2ACZP-ZED30Wireless Scale pad

Wireless Scale Pad Model # ZeD3.0 User’s Manual Access Bluetooth Select OK to allow this device to use Bluetooth。 “ZeD” Would Like to Use Bluetooth ;; Select device ❏My Device : devices connected before。 ❏Other Device : new device found。 ;; Close device selection page and go to main page. Tap to go back to device selection page when no devices found or make new selection ;; Main Page ;; Locate the car with 4 wheels on 4 scale pads. Every module will receive the measured weight and display on assigned locations. ;; Device location LF / RF / LR / RR Battery status : Battery turn red when power under 25% Unit : lbs & kg Default unit is lbs. To change unit, go to Menu to select Kg Memory : See next page # ;; ;; ;; ;; ;; Shut down the power of whole kit Tap for 2 seconds, the warning dialog box pop up for confirmation To turn on devices again, push power button on module. Calibration Place the scale pad on a flat & stable surface. Keep scale pad clear and no any weight on top. Keep still for 10 seconds, then tap Next to start calibration. Apply 3 Point Calibration process for higher accuracy. Step 1 : 1 st point Calibration : Step 2 – the 2 nd Point Note : 1.The weight input in Step 2 can not be zero. 2.Make sure the unit (lbs/kg) of weight input and App setting are the same. Place the weight in center area of scale pad. Input the second weight. Tap Start Calibration. Tap Start Calibration and wait 10 seconds to complete Step 2. Input the second weight. This weight can not be zero . Calibration : Step 3 – the 3 rd Point Place the weight for the 3 rd Point on scale pad center and Input the weight (lbs/kg). Note : 1.The weight in Step 3 must be higher than in Step 2. 2.Make sure the weight input and App setting unit are the same. ( lbs or kg ) This weight must be higher than the 2 nd point.. Calibration : Step 3 – the 3 rd Point Tap Start Calibration and wait for 10 seconds to complete Step 3. Tap” OK” after Calibration completed dialog box pop up and remove the weight. App will go back to Calibration entrance page. Hardware outline Battery door Power button RF connecting indicator Power on indicator Load cell input terminal #1, #2, #3 Load cell input terminal #4 When setting mode, user can using 3-Load cell or 4- Load cell input. If setting for 3-load input, please let terminal #4 open, and load cell connected to #1, #2 and #3. Warranty Limited One (1) Year Warranty Jackco Transnational Inc. warrants “Sharp Align” branded products to the original purchaser against any manufacturing defect in material or worksmanship for a period of one (1) year from the original date of purchase. If the defective product is determined to be covered under this warranty, it shall be repaired or replaced at manufacturer’s discretion without charge. Provided that the product must be returned with proof of purchase and freight prepaid when returned to the manufacturer. This warranty shall not apply to damage due to accident, negligent use, lack of maintenance, abuse or applications other than the specic function the product is designed for. No other warranties, expressed or implied, including those of merchantability or tness for particular purpose shall be applicable to Jackco except as specically stated herein. In no event shall Jackco be liable to any party for any special, direct, indirect, consequential, punitive damage of any nature caused by the sale or use of the equipment, tool, or product. Note: This warranty gives the original purchaser specific legal rights which may vary from state to state. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia MD 21046 USA Grantee Code: 2ACZP Ref: Attestat ion Statements Part 2.911(d)(7) Filing Designated U.S. Agent Information: FRN: 0023877905 U.S. Agent for Service of Process Attestation Jackco Transnational Inc. ("the applicant") certifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. Name: Jackco Transnational Inc. Contact Person: John Huang Address: 642 South Duggan Ave. Azusa CA 91702 USA Tel.: 1-626-582-8055 Jackco Transnational Inc. Email: jhuang @jackco. com Sincerely, Company name Company address Signature Name 642 South Duggan Ave. Azusa CA 91702 USA E-Mail Te Jackco Transnational Inc. : 642 South Duggan Ave. Azusa CA 91702 USA : jhuang@jackco. com Date: 2023/8/24 1-626-582-8055

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 FCC ID : 2ACZP-ZED30 To Whom It May Concern: Subject: Attestation Statements Part 2.911(d)(5)(i)-(ii) Filing Respectfully, Applicant's company name Applicant's company address Jackco Transnational Inc. ("the applicant") certifies that the equipment for which authorization is sought is not "covered" equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Signature Jackco Transnational Inc. Narme and Job Title Jackco Transnational Inc. ("the applicant") certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically narmed entity or any of its subsidiaries or affiliates) as an entity producing "covered" equipment. E-Mail 642 South Duggan Ave. Azusa CA 91702 USA Tel Attestation Statements Fax Statement for 47 CFR section 2.911(d) (5)0) Statement for 47 CFR section 2.911(d)(5)(i1) Jackco Transnational Inc. 642 South Duggan Ave. Azusa CA 91702 USA Join Huang /N/A : [email protected] Date: 2023/8/21 : 1-626-582-8055 : 1-626-582-8057

