2AD8PHXHP910BT headphone

Warranty and Safety Information Información de garantía y seguridad Information sur la garantie et de sécurité FCC DISCLAIMER ICID: RSS-GEN ISSUE 4 NOVEMBER 2014 ENGLISH Note: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Note: Changes or modifications not expressly approved by HMDX could void the user's authority to operate this equipment. This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device ONE YEAR LIMITED WARRANTY For detailed Warranty Instructions and Information visit: http://www.jamaudio.com/customer-support/warranty-1yr To obtain warranty service on your JAM product, contact a Consumer Relations Representative by the telephone number or email address for your country of residence. Please make sure to have the model number of the product available. IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING • WARNING: Listen responsibly. To avoid hearing damage, make sure the volume on your device is turned down before connecting headphones. After placing headphones on your ears, gradually turn up the volume until you reach a comfortable listening volume. • Use this product only for its intended use as described in this manual. Do not use attachments not recommended by HMDX. • HMDX is not liable for any damage caused to Smartphones, iPod/MP3 player or any other device. • Do not place or store this product where it can fall or be dropped into a tub or sink. • Do not place or drop into water or any other liquid. • Not for use by children. THIS IS NOT A TOY. • Never operate this product if it has a damaged cord, plug, cable or housing. • Keep away from heated surfaces. • Only set on dry surfaces. Do not place on surface wet from water or cleaning solvents. WARNING: This product has an internal, non-replaceable lithium battery. Please dispose in accordance with your local, state, province and country guidelines. This product contains small parts that may present a choking hazard for young children. CAUTION: All servicing of this product must be performed by authorized HMDX Service Personnel only. Attention California Residents: WARNING: This product contains chemicals known to the State of California to cause cancer, birth defects and other reproductive harm. For Service in the USA email: [email protected] tel: 1.888.802.0040 8:30am - 7:00pm EST M–F For Service in Canada email: [email protected] tel: 1.888.225.7378 8:30am - 5:00pm EST M–F For complete user guide and to register your product, visit www.jamaudio.com (USA) or www.jamaudio.ca (Canada) GARANTÍA LIMITADA POR UN AÑO Para instrucciones detalladas de su Garantia e información visite: http://www.jamaudio.com/customer-support/warranty-1yr DECLARACIÓN DE RENUNCIA DEL FCC ESPAÑOL Nota: Este dispositivo cumple con los requisitos de la parte 15 de las reglas del FCC. Funcionamiento está sujeto a las dos condiciones siguientes: (1) Este dispositivo no puede causar interferencias dañinas, y (2) este dispositivo tiene que aceptar cualquier interferencia recibida, incluyendo interferencias que puedan causar funcionamiento que no sea deseado. Nota: Este dispositivo ha sido probado y se encontró en cumplimiento con los límites para un dispositivo digital de Clase B, de acuerdo a la parte 15 de las reglas del FCC. Estos límites son designados para proveer protección adecuada contra interferencias dañina en una instalación del hogar. Este dispositivo genera, usa y puede radiar energía de radio-frecuencias y si no es instalado y usado de acuerdo con las instrucciones proferidas, puede causar interferencias dañinas a radio comunicaciones. Pero no hay garantías que interferencias no ocurrirán en una instalación particular. Si este dispositivo causa interferencias dañinas a las recepciones de radio o televisión, que puedan ser identificadas por el encendido y apague del dispositivo, se recomienda que el usuario trate de corregir la interferencia usando una o más de las siguientes medidas: • Reoriente o traslade la antena receptora. • Aumente la separación entre el dispositivo y el receptor. • Conecte el dispositivo a un tomacorriente en un circuito distinto de aquel al que está conectado el receptor. • Consulte con el distribuidor o alguien con experiencia técnica en recepción de radio o televisión para obtener ayuda. Nota: Cualquier cambio o modificación no aprobada expresamente por HMDX podría anular la autorización del usuario para utilizar este dispositivo. BC ©2015 HMDX. All Rights Reserved. PP-LCJAMHP Pour les s…

Text truncated - open the document above for the full version.

Dongguan Laccess Electronic Technology Ltd. Date: 28 Feb, 2015 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Dongguan Laccess Electronic Technology Ltd. the undersigned, hereby authorizes Mr. Zhang Shangwen from CCIC-SET to act on the behalf of the Dongguan Laccess Electronic Technology Ltd. solely in matters relating to the application for an FCC equipment authorization for FCC ID: 2AD8PHXHP910 including the signing of documents in connection with this Application. Necessary acts carried out by CCIC-SET on our behalf of the Dongguan Laccess Electronic Technology Ltd. in connection with the application shall have the same effect as acts of the Dongguan Laccess Electronic Technology Ltd. The Dongguan Laccess Electronic Technology Ltd. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Yours Sincerely, Signature Name/Title: Jennifer Tan/President

