SAR Test Report Report Format Version 8.0.0 Page No. : 1 of 25 Report No. : SFBGWF-WTW-P24100633 Issued Date : Nov. 28, 2024 SAR Test Report FCC Rule Part : CFR §2.1093 Standards : IEEE Std 1528:2013, , KDB 865664 D01 v01r04, KDB 865664 D02 v01r02, KDB 447498 D04 Interim General RF Exposure Guidance v01, KDB 447498 D02 v02r01, Report No. : SFBGWF-WTW-P24100633 Applicant : KaiJet Technology International Corporation Address : 8F., No.109, Zhongcheng Rd., Tucheng Dist., New Taipei City 236, Taiwan. Product : CrossLink Wireless Dongle FCC ID : 2AD37JUAW22 Brand : j5create Model No. : JUAW22 Sample Received Date : Oct. 28, 2024 Date of Testing : Nov. 06, 2024 Lab Address : No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location : No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City, Taiwan FCC Accredited No. : TW0003 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch–Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Gina Liu / Specialist Approved By : Gordon Lin / Manager This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. SAR Test Report Report Format Version 8.0.0 Page No. : 2 of 25 Report No. : SFBGWF-WTW-P24100633 Issued Date : Nov. 28, 2024 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Test Reference Guidance ...................................................................................................................................................... 4 2. Summary of Maximum SAR Value ....................................................................................................................................... 5 3. Description of Equipment Under Test ................................................................................................................................. 6 4. SAR Measurement System ................................................................................................................................................... 7 4.1 Definition of Specific Absorption Rate (SAR) ............................................................................................................... 7 4.2 SPEAG DASY6 System ............................................................................................................................................... 7 4.2.1 Robot ............................................................................................................................................................... 8 4.2.2 Probes ............................................................................................................................................................. 9 4.2.3 Data Acquisition Electronics (DAE) .................................................................................................................. 9 4.2.4 Phantoms ......................................................................................................................................................... 9 4.2.5 Device Holder ................................................................................................................................................ 10 4.2.6 System Validation Dipoles ............................................................................................................................. 11 4.2.7 Power Source ................................................................................................................................................ 11 4.2.8 Tissue Simulating Liquids .............................................................................................................................. 12 4.3 SAR System Verification ...........................................................................…

Text truncated - open the document above for the full version.