. Dear Sir, Address Thereby have entrusted the following person to be a proxy regarding application for Type Certification. Name Sporton International Inc. Hsinchu Laboratory Job Title e-mail Respectfully, Jackco Transnational Inc. FCC ID: 2ACZP-ZED30 Signature Leo Huang I am therefore responsible for the contents of the application. E-Mail No.8, Lane 724, Bo-ai St., Jhubei City, HsinChu County 302, Taiwan, R.O.C. Manager Applicant's company name Tel Applicant's company address Fax 642 South Duggan Ave. Azusa CA 91702 USA Name and Job Title Power of Attorney [email protected] : Jackco Transnational Inc. 642 South Duggan Ave. Azusa CA 91702 USA [email protected] 1-626-582-8055 : 1-626-582-805 7 Date: 2023/8/21

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID : 2ACZP-ZED30 To Whom It May Concern: Long Term Confidentiality Block Diagrams Pursuant to Sections 0.457 and 0.459 of the Commission's Rules, we hereby respectfully request confidential treatment of information accompanying this application as outlined below: Schematics Operational Description Respectfuly, Applicant's company name The above materials contain trade secrets and proprietary information not customarily released to the public. The public disciosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. Applicant's company address Jackco Transnational Inc. We understand that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Signature Tel Name and Job Title Fax E-Mail 642 South Duggan Ave. Azusa CA 91702 USA Confidential Letter Jackco Transnational Inc. 642 South Duggan Ave. Azusa CA 91702 USA Date: 2023/8/21 : [email protected] 1-626-582-8055 1-626-582-8057

PHOTOGRAPHS OF EUT EP372612 Sporton International Inc. Page No. : 1 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Aug. 23, 2023 Report Version : 01 Brand Name: ZeD Model Name: ZeD 3.0 PHOTOGRAPHS OF EUT EP372612 Sporton International Inc. Page No. : 2 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Aug. 23, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP372612 Sporton International Inc. Page No. : 3 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Aug. 23, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP372612 Sporton International Inc. Page No. : 4 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Aug. 23, 2023 Report Version : 01 M8 female circle connector PHOTOGRAPHS OF EUT EP372612 Sporton International Inc. Page No. : 5 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Aug. 23, 2023 Report Version : 01

Label and location

PHOTOGRAPHS OF EUT EP372612 Sporton International Inc. Page No. : 1 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Aug. 23, 2023 Report Version : 01 Brand Name: ZeD Model Name: ZeD 3.0 PHOTOGRAPHS OF EUT EP372612 Sporton International Inc. Page No. : 2 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Aug. 23, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP372612 Sporton International Inc. Page No. : 3 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Aug. 23, 2023 Report Version : 01 Ant. 1 PHOTOGRAPHS OF EUT EP372612 Sporton International Inc. Page No. : 4 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Aug. 23, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP372612 Sporton International Inc. Page No. : 5 of 5 Report Template No.: SE Ver 1.0_EP Issued Date : Aug. 23, 2023 Report Version : 01

