the full version.