Plots of System Verification Appendix A. Plots of System Verification The plots for system verification are shown as follows. Report No.: SFBGWF-WTW-P24100633 Plots of System Verification Measurement Report S01 System Check_H2450_241106 Device under Test Properties Model, Manufacturer Dimensions [mm] IMEI DUT Type D2450V2 10.0 x 10.0 x 290.0 Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, - , CW, 0-- 2450.000, 0 7.35 1.80 39.0 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2122 H19T27N9 , 2024-11-06 EX3DV4 - SN7554, 2024-09-17 DAE4 Sn1277, 2024-05-14 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 48.0 x 96.0 35.0 x 35.0 x 30.0 Grid Steps [mm] 12.0 x 12.0 5.0 x 5.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan Date 2024-11-06 2024-11-06 psSAR1g [W/kg] 2.56 2.53 psSAR10g [W/kg] 1.23 1.20 Power Drift [dB] 0.02 0.01 Report No.: SFBGWF-WTW-P24100633 Plots of Measurement Appendix B. Plots of Measurement The SAR plots for highest measured SAR in each exposure configuration, wireless mode and frequency band combination are shown as follows. Report No.: SFBGWF-WTW-P24100633 Plots of Measurement Measurement Report P01 BT_LE-1M_Horizontal Up_5mm_Ch0_Ant 0 Device under Test Properties Model, Manufacturer Dimensions [mm] IMEI DUT Type JUAW22 7.0 x 15.0 x 6.0 Wireless Dongle Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, Horizontal Up, 0.00 ISM 2.4 GHz Band Bluetooth, 10670-AAA 2402.000, 0 7.35 1.77 39.1 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2122 H19T27N9 , 2024-11-06 EX3DV4 - SN7554, 2024-09-17 DAE4 Sn1277, 2024-05-14 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 60.0 x 60.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 12.0 x 12.0 5.0 x 5.0 x 5.0 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan Date 2024-11-06 2024-11-06 psSAR1g [W/kg] 0.021 0.024 psSAR10g [W/kg] 0.01 0.011 Power Drift [dB] 0.13 -0.06 M2/M1 [%] 49.8 Dist 3dB Peak [mm] 8.6 Report No.: SFBGWF-WTW-P24100633 Appendix D. Maximum Target Conducted Power The maximum conducted average power (Unit: dBm) including tune-up tolerance is shown as below. Report No.: SFBGWF-WTW-P24100633 Tune-up Power (Full) ModeChannel Frequency Ant 0 Max Tune-up 024024.0 1924404.0 3924804.0 024024.0 1924404.0 3924804.0 Bluetooth LE-2M LE-1M Report No.: SFBGWF-WTW-P24100633 Appendix E. Measured Conducted Power Result The measuring conducted power (Unit: dBm) are shown as below. Report No.: SFBGWF-WTW-P24100633 Conducted Power (Full) ModeChannel Frequency SISO Ant 0 Avg. Power 024023.34 1924403.03 3924802.68 024023.28 1924403.01 3924802.63 LE-1M LE-2M Bluetooth Ant 0 Report No.: SFBGWF-WTW-P24100633 Appendix F. SAR Test Result SAR Results for Body Exposure Condition. N ote: 1. SAR testing for BT was performed on the maximum power mode. 2. The “< 0.001” means there is no SAR value or the SAR is too low to be measured. Report No.: SFBGWF-WTW-P24100633 Plot No. Band Mode Test Position Separation Distance (mm) Channel Ant Status Duty Cycle Crest Factor Max. Tune-up Power (dBm) Measured Conducted Power (dBm) Scaling Factor Power Drift (dB) Measured SAR-1g (W/kg) Scaled SAR-1g (W/kg) 1 BT LE-1M Horizontal Up 5 0 Ant 0 74.10 1.35 4.00 3.34 1.16 -0.06 0.024 0.04 BT LE-1M Horizontal Down 5 0 Ant 0 74.10 1.35 4.00 3.34 1.16 0.03 0.02 0.03 BT LE-1M Vertical Front 5 0 Ant 0 74.10 1.35 4.00 3.34 1.16 -0.07 0.016 0.03 BT LE-1M Vertical Back 5 0 Ant 0 74.10 1.35 4.00 3.34 1.16 0.07 0.014 0.02 BT LE-1M Tip Mode 5 0 Ant 0 74.10 1.35 4.00 3.34 1.16 0 <0.001 0.00 BT LE-1M Horizontal Up 5 19 Ant 0 74.10 1.35 4.00 3.03 1.25 -0.12 0.022 0.04 BT LE-1M Horizontal Up 5 39 Ant 0 74.10 1.35 4.00 2.68 1.36 0.12 0.019 0.03 - 1.00 - - 1 - - DUT Configuration System & Position Body SAR Test Result SAR Report No.: SFBGWF-WTW-P24100633 Appendix Z. Calibration Certificate for Probe and Dipole The SPEAG calibration certificates are shown as follows. Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633 Report No.: SFBGWF-WTW-P24100633