RADIO EXPOSURE TEST REPORT Report No. : FA372612 TEL : 886-3-656-9065 Page Number : 2 of 8 FAX : 886-3-656-9085 Issued Date : Aug. 23, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1 General Description ............................................................................................................................. 5 1.1 EUT General Information ....................................................................................................................... 5 1.2 Antenna Information ............................................................................................................................... 5 1.3 Accessories ............................................................................................................................................ 5 1.4 Applicable Standards ............................................................................................................................. 5 1.5 Testing Location ..................................................................................................................................... 5 2 Maximum Permissible Exposure ........................................................................................................ 6 2.1 Limit of Maximum Permissible Exposure ............................................................................................... 6 2.2 MPE Calculation Method ........................................................................................................................ 6 2.3 MPE Exemption ...................................................................................................................................... 7 2.4 Calculated Result and Limit .................................................................................................................... 8 Photographs of EUT v01 RADIO EXPOSURE TEST REPORT Report No. : FA372612 TEL : 886-3-656-9065 Page Number : 3 of 8 FAX : 886-3-656-9085 Issued Date : Aug. 23, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 History of this test report Report No. Version Description Issued Date FA372612 01 Initial issue of report Aug. 23, 2023 RADIO EXPOSURE TEST REPORT Report No. : FA372612 TEL : 886-3-656-9065 Page Number : 4 of 8 FAX : 886-3-656-9085 Issued Date : Aug. 23, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 2 - Exposure evaluation PA SS - Conformity Assessment Condition: 1. The test results (PASS/FAIL) with all measurement uncertainty excluded are presented against the regulation limits or in accordance with the requirements stipulated by the applicant/manufacturer who shall bear all the risks of non-compliance that may potentially occur if measurement uncertainty is taken into account. 2. The measurement uncertainty please refer to each test result in the chapter "Measurement Uncertainty". Disclaimer: The product specifications of the EUT presented in the test report that may affect the test assessments are declared by the manufacturer who shall take full responsibility for the authenticity. Reviewed by: Sam Chen Report Producer: Cathy Chiu RADIO EXPOSURE TEST REPORT Report No. : FA372612 TEL : 886-3-656-9065 Page Number : 5 of 8 FAX : 886-3-656-9085 Issued Date : Aug. 23, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 1 General Description 1.1 EUT General Information RF General Information Evaluation Mode Frequency Range (MHz) Operating Frequency (MHz) Modulation Type Bluetooth 2400-2483.5 2402-2480 LE: GFSK 1.2 Antenna Information Ant. Port Brand Model Name Antenna Type Connector Gain (dBi) 1 1 J-MEX Scalar Module PCB Printed Antenna N/A 2.09 Note: The above information was declared by manufacturer. <For Bluetooth function> (1TX/1RX): Only Port 1 can be used as transmitting/receiving antenna. 1.3 Accessories Accessories Equipment Name Brand Name Model Name M8 female circle connector*4 Kinsun 4016Z40000 1.4 Applicable Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards:  47 CFR Part 2.1091  KDB 447498 D04 Interim General RF Exposure Guidance v01 The following reference test guidance is not within the scope of accreditation of TAF.  47 CFR Part 1.1307  47 CFR Part 1.1310 1.5 Testing Location Testing Location Information Test Lab.：Sporton International Inc. Hsinchu Laboratory Hsinchu ADD: No.8, Ln. 724, Bo’ai St., Zhubei City, Hsinchu County 302010, Taiwan (R.O.C.) (TAF: 3787) TEL: 886-3-656-9065 FAX: 886-3-656-9085 Test site Designation No. TW3787 with FCC. Conformity Assessment Body Identifier (CABID) TW3787 with ISED. RADIO EXPOSURE TEST REPORT Report No. : FA372612 TEL : 886-3-656-9065 Page Number : 6 of 8 FAX : 886-3-656-9085 Issued Date : Aug. 23, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 2 Maximum Permissible Exposure 2.1 Limit of Maximum Permissible Exposure (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 *(100) <6 3.0-30 1842/f 4.89/f *(900/f 2 ) <6 30-300 61.4 0.163 1.0 <6 300-1500 - - f/300 <6 1500-100,000 - - 5 <6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 *(100) <30 1.34-30 824/f 2.19/f *(180/f 2 ) <30 30-300 27.5 0.073 0.2 <30 300-1500 - - f/1…

Text truncated - open the document above for the full version.

