2ACP2LGP302NTotal Station

W-1502N Series Total Station Instruction Manual 1 Dear Customer: Congratulations! We, PENTAX are proud to present you with an W-1502N instrument. Your total station is a rugged and reliable instrument whose performance and designare not surpassed. To fully appreciate and protect your investment, we suggest that you take the necessary time to read and fully understand this manual. We have a dedicated service organization.If the need arises, please don’t hesitate to call us. Thank you for your trust and confidence. 2 NOTE: Don’t collimate the sun directly Avoid insolating the instrument, and don’t collimate the sun directly for protecting eyes and instrument. Set up the instrument on the tripod When using it please insure the connection between tripod and instrument is firm. It is better to work with wooden tripod for the measurement accuracy. Assemble the tribrach on the instrument The setting of tribrach would influence the accuracy. The tribrach should be check frequently, the screw which connects the tribrach and alidade must be locked tightly. And the central fixing screw should be tight. Avoiding the librations on the instrument When transporting, keep the instrument in the case and try your best to lighten librations. Carry the instrument When carrying，the instrument handle must be held tight. High temperature condition If put the instrument in high temperature condition for a long time, it is bad for the instrument performance. Temperature changing sharply The sharp temperature changing on theinstrument or prism will shorten the distance measurement range, for example, after taking the instrument out from a warm car to a cold condition, wait for some time, it can be used when it adapts to the surrounding condition. Check the battery power Before using it, you should check the power whether it is enough. Take out the battery It is not suggested to take out the battery when the instrument is on, otherwise, the stored data may be lost, so it is better to replace the battery after power off the instrument. Stored data responsibility PENTAX should not be held liability for the lost data because of wrong operation. The noise from the instrument When the instrument is working, it is normal if you hear the noise from instrument motor, it will not affect the instrument work. 3 Definition of Indication For the safety of your product and prevention of injury to operators and other persons as well as prevention of property damage, items which should be observed are indicated by an exclamation point within a triangle used with WARNING and CAUTION statements in this manual. The definitions of the indication are listed below. Be sure you understand them before reading the manual’s main text. PRECAUTIONS FOR SAFE OPERATION ●Only PENTAX authorized distributors can disassemble or rebuilt the instrument. ●Do not collimate the sun directly. The eye injury or blind could result. ●Cover the charger maybe result fire when charging. ●If use defection power cable, socket or plug, there is danger of fire, or electronic shock. ●Using wet battery or charger maybe result fire, or electronic shock. ●Do not close the instrument to burning gas or liquid, and do not use the instrument in coal mine. Blast could be result. ●Do not put the battery in the fire or high temperature condition. Explosion, damage could result. ●If use the battery which is not specified by PENTAX, there is a danger of fire, electric shock or burn. ●If use the power cable which is not specified by PENTAX, there is a danger WARNING: CAUTION: ！WARNING ！ ！ Ignoring this indication and making an operation error could possibly result in death or serious injury to the operator. Ignoring this indication and making an operation error could possibly result in personal injury or property damage. 4 of fire. ●If short circuit of the battery, there is a danger of fire.. ●When this product encounters disturbance of severe Electrostatic Discharge, perhaps it will have some degradation of performance like switching on/off automatically and so on. ●If touch the instrument with wet hand, there is danger of electric shock. ●Stand or seat on the carrying case, or turn over the carrying case arbitrarily, the instrument maybe damaged. ●Be careful of the tripod tiptoe when setup or move it. ●Drop the instrument or the carrying case, or use defective belt, agraffe or hinge, instrument damage could result. ●Do not touch liquid leaking from the instrument or battery. Harmful chemicals could cause burn or blisters. ●Please assemble the tribrach carefully, if the tribrach is not stable, series damage could result. ●Drop the instrument or tripod, series damage could result. Before use it, check the central screw is tight. User 1) This product is for professional user only! The user is required to be a qualified surveyor or have a good knowledge of surveying, in order to understand the user manual and safety instructions, before operating, inspecting or adjusting. 2) Wear the required protectors (safety shoes, helmet, etc.) when operating. Exceptions from Responsibility 1) The user of this product is expected to follow all operating instructions and make periodic checks of the product’s performance. 2) The manufacturer assumes no responsibility for results of a faulty or intentional usage or misuse including any direct, indirect, consequential damage, and loss of profits. 3) The manufacturer assumes no responsibility for consequential damage, ！CAUTION 5 and loss of profits by any disaster, (an earthquake, storms, floods etc.). 4) The manufacturer assumes no responsibility for any damage, and loss of profits due to a change of data, loss of data, an interruption of business etc., caused by using the product or an unusable product. 5) The manufacturer assumes no responsibility for any damage, and loss of profits caused by usage except for explained in the user manual. 6) The manufacturer assumes no responsibility for damage caused by wrong transport, or action due to conne…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 TI PRECISION SHANGHAI CO.,LTD. No.158 Beiyang Road, SongjiangDistrict,Shanghai,China 2014-7-3 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, TI PRECISION SHANGHAI CO.,LTD. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: 2ACP2LGP302N Model:LGP-302N,LGP-305N,W-1502N,W-1505N,TS-802W Product name: Total Station Sincerely, signature : name / title: Shi Yunfei / Electronic engineer address: No.158 Beiyang Road, SongjiangDistrict,Shanghai,China SCS-F18: Project and Product Certification Representative Authorization Letter Page 3 of 3 Rev 4.0 TI PRECISION SHANGHAI CO.,LTD. No.158 Beiyang Road, SongjiangDistrict,Shanghai,China 2014-7-3 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, TI PRECISION SHANGHAI CO.,LTD. hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): FCC ID: 2ACP2LGP302N Model:LGP-302N,LGP-305N,W-1502N,W-1505N,TS-802W Product name: Total Station We affirm that between SIEMIC, Inc. and TI PRECISION SHANGHAI CO.,LTD., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, signature : name / title: Shi Yunfei / Electronic engineer address: No.158 Beiyang Road, SongjiangDistrict,Shanghai,China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 TI PRECISION SHANGHAI CO.,LTD. No.158 Beiyang Road, SongjiangDistrict,Shanghai,China 2014-7-7 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACP2LGP302N We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: Shi Yunfei / Electronic engineer address: No.158 Beiyang Road, SongjiangDistrict,Shanghai,China