Dongguan Laccess Electronic Technology Ltd. Feb. 28, 2015 Federal Communications Commission Authorization and Evaluation Division FCC ID：2AD8PHXHP910 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1. Block Diagram CONF APPENDIX 2AD8PHXHP910_Block Diagram.pdf 2. Circuit Diagram CONF APPENDIX 2AD8PHXHP910_Schematics.pdf 3. Operational Description CONF APPENDIX 2AD8PHXHP910_Operational description.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Signature Name/Title: Jennifer Tan/President Applicant: Dongguan Laccess Electronic Technology Ltd. Address: Huaxing Industrial Park, tianxin, Qiaotou Town, DongGuan, GuangDong, China TEL: 86-769-38935255 FAX: 86-769-83349336 Email: [email protected]

External Photo

Report No.: SET2015-02539 P Page 1 of 74 RF TEST REPORT Report No.: SET2015-02539 Product Name: JAM TRANSIT TOUCH FCC ID: 2AD8PHXHP910 Model No. : HX-HP910 Applicant: Dongguan Laccess Electronic Technology Ltd Address： Huaxing Industrial Park,tianxin,Qiaotou Town,DongGuan, GuangDong,China Issued by: CCIC-SET Lab Location: Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055, P. R. China Tel: 86 755 26627338 Fax: 86 755 26627238 This test report consists of 74 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 20 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No.: SET2015-02539 Page 2 of 74 Test Report Product Name ....................... : JAM TRANSIT TOUCH Brand Name .......................... : JAM Trade Name ........................... : JAM Applicant ............................... : Dongguan Laccess Electronic Technology Ltd Applicant Address ................ : Huaxing Industrial Park,tianxin,Qiaotou Town,DongGuan, GuangDong,China Manufacturer......................... : Dongguan Laccess Electronic Technology Ltd Manufacturer Address ......... : Huaxing Industrial Park,tianxin,Qiaotou Town,DongGuan, GuangDong,China Test Standards ...................... : 47 CFR Part 15 Subpart C 2013：Radio Frequency Devices ANSI C63.10:2014：American National Standard for Testing Unlicensed Wireless Devices DA 00-705: Filing and Measurement Guidelines for Frequency Hopping Spread Spectrum Systems Test Result ............................ : PASS Tested by ............................. : 2015.02.28 Haigang He， Test Engineer Reviewed by ......................... : 2015.02.28 Zhu Qi, Senior Engineer Approved by ......................... : 2015.02.28 Wu Li’an, Manager Report No.: SET2015-02539 Page 3 of 74 Table of contents 1. GENERAL INFORMATION .................................................................................................... 4 1.1. EUT Description ....................................................................................................................... 4 1.2. Support Equipment ................................................................................................................... 5 1.3. Test Standards and Results ........................................................................................................ 5 1.4. Facilities and Accreditations ..................................................................................................... 6 2. 47 CFR PART 15C REQUIREMENTS .................................................................................... 7 2.1. Antenna requirement ................................................................................................................. 7 2.2. Number of Hopping Frequency ................................................................................................ 8 2.3. Peak Output Power.................................................................................................................. 11 2.4. 20dB Bandwidth ..................................................................................................................... 18 2.5. Carried Frequency Separation ................................................................................................. 25 2.6. Time of Occupancy (Dwell time) ........................................................................................... 28 2.7. Conducted Spurious Emissions ............................................................................................... 35 2.8. Band Edge ............................................................................................................................... 47 2.9. Conducted Emission ............................................................................................................... 58 2.10. Radiated Emission................................................................................................................... 62 2.11. RF exposure evaluation ........................................................................................................... 74 Change History Issue Date Reason for change 1.0 2015.02.28 First edition Report No.: SET2015-02539 Page 4 of 74 1. General Information 1.1. EUT Description EUT Type ............................. : JAM TRANSIT TOUCH Hardware Version ................. : V04 Software Version .................. : V01 Frequency Range .................. : The frequency range used is 2402MHz - 2480MHz (79 channels, at intervals of 1MHz); The frequency block is 2400MHz to 2483.5MHz. Modulation Type .................. : Bluetooth: FHSS (GFSK(1Mbps), π/4-DQPSK(EDR 2Mbps), 8-DPSK(EDR 3Mbps)) Antenna Type ........................ : PCB Antenna Antenna Gain ........................ : 0dBi Note 1: The EUT is a JAM TRANSIT TOUCH, it contains Bluetooth Module operating at 2.4GHz ISM band; the frequencies allocated for the Bluetooth Module is F(MHz)=2402+1*n (0<=n<=78). The lowest, middle, highest channel numbers of the Bluetooth Module used and tested in this report are separately 0 (2402MHz), 39 (2441MHz) and 78 (2480MHz). Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Note 3: a. When power on, the EUT will scan the whole frequency until a Connection command from the other BT devices. b. When receiving the signal from the other BT devices, The EUT transmit are sponse signal. c. The other devices receive the response signal and recognize…

Text truncated - open the document above for the full version.

Conducted Emission Test setup photos Radiated Emission Test setup photos Below 1 GHz Above 1 GHz Conducted Te s t setup photo
