SHENZHENG YONGCHENGCHUANGXIN TECHNOLOGY CO., LTD. Letter of Authorization Company: SHENZHENG YONGCHENGCHUANGXIN TECHNOLOGY CO., LTD. Address: 7/F.Keji Block, Yongqixifa C district, yintian baoan, Shenzhen, China Product Name: BLUETOOTH SPEAKER Model Number: PBT3014, PBT 3015, PBT1010, SBT1010, SBT1012, SBT1011, PBT1011, PBT1012, BT-101, BT-104, BT-105, BT-110, BT-109 We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, CA 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. This shall include the following: • Testing • Approval applications (includes complete product documentation package, including Confidential information) and procedures • Payment of approval fees We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, CA 94566, USA, is allowed to forward all information related to the approval project to the applied notified body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: James Lai Date: 2015.05.20 Signature of applicant:

< SHENZHENG YONGCHENGCHUANGXIN TECHNOLOGY CO., LTD.> Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2015.05.20 Subject; Request for Confidentiality FCC ID: 2ACN6PBT3014 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure indefinitely. • Schematic Diagram • Block Diagram • Operational Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: James Lai Email: [email protected]

External photo (BLUETOOTH SPEAKER Model: PBT3014)

LABEL ARTWORK AND LOCATION Label Location

Internal photo (BLUETOOTH SPEAKER Model: PBT3014) Antenna Location

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2ACN6PBT3014 Product: BLUETOOTH SPEAKER Model No.: PBT3014 Additional Model: PBT 3015, PBT1010, SBT1010, SBT1012, SBT1011, PBT1011, PBT1012, BT-101, BT-104, BT-105, BT-110, BT-109 Trade Mark: POLAROID, SHARPER IMAGE Report No.: TCT150506E008 Issued Date: May 22, 2015 Issued for : SHENZHENG YONGCHENGCHUANGXIN TECHNOLOGY CO., LTD. 7/F.Keji Block, Yongqixifa C district, yintian baoan, Shenzhen, China Issued By: Shenzhen Tongce Testing Lab. 1F, Leinuo Watch Building, Fuyong Town, Baoan Dist, Shenzhen, China TEL: +86-755-27673339 FAX: +86-755-27673332 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT150506E008 Page 2 of 45 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification....................................................................................... 3 2. Test Result Summary ............................................................................... 4 3. EUT Description ........................................................................................ 5 4. Genera Information................................................................................... 6 4.1. Test environment and mode................................................................................. 6 4.2. Description of Support Units................................................................................ 6 5. Facilities and Accreditations ................................................................... 7 5.1. Facilities .................................................................................................................7 5.2. Location ................................................................................................................. 7 5.3. Measurement Uncertainty..................................................................................... 7 6. Test Results and Measurement Data ...................................................... 8 6.1. Antenna requirement ............................................................................................ 8 6.2. Conducted Emission ............................................................................................. 9 6.3. Conducted Output Power ................................................................................... 13 6.4. 20dB Occupy Bandwidth .................................................................................... 17 6.5. Carrier Frequencies Separation ......................................................................... 21 6.6. Hopping Channel Number .................................................................................. 25 6.7. Dwell Time............................................................................................................ 28 6.8. Pseudorandom Frequency Hopping Sequence ................................................ 31 6.9. Conducted Band Edge Measurement ................................................................ 32 6.10. Conducted Spurious Emission Measurement................................................. 35 6.11. Radiated Spurious Emission Measurement.................................................... 38 Report No.: TCT150506E008 Page 3 of 45 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: BLUETOOTH SPEAKER Model No.: PBT3014 Additional Model: PBT 3015, PBT1010, SBT1010, SBT1012, SBT1011, PBT1011, PBT1012, BT-101, BT-104, BT-105, BT-110, BT-109 Applicant: SHENZHENG YONGCHENGCHUANGXIN TECHNOLOGY CO., LTD. Address: 7/F.Keji Block, Yongqixifa C district, yintian baoan, Shenzhen, China Manufacturer: SHENZHENG YONGCHENGCHUANGXIN TECHNOLOGY CO., LTD. Address: 7/F.Keji Block, Yongqixifa C district, yintian baoan, Shenzhen, China Date of Test: May 06 - May 22, 2015 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 The above equipment has been tested by Shenzhen Tongce Testing Lab. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date:May 22, 2015 Beryl Zhao Reviewed By: Date:May 22, 2015 Joe Zhou Approved By: Date:May 22, 2015 Tomsin Report No.: TCT150506E008 Page 4 of 45 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna Requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247 (b)(1) PASS 20dB Occupied Bandwidth §15.247 (a)(1) PASS Carrier Frequencies Separation §15.247 (a)(1) PASS Hopping Channel Number §15.247 (a)(1) PASS Dwell Time §15.247 (a)(1) PASS Radiated Emission §15.205/§15.209 PASS Band Edge §15.247(d) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT150506E008 Page 5 of 45 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product Name: BLUETOOTH SPEAKER Model : PBT3014 Additional Model: PBT 3015, PBT1010, SBT1010, SBT1012, SBT1011, PBT1011, PBT1012, BT-101, BT-104, BT-105, BT-110, BT-109 Trade Mark: POLAROID, SHARPER IMAGE Operation Frequency: 2402MHz~2480MHz Transfer Rate: 1/2 Mbits/s Numbe…

Text truncated - open the document above for the full version.

Setup photo (BLUETOOTH SPEAKER Model: PBT3014) Conducted Emission Radiated Emission
