BloomSky TM BLOOM1 OWNER’S MANUAL Introduction This manual will guide you through the setup procedures and highlight BloomSky’s key features. Package Contents zOne indoormodule zOne powe radaptor zOne quick startmanual Intended Use The BLOOM1 is designed to allow you to monitor indoor temperature and humidity. The data will display on the screen of the device and be send to the cloud by Wi-Fi as well. User can obtain these data anywhere by BloomSky APP . Requirements ziOS version 7.0 orhigher zAndroi dversion 4.0 orhigher Setup Procedures Step 1: Install the BloomSky APP Step 2: Connect the BLOOM1 to your wall outlet. Waiting for about 3 seconds, The screen will display temperature and humidity data. Step 3: Launch the BloomSky app, and follow the on-screen instructions to create an account and register the BLOOM1. After that the BLOOM1 will connect to your Wi-Fi automatically and upload data every 5 minutes. Key operation: Key ： Button: Press this button more than 5 seconds to clean the Wi-Fi information when the device is powered on. Display: z In this situation, the device can’t connect to server successfully. Please confirm your Wi-Fi password is correct and DHCP function is enabled and Wi-Fi is not working in 5 GHz brands. Technical Specifications zModel: BLOOM1 zClassification: External power zPower Adapter Model: 100-240V~50/60Hz Output: DC 5V--- 1A zWLAN Standard: Single-band 2.4GHz IEEE 802.11b/g/n zFrequency Range: 2.400 GHz ~ 2.497 GHz (2.4 GHz ISM Band) zNumber of Channels: 2.4GHz:Ch1 ~ Ch11 zBuilt-in temperature and humidity sensor with excellent accuracy. zTemperature display outdoor and indoor. zF° /C° temperature unit switchable. zPowered by A/C Adapter zDesktop placing zRelative Humidity Precision :± 4% RH (max), 0–80% RH zTemperature Accuracy: ±0.4 °C (max), –10 to 85 °C General Safety and Precautions 1. Read all of the information in the owner’s manual and other included product information in the packaging before operating the product. 2. The BLOOM1 will not operate within a Faraday cage. 3. This device complies with the essential requirements and other 60950‐1:2006+A11:2009+A1:2010+A12:2011. Statements: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Cet appareil est conforme à la section 15 des réglementations de la FCC. Le fonctionnement de l’appareil est sujetaux deux conditions suivantes : (1) cet appareil ne doit pas provoquer d’interférences néfastes, et (2) cet appareil doit tolérer les interférences reçues, y compris celles qui risquent de provoquer un fonctionnement indésirable. Note: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this product does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment should be installed and operated with a minimum distance 20cm between the radiator and your body Cet équipement doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et votre corps This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radioexempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peutfonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Care and Maintenance 1. Do not attempt to disassemble the device. 2. Clean the product with a soft damp cloth. Do not use abrasive or solvent‐based…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 6 Page 1 of 6 BLOOM1 _External Photos-FCC Application No.: SHEM1503000515CR Applicant: BloomSky, Inc. Address of Applicant: 723 N Shoreline Blvd. Mountain View CA 94043 Equipment Under Test (EUT): Product Name: BLOOM Brand Name: BLOOMSKY Model No.: BLOOM1 FCC ID: 2AD8EBLOOM1 IC: 12733A-BLOOM1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 6 Page 2 of 6 1 Contents Page 1 CONTENTS.......................................................................................................... 2 2 EXTERNAL PHOTOS ........................................................................................ 3 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 6 Page 3 of 6 2 External Photos SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 6 Page 4 of 6 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 6 Page 5 of 6 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 6 Page 6 of 6 End

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 13 Page 1 of 13 BLOOM1 _Internal Photos-FCC Application No.: SHEM1503000515CR Applicant: BloomSky, Inc. Address of Applicant: 723 N Shoreline Blvd. Mountain View CA 94043 Equipment Under Test (EUT): Product Name: BLOOM Brand Name: BLOOMSKY Model No.: BLOOM1 FCC ID: 2AD8EBLOOM1 IC: 12733A-BLOOM1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 13 Page 2 of 13 1 Contents Page 1 CONTENTS.......................................................................................................... 2 2 INTERNAL PHOTOS ......................................................................................... 3 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 13 Page 3 of 13 2 Internal Photos SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 13 Page 4 of 13 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 13 Page 5 of 13 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 13 Page 6 of 13 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 7 of 13 Page 7 of 13 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 8 of 13 Page 8 of 13 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 9 of 13 Page 9 of 13 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 10 of 13 Page 10 of 13 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 11 of 13 Page 11 of 13 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 12 of 13 Page 12 of 13 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 13 of 13 Page 13 of 13 E EE En nn nd dd d

