2ACZ4BLTC-200SMART LED CONTROLLER BLE

FCC Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is con-nected. • Consult the dealer or an experienced radio/TV technician for help. Caution Modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Compliance Information : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation IMPORTANT NOTE: FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this equipment near water. 6) Do not using near any heat sources such as radiators, heat resisters, stove, or other equipment that produce heat. European CE notice to users and product statements This product is CE marked according to the provisions of the R&TTE Directive(99/5/EC). Hereby, GB solutions Inc. declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. For further information, please contact http:// www.gb-solutions.org GB solutions Inc. A-203#, 29, Gonghang-daero 61-gil, Gangseo-gu, Seoul, Korea Tel: 82-2-717-9901 Fax: 82-2-943-9901 URL: www.gb-solutions.org CONTACT INFORMATION Manufacturer Address : A-203#, 29, Gonghang-daero 61-gil, Gangseo-gu, Seoul, Korea To locate in-country GB SOLUTIONS INC., distributors of the SMART LED CONTROLLER BLE please refer to the GB SOLUTIONS INC. Website http:// www.gb-solutions.org These distributor(s) represent local contacts for this product. CORPORATE HEADQUARTERS: GB SOLUTIONS INC. A-203#, 29, Gonghang-daero 61-gil, Gangseo-gu, Seoul, Korea Tel: 82-2-717-9901 Fax: 82-2-943-9901 Web: http://wwww.gb-solutions.org This device complies with Industry Canada license-exempt RSS standard(s). Operation is Subject to the following two condition: (1) this device may not cause interference ,and (2) this device must accept any interference, including interference that may cause undesired operation of the device. EUROPEAN UNION “DECLARATION OF CONFORMITY” DECLARATION OF CONFORMITY GB SOLUTIONS INC. A-203#, 29, Gonghang-daero 61-gil, Gangseo-gu, Seoul, Korea declare under our sole responsibility that the product(s) SMART LED CONTROLLER BLE – BLTC-200 to which this declaration relate(s) is in conformance with the following standards: EN 301 489-1 V1.9.2:2011 EN 301 489-17 V2.2.1:2012 EN 60950-1:2006/A2:2013 EN 300 328 V1.8.1:2012 following the provisions of the 1999/5/EC Directives.

GB solutions Inc. A-203#, 29, Gonghang-daero 61-gil, Gangseo-gu, Seoul, Korea November 03, 2014 Subject: DoC declaration To Whom it may concern, We, as the grantee of this project FCC ID: 2ACZ4BLTC-200, would like to declare that the composite portion categorized as computer peripheral has been authorized under the Declaration of Conformity procedures. Test Laboratory : Standard Engineering Co. Ltd. 145, Hwanggeumteo-gil, Eumam-myeon, Seosan-si, Chungcheongnam-do, Republic of Korea 356-844 Regards, Signature: Name/Title: jong kuk Park / Senior Research Engineer Company Name: GB solutions Inc. Brand Name : N/A Address: A-203#, 29, Gonghang-daero 61-gil, Gangseo-gu, Seoul, Korea TEL : +82-2-717-9901 FAX : +82-2-943-9901 Email : [email protected]

Photo 1: Exterior Photographs Top Bottom Side 1 Side 2 Side 3 Side 4

Label Information 1. Label Location 2. Label Drawing Label position 35mm 25mm

Interior view of EUT Internal Photos View of Main PCB(Top) View of Main PCB(Bottom) View of Antenna

PART LIST Bill Of Materials October 16,2015 16:11:31 Page1 Item Quantity Reference Part ______________________________________________ 1 1 ANT1 SDBTPTR3015 2 2 C1,C6 104 3 1 C2 1.5pF 4 1 C3 1.8nH 5 1 C4 100pF 6 1 C5 0.75pF 7 1 C7 16V 330uF 8 1 C8 47uF 20V 9 1 C9 22uF 10 1 D1 1N4148 11 2 D2,D3 LINK 12 12 D4,D5,D6,D7,D8,D9,D10, LED_0 D11,D12,D13,D14,D15 13 1 J1 CON5 14 1 J2 micro 5pin 15 1 J3 CON2 16 4 J4,J5,J6,J7 CON1 17 1 M1 MD-TLES 18 1 Q1 FDB8447L 19 2 R1,R19 10K 20 2 R2,R3 2.2K 21 1 R4 N.C 22 13 R5,R6,R7,R8,R9,R10,R11, 1M R12,R13,R14,R15,R16,R17 23 1 R18 1K (3225) 24 1 U1 PIC16F690 20-SSOP 25 1 U2 LDO, 3.3V (AP1117D33LA) 1 페이지

