2ACYPYN622CE-TTL Wireless Flash Trigger Transceiver

User Manual 用户手册 注意事项CONTENTS Cautions. . . . . . . . . . . . . . . . . .1 General Description. . . . . . . . . . . . .2 Suppor ted Functions List. . . . . . . . . . .3 Compatibility List. . . . . . . . . . . . . .4 Name of Par ts . . . . . . . . . . . . . . .5 Preparation Before Use. . . . . . . . . . .6-7 Setting. . . . . . . . . . . . . . . . . .8-9 Flash Awaking /Testing Flash. . . . . . . . .10 Remote Control Mode. . . . . . . . . . . .11 Automatic Flash (E-TTL II). . . . . . . . .12 Shutter Sync. . . . . . . . . . . . . . .13 FEB/FEC . . . . . . . . . . . . . . . .14 Zoom (Flash Coverage) . . . . . . . . . .15 Manual/Multi Flash. . . . . . . . . . . .16 Wireless Function. . . . . . . . . . .17-20 Mix Control Mode. . . . . . . . . . . . .21 Flash Triggering of Type B/C Camera. . . . .22 PC Por t Triggering . . . . . . . . . . . . .23 References . . . . . . . . . . . . . .24-25 Troubleshooting. . . . . . . . . . . .26-27 Specifications. . . . . . . . . . . . . . .28 vRead this user manual while also referring to your camera's & flash's user manual before using in order to correct use this product. ŸPlease turn off power supplies of all equipment when connecting or installing the product. ŸPlease keep it dr y. Be sure not to use wet hand to touch the product. It is also not allowed to immerse the product into waster or make it be exposed in the rain; other wise it may not work normally or even be damaged. ŸDo not use it in explosive situations; violation of this warning may cause an explosion or fire. ŸThis product involves batter y, please be in strict accordance with the relevant provisions on the use of the batter y, other wise it would cause proper ty damage or personal injur y. Cautions 1 The functions described in this user manual are all under the conditions that: all transceivers are set in the same channel, power of all equipments is on, enabled the flash firing. This product is a wireless transceiver, to express conveniently, in this user manual, it is called (master control unit) when being installed on the hot shoe of the camera, while it is called (slave unit) when a flash is installed or connected. transmitter receiver Thank you for purchase the products of Yongnuo firstly. ŸY N - 6 2 2 C E - T T L w i r e l e s s f l a s h t r i g g e r i s a h i g h performance master and slave equipment of multiple flashes photography, through digital FSK 2.4GHz radio wireless transmission, and different photographic effects can be realized through setting your flash at 360 degrees. It design of transceiver, the distance of remote control reaches 100M, suppor ting 7 wireless channels and A/B/C three groups. ŸRemotely change the modes and parameters of the flash quickly when using the Canon EOS series DSLR cameras which suppor ts external flash function , such as TTL ratio or manually set each group of flash output. Suppor t high-speed sync, the max sync speed is 1/8000s*, Suppor t E-TTL, Manual and Multi flash modes. Suppor t E-TTL flash installing on the top of transmitter. ŸY N - 6 2 2 C 2 t r a n s c e i v e r s k i t c o n s i s t t w o s i m i l a r transceivers, suppor t one camera controlling multiple flashes at the same time. Install the flashes with the receiver additionally purchased to make them into an application form of multiple-flashes, number of the receivers is not limited. ※Compatible cameras/flashes is needed when using TTL function ※ The highest sync speed of some camera types is 1/4000s, some of flash or camera models may reach to 1/250s only or less if it doesn't suppor t high sync speed. General Description 2 ŸCompatible flash mode: E-TTL (II)/ Manual/ Multi ŸCompatible Shutter sync: 1st cur tain, 2nd cur tain, high speed sync (HSS/FP), Max 1/8000s sync speed ŸControl remote flash using camera's flash control menu screen(Remote Control Mode) ŸSuppor t E-TTL / Manual/ Multi flash mode mix using(Mix Control Mode) ŸFlash on hot-shoe of transmitter suppor ts ETTL ŸSuppor t Flash Exposure Compensation (FEC) ŸSuppor t Flash Exposure Bracketing (FEB) ŸSuppor t Flash Exposure Lock (FEL) ŸSuppor t modeling Flash ŸSuppor t E-TTL group ratio (ALL/ A:B/ A:B C) ŸSuppor t Manual/Multi group (ALL/ A:B/ A:B:C) ŸSuppor t flash zooming (auto, manual) ŸSuppor t AF assist beam emitter(AF Lamp) ŸSuppor t PC por t triggering strobe flashes and suppor t 1st, 2nd cur tain/HSS (Super Sync) ŸSuppor t LCD Live view triggering ŸSuppor t high-speed continuous shooting trigger ŸSettings saved automatically ŸCompatible with ALL YongNuo/ Canon EXII series flashes ŸSuppor t single-contact of camera & flash triggering (max sync speed is 1/250s) Suppor ted Functions List 3 List of Type A cameras: Canon EOS 5D Mark II/5DMark III,1Ds Mark III,1D Mark IV/1D Mark III,7D,60D, 50D,40D /650D/600D/550D/500D/450D/1100D/1000D List of Type B cameras: Canon EOS 5D,10D,20D,30D, 300D,350D,400D,1D,1D Mark II Compatible ETTL flash list (suppor t wireless remote control through camera menu) Canon 600EX(RT)/580EXII/430EXII/320EX/270EX(II) YongNuo YN568EX/YN565C/YN468C(II)/YN467C(II)/ YN465C Compatibility List 4 Functions suppor ted by the product depend on the camera and flash used. According to different types of cameras, in this user manual, the EOS DSLR camera with external flash(speedlite) control menu is called ; while EOS DSLR camera without external flash control menu is called ; other camera brands with standard hot-shoe is called . type A camera type B camera type C camera 430EX/550EX/580EX or other par ts of the flash is not suppor ted remote control via the camera menu, need to manually set the flash modes(parameters). ※ When using general type manual flash or strobe flash connect to PC por t, flash output needs to be set manually. ※ In this user manual, assumes that you are using the type A camera and compatible ETTL flash, as for type B/ C camera, please refer to page 22. Name of Par ts ※The protective film can be torn out. 5 1).Standby state(red) 2).TX communicating state(green blinks) 3).RX communic…

