2AD8P-HM100THE HAYMAKER headphones

When position to BT or ANC position, touch the logo area you can control below functions: Music and Call Touch Controls (Left Logo) THE HAYMAKER headphones USER MANUAL Control Switch LED lndicator 3.5mm Jack Line-in Port Music and Call Touch Controls Light Feature Touch Controls Type-C Charging Port LED lndicator Left Speaker Cup ActionFunctionStatus Single TapAnswer callIncoming call Long press（≧2 sec） Reject callIncoming call Single TapEnd callOn the call Swipe back to front twiceVoice controlBT/ANC on Swipe front to back twiceRedial latest callerBT/ANC on Double TapPlay/Pause musicBT/ANC on Swipe backTrack BackBT/ANC on Swipe frontTrack ForwardBT/ANC on Swipe upVolume UpBT/ANC on Swipe downVolume DownBT/ANC on Long press （≧8 sec） Clear pairing recordNo BT connection PC Controller CableRight Speaker Cup Note：Dirac 7.1, Dirac HD sound software needs to be downloaded System supported：Windows10. ANC OFF BT RL RL Light Feature Touch Controls (Right Logo) Note：The LED light of headband logo is synchronized with the speaker cup logo, touch the logo area to control. (PC Gaming Mode) from www.the-haymker.com Left Speaker CupLeft Speaker Cup Left Speaker Cup Important safety instructions 1. Read, follow and keep these instructions. 2. For the best possible experience, always use the product as described by the manufacturer. 3. Always handle your headphones with care and protect them from external damage. 4. Clean your headphones using a soft dry cloth. Never use water, cleaning detergent, leather polish or other substances as they may damage your he adphones permanently. 5. Avoid exposure to extreme conditions such as very cold or hot temperatures, magnetic fields or damp environments. 6. Listening to music at high volume for prolonged periods of time can cause permanent damage to your hearing. 7. Contains small parts and are not suitable for children age three (3) and below. 8. The headphones contain magnetic material. 9. The headphones contain a Lith ium battery. If misused or damaged it can become a hazard and is at risk of explosion. 10. Should a battery cell leak, do not allow the liquid to come in contact with skin or eyes. 11. The headphones must be disposed of with regular household waste. Please dispose of in accordance with local regulations. 12. Do not use your headphones in the immediate proximity (10 cm) of a pacemaker. 13. Do not subject the headphones and included accessories to abnormal wear and tear. 14. Do not expose the headphones to temperatures below - 20°C or above +45°C. 15. Do not charge the headphones in temperatures below 0°C or above +45°C. 16. Do not attempt to burn the headphones. The battery could explode causing injury or death. 18. Do not attempt to open, modify, disassemble, repair or try to access the internal structure of the headphones. They are not user serviceable. 17. Do not use or store the headphones near to a vehicle airbag due to risk of injury. 19. Do not use headphones while driving, jogging or walking through traffic areas. Headphones effectively isolate external sound and noise which means that when in use, you might not be able to hear your surroundings. 20. Do not drop, sit on or cause other unusual impact to the headph ones. 21. Do not expose to fire, water or high voltage equipment. 22. Do not expose the headphones to rain or moisture. 23. Do not use the headphones near water, bathtubs, sinks, saunas, pools, other liquids or moist areas. © 2019 Peak Audio, LLC. All rights reserved. Model: HM100. Troubleshooting Problem pairing and connecting • Make sure the headphones are not connected to another device. • Disable an d enable Bluetooth on your device. • Move the headphones closer to the device or alter their positions to avoid Bluetooth interference. • Verify no other wireless equipment interfere with your headphones Bluetooth signal. Problem with sound transmission Move the streaming device to another position. Your body, distance, different materials and other wireless equipment can interfere with the wireless signal between your device and headphones. FAQ and quick start guide Visit: www.thehaymaker.com for more instructions and help on this product. ANC OFF BT When replacing the ear pads, the ear pad will be automatically forced into the correct position by magnets. Ear Pad Replacement Action Function Long press ≧3 sec LED light On/Off Triple TapAmbient Sound On/Off Swipe forward or back Choose Color Swipe up or downChange RGB Light Mode Remark ANC ON Status, when Ambient Sound On, the content will be lower 10% volume Total 8 colors to choose Single color breathing, Flash, Stay on, Auto cycling for 8 colors 3s x3 x1 x1 R R On the left frame edge, position to BT button to turn on Biuetooth , the operation LED flashes in blue, and the headphones enter pairing mode automatically as the operation LED flashes quickly in red and blue. To pair, go to Bluetooth® settings on your device and select “THE HAYMAKER”. The operation LED will flash slowly in blue upon a successful connection. R R R If you do not pairsuccessfully, please check the device, clear the device name, repeat pairing process again. Note: After the first pairing, the device name "The HAYMAKER" will be displayed in the Bluetooth directory of the paired device. R Upon successful pairing to device, headphones will pair automaticallywithin 5 seconds. H eadphones can be paired to 2 devices at the same time. Note: When Auxiliary cord is used, left control panel function is deactivated. Must use paired device for 1. Wired Playback 2. Console Play 3. PC Mode controls. 1. Wired Playback, plug auxiliary cord into headphone jack then into device. Action LED indicator Function Single click Mic button Mic Mute LED on Micr ophone Mute Sound Effect button cyclingDirac 7.1 / HD LED on Stereo 2.0 (LED off), Virtual 7.1 / HD ON Need software installed Volume Up/DownN/AControl volume x1 x1 x1 2. Console Play, plug auxiliary cord into headphone jack and then into controller. 3. P C Mode, plug included …

