2ACWISE50FYTBLED TV

Printed in China www.SEIKI.com Service Hotlin e: 1-855-MY-SEIKI (1-855-697-3454) Ligne d’assistance téléphonique: Línea de servicio: Imprimé en Chine Impreso en China USER MANUAL Read the User Manual carefully before using the TV and keep it for further reference. MANUEL D’UTILISATION MANUAL DEL USUARIO Avant d’utiliser le téléviseur, lisez attentivement le manuel d’utilisation et conservez-le pour consultation future Lea el Manual del usuario antes de utilizar el televisor y consérvelo para futuras consultas SE50FYT © 2015 Seiki LLCAll r ights reserved. 1 En - CONTENTS Important Safety Instructions 2 Safety Information 3 Preparation 4 What's Included 4 Front View 5 Rear View 6 Installing the Stand 7 Removing the Stand for Wall-Mounting 7 Remote Control 8 Connecting External Devices 9 Customizing TV Settings 10 Initial Setup 10 Navigating the Setup Settings 11 Streaming 12 Media 13 Viewing Photos 13 Listening to Music 14 Source 14 Setup 15 Settings 15 Audio 16 Picture 17 Channel 18 Time 18 Network 19 Lock 21 Parental Control 22 Troubleshooting 24 Maintaining 25 Specification 26 Limited Warranty 27 OTT APP Service 28 CONTENTS 2 En - IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS • Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as the power - supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. • Please keep the unit in a well-ventilated environment. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus should not be exposed to dripping or splashing. Objects filled with liquids, such as vases should not be placed on apparatus. WARNING: The batteries shall not be exposed to excessive heat such as sunshine, fire or the like. WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable. WARNING: To reduce the risk of electric shock, do not remove cover (or back) as there are no user-serviceable parts inside. Refer servicing to qualified personnel. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance. This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth. This product contains electrical or electronic materials. The presence of these materials may,if not disposed of properly, have potential adverse effects on the environment and human health. Presence of this label on the product means it should not be disposed of as unsorted waste and must be collectedseparately. As a consumer, you are responsible for ensuring that this product is disposed of properly. • Read these instructions – All the safety and operating instructions should be read before this product is operated. • Keep these instructions – The safety and operating instructions should be retained for future reference. • Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to. • Follow all instructions – All operating and use instructions should be followed. • Do not use this apparatus near water – The appliance should not be used near water or moisture – for example, in a wet basement or near a swimming pool, and the like. • Clean only with dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. • Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. • Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. • Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. • Only use attachments/accessories specified by the manufacturer. • Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over. • Unplug this apparatus during lightning storms or when unused for long periods of time. 3 En - SAFETY INFORMATION SAFETY INFORMATION To ensure reliable and safe operation of this equipment, please carefully read all the instructions in this user guide, especially the safety information below. Electrical Safety • The TV set should only be connected to a main power supply with voltage that matches the label at the rear of the product. • To prevent overload, do not share the same power supply socket with too many other electronic components. • Do not place any connecting wires where they may be stepped on or tripped over. • Do not place heavy items on any connecting wire, which may damage the wire. • Hold the main plug, not the wires, when removing from a socket. • During a thunderstorm or when not in using the television for long periods, turn off the power switch on the back of the television. • Do not allow water or moisture to enter the TV or power adapter. Do NOT use in wet, moist areas, such as bathrooms, steamy kitchens or near…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Shenyang Tongfang Multimedia Technology Co., Limited (2015-11-20) To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Shenyang Tongfang Multimedia Technology Co., Limited hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product: LED TV M/N: SE50FS, SE50FYT, SE50XXXXXXXXX (where X would be any Arabian number or English letter or blank) FCC ID: 2ACWISE50FYTB Sincerely, Yu Li Engineer Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template& Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (current) 4.0 5.0 Nov 19 2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 5.0 Shenyang Tongfang Multimedia Technology Co., Limited (2015-11-20) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACWISE50FYTB Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Yu Li Engineer Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China

Shenyang Tongfang Multimedia Technology Co., Limited WIFI Channel 12 & 13 Declaration Letter To whom it may concern : We have declared below featured for FCC equipment authorization in regard to 802.11b/g/n channel 12 & 13 operating capability for FCC ID: 2ACWISE50FYTB Please check Product hardware does not have the capability to operate on channel 12 & 13 Product hardware has the capability to operate on channel 12 & 13. However , these 2 channels will be disabled via software and user will not able to enable these 2 channels Product hardware has the capability to operate on channel 12 & 13. And meeting KDB 594280 D01 requirement. Pls explain detail here. Others Pls explain detail here. Yu Li Engineer Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China Telephone: 86-755-33010881 E-mail: [email protected]

Declaration on model difference Page 1 of 1 We the undersigned hereby confirm that these models are identical, and all models have the same RF module and antenna, except for decorative parts in front panels, color of enclosures and design of signal input/output terminals in secondary circuits. „ Productio n name Trade name FCC ID INPUT Model no. LED TV Element, Fluid, THTF, SEIKI, Westinghouse, Sharp, Onn, ELEMENT ELECTRONICS 2ACWISE50FYTB AC 100V- 240V, 50/60Hz, 120W SE50FS, SE50FYT, SE50XXXXXXXXX (where X would be any Arabian number or English letter or blank) Confirmed by: Yu Li Engineer 2015-11-20 Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China

Date: 2015-11-20 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2ACWISE50FYTB To Whom It May Concern: This letter is to ascertain that Shenyang Tongfang Multimedia Technology Co., Limited Product LED TV has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Yu Li Engineer Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China