Text truncated - open the document above for the full version.

SHENZHEN YONGNUO PHOTOGRAPHIC EQUIPMENT CO., LTD Date: 16.08.2014 Authority to Act as an Agent We declare that the following representative (agent) Name Mark Zhu Position Manager Company Name Shenzhen Certification Technology Service Co., Ltd. Address 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2 nd Road, Bao’an District, Shenzhen 518126, P.R. China Tel / Fax 0755-86375541/0755-26736857 Email [email protected] to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Name E-TTL Wireless Flash Trigger Transceiver Model Name YN622C Brand Name YONGNUO . Yours sincerely, Signatory Name salas Li Position Manager Company Name SHENZHEN YONGNUO PHOTOGRAPHIC EQUIPMENT CO., LTD Address B509 5/F, BUILDING 2, SAIGE SCIENCE AND TECHNOLOGY PARK, NORTH OF HUAQIANG ROAD, FUTIAN, SHENZHEN, CHINA. Tel +86-755-83762448 Fax +86-755-83762765 Email [email protected] In case of FCC, we certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance.

SHENZHEN YONGNUO PHOTOGRAPHIC EQUIPMENT CO., LTD Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: SHENZHEN YONGNUO PHOTOGRAPHIC EQUIPMENT CO., LTD FCC ID : 2ACYPYN622C FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 we hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☒ Block Diagrams Details of device showing the frequency of all oscillators ☒ Operational Description Description of the circuit functions Note: Exhibit types that are commonly held confidential are: (1) Schematics, (2) Block Diagrams, (3) Bill Of Materials, (4) Operational Descriptions. Any exhibit NOT granted confidentiality is viewable on the FCC website as soon as a grant is issued. These documents contain detailed system and equipment description and related information about the product which we considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, we consider that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours sincerely, Signatory Name salas Li Position Manager Company Name SHENZHEN YONGNUO PHOTOGRAPHIC EQUIPMENT CO., LTD Address B509 5/F, BUILDING 2, SAIGE SCIENCE AND TECHNOLOGY PARK, NORTH OF HUAQIANG ROAD, FUTIAN, SHENZHEN, CHINA. Tel +86-755-83762448 Fax +86-755-83762765 Email [email protected]