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 588 West Jindu Road,Songjiang District,Shanghai,China Telephone: +86 (0) 21 6191 5666 Fax: +86 (0) 21 6191 5678 [email protected] Report No.: SHEM150300051503 Page: 1 of 8 Parlam Zhan E&E Section Manager SGS-CSTC (Shanghai) Co., Ltd. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only 1 Cover Page FCC MPE REPORT Application No.: SHEM1503000515CR Applicant: BloomSky, Inc. FCC ID: 2AD8EBLOOM1 IC: 12733A-BLOOM1 Equipment Under Test (EUT): NOTE: The following sample(s) was/were submitted and identified by the client as Product Name: BLOOM Model No.(EUT): BLOOM1 Standards: FCC Rules 47 CFR §2.1091 KDB447498 D01 General RF Exposure Guidance Date of Receipt: March 03, 2015 Date of Test: March 16, 2015 to March 19, 2015 Date of Issue: April 02, 2015 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM150300051503 Page: 2 of 8 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e- document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to thesample(s) tested and such sample(s) are retained for 90 days only 2 Version Revision Record Version Chapter Date Modifier Remark 00 / April 02, 2015 / Original Authorized for issue by: Engineer Eddy Zong Print Name Clerk Susie Liu Print Name Reviewer Keny Xu Print Name SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM150300051503 Page: 3 of 8 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e- document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to thesample(s) tested and such sample(s) are retained for 90 days only 3 Contents Page 1 COVER PAGE ............................................................................................................................ 1 2 VERSION ..................................................................................................................................... 2 3 CONTENTS ................................................................................................................................. 3 4 GENERAL INFORMATION ....…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. 588 West Jindu Road,Songjiang District,Shanghai,China Telephone: +86 (0) 21 6191 5666 Fax: +86 (0) 21 6191 5678 [email protected] Report No.: SHEM150300051402 Page: 1 of 74 Parlam Zhan E&E Section Manager SGS-CSTC (Shanghai) Co., Ltd. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only 1 Cover Page RF TEST REPORT Application No.: SHEM1503000515CR Applicant: BloomSky, Inc. FCC ID: 2AD8EBLOOM1 IC: 12733A-BLOOM1 Equipment Under Test (EUT): NOTE: The following sample(s) was/were submitted and identified by the client as Product Name: BLOOM Model No.(EUT): BLOOM1 Standards: FCC PART 15 Subpart C: 2014 RSS-210 Issue 8 (December 2010)+A1 (February 2015) RSS-Gen Issue 4 (November 2014) Date of Receipt: March 03, 2015 Date of Test: March 16, 2015 to March 19, 2015 Date of Issue: April 02, 2015 Test Result: Pass* *In the configuration tested, the EUT detailed in this report complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM150300051402 Page: 2 of 74 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e- document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to thesample(s) tested and such sample(s) are retained for 90 days only 2 Version Revision Record Version Chapter Date Modifier Remark 00 / April 02, 2015 / Original Authorized for issue by: Engineer Eddy Zong Print Name Clerk Susie Liu Print Name Reviewer Keny Xu Print Name SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM150300051402 Page: 3 of 74 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e- document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to thesample(s) tested and such sample(s) are retained for 90 days only 3 Test Summary Test Item FCC Requirement IC Requirement Test method Result Antenna Requirement FCC Part 15, Subpart C Section 15.203/15.247 (c) RSS-Gen Section8.1.3 --- PASS AC Power Line Conducted Emission FCC Part 15, Subpart C Section 15.207 RSS-Gen Section 8.8 ANSI C63.10 (2013) Section 6.2 N/A Minimum 6dB Bandwidth FCC Part 15, Subpart C Section 15.247 (a)(2) RSS-210 Issue 8 Annex 8 ANSI C63.10…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 4 Page 1 of 4 BLOOM1 _Test Setup Photos-FCC Application No.: SHEM1503000515CR Applicant: BloomSky, Inc. Address of Applicant: 723 N Shoreline Blvd. Mountain View CA 94043 Equipment Under Test (EUT): Product Name: BLOOM Brand Name: BLOOMSKY Model No.: BLOOM1 FCC ID: 2AD8EBLOOM1 IC: 12733A-BLOOM1 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 4 Page 2 of 4 1 Contents Page 1 CONTENTS............................................................................................................... 2 2 EQUIPMENT UNDER TEST PICTURES ............................................................ 3 2.1 Radiated Emission Test Setup ............................................................. 3 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 4 Page 3 of 4 2 EQUIPMENT UNDER TEST PICTURES 2.1 Radiated Emission Test Setup Below 30MHz: 30MHz to 1GHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 4 Page 4 of 4 Above 1GHz 2.2 Conducted Emissions Test Setup End
