Technical description Description Function Component Antenna Transmit modulated RF signal ANT Filter Suppression of spurious emissions L1, T1, C1, C2, C13 RF IC Generate code signal to modulator U1 Oscillator Generate 27.145 MHz carrier X1, Q2 RF power amplifier and modulator Modulate the carrier and amplify the modulated RF signal Q1 Antenna Type: telescope antenna with unique antenna connector Antenna Gain: 0dBi Modulation Type: Pulse modulation The nominal conducted output power specified: -10.00dBm (+/- 3dB) The nominal radiated output power (e.r.p) specified: -12.15dBm (+/- 3dB)

1 INTERTEK TESTING SERVICES Analysis Report The equipment under test (EUT) is a portable transmitter for a Helicopter Series operating at 27.145 MHz which is controlled by a crystal. The EUT is powered by six 1.5V AA size batteries. For more detail information pls. refer to the user manual. Antenna Type: telescope antenna with unique antenna connector Antenna Gain: 0dBi The nominal conducted output power specified: -10.00dBm (+/- 3dB) The nominal radiated output power (e.r.p) specified: -12.15dBm (+/- 3dB) Modulation Type: Pulse modulation According to the KDB 447498: The worst-case peak radiated emission for the EUT is 84.3dBμV/m at 3m in the frequency 27.145MHz The EIRP = [(FS*D) ^2 / 30] mW= -10.93dBm The ERP = EIRP – 2.15 = -13.08 dBm which is within the production variation. The maximun conducted output power specified is -7dBm =0.2mW The source- based time-averaging conducted output power = 0.2* Duty Cycle mW < 0.2mW (Duty Cycle<100%) The SAR Exclusion Threshold Level for 27.145MHz when the minimum test separation distance is < 50mm: = 474 * [1 + log(100/f(MHz)]/2 = 371.2 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. Transmitter Duty Cycle Calculation The duration of one cycle = 100ms Effective period of the cycle= 840μs x 24 + 1.68ms x 13 + 3.08ms x 2 = 48.16ms DC = 48.16ms / 100ms = 0.4816 or 48.16% FCC ID: 2ACUT-482015005350V

Transmitter Circuit Diagram 27.145MHz NC NC NC DIP-14 DC 9V
