TOTAL STATION LTS-200SERIES LTS-202N LTS-205N On-Board Application LinertecExpress INSTRUCTION MANUAL - 1 - 2 Before using this product, be sure that you have thoroughly read and understood this instruction manual to ensure proper operation. After reading this manual, be sure to keep in a convenient place for easy reference. Exemption clause 1)TI Asahi Co.,Ltd. (TIA) shall not be liable for damage caused by Acts of God, fire, alteration or servicing by unauthorized parties, accident, negligence, misuse, abnormal operating conditions. 2)TIPS shall not be liable for changes or disappearance of data, loss of company profit or interruption of company operation incurred by the use of this product or malfunction of it. 3)TIPS shall not be liable for damage caused by usage not explained in the instruction manual. 4)TIPS shall not be liable for damage to this product caused by other equipment connected to this product. Copyright © 2014 TI Asahi Co., Ltd. 3 DISPLAY AND KEYBOARD.................................................................................................6 Operation Key...................................................................................................................6 Function Key.....................................................................................................................7 1. INTRODUCTION.................................................................................................................9 1.1 Introduction.................................................................................................................9 1.2 Before using the LinertecExpress manual..............................................................10 2. ACCESSING LINERTECEXPRESS...............................................................................12 2.1 How to access LinertecExpress................................................................................12 2.2 Allocation of each LinertecExpress Function key..................................................12 2.3 Typical Function keys of LinertecExpress.............................................................13 3. PROGRAM.........................................................................................................................14 3.1 RDM (Remote Distance Measurement)..................................................................14 3.1.1 PH INPUT.......................................................................................................15 3.1.2 Reference Point-Target Distance..................................................................15 3.1.3 Target-Target Distance.................................................................................15 3.1.4 New Reference Point Selection.....................................................................15 3.2 REM...........................................................................................................................16 3.2.1 General Pictures of Measurement................................................................16 3.3. VPM..........................................................................................................................17 4. COMMUNICATION..........................................................................................................20 4.1 Text File read / write.................................................................................................22 4.1.1 Writing to Text File.......................................................................................22 4.1.2 Reading from Text File..................................................................................23 4.1.3 Text File setup................................................................................................26 4.2 Communication with USB........................................................................................28 4.3 DATA TRANSFER...................................................................................................29 4.3.1 Receiving Coordinate Data...........................................................................29 4.3.2 Sending Data..................................................................................................30 4.3.4 About DataLink DL-01 Software.................................................................34 5.SETUP...................................................................................................................................38 5.1 ADJUST SETTING...............................................................................................38 [3.SHEET CONST]..........................................................................................................38 [4.CRV/REF CORR]........................................................................................................38 [4. COMP AXIS]..............................................................................................................39 to enter..............................................................................................................................39 5.2 ACTION SETTING...............................................................................................39 5.3 UNIT SETTING.....................................................................................................41 5.4 COMMUNICATION SETTING..........................................................................42 5.5 FUNCTION SETTING.........................................................................................42 5.5.1 Language Selection........................................................................................43 5.5.3 Input method selection..................................................................................45 5.5.4 Action Method Selection................................................................................47 5.5.5 Remote method selection.........................................…
Text truncated - open the document above for the full version.
SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 TI PRECISION SHANGHAI CO.,LTD. No.158 Beiyang Road, SongjiangDistrict,Shanghai,China 2014-7-7 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, TI PRECISION SHANGHAI CO.,LTD. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: 2ACP2LGP202N Model: LTS-202N, LTS-205N, LTS352N Product name: Total Station Sincerely, signature : name / title: Shi Yunfei / Electronic engineer address: No.158 Beiyang Road, SongjiangDistrict,Shanghai,China SCS-F18: Project and Product Certification Representative Authorization Letter Page 3 of 3 Rev 4.0 TI PRECISION SHANGHAI CO.,LTD. No.158 Beiyang Road, SongjiangDistrict,Shanghai,China 2014-7-7 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, TI PRECISION SHANGHAI CO.,LTD. hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): FCC ID: 2ACP2LGP202N Model: LTS-202N, LTS-205N, LTS352N Product name: Total Station We affirm that between SIEMIC, Inc. and TI PRECISION SHANGHAI CO.,LTD., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, signature : name / title: Shi Yunfei / Electronic engineer address: No.158 Beiyang Road, SongjiangDistrict,Shanghai,China
SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 TI PRECISION SHANGHAI CO.,LTD. No.158 Beiyang Road, SongjiangDistrict,Shanghai,China 2014-7-7 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACP2LGP202N We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: Shi Yunfei / Electronic engineer address: No.158 Beiyang Road, SongjiangDistrict,Shanghai,China
Updated on 2005/02/07 by Kally Chan DECLARATION OF IDENTITY FCC ID: 2ACP2LGP202N Hereby we: TI Precision Shanghai Co.,Ltd. (Name of Manufacturer) Basic Model Number: LTS-202N Basic Brand Name: / Basic Product Name: Total Station Declare the Circuit, PCB Layout, shape of enclosure and Electrical Parts of the following product(s) are identical to the basic model: New / Additional Model Number(s): LTS-205N, LTS352N New / Additional Brand Name(s): / Except the following(s) : Model numbers,outlook color, operation language Signature with Company Chop : Printed Name : Shi Yunfei DATE:2014-07-7
Label location Model No.: LGP-202N FCC ID: 2ACP2LGP202N This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Antenna location
FCC ID: 2ACP2LGP202N Keyway Testing Technology Co., Ltd. Report No. 14KWE07152801F Page 1 of 24 FCC TEST REPORT(Bluetooth) for TI Precision Shanghai Co.,Ltd. Total Station Model Number: LTS-202N, LTS-205N, LTS352N FCC ID: 2ACP2LGP202N Prepared for : TI Precision Shanghai Co.,Ltd. Address : No.158 Beiyang Road, Songjiang District, Shanghai, China Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 14KWE07152801F Date of Test : Jul. 2~5, 2014 Date of Report : Jun. 6, 2014 FCC ID: 2ACP2LGP202N Keyway Testing Technology Co., Ltd. Report No. 14KWE07152801F Page 2 of 24 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY.............................................................................................................4 2. GENERAL PRODUCT INFORMATION ............................................................................4 2.1. Product Function .......................................................................................................4 2.2. Description of Device (EUT) ......................................................................................4 2.3. Difference between Model Numbers..........................................................................4 2.4. Independent Operation Modes ..................................................................................4 2.5. Test Supporting System ............................................................................................4 3. TEST SITES .....................................................................................................................5 3.1. Test Facilities.............................................................................................................5 3.2. List of Test and Measurement Instruments................................................................6 4. TEST SET-UP AND OPERATION MODES......................................................................7 4.1. Principle of Configuration Selection ...........................................................................7 4.2. Block Diagram of Test Set-up ....................................................................................7 4.3. Test Operation Mode and Test Software ...................................................................7 4.4. Special Accessories and Auxiliary Equipment ...........................................................7 4.5. Countermeasures to Achieve EMC Compliance........................................................7 5. EMISSION TEST RESULTS.............................................................................................8 5.1. Radiated Emission Test.............................................................................................8 6. 20DB OCCUPY BANDWIDTH ........................................................................................14 6.1. Limits .......................................................................................................................14 6.2. Test setup................................................................................................................14 7. BAND EDGE COMPLIANCE TEST ................................................................................16 7.1. Limits .......................................................................................................................16 7.2. Test setup................................................................................................................16 8. ANTENNA REQUIREMENTS.........................................................................................17 8.1. Limits .......................................................................................................................17 8.2. Result ......................................................................................................................17 9. PHOTOGRAPHS OF TEST SET-UP..............................................................................18 10. PHOTOGRAPHS OF THE EUT ..................................................................................19 FCC ID: 2ACP2LGP202N Keyway Testing Technology Co., Ltd. Report No. 14KWE07152801F Page 3 of 24 Keyway Testing Technology Co., Ltd. Applicant: Address: TI Precision Shanghai Co.,Ltd. No.158 Beiyang Road, Songjiang District, Shanghai, China Manufacturer: Address: TI Precision Shanghai Co.,Ltd. No.158 Beiyang Road, Songjiang District, Shanghai, China E.U.T: Total Station Model Number: LTS-202N, LTS-205N, LTS352N Trade Name: ------ Serial No.: ------ Date of Receipt: Jul. 2, 2014 Date of Test: Jul. 2~5, 2014 Test Specification: FCC Part 15, Subpart C Section 15.249: Oct. 1, 2013 ANSI C63.4:2009 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Jul. 6, 2014 Tested by: Reviewed by: Approved by: Andy Gao / Engineer Jade Yang/ Supervisor Chris Du / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology Co., Ltd. FCC ID: 2ACP2LGP202N Keyway Testing Technology Co., Ltd. Report No. 14KWE07152801F Page 4 of 24 1. TEST SUMMARY Test Items Test Requirement Result Conducted Emissions 15.207 N/A Radiated Emissions 15.209 15.249(a)(d) PASS 20dB Bandwidth 15.249 PASS Emissions from out of band 15.249(d) PASS Antenna Requirement 15.203 PASS 2. GENERAL PRODUCT INFORMATION 2.1. Product Function Refer to Technical Construction Form and User Manual. 2.2. Description of Device (EUT) Product Name: Total Station Model No.: LTS-202N, LTS-205N, LTS352N Operation Frequency: 2402~2480MHz Channel numbers: 79 Channels Channel separation: 1…
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | - |

Total Station
Equipment Class
DXT - Part 15 Low Power Transceiver, Rx Verified