Report No.: AGBEBB-WTW-P23120493 Page No. 1 / 11 Report Format Version:6.1.2 Antenna Gain Measurement Report Report No.: AGBEBB-WTW-P23120493 Product: Wireless Dongle Antenna Brand: MCT Model No.: MCTU2-A9100 Received Date: 2023/12/20 Test Date: 2023/12/26 Issued Date: 2024/1/11 Applicant: Magic Control Technology Corporation Address: 10F., No.123, Zhongcheng Rd., Tucheng Dist., New Taipei City 236, Taiwan R.O.C. Manufacturer: Magic Control Technology Corporation Address: 10F., No.123, Zhongcheng Rd., Tucheng Dist., New Taipei City 236, Taiwan R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan FCC Registration / Designation Number: 198487 / TW2021 Prepared by : , Date: 2024/1/11 Annie Chang / Senior Specialist Approved by : , Date: 2024/1/11 Jeremy Lin / Project Engineer This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: AGBEBB-WTW-P23120493 Page No. 2 / 11 Report Format Version:6.1.2 Table of Contents Release Control Record .................................................................................................................................. 3 1 EUT Antenna System Description .................................................................................................... 4 1.1 Antenna Information.............................................................................................................................. 4 1.2 Antenna Location .................................................................................................................................. 4 2 2D Antenna Pattern Measurement .................................................................................................... 5 2.1 Test Location ......................................................................................................................................... 5 2.2 Test Measurement procedure ............................................................................................................... 5 2.3 Test Setup Diagram @ Fully Anechoic Chamber ................................................................................. 5 2.4 Test Setup Diagram for EUT ................................................................................................................. 6 2.5 Test Instruments .................................................................................................................................... 6 2.6 Measurement Uncertainty ..................................................................................................................... 6 2.7 Test Procedure ...................................................................................................................................... 7 2.8 Test Result ............................................................................................................................................ 7 2.9 2D Pattern Test Plots ............................................................................................................................ 8 Appendix - Information of the Testing Laboratories ................................................................................... 11 Report No.: AGBEBB-WTW-P23120493 Page No. 3 / 11 Report Format Version:6.1.2 Release Control Record Issue No. Description Date Issued AGBEBB-WTW-P23120493 Original release. 2024/1/2 Report No.: AGBEBB-WTW-P23120493 Page No. 4 / 11 Report Format Version:6.1.2 1 EUT Antenna System Description 1.1 Antenna Information Frequency Range (GHz) Antenna Type Connector Type Max Gain (dBi) 2.4 ~ 2.4835 PCB None 0.4 1.2 Antenna Location Please refer to the attached file (Test Setup Photo) Report No.: AGBEBB-WTW-P23120493 Page No. 5 / 11 Report Format Version:6.1.2 2 2D Antenna Pattern Measurement 2.1 Test Location 2D antenna pattern measurement in Fully Anechoic Chamber 2.2 Test Measurement procedure CISPR 16-1-6 ANSI 63.10-2013 clause 13 KDB 412172 D01 Determining ERP and EIRP v01r01 2.3 Test Setup Diagram @ Fully Anechoic Chamber The 2D antenna pattern measurement is using the test system (refer to Figure 1). The EUT is positioned on center of turntable, for Free Space only in fully anechoic chamber. Data (Raw Value) is recorded using the spectrum an…

Text truncated - open the document above for the full version.

Report No.: RFBGWF-WTW-P24100633 Page No. 1 / 43 Report Format Version: 7.1.0 Reference No.: BGWF-WTW-P24100633 TEST REPORT CERTIFICATE OF CONFORMITY Standard: 47 CFR FCC Part 15, Subpart C (Section 15.247) Report No.: RFBGWF-WTW-P24100633 FCC ID: 2AD37JUAW22 Product: CrossLink Wireless Dongle Brand: j5create Model No.: JUAW22 Received Date: 2024/10/28 Test Date: 2024/11/9 ~ 2024/11/14 Issued Date: 2024/11/27 Applicant: KaiJet Technology International Corporation Address: 8F., No.109, Zhongcheng Rd., Tucheng Dist., New Taipei City 236, Taiwan. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan FCC Registration / Designation Number: 198487 / TW2021 Approved by: , Date: 2024/11/27 Jeremy Lin / Project Engineer This test report consists of 43 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. Prepared by : Annie Chang / Senior Specialist This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our- business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: RFBGWF-WTW-P24100633 Page No. 2 / 43 Report Format Version: 7.1.0 Reference No.: BGWF-WTW-P24100633 Table of Contents Release Control Record ....................................................................................................................................................... 4 1 Certificate .................................................................................................................................................................... 5 2 Summary of Test Results .......................................................................................................................................... 6 2.1 Measurement Uncertainty ........................................................................................................................................ 6 2.2 Supplementary Information ...................................................................................................................................... 6 3 General Information ................................................................................................................................................... 7 3.1 General Description .................................................................................................................................................. 7 3.2 Antenna Description of EUT ..................................................................................................................................... 7 3.3 Channel List .............................................................................................................................................................. 7 3.4 Test Mode Applicability and Tested Channel Detail .................................................................................................. 8 3.5 Duty Cycle of Test Signal .......................................................................................................................................... 9 3.6 Test Program Used and Operation Descriptions .................................................................................................... 10 3.7 Connection Diagram of EUT and Peripheral Devices ............................................................................................ 10 3.8 Configuration of Per…