Updated on 2005/02/07 by Kally Chan DECLARATION OF IDENTITY FCC ID: 2ACP2LGP302N Hereby we: TI Precision Shanghai Co.,Ltd. (Name of Manufacturer) Basic Model Number: LGP-302N Basic Brand Name: / Basic Product Name: Total Station Declare the Circuit, PCB Layout, shape of enclosure and Electrical Parts of the following product(s) are identical to the basic model: New / Additional Model Number(s): LGP-305N,W-1502N,W- 1505N,TS-802W New / Additional Brand Name(s): / Except the following(s) : Model numbers，outlook color, operation system, language Signature with Company Chop : Printed Name : Shi Yunfei DATE:2014-07-7

Label location Model No.: LGP-302N FCC ID: 2ACP2LGP302N This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Antenna location

FCC ID: 2ACP2LGP302N Keyway Testing Technology Co., Ltd. Report No. 14KWE07152701F Page 1 of 24 FCC TEST REPORT(Bluetooth) for TI Precision Shanghai Co.,Ltd. Total Station Model Number: LGP-302N,LGP-305N,W-1502N,W-1505N,TS-802W FCC ID: 2ACP2LGP302N Prepared for : TI Precision Shanghai Co.,Ltd. Address : No.158 Beiyang Road, Songjiang District, Shanghai, China Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 14KWE07152701F Date of Test : Jul. 2~5, 2014 Date of Report : Jun. 6, 2014 FCC ID: 2ACP2LGP302N Keyway Testing Technology Co., Ltd. Report No. 14KWE07152701F Page 2 of 24 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY .......................................................................................................................... 4 2. GENERAL PRODUCT INFORMATION......................................................................................... 4 2.1. Product Function.................................................................................................................... 4 2.2. Description of Device (EUT) .................................................................................................. 4 2.3. Difference between Model Numbers...................................................................................... 4 2.4. Independent Operation Modes .............................................................................................. 4 2.5. Test Supporting System......................................................................................................... 4 3. TEST SITES .................................................................................................................................. 5 3.1. Test Facilities ......................................................................................................................... 5 3.2. List of Test and Measurement Instruments............................................................................ 6 4. TEST SET-UP AND OPERATION MODES .................................................................................. 7 4.1. Principle of Configuration Selection .......................................................................................7 4.2. Block Diagram of Test Set-up ................................................................................................ 7 4.3. Test Operation Mode and Test Software ............................................................................... 7 4.4. Special Accessories and Auxiliary Equipment ....................................................................... 7 4.5. Countermeasures to Achieve EMC Compliance.................................................................... 7 5. EMISSION TEST RESULTS ......................................................................................................... 8 5.1. Radiated Emission Test ......................................................................................................... 8 6. 20DB OCCUPY BANDWIDTH..................................................................................................... 14 6.1. Limits.................................................................................................................................... 14 6.2. Test setup ............................................................................................................................ 14 7. BAND EDGE COMPLIANCE TEST............................................................................................. 16 7.1. Limits.................................................................................................................................... 16 7.2. Test setup ............................................................................................................................ 16 8. ANTENNA REQUIREMENTS...................................................................................................... 17 8.1. Limits.................................................................................................................................... 17 8.2. Result................................................................................................................................... 17 9. PHOTOGRAPHS OF TEST SET-UP .......................................................................................... 18 10. PHOTOGRAPHS OF THE EUT............................................................................................... 19 FCC ID: 2ACP2LGP302N Keyway Testing Technology Co., Ltd. Report No. 14KWE07152701F Page 3 of 24 Keyway Testing Technology Co., Ltd. Applicant: Address: TI Precision Shanghai Co.,Ltd. No.158 Beiyang Road, Songjiang District, Shanghai, China Manufacturer: Address: TI Precision Shanghai Co.,Ltd. No.158 Beiyang Road, Songjiang District, Shanghai, China E.U.T: Total Station Model Number: LGP-302N,LGP-305N,W-1502N,W-1505N,TS-802W Trade Name: ------ Serial No.: ------ Date of Receipt: Jul. 2, 2014 Date of Test: Jul. 2~5, 2014 Test Specification: FCC Part 15, Subpart C Section 15.249: Oct. 1, 2013 ANSI C63.4:2009 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Jul. 6, 2014 Tested by: Reviewed by: Approved by: Andy Gao / Engineer Jade Yang/ Supervisor Chris Du / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology Co., Ltd. FCC ID: 2ACP2LGP302N Keyway Testing Technology Co., Ltd. Report No. 14KWE07152701F Page 4 of 24 1. TEST SUMMARY Test Items Test Requirement Result Conducted Emissions 15.207 N/A Radiated Emissions 15…

Text truncated - open the document above for the full version.

Radiated Emission