Size:5mm*15mm FCC ID: 2ACYPYN622C

Label Location

Antenna

Shenzhen Certification Technology Service Co., Ltd 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2nd Road, Bao'an District, Shenzhen518126, P.R. China. TEST REPORT FCC ID: 2ACYPYN622C Applicant : SHENZHEN YONGNUO PHOTOGRAPHIC EQUIPMENT CO., LTD Address : B509 5/F, BUILDING 2, SAIGE SCIENCE AND TECHNOLOGY PARK, NORTH OF HUAQIANG ROAD, FUTIAN, SHENZHEN, CHINA . Equipment under Test (EUT): Name : E -TTL Wireless Flash Trigger Transceiver Model : YN622C Standards : FCC PART 15, SUBPART C : 2013 (Section 15.249) Report No. : CST-TCB140624033 Date of Test : August 03 - 08, 2014 Date of Issue : August 09, 2014 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Certification Technology Service Co., Ltd. Or test done by Shenzhen Certification Technology Service Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Certification Technology Service Co., Ltd. Approvals in writing. FCC ID: 2ACYPYN622C Page 1 of 35 Report No.: CST-TCB140624033 TABLE OF CONTENT Description Page 1 General Information ----------------------------------------------------------------------------------- 3 1.1 Description of Device (EUT) ---------------------------------------------------------------- 3 1.2 Description of Test Facility ------------------------------------------------------------------ 3 2 EMC Equipment List ------------------------------------------------------------------------------- 4 3 Test Procedure ---------------------------------------------------------------------------------------- 5 4 Summary of Measurement ------------------------------------------------------------------------ 6 4.1 Summary of test result ----------------------------------------------------------------------- 6 4.2 Test mode -------------------------------------------------------------------------------------- 6 5 POWER LINE CONDUCTED EMISSION --------------------------------------------------- 8 5.1 Conducted Emission Limits(15.209&249) ------------------------------------------------ 8 5.2 Test Setup -------------------------------------------------------------------------------------- 8 5.3 Test Procedure --------------------------------------------------------------------------------- 9 5.4 Test Results ------------------------------------------------------------------------------------ 9 6 Radiation Emission -------------------------------------------------------------------------------- 10 6.1 Radiation Emission Limits(15.209&249 (a)) -------------------------------------------- 10 6.2 Test Setup ------------------------------------------------------------------------------------- 11 6.3 Test Procedure -------------------------------------------------------------------------------- 12 6.4 Test Equipment Setting For emission test. ----------------------------------------------- 13 6.5 Test Condition -------------------------------------------------------------------------------- 13 6.6 Test Result ------------------------------------------------------------------------------------ 13 7 Occupied bandwidth ------------------------------------------------------------------------------- 19 7.1 Test limit -------------------------------------------------------------------------------------- 19 7.2 Method of measurement -------------------------------------------------------------------- 19 7.3 Test Setup ------------------------------------------------------------------------------------- 19 7.4 Test Results ----------------------------------------------------------------------------------- 19 8 Band Edge Check ---------------------------------------------------------------------------------- 22 8.1 Test limit -------------------------------------------------------------------------------------- 22 8.2 Test Procedure -------------------------------------------------------------------------------- 22 8.3 Test Setup ------------------------------------------------------------------------------------- 22 8.4 Test Result ------------------------------------------------------------------------------------ 22 9 Antenna Requirement ----------------------------------------------------------------------------- 27 9.1 Standard Requirement ----------------------------------------------------------------------- 27 9.2 Antenna Connected Construction ---------------------------------------------------------- 27 9.3 Result ------------------------------------------------------------------------------------------ 27 10 Photographs of Test Setup ------------------------------------------------------------------------ 28 11 Photographs of EUT ------------------------------------------------------------------------------- 30 FCCID: 2ACYPYN622C Page 2 of 35 Report No.: CST-TCB140624033 1 General Information 1.1 Description of Device (EUT) Trade Name : YONGNUO EUT : E-TTL Wireless Flash Trigger Transceiver Model No. : YN622C D I F F. : N/A Type of Antenna : PCB Antenna, Max. Gain: 1.5dBi Operation Frequency : 2403-2470MHz Channel number : 7 Modulation type : FSK Power Supply : DC 3V Supply by battery Applicant : SHENZHEN YONGNUO PHOTOGRAPHIC EQUIPMENT CO., LTD Address : B509 5/F, BUILDING 2, SAIGE SCIENCE AND TECHNOLOGY PARK, NORTH OF HUAQIANG ROAD, FUTIAN, SHENZHEN, CHINA . Manufacturer : SHENZHEN YONGNUO PHOTOGRAPHIC EQUIPMENT CO., LTD Address : B509 5/F, BUILDING 2, SAIGE SCIENCE AND TECHNOLOGY PARK, NORTH OF HUAQIANG ROAD, FUTIAN, SHENZHEN, CHINA . 1.2 Description of Test Facility Shenzhen Certification Technolog…

Text truncated - open the document above for the full version.

Photographs-Radiated Emission Test Setup in Chamber Below 1G Above 1G