STANDARD ENGINEERING FCC ID : 2ACZ4BLTC-200 Report Number : STD-FCC-15070 Page 1/48 1. Applicant Name : GB solutions Inc. Brand Name : N/A Address : A-203#, 29, Gonghang-daero 61-gil, Gangseo-gu, Seoul, Korea FCC ID : 2ACZ4BLTC-200 2. Products Name : SMART LED CONTROLLER BLE Model No. : SBLTC-200 Variant Model No. : N/A Manufacturer : GB solutions Inc. Address : A-203#, 29, Gonghang-daero 61-gil, Gangseo-gu, Seoul, Korea 3. Test Standard: 47 CFR Part 15, Subpart C 4. Test Method: ANSI C63.10-2009 5. Test Result: PASS 6. Dates of Test: November 02, 2015 to November 06, 2015 7. Date of Issue: November 09, 2015 8. Test Laboratory : Standard Engineering Co. Ltd. FCC Designation Number : 624439 TEST REPORT Tested by Approved by SoonHo, Kim / Test Engineer SeongSeok, Seo / Compliance Engineer This report may not be reproduced without the full written consent of Standard Engineering Laboratory. Standard Engineering Co. Ltd. 377-11, Sinjang-ri, Eumam-myeon, Seosan-si, ChoongNam 356-844, South Korea Tel.: +82-41-663-9436, Fax :+82-41-663-9434 www.stdeng.com STANDARD ENGINEERING FCC ID : 2ACZ4BLTC-200 Report Number : STD-FCC-15070 Page 2/48 1. Test Summary TestTest RequirementTest methodResult Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203/15.247 (c) ANSI C63.10 2009 PASS AC Power Line Conducted Emission 47 CFR Part 15, Subpart C Section 15.207 ANSI C63.10 2009 PASS Conducted Peak Output Power 47 CFR Part 15, Subpart C Section 15.247 (b)(3) KDB558074 D01 v03r01 PASS 6dB Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.247 (a)(2) KDB558074 D01 v03r01 PASS Power Spectral Density 47 CFR Part 15, Subpart C Section 15.247 (e) KDB558074 D01 v03r01 PASS Band-edge for RF Conducted Emissions 47 CFR Part 15, Subpart C Section 15.247(d) KDB558074 D01 v03r01 PASS RF Conducted Spurious Emissions 47 CFR Part 15, Subpart C Section 15.247(d) KDB558074 D01 v03r01 PASS Radiated Spurious Emissions 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 2009PASS Band Edge (Radiated Emission) 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 2009PASS STANDARD ENGINEERING FCC ID : 2ACZ4BLTC-200 Report Number : STD-FCC-15070 Page 3/48 2. TABLE OF CONTENTS 1. Test Summary...........................................................................................................................................................2 2. Table of Contents....................................................................................................................................................3 3. General Information...............................................................................................................................................4 3.1 Client Information............................................................................................................................................4 3.2 General Description of E.U.T........................................................................................................................4 3.3 Details of E.U.T..................................................................................................................................................4 3.4 Operation Frequency each of channel.....................................................................................................5 3.5 Description of Support Units ......................................................................................................................5 3.6 Abnormalities from Standard Conditions...............................................................................................6 3.7 Other Information Requested by the Customer..................................................................................6 3.8 Test Location.....................................................................................................................................................6 4. Equipment Used during Test..............................................................................................................................7 5. Test Results and Measurement Data...............................................................................................................8 5.1 Antenna Requirement....................................................................................................................................8 5.2 Conducted Peak Output Power..................................................................................................................9 5.3 6dB Occupy Bandwidth...............................................................................................................................12 5.4 Power Spectral Density...............................................................................................................................15 5.5 Band-edge for RF Conducted Emissions..............................................................................................18 5.6 RF Conducted Spurious Emissions..........................................................................................................20 5.7 Radiated Spurious Emissions....................................................................................................................24 5.7.1Harmonic and other spurious emissions........................................................................................28 5.7.1.1 Test at Lowest Channel in transmitting status..........................................................................28 5.7.1.2 Test at middle Channel in transmitting status..........................................................................31 5.7.1.3 Test at Highest Channel in transmitting status........................................................................34 5.8 Band Edge (Radiated Emission)...............................................................................................................37 5.9 Conducted Emissions at Mains Terminals 150 kHz to 30…