Text truncated - open the document above for the full version.

Dongguan Laccess Electronic Technology Co.,Ltd. Letter of Authorization Company: Dongguan Laccess Electronic Technology Co.,Ltd. Address: No. 2 Xiangyang Road, Tian Xin Huaxing Industrial Area, Qiaotou town, Dongguan , China. Product Name: THE HAYMAKER headphones Model Number: HM100 FCC Identifier: 2AD8P-HM100 We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Jennifer Tan Date: 2019/12/18 Title: President Signature of applicant:

Dongguan Laccess Electronic Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2019/12/18 Subject; Request for Confidentiality FCC ID: 2AD8P- HM100 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jennifer Tan Title: President

BT ANT

FCC RF Exposure FCC ID: 2AD8P‐ HM100 Applicant: Dongguan Laccess Electronic Technology Ltd. Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Portable Device Refer Standard: KDB 447498 D01 General RF Exposure Guidance v06 FCC Part 2 §2.1093 Evaluation method According to KDB D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations:“ Unless specifically required by the published RF exposure KDB procedures, standalone 1‐g head or body and 10‐g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source‐based time‐averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune‐up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two‐way radios, handsets, laptops & tablets etc.23 “[(max. power of channel, including tune‐up tolerance, mW)/ (min. test separation distance, mm)] ∙ [√f (GHz)]≤ 3.0 for 1‐g SAR and ≤ 7.5 for 10‐g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is <5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. Conducted Power Results Bluetooth GFSK Channel Channel 0 Channel 39 Channel 78 Output Power (dBm) 1.31 1.77 1.33 Bluetooth π/4‐DQPSK Channel Channel 0 Channel 39 Channel 78 Output Power (dBm) 0.90 1.84 1.82 Bluetooth 8‐ DPSK Channel Channel 0 Channel 39 Channel 78 Output Power (dBm) 1.01 1.84 1.82 Manufacturing tolerance Bluetooth GFSK Channel Channel 0 Channel 39 Channel 78 Tolerance ±(dB) 1.0±1.0 1.0±1.0 1.0±1.0 Bluetooth π/4‐DQPSK Channel Channel 0 Channel 39 Channel 78 Tolerance ±(dB) 1.0±1.0 1.0±1.0 1.0±1.0 Bluetooth 8‐ DPSK Channel Channel 0 Channel 39 Channel 78 Tolerance ±(dB) 1.0±1.0 1.0±1.0 1.0±1.0 Evaluation Results Bluetooth Mode Antenna Distance （mm） RF output power (including tune‐up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW GFSK 5 2 1.58 0.49＜3.0 Yes π/4‐DQPSK 5 2 1.58 0.49＜3.0 Yes 8‐ DPSK 5 2 1.58 0.49＜3.0 Yes Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 D01V06.

