2ACVQ57930TPIR CHIME WITH WIRELESS RECEIVER

1. Insert 3AA batteries in rear compartment of Receiver and 1 9V battery in rear compartment of Sensor. 2. Volume Control. There 4 levels of sound (off, low, medium, loud) which is adjusted one level at a time at (A) upper switch on side of Receiver. 3. Ring Tones. There are 32 ring tones, which are set at (B) lower part of switch on side of Receiver. The ring tones may be changed one at a time by pressing the switch. The LED light (C) on the front of the Receiver will flash when the ring tones are playing. 4. Screw Mounting Bracket into wall. Slide opposite end of ball-looking part into rear lower section (D) of Sensor. Press ball into Mounting Bracket and adjust angle as needed. Note: The Sensor works at an angle of about 100 degrees and with a motion-detection range of about 20 feet. If sensor is detecting more movement than you wish, cover part of Sensor with opaque tape or paper to narrow sensing angle. 5. Place Receiver where needed. Note that the fewer walls that separate the Sensor from the Receiver the longer the distance that the Receiver can be placed. Over time, the batteries will weaken and may need to be replaced. 6. Adjust On/Off switch (E) on side of Sensor as needed. INSTRUCTIONS FOR USE E D C A B RECEIVERSENSOR FCC STATEMENT 1.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. 2.Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/ TV technician for help. 10

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 4.0 Tatco Products, Inc. Aug 22, 2014 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Tatco Products, Inc. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product name: PIR CHIME WITH WIRELESS RECEIVER Model No.: 57930-T FCC ID: 2ACVQ57930T Sincerely, Client’s signature: Client’s name / title: Jeff Dworetz / President Contact address: 6750-B Jones MIII Court Norcross, GEORGIA 30092, USA

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] FCC Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Tatco Products, Inc. FCC Confidentiality Request Letter Aug 22, 2014 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACVQ57930T We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Client’s signature: Client’s name / title: Jeff Dworetz / President Contact address: 6750-B Jones MIII Court Norcross, GEORGIA 30092, USA

External photos

Internal photos Antenna

Report No.: ATE20141451 Page 1 of 27 FCC ID: 2ACVQ57930T ACCURATE TECHNOLOGY CO., LTD APPLICATION CERTIFICATION On Behalf of Tatco Products, Inc. PIR CHIME WITH WIRELESS RECEIVER Model No.: 57930-T FCC ID: 2ACVQ57930T Prepared for : Tatco Products, Inc. Address : 6750-B Jones MIII Court Norcross, GEORGIA 30092, USA Prepared by : ACCURATE TECHNOLOGY CO., LTD Address : F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20141451 Date of Test : July 26 – Aug 19, 2014 Date of Report : Aug 19, 2014 Report No.: ATE20141451 Page 2 of 27 FCC ID: 2ACVQ57930T ACCURATE TECHNOLOGY CO., LTD TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 4 1.1. Description of Device (EUT)....................................................................................................................4 1.2. Description of Test Facility ......................................................................................................................5 1.3. Measurement Uncertainty.........................................................................................................................5 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 6 3. SUMMARY OF TEST RESULTS................................................................................................... 7 4. THE FIELD STRENGTH OF RADIATION EMISSION ............................................................ 8 4.1. Block Diagram of Test Setup....................................................................................................................8 4.2. The Field Strength of Radiation Emission Measurement Limits..............................................................8 4.3. Configuration of EUT on Measurement ...................................................................................................9 4.4. Operating Condition of EUT ....................................................................................................................9 4.5. Test Procedure ..........................................................................................................................................9 4.6. The Field Strength of Radiation Emission Measurement Results ..........................................................10 5. 20DB OCCUPIED BANDWIDTH ................................................................................................ 12 5.1. Block Diagram of Test Setup..................................................................................................................12 5.2. The Bandwidth of Emission Limit According To FCC Part 15 Section 15.231(c) ................................12 5.3. EUT Configuration on Measurement .....................................................................................................12 5.4. Operating Condition of EUT ..................................................................................................................12 5.5. Test Procedure ........................................................................................................................................12 5.6. Measurement Result ...............................................................................................................................13 6. RELEASE TIME MEASUREMENT............................................................................................ 14 6.1. Block Diagram of Test Setup..................................................................................................................14 6.2. Release Time Measurement According To FCC Part 15 Section 15.231(e) ..........................................14 6.3. EUT Configuration on Measurement .....................................................................................................14 6.4. Operating Condition of EUT ..................................................................................................................14 6.5. Test Procedure ........................................................................................................................................14 6.6. Measurement Result ...............................................................................................................................15 7. AVERAGE FACTOR MEASUREMENT .................................................................................... 16 7.1. Block Diagram of Test Setup..................................................................................................................16 7.2. Average factor Measurement according to ANSI C63.4-2009...............................................................16 7.3. EUT Configuration on Measurement .....................................................................................................16 7.4. Operating Condition of EUT ..................................................................................................................16 7.5. Test Procedure ........................................................................................................................................16 7.6. Measurement Result ...............................................................................................................................17 8. ANTENNA REQUIREMENT........................................................................................................ 18 8.1. The Requirement ....................................................................................................................................18 8.2. Antenna Construction .............................................................................................................................18 Report No.:…