46.5mm 66mm Model No.: SE50FYT INPUT POWER: AC 100-240V~ 50/60Hz, 120W THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION CONFORMS TO/CONFORME À ANSI/UL STD.60065 CERTIFIED TO/CERTIFIÉ AU CAN/CSA STD. C22.2 No.60065 IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. FCC ID:2ACWISE50FYTB MADE IN CHINAS/N:

Label Location on EUT

Antenna

RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) FCC ID：2ACWISE50FYTB EUT Specification EUT LED TV Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classification Occupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 14.55dBm for 802.11b; 13.52dBm for 802.11g; 12.61Bm for 802.11n(HT20); 11.57dBm for 802.11n(HT40); Antenna gain (Max) 2.0dBi ( for per antenna port Max) Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 , Pout=output power to antenna in Mw G= gain of antenna in linear scale, Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Test Channel Measurement Peak Output Power(dBm) 802.11b 802.11g 802.11n(HT20) 802.11n(HT40) Lowest 12.11 11.59 10.68 9.65 Middle 13.26 12.96 11.85 10.16 Highest 14.55 13.52 12.61 11.57 Operating Mode Test Channel Tune up tolerance (dBm) Max tune up conducted power(dBm) Output Peak power (mW) Ant. Gain (dBi) Ant. Gain (numeric) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 802.11b 1 12±1 13 19.953 2 1.585 0.006291 1 6 13±1 14 25.119 2 1.585 0.007920 1 11 15±1 16 39.811 2 1.585 0.012552 1 802.11g 1 12±1 13 19.950 2 1.585 0.006291 1 6 13±1 14 25.120 2 1.585 0.007920 1 11 14±1 15 31.620 2 1.585 0.009971 1 802.11n (HT20) 1 11±1 12 15.850 2 1.585 0.004997 1 6 12±1 13 19.950 2 1.585 0.006291 1 11 13±1 14 25.120 2 1.585 0.007920 1 802.11n (HT40) 3 10±1 11 12.590 2 1.585 0.003969 1 6 10±1 11 12.590 2 1.585 0.003969 1 9 12±1 13 19.950 2 1.585 0.006291 1 Signature: Print: Sam Lv Title: Manager Date: 2015-11-23

TRF No.: FCC 15.247/A Page 1 of 73 Report No.: ED151012027E Ver.1.0 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF LED TV Model No.: SE50FS, SE50FYT, SE50XXXXXXXXX (where X would be any Arabian number or English letter or blank) FCC ID: 2ACWISE50FYTB Trademark: Element, Fluid, THTF, SEIKI, Westinghouse, Sharp, Onn, ELEMENT ELECTRONICS Report No.: ED151012027E Issue Date: November 27, 2015 Prepared for Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road HunNan New District Shenyang, LiaoNing Province P.R .China Prepared by EMTEK(Dongguan) Co., Ltd. No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: 86-769-22807078 FAX: 86-769-22807079 This report shall not be reproduced, except in full, without the written approval of EMTEK(Dongguan) Co., Ltd. TRF No.: FCC 15.247/A Page 2 of 73 Report No.: ED151012027E Ver.1.0 VERIFICATION OF COMPLIANCE Applicant: Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China Manufacturer: Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China Product Description: LED TV Model Number: SE50FS, SE50FYT, SE50XXXXXXXXX (where X would be any Arabic number or English letter or blank) (Notes: these models are identical except for decorative parts in front panels, color of enclosures and design of signal input/output terminals in secondary circuits. So we prepared SE50FYT for full test.) We hereby certify that: The above equipment was tested by EMTEK(Dongguan) Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10-2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247(2015). Date of Test : October 12, 2015 to November 02, 2015 Prepared by : Mary Jiang/Editor Reviewer : Alan He/Supervisor Approved & Authorized Signer : Sam Lv/Manager TRF No.: FCC 15.247/A Page 3 of 73 Report No.: ED151012027E Ver.1.0 Modified Information Version Summary Revision Date Report No. Ver.1.0 Original Report / ED151012027E TRF No.: FCC 15.247/A Page 4 of 73 Report No.: ED151012027E Ver.1.0 Table of Contents 1. GENERAL INFORMATION .......................................................................................................................... 6 1.1 PRODUCT DESCRIPTION ............................................................................................................................ 6 2. SYSTEM TEST CONFIGURATION ............................................................................................................. 7 2.1 EUT CONFIGURATION ............................................................................................................................... 7 2.2 EUT EXERCISE ......................................................................................................................................... 7 2.3 TEST PROCEDURE .................................................................................................................................... 7 2.4 CONFIGURATION OF TESTED SYSTEM ......................................................................................................... 7 3. DESCRIPTION OF TEST MODES .............................................................................................................. 8 4. SUMMARY OF TEST RESULTS ................................................................................................................. 9 5. TEST FACILITY ......................................................................................................................................... 10 6. CONDUCTED EMISSIONS TEST ............................................................................................................. 11 6.1 MEASUREMENT PROCEDURE ................................................................................................................... 11 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .............................................................................. 11 6.3 MEASUREMENT EQUIPMENT USED ........................................................................................................... 11 6.4 CONDUCTED EMISSION LIMIT ................................................................................................................... 11 6.5 MEASUREMENT RESULT .......................................................................................................................... 11 7. RADIATED EMISSION TEST .................................................................................................................... 16 7.1 MEASUREMENT PROCEDURE ................................................................................................................... 16 7.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .............................................................................. 17 7.3 MEASUREMENT EQUIPMENT USED ........................................................................................................... 18 7.4 RADIATED EMISSION LIMIT ....................................................................................................................... 19 7.5 MEASUREMENT RESULT .......................................................................................................................... 20 8. 6DB BANDWIDTH TEST ........................................................................................................................... 29 8.1 MEASUREMENT PROCEDURE ................................................................................................................... 29 8.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ...…

Text truncated - open the document above for the full version.