Report No.: SET2019-16008 CCIC-SET/ TRF:IRF(2019-05-23) Page 1 of 69 RF TEST REPORT Report No.: SET2019-16008 Product Name: THE HAYMAKER headphones FCC ID: 2AD8P- HM100 IC: 12709A-HM100 Model No. : HM100 Applicant: Dongguan Laccess Electronic Technology Co.,Ltd. Address： No. 2 Xiangyang Road, Tian Xin Huaxing Industrial Area, Qiaotou town, Dongguan , China. Dates of Testing: 12/01/2019 —12/05/2019 Issued by: CCIC Southern Testing Co., Ltd Lab Location: Electronic Testing Building, No. 43 Shahe Road Xili Street, Nanshan District，Shenzhen, Guangdong 518055，China Tel: 86 755 26627338 Fax: 86 755 26627238 This test report consists of 69 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 20 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No.: SET2019-16008 CCIC-SET/ TRF:IRF(2019-05-23) Page 2 of 69 Test Report Product Name ....................... : THE HAYMAKER headphones Brand Name .......................... : HAYMAKER Trade Name ........................... : HAYMAKER Applicant ............................... : Dongguan Laccess Electronic Technology Co.,Ltd. Applicant Address ................ : No. 2 Xiangyang Road, Tian Xin Huaxing Industrial Area, Qiaotou town, Dongguan , China Manufacturer ........................ : Dongguan Laccess Electronic Technology Co.,Ltd.. Manufacturer Address ......... : No. 2 Xiangyang Road, Tian Xin Huaxing Industrial Area, Qiaotou town, Dongguan , China Test Standards ...................... : 47 CFR Part 15 Subpart C： IC RSS-Gen (Issue 5, March 2019) IC RSS-247 (Issue 2, Feb. 2017) Test Result ............................ : PASS Tested by ............................. : 2019.12.10 Vincent, Test Engineer Reviewed by ......................... : 2019.12.10 Chris You, Senior Engineer Approved by ......................... : 2019.12.10 Shuangwen Zhang, Manager Report No.: SET2019-16008 CCIC-SET/ TRF:IRF(2019-05-23) Page 3 of 69 Table of contents RF TEST REPORT .......................................................................................................................... 1 1. GENERAL INFORMATION .................................................................................................... 5 1.1. EUT Description ....................................................................................................................... 5 1.2. Test Standards and Results ........................................................................................................ 6 1.3. Frequency Hopping System Requirements ............................................................................... 7 1.4. Facilities and Accreditations ..................................................................................................... 9 2. 47 CFR PART 15C REQUIREMENTS .................................................................................. 10 2.1. Antenna requirement ............................................................................................................... 10 2.2. Number of Hopping Frequency .............................................................................................. 11 2.3. Peak Output Power.................................................................................................................. 13 2.4. 20dB and 99% Occupied Bandwidth ...................................................................................... 15 2.5. Carried Frequency Separation ................................................................................................. 17 2.6. Dwell time ............................................................................................................................... 19 2.7. Conducted Spurious Emissions ............................................................................................... 21 2.8. Conducted Band Edge ............................................................................................................. 23 2.9. Conducted Emission ............................................................................................................... 25 2.10. Radiated Band Edges and Spurious Emission ........................................................................ 29 3. LIST OF MEASURING EQUIPMENT ................................................................................. 43 APPENDIX A .................................................................................................................................. 44 Report No.: SET2019-16008 CCIC-SET/ TRF:IRF(2019-05-23) Page 4 of 69 Change History Issue Date Reason for change 1.0 2019.12.10 First edition Report No.: SET2019-16008 CCIC-SET/ TRF:IRF(2019-05-23) Page 5 of 69 1. General Information 1.1. EUT Description EUT Type THE HAYMAKER headphones Frequency Range Bluetooth EDR 2402MHz~2480MHz Channel Number Bluetooth EDR 79 Bit Rate of Transmitter Bluetooth EDR 1/2/3Mbps Modulation Type Bluetooth EDR GFSK,PI/4DQPSK,8DPSK HW V1.1 SW V2.30 Antenna Type Internal Antenna Gain 4dBi Note 1: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Note 2: a. When power on, the EUT will scan the whole frequency until a Connection command from the other BT devices. b. When receiving the signal from the other BT devices, The EUT transmit are sponse signal. c. The other devices receive the response signal and recognize it, then send a connection command to establish the connection. d. After the connection establish successfully, the data transmiss…
