2ACUQ2836LED Controller

RF RGB controller SR-2836RGB(US) Parameter Installation Remote Part No. Operation Voltage Operation Frequency SR-2836RGB(US) 3VDC 868MHz Remarks RF Wireless Wiring diagram Part No. Iuput Voltage Remarks Current SR-1009FA 12-36VDC Constant voltage 4x(60-180)W 4x5A Output SR-1009EA 12-36VDC Constant voltage 4x(96-288)W 4x8A Receiver SR-1009FA3 12-36VDC Constant current 4x(4.2-12.6)W 4x350mA SR-1009FA7 12-36VDC Constant current 4x(8.4-25.2)W 4x700mA 1)Receiver Connection Diagram for Single Unit2) Connection Diagram for Multiple Units Receiver Power Supply12-36VDC L N 110V-230VAC white SR-1009FA LED CONTROLLER 1 2 3 4 Learning Key white SR-1009FA LED CONTROLLER 1 2 3 4 Learning Key white SR-1009FA LED CONTROLLER 1 2 3 4 Learning Key Power Supply12-36VDC L N 110V-230VAC white SR-1009FA LED CONTROLLER 1 2 3 4 Learning Key Operation a.LearningPress shortly the learning Key on the receiver, then push the rotary button .Once successfully learn, the LEDlights will blink on the receiver. Do the same for the other receivers if you use them, you can add as manyoptional receivers as you wantb.Operation-Short push rotary button to switch ON/OFF-Adjust dim brightness by the rotary button from left to right 1-100%-Adjust dim brightness by the rotary button from right to left 100-1%-Long press rotary button, the light will be 100% brightness-Double click rotary button, it will change color of RGB light. Double click again, will enter into dimmingbrightness mode Safety & Warnings 1) The product shall be installed and serviced by a qualified person.2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proofenclosure.3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.4) Please check if the output voltage of any LED power supplies used comply with the working voltage of theproduct 5 Power supply SR-2836RGB(US) is RF controllers for RGB color lighting.Each white can achieve 256 levels brightness adjustment.Key part can be uninstall every easily to change battery andframes from other factory.Receivers work with WIFI-RF convertor to be controlled bysmart phone. Warranty Agreement 1) We provide lifelong technical assistance with this product: 5-year warranty. We print date on every products, for example :1125 means year 2011,week 25.The warranty is for free repair or replacement and covers manufacturing faults only. For faults beyond the 5-year warranty we reserve the right to charge for time and parts. 2) Limited Warrenty Any defects caused by wrong operation.Any damages caused by unauthorized removal, maintenance, modifying, incorrect connection and replacement of chips. Any damages due to transportation, vibration etc. after purchase.Any damages caused by earthquake, fire, lightning, pollution and abnormal voltage.Any damages caused by negligence, inappropriate storing at high temperatures and humidity or near harmful chemicals. Product has been updated 3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.5) Never connect any cables while power is on and always assure correct connections to avoid short circuitsbefore switching on.6)7) For update information please consult your supplier. Please ensure that the cable is secured tightly in the connector

Shenzhen Sunricher Technology Co.,Ltd 310,Longtaili building No.30,Avenue 4th,High Tech Sience Park,Shenzhen Confidentiality Request Letter Page 1 of 1 Rev 2.0 September 7, 2015 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Permanent Confidentiality Request Confidentiality Request regarding application for certification of FCC ID:2ACUQ2836 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: Zou Lifang/ Manager Contact information / address: 310,Longtaili building No.30,Avenue 4th,High Tech Sience Park,Shenzhen TEL: 0755-86017718 FAX: 0755-26765389 E-mail: [email protected]

External Photo

FCC Certification Label FCC ID:2ACUQ2836 Label Location on EUT label size:high 1cm, Wide:2 cm EUT View/ FCC ID Label Location

Internal Photo Antenna

FCC PART 15.231 EMI MEASUREMENT AND TEST REPORT For Shenzhen Sunricher Technology Co.,Ltd 310,Longtaili building No.30,Avenue 4th,High Tech Sience Park,Shenzhen FCC ID:2ACUQ2836 (M/N): SR-2836RGB(US),SR-2836R(US),SR-2836CCT(US) This Report Concerns: Original Report Equipment Type: LED Controller Test Engineer: Lisa Chen Report No.: BSL150907-1 Receive EUT Date/Test Date: September 1, 2015/ September 1- September 23, 2015 Reviewed By: Mike moo Prepared By: BSL Testing Co.,LTD. NO. 24, ZH Park, Nantou, Shenzhen, 518000 China Tel: 86- 755-26508703 Fax: 86- 755-26508703 Page 2/27 TABLE OF CONTENTS 1. GENERAL INFORMATION ....................................................................................................3 1.1. Report information ............................................................................................................3 1.2. Measurement Uncertainty .................................................................................................3 2. PRODUCT DESCRIPTION ......................................................................................................4 2.1. EUT Description ...............................................................................................................4 2.2. Block Diagram of EUT Configuration..............................................................................5 2.3. Support Equipment List ....................................................................................................5 2.4. Test Conditions .................................................................................................................5 3. TEST RESULTS SUMMARY ...................................................................................................6 Modifications ................................................................................................................................6 4. TEST EQUIPMENT USED .......................................................................................................7 5. ANTENNA REQUIREMENT ...................................................................................................8 5.1. Standard Applicable..........................................................................................................8 5.2. Antenna Connected Construction .....................................................................................8 5.3. Result ................................................................................................................................8 6. CONDUCTED POWER LINE TEST .......................................................................................9 6.1. Test Equipment .................................................................................................................9 6.2. Test Procedure ..................................................................................................................9 6.3. Test Setup..........................................................................................................................9 6.4. Conducted Power line Emission Limits............................................................................9 6.5. Conducted Power Line Test Result.................................................................................10 7. RADIATED EMISSION TEST ...............................................................................................11 7.1. Test Equipment ...............................................................................................................11 7.2. Test Procedure ................................................................................................................11 7.3. Radiated Test Setup ........................................................................................................11 7.4. Radiated Emission Limit.................................................................................................13 7.5. Radiated Emission Test Result .......................................................................................14 8. 20DB OCCUPIED BANDWIDTH ..........................................................................................22 8.1. Test Equipment ...............................................................................................................22 8.2. Test Procedure ................................................................................................................22 8.3. FCC 15.231(c) 20dB Bandwidth Limit...........................................................................22 8.4. Test Result ......................................................................................................................23 9. DEACTIVATION TESTING...................................................................................................25 9.1. Test Equipment ...............................................................................................................25 9.2. Test Procedure ................................................................................................................25 9.3. Deactivation Testing Requirement .................................................................................25 9.4. Test Result ......................................................................................................................26 Page 3/27 1. GENERAL INFORMATION 1.1. Report information 1.1.1.This report is not a certificate of quality; it only applies to the sample of the specific product/equipment given at the time of its testing. The results are not used to indicate or imply that they are application to the similar items. In addition, such results must not be used to indicate or imply that BSL approves recommends or endorses the manufacture, supplier or use of such product/equipment, or that BSL in any way guarantees the later performance of the product/equipment. 1.1.2.The sample/s mentioned in this report is/are suppli…

Text truncated - open the document above for the full version.

Radiated emissions test
