MyTagAnti-lossDevice USERGuide ScantoInstallappforIOSScantoInstallappforAndroid DeviceCompatibility FirstmakesureyourdevicesupportâBluetooth4.0Smartâ IOS IOS IOS IOS:IOS7orabovesuchas IPhone4S/5/5s/5c/6/6plus IPad3/4/Mini/Air/Mini2/iPodTouch5 Andro Andro Andro Android id id id:Android4.3orabovesuchas SamsungS3/S4/S5/S5MINI/SamsungNote2/Note3/Note4/850 XiaoMi2s/3/4 HuaWeiB199/8816/Honor3C/Honor6/Mate7/P7 SonyXPERIAZ2/XPERIAZ3 HTCDESIRE816/HTCONE OPPOFind7/R7007 LGNEXUS5/G3/G4/NEXUS6 SETUP Step1 ForiPhone,pleasesearchanddownloadA A A ATag Tag Tag TagatiTunesAppStore; ForAndroidphone,pleasesearchanddownloadM M M MyTag yTag yTag yTagatGooglePlay. Applogo: Step2 TurnBluetoothonforyourdevice.Goto"Settings"then"General"onyourmobile phoneandmakesurethatBluetoothisONorEnabled. Step3 Presspowerbutton3secondsuntiltheanti-lostbeepanditisinpairingmode.Turn onAPPandtapsearchiconandtheanti-lostalarmwillshowontheSearchList.Tap theanti-lostalarmicontoconnectit. Step4 Nameyourdevice.Tapthepeniconandinputanewnameforanti-lostalarm. Step5 Inthesettingpage:Aboutthealertswitch,flashlightswitch,alarmdistance,These settingsareshared,whenyouchangeone,theotherdeviceswilltogetherchange; Eachdeviceâsdisconnectswitchandfindmebuttonareindependent,youcloseone,it doesn'taffectotherdevices;Eachdevicedisconnectandfindmealarmsoundare independent,youchangethesoundofonedevice,doesnotaffectotherdevices IOSsystemmainscreen Androidsystemmainscreen Operation 1.Maketheanti-lostalarmsound.FromtheAppmainscreen,tapthesearchicon.The anti-lostalarmwillsound.ClicktheFunctionButtononanti-lostalarmtoturnoffthe sound. 2.Makeyourphonealarmsound.Fromtheanti-lostalarm,clicktheFunctionButton, theanti-lostalarmAppwillringthesoundyouselectedonconfiguration. In/OutofRangeAlert 1.IfthedistanceofthePairedanti-lossalarmandmobilephoneisoutofrange,both anti-lossalarmandmobilephonewilltriggeralert."Setting"inAppwilldefinethe soundofalert. 2.Mobilephonewilltriggeralertifpre-pairedanti-lossalarmandmobilephone re-connected. Closemytag TapofficonfromAppinpairedstatusandanti-lossalarmwillenterclosedstatus. Selfie EnterselfiepagebytappingthecameraiconontheAppordoubleclicktheFunction Buttonofanti-lostalarm.ClicktheFunctionButtontotakepicture.TaptheBackicon onAppordoubleclickFunctionButtontoexitselfiemode. Record (forIOS):EnterrecordpagebytappingthemicrophoneicononApporlongpress FunctionButtonofanti-lostalarm.ClicktheFunctionButtontorecord.Clickthe FunctionButtonagaintostoprecording.TapâBackâonApporlongpressFunction Buttontoexitrecordpage. (forAndroid):StartrecordingbytappingthemicrophoneicononApporlongpress FunctionButtonofanti-lostalarm.ClicktheFunctionButtontostoprecording.Tap BackicononApporlongpressFunctionButtontoexitrecordpage. BatteryLevel Theapplicationcanshowmytagbatterylevel Maplocation Clickthemaplocationbuttonwecanseethelastpositionofmytagdisconnected TemperatureDetection(Needtocustomize) Showthearoundthetemperatureofmytaginthephoneapp ReplaceBattery Opentheshellbypushingthe2piecesofshellagainsteachother.Takeoutthebattery andchangeit. Federal Communications Commission (FCC) Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: âReorient or relocate the receiving antenna. âIncrease the separation between the equipment and receiver. âConnect the equipment into an outlet on a circuit different from that to which the receiver is connected. âConsult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications made to this device not expressly approved by Shenzhen Aoxingao Technology Co.,Ltd may void the FCC authorization to operate this device. Note: The manufacturer is not responsible for any radio or tv interference caused by unauthorized modifications to this equipment. Such modifications could void the userâs authority to operate the equipment.
Shenzhen Aoxingao Technology Co.,Ltd Rm602, Building C2, Huatongyuan Logistics Center, Minzhi Avenue, Longhua Town, Shenzhen, China TEL: +86-755-29232900-810 FAX: +86-755-29676711 DATE 01-15-2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ACN3-PC032 Product Name: Anti-Loss Device Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality â for example ...) ⢠Schematics ⢠Block diagram ⢠Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 01-15-2015 By: Sue Liang Signature Printed Title: Manager On behalf of : Shenzhen Aoxingao Technology Co.,Ltd Telephone: +86-755-29232900-810
Shenzhen Aoxingao Technology Co.,Ltd Rm602, Building C2, Huatongyuan Logistics Center, Minzhi Avenue, Longhua Town, Shenzhen, China TEL: +86-755-29232900-810 FAX: +86-755-29676711 Series Models Description FCC ID: 2ACN3-PC032 Date: Dec. 29, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: To whom concern: The device (Product Name: Anti-Loss Device) Models Name: PC032, PC033, PC034, PC035, PC036, PC037, PC038, PC023) have same electrical, PCB and BOM, only the modelâs name and color are different for marketing requirements. Sincerely, Sue Liang/Manager are electrically identical, only the modelâs name and color are different for marketing requirements. modelâs namecolor enclosure shape are different for marketing use.