RADIO TEST REPORT Report No. : FR372612 TEL : 886-3-656-9065 Page Number : 2 of 24 FAX : 886-3-656-9085 Issued Date : Aug. 23, 2023 Report Template No.: CB-A10_6 Ver1.3 Report Version : 01 Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1 General Description ............................................................................................................................. 5 1.1 Information .............................................................................................................................................. 5 1.2 Applicable Standards ............................................................................................................................. 7 1.3 Testing Location Information .................................................................................................................. 7 1.4 Measurement Uncertainty ...................................................................................................................... 8 2 Test Configuration of EUT ................................................................................................................... 9 2.1 Test Channel Mode ................................................................................................................................ 9 2.2 The Worst Case Measurement Configuration ........................................................................................ 9 2.3 EUT Operation during Test .................................................................................................................. 10 2.4 Accessories .......................................................................................................................................... 10 2.5 Support Equipment ............................................................................................................................... 10 2.6 Test Setup Diagram ............................................................................................................................. 11 3 Transmitter Test Result ..................................................................................................................... 12 3.1 DTS Bandwidth..................................................................................................................................... 12 3.2 Maximum Conducted Output Power .................................................................................................... 13 3.3 Power Spectral Density ........................................................................................................................ 16 3.4 Emissions in Non-restricted Frequency Bands .................................................................................... 18 3.5 Emissions in Restricted Frequency Bands ........................................................................................... 19 4 Test Equipment and Calibration Data .............................................................................................. 23 Appendix A. Test Results of DTS Bandwidth Appendix B. Test Results of Maximum Conducted Output Power Appendix C. Test Results of Power Spectral Density Appendix D. Test Results of Emissions in Non-restricted Frequency Bands Appendix E. Test Results of Emissions in Restricted Frequency Bands Appendix F. Test Photos Photographs of EUT v01 RADIO TEST REPORT Report No. : FR372612 TEL : 886-3-656-9065 Page Number : 3 of 24 FAX : 886-3-656-9085 Issued Date : Aug. 23, 2023 Report Template No.: CB-A10_6 Ver1.3 Report Version : 01 History of this test report Report No. Version Description Issued Date FR372612 01 Initial issue of report Aug. 23, 2023 RADIO TEST REPORT Report No. : FR372612 TEL : 886-3-656-9065 Page Number : 4 of 24 FAX : 886-3-656-9085 Issued Date : Aug. 23, 2023 Report Template No.: CB-A10_6 Ver1.3 Report Version : 01 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 1.1.2 15.203 Antenna Requirement PA SS - - 15.207 AC Power-line Conducted Emissions N/A Note 3.1 15.247(a) DTS Bandwidth PA SS - 3.2 15.247(b) Maximum Conducted Output Power PA SS - 3.3 15.247(e) Power Spectral Density PA SS - 3.4 15.247(d) Emissions in Non-restricted Frequency Bands PA SS - 3.5 15.247(d) Emissions in Restricted Frequency Bands PA SS - Note: It was supplied power by Battery for EUT; it’s not necessary to apply to AC Power Port Conducted Emission tests. Conformity Assessment Condition: 1. The test results (PASS/FAIL) with all measurement uncertainty excluded are presented against the regulation limits or in accordance with the requirements stipulated by the applicant/manufacturer who shall bear all the risks of non-compliance that may potentially occur if measurement uncertainty is taken into account. 2. The measurement uncertainty please refer to each test result in the chapter "Measurement Uncertainty". Disclaimer: The product specifications of the EUT presented in the test report that may affect the test assessments are declared by the manufacturer who shall take full responsibility for the authenticity. Reviewed by: Sam Chen Report Producer: Cathy Chiu RADIO TEST REPORT Report No. : FR372612 TEL : 886-3-656-9065 Page Number : 5 of 24 FAX : 886-3-656-9085 Issued Date : Aug. 23, 2023 Report Template No.: CB-A10_6 Ver1.3 Report Version : 01 1 General Description 1.1 Information 1.1.1 RF General Information Frequency Range (MHz) Bluetooth Mode Ch. Frequency (MHz) Channel Number 2400-2483.5 LE 2402-2480 0-39 [40] Band Mode BWch (MHz) Nant 2.4-2.4835GHz BT-LE(2Mbps) 2.0 1TX Note:  Bluetooth LE uses a GFSK modulation.  BWch is the nominal channel bandwidth. RADIO TEST REPORT Report No. : FR3726…

Text truncated - open the document above for the full version.

Bran Mode Type Manu Add Ant. P Tot. R Peak Direc Effici Effici Gai NHP NHP nd：J-MEX el No. : Sca e：PCB Pri ufacture: J ress : B2, Freque Port Input Pw Rad. Pwr. (d k EIRP (dB ) ctivity (dBi) ency (dB) ency (%) n (dBi) RP ±Pi/4 (dB RP ±Pi/6 (dB alar Modul nted J-MEX Inc. 3F, No. 1 ency wr. (dB ) B ) B ) B ) e , Li-Hsin 1 2402 0 -1.75 2.05 3.79 -1.75 66.88 2.05 -3.23 -4.64 1st Road, 2440 0 -2.19 1.61 3.81 -2.19 60.35 1.61 -3.68 -5.04 SBIP Hsin 2441 0 -2.21 1.57 3.78 -2.21 60.13 1.57 -3.69 -5.05 n Chu, 300 2480 0 -2.52 2.09 4.60 -2.52 56.03 2.09 -4.10 -5.45 0 Taiwan

Test Photos Appendix F Sporton International Inc. Hsinchu Laboratory Page No. : 1 of 2 1. Photographs of Radiated Emissions Test Configuration Test Configuration: 30MHz~1GHz FRONT VIEW REAR VIEW Report No. : FR372612 Test Photos Appendix F Sporton International Inc. Hsinchu Laboratory Page No. : 2 of 2 Test Configuration: Above 1GHz FRONT VIEW REAR VIEW ─────THE END───── Report No. : FR372612