FCC ID Label Information 1. Label location: 2. FCC ID Label: Model: PC032 FCC ID: 2ACN3-PC032 FCCID Label Location
RF Exposure evaluation According to KDB 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ⤠50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ¡[âf(GHz)] ⤠3.0 for 1-g SAR and ⤠7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Field strength = 90.74 dBuV/m @3m Ant gain 0dBi, so Ant numeric gain=1 So pt={ [10 (90.74 /20) /10 6 x3] 2 /30x1 }x1000 mW = 0.36 mW So ( 0.36 mW/5mm)x â2.480GHz = 0.11 <3 Then SAR evaluation is not required
Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 FCC PART 15 SUBPART C TEST REPORT Report Reference No......................: CTL1412112993-WF Compiled by ( position+printed name+signature)..: File administrators Jacky Chen Name of the organization performing the tests ( position+printed name+signature)..: Test Engineer Tracy Qi Approved by ( position+printed name+signature)..: Manager Tracy Qi Date of issue.....................................: Jan. 05, 2015 Test Firm..........................................: Shenzhen CTL Testing Technology Co., Ltd. Address.............................................: Floor 1-A, Baisha Technology Park, No. 3011, Shahexi Road, Nanshan, Shenzhen 518055 China. Applicantâs name............................: Shenzhen Aoxingao Technology Co.,Ltd Address.............................................: Rm602, Building C2, Huatongyuan Logistics Center Minzhi Avenue, Longhua Town, Shenzhen, China Test specification: Standard ...........................................: FCC Part 15.249: Operation within the bands 920-928 MHz, 2400- 2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz TRF Originator ..................................: Shenzhen CTL Testing Technology Co., Ltd. Master TRF.......................................: Dated 2011-01 Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Anti-Loss Device Trade Mark .......................................: N/A Models/Type reference.....................: PC032, PC033, PC034, PC035, PC036, PC037, PC038, PC023 Modulation .......................................: GFSK Work Frequency...........................: 2402 MHz~2480 MHz Antenna Type..............................: internal FCC ID .............................................: 2ACN3-PC032 Result................................................: Positive V1.0 Page 2 of 45 Report No.: CTL1412112993-WF T E S T R E P O R T Test Report No. :CTL1412112993-WF Jan. 05, 2015 ______________________________________________________________________________________________ Date of issue Equipment under Test : Anti-Loss Device Model /Type : PC032 Listed Modes : PC033, PC034, PC035, PC036, PC037, PC038, PC023 Difference Description : Only the color and model's name is different Applicant : Shenzhen Aoxingao Technology Co.,Ltd Address : Rm602, Building C2, Huatongyuan Logistics Center Minzhi Avenue, Longhua Town, Shenzhen, China Manufacturer Shenzhen Aoxingao Technology Co.,Ltd Address Rm602, Building C2, Huatongyuan Logistics Center Minzhi Avenue, Longhua Town, Shenzhen, China Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 45 Report No.: CTL1412112993-WF Contents 1.TEST STANDARDS .................................................................. 4 2.SUMMARY............................................................................. 5 2.1.General Remarks 5 2.2.Equipment Under Test 5 2.3.Short description of the Equipment under Test (EUT) 5 2.4.EUT operation mode 6 2.5.EUT configuration 6 2.6.Related Submittal(s) / Grant (s) 6 2.7.Modifications 6 3. TEST ENVIRONMENT............................................................... 7 3.1.Address of the test laboratory 7 3.2.Test Facility 7 3.3.Environmental conditions 7 3.4.Configuration of Tested System 7 3.5.Statement of the measurement uncertainty 8 3.6.Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1.Conducted Emissions Test 10 4.2.Fundamental Emissions 12 4.3.Transmitter Radiated Unwanted Emissions 13 4.4.Band Edge Measurement 29 4.5.Occupied Bandwidth Measurement 38 5. ANTENNA REQUIREMENT ....................................................... 40 6.TEST SETUP PHOTOS OF THE EUT .......................................... 41 7.EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 42 V1.0 Page 4 of 45 Report No.: CTL1412112993-WF 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.249: Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz. ANSI C63.4-2009 V1.0 Page 5 of 45 Report No.: CTL1412112993-WF 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Dec. 12, 2014 Testing commenced on : Dec. 12, 2014 Testing concluded on : Jan. 05, 2015 2.2.Equipment Under Test Power supply system utilised Power supply voltage : o 120V / 60 Hz o 115V / 60Hz o 12 V DC o 24 V DC Ć˝ Other (specified in blank below) DC 3.0V from battery(CR2016) 2.3. Short description of the Equipment under Test (EUT) The EUT is an Anti-Loss Device work at 2402~2480 MHz support Bluetooth 4.0. Channel List: Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 20 2442 01 2404 21 2444 02 2406 22 2446 03 2408 23 2448 04 2410 24 2450 05 2412 25 2452 06 2414 26 2454 07 2416 27 2456 08 2418 28 2458 09 2420 29 2460 10 2422 30 2462 11 2424 31 2464 12 2426 32 2466 13 2428 33 2468 14 2430 34 2470 15 2432 35 2472 16 2434 36 2474 17 2436 37 2476 18 2438 38 2478 19 2440 39 2480 Modulation: GFSK For more details, refer to the userâs manual of the EUT. Serial number: Prototype V1.0 Page 6 of 45 Report No.: CTL1412112993-WF 2.4. EUT operation mode Test Mode(TM) Description Remark TM1 Bottom Channel Transmitting / TM2 Middle Channel Transmitting / TM3 Top Channel Transmitting / The field strength of radiation emission waâŚ
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | - |

Anti-Loss Device
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
